DENON AVR3806 RC CODE

FORMAT SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

SYSTEM ADDRESS(C1~C5) :01000 ,EXTENSION BIT(C12,C13) :11

No.

Data (C6~C11) Key Name No. Data (C6~C11) Key Name

0000000 16 000010 FR LEVEL DOWN

1100000 POWER 17 100010

2010000 FL LEVEL UP 18 010010 CDR/TAPE

3110000 PHONO 19 110010

4001000 CD 20 001010

5101000 TUNER 21 101010 CINEMA EQ ON

6011000 22 011010 SR LEVEL UP

7111000 FL LEVEL DOWN 23 111010 SR LEVEL DOWN

8000100 DBS 24 000110 VIDEO SELECT

9100100 TV 25 100110 CINEMA EQ OFF

10 010100 VDP 26 010110

11 110100 FR LEVEL UP 27 110110 MULTI

12 001100 V.AUX 28 001110 INPUT MODE ANALOG

13 101100 VCR-129 101110 CURSOR RIGHT

14 011100 VCR-230 011110 STATUS

15 111100 31 111110 ON SCREEN

SYSTEM ADDRESS(C1~C5) :01000 ,EXTENSION BIT(C12,C13) :11

No.

Data (C6~C11) Key Name No. Data (C6~C11) Key Name

32 000001 ENTER 48 000011 MUTING

33 100001 POWER ON 49 100011 MASTER VOLUME UP

34 010001 POWER OFF 50 010011 MASTER VOLUME DOWN

35 110001 DVD 51 110011 SL LEVEL UP

36 001001 STANDARD(DOLBY/DTS SURR.) 52 001011 SL LEVEL DOWN

37 101001 SW LEVEL DOWN 53 101011 CENTER LEVEL UP

38 011001 DSP SIMULATION 54 011011 CENTER LEVEL DOWN

39 111001 SB/SBL LEVEL UP 55 111011 SBR LEVEL UP

40 000101 56 000111 SBR LEVEL DOWN

41 100101 57 100111 TONE DEFEAT ON

42 010101 TEST TONE 58 010111 TONE DEFEAT OFF

43 110101 SB/SBL LEVEL DOWN 59 110111 SB:MATRIX ON

44 001101 SW LEVEL UP 60 001111 SB:NON MATRIX

45 101101 SPEAKER 61 101111 SB:OFF

46 011101 62 011111

47 111101 63 111111

DENON AVR3806 RC CODE

FORMAT SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

SYSTEM ADDRESS(C1~C5) :00110 ,EXTENSION BIT (C12,C13) :01

No.

Data (C6~C11) Key Name No. Data (C6~C11) Key Name

0000000 ALL BASS DOWN 16 000010 ZONE2 CD

1100000 17 100010 ZONE2 TUNER

2010000 SURROUND BACK 18 010010 ZONE2 VDP

3110000 MASTER VOL. PRESET1(0dB) 19 110010 ZONE2 V.AUX

4001000 20 001010 ZONE2 VCR-1

5101000 MASTER VOL. PRESET2(-20dB) 21 101010

6011000 MASTER VOL. PRESET3(-40dB) 22 011010 MULTI PRESET UP

7111000 ZONE2 VOL. PRESET1(0dB) 23 111010 MULTI PRESET DOWN

8000100 ZONE2 VOL. PRESET2(-20dB) 24 000110

9100100 ZONE2 VOL. PRESET3(-40dB) 25 100110 ZONE2 VCR-2

10 010100 ZONE2 DBS 26 010110

11 110100 27 110110 ZONE2 TV

12 001100 ZONE3 VOL. PRESET1(0dB) 28 001110 ZONE2 CDR/TAPE

13 101100 ZONE2 VOLUME UP 29 101110 STEREO

14 011100 ZONE2 VOLUME DOWN 30 011110 DIRECT

15 111100 ZONE2 PHONO 31 111110 ZONE3 VOL. PRESET2(0dB)

SYSTEM ADDRESS(C1~C5) :00110 ,EXTENSION BIT (C12,C13) :01

No.

Data (C6~C11) Key Name No. Data (C6~C11) Key Name

32 000001 SYSTEM SETUP 48 000011 CH VOLUME UP

33 100001 SURROUND PARAMETER 49 100011 CH VOLUME DOWN

34 010001 ZONE3 VOL. PRESET2(0dB) 50 010011

35 110001 CURSOR UP 51 110011

36 001001 CURSOR DOWN 52 001011

37 101001 53 101011 INPUT MODE EXT.IN

38 011001 54 011011 INPUT MODE

39 111001 55 111011 ALL TREBLE UP

40 000101 7CH STEREO 56 000111 ALL TREBLE DOWN

41 100101 57 100111 TUNER SHIFT A

42 010101 58 010111 TUNER SHIFT B

43 110101 SHIFT F 59 110111 TUNER SHIFT C

44 001101 AUDIO FUNCTION 60 001111 TUNER SHIFT D

45 101101 VIDEO FUNCTION 61 101111 TUNER SHIFT E

46 011101 SHIFT G 62 011111 ZONE2 DVD

47 111101 CH SELECT 63 111111 ALL BASS UP

DENON AVR3806 RC CODE

FORMAT SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

SYSTEM ADDRESS(C1~C5) :00110 ,EXTENSION BIT (C12,C13) :10

No.

Data (C6~C11) Key Name No. Data (C6~C11) Key Name

32 000001 48 000011

33 10000149 100011

34 010001 50 010011

35 110001 51 110011

36 001001 52 001011

37 101001 53 101011

38 011001 54 011011

39 111001 55 111011

40 000101 56 000111

41 100101 57 100111

42 010101 58 010111

43 110101 59 110111

44 001101 60 001111

45 101101 61 101111

46 011101 62 011111

47 111101 63 111111 CURSOR LEFT

SYSTEM ADDRESS(C1~C5) :00110 ,EXTENSION BIT (C12,C13) :11

No.

Data (C6~C11) Key Name No. Data (C6~C11) Key Name

0000000 16 000010

1100000 TUNER PRESET/XM CH 1 17 100010

2010000 TUNER PRESET/XM CH 2 18 010010 RDS/SEARCH

3110000 TUNER PRESET/XM CH 3 19 110010

4001000 TUNER PRESET/XM CH 4 20 001010 PTY

5101000 TUNER PRESET/XM CH 5 21 101010 TUNER PRESET DOWN

6011000 TUNER PRESET/XM CH 6 22 011010 TUNER PRESET UP

7111000 TUNER PRESET/XM CH 7 23 111010 TUNER BAND

8000100 TUNER PRESET/XM CH 8 24 000110 TUNING MODE(AUTO/MANUAL)

9100100 XM CH 925 100110 TUNER TUNING UP

10 010100 XM CH 026 010110 TUNER TUNING DOWN

11 110100 27 110110

12 001100 TUNER MEMORY 28 001110

13 101100 TUNER SHIFT 29 101110

14 011100 RT 30 011110

15 111100 31 111110 DIMMER

DENON AVR3806 RC CODE

FORMAT SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

SYSTEM ADDRESS (C1~C5) :01000 ,EXTENSION BIT (C12,C13) :10

No.

Data (C6~C11) Key Name No. Data (C6~C11) Key Name

0000000 16 000010

1100000 17 100010

2010000 18 010010 ZONE3 TV

3110000 19 110010 ZONE3 DBS

4001000 20 001010 ZONE3 VCR-1

5101000 21 101010 ZONE3 VCR-2

6011000 22 011010

7111000 23 111010 ZONE3 V.AUX

8000100 ZONE3 TUNER 24 000110

9100100 ZONE3 PHONO 25 100110

10 010100 ZONE3 CD 26 010110

11 110100 27 110110 ZONE3 CDR/TAPE

12 001100 28 001110

13 101100 29 101110 ZONE2 ON/OFF

14 011100 ZONE3 DVD 30 011110

15 111100 ZONE3 VDP 31 111110

SYSTEM ADDRESS (C1~C5) :01000 ,EXTENSION BIT (C12,C13) :10

No.

Data (C6~C11) Key Name No.

Data (C6~C11) Key Name

32 000001 48 000011

33 100001 49 100011

34 010001 50 010011

35 110001 51 110011

36 001001 52 001011

37 101001 ZONE3 VR DOWN 53 101011

38 011001 ZONE3 VR UP 54 011011

39 111001 55 111011

40 000101 56 000111

41 100101 57 100111 MAIN ZONE ON

42 010101 PURE DIRECT 58 010111 MAIN ZONE OFF

43 110101 59 110111 MULTI ZONE2 ON

44 001101 60 001111 MULTI ZONE2 OFF

45 101101 61 101111 MULTI ZONE3 ON

46 011101 62 011111 MULTI ZONE3 OFF

47 111101 63 111111

DENON AVR3806 RC CODE

FORMAT SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

SYSTEM ADDRESS (C1~C5) :00100 ,EXTENSION BIT (C12,C13) :01

No.

Data (C6~C11) Key Name No. Data (C6~C11) Key Name

0000000 16 000010 DOLBY PLII MUSIC

1100000 WIDE SCREEN 17 100010 DOLBY PL

2010000 SUPER STADIUM 18 010010

3110000 ROCK ARENA 19 110010 DTS ES MATRIX

4001000 JAZZ CLUB 20 001010 DOLBY DIGITAL EX

5101000 CLASSIC CONCERT 21 101010 CINEMA MODE

6011000 MONO MOVIE 22 011010 MUSIC MODE

7111000 MATRIX 23 111010 GAME MODE

8000100 VIDEO GAME 24 000110 NIGHT MODE

9100100 VIRTUAL 25 100110

10 010100 26 010110

11 110100 27 110110

12 001100 28 001110

13 101100 DTS NEO:6 CINEMA 29 101110 ROOM EQ

14 011100 DTS NEO:6 MUSIC 30 011110

15 111100 DOLBY PLII CINEMA 31 111110

SYSTEM ADDRESS (C1~C5) :00100 ,EXTENSION BIT (C12,C13) :0 1

No.

Data (C6~C11) Key Name No. Data (C6~C11) Key Name

32 000001 48 000011

33 100001 49 100011

34 010001 50 010011

35 110001 51 110011 INPUT MODE AUTO

36 001001 52 001011 INPUT MODE PCM

37 101001 53 101011 INPUT MODE DTS

38 011001 54 011011

39 111001 55 111011 INPUT MODE EXT.IN

40 000101 56 000111

41 100101 57 100111

42 010101 58 010111

43 110101 59 110111

44 001101 60 001111

45 101101 61 101111

46 011101 62 011111

47 111101 63 111111

DENON AVR3806 RC CODE

FORMAT KASEIKYO

DATA CONSTRUCTION 48bits

DENON CODE Parity GENRE1

452304

12345678910

11 12

13 14

18 19

21 22 23

0010

1010

0001

GENRE2 Data parity

Key Name

MAIN ZONE USER-1

MAIN ZONE USER-2

MAIN ZONE USER-3

DIRECT/STEREO

MAIN ZONE AUDIO DELAY UP

MAIN ZONE AUDIO DELAY DOWN

BAND FM

BAND AM

1 0 0 0

BAND XM

11000

ZONE2 VR MUTE

10 1 00

ZONE3VR MUTE
