Delta Amplon Series Manual de usuario
Delta UPS - Amplon Family
The power behind competitiveness
www.deltapowersolutions.com
User Manual
RT Series, Three Phase
11/ 15/ 17/ 20 kVA
Lithium-ion Battery Pack
Amplon RT series
SAVE THIS MANUAL
Copyright © 2019 by Delta Electronics Inc. All Rights Reserved. All rights of this
User Manual (“Manual”), including but not limited to the contents, information, and
figures are solely owned and reserved by Delta Electronics Inc.(“Delta”). The
Manual can only be applied to the operation or the use of this product. Any
disposition, duplication, dissemination, reproduction, modification, translation,
extraction, or usage of this Manual in whole or in part is prohibited without the prior
written permission of Delta. Given that Delta will continuously improve and develop
the product, changes may be made to the information in this Manual at any time
without obligation to notify any person of such revision or changes. Delta will make
all possible efforts to secure the accuracy and the integrity of this Manual. Delta
disclaims any kinds or forms of warranty, guarantee, or undertaking, either
expressly or implicitly, including but not limited to the completeness, faultlessness,
accuracy, non-infringement, merchantability or fitness for a particular purpose of
the manual.
This manual contains important instructions and warnings that you should
follow during the installation, operation, storage and maintenance of this
product. Failure to heed these instructions and warnings will void the
warranty.
1
Table of Contents
Chapter 1 : Product Introduction ................................................................... 3
Chapter 2 : Important Safety Instructions ..................................................... 4
2.1 Safety Instructions .................................................................................... 4
2.2 Standard Compliance ............................................................................... 5
2.3 Storage ....................................................................................................... 6
2.4 Recycling and Disposal ............................................................................ 6
Chapter 3 : Package list .................................................................................. 7
Chapter 4 : Rear Panel .................................................................................... 8
Chapter 5 : Installation Procedure ................................................................. 9
5.1 Rack Mounting........................................................................................... 9
5.2 Tower Mounting....................................................................................... 10
Chapter 6 : Connections ............................................................................... 14
6.1 The connection of the Delta Lithium-ion Battery Pack
RT-20K-LIB with the UPS........................................................................ 14
Chapter 7 : Installation of Lithium-ion Battery Module .............................. 17
Chapter 8 : Operation Procedures ............................................................... 19
Chapter 9 : Maintenance ............................................................................... 20
Appendix 1: Technical Specifications ......................................................... 21
Appendix 2: Warranty ................................................................................... 23
2
Amplon RT series
Chapter 1 : Product Introduction
The Delta Lithium-ion Battery Pack RT-20K-LIB is the external battery pack
providing DC power, which maintains inverter operation to supply stable power to
the critical loads connected to the UPS. Please note that the Delta Lithium-ion
Battery Pack RT-20K-LIB must operate in conjunction with different Delta Amplon
RT series UPS model. Please refer to the following table. You can also see
Figure 1-1 and Figure 1-2 to check the appearance and block diagram of RT-
20K-LIB.
The Delta Lithium-ion
Battery Pack Model
Applicable to Delta Amplon
RT Series UPS Model
RT-20K-LIB RT-11K3P-LV, RT-15K3P,
RT-17K3P, RT-20K3P
(Figure 1-1: the Front View of the RT-20K-LIB )
(Figure 1-2: Block Diagram of the RT-20K-LIB)
Cha
p
ter 1 : Product Introduction
3
Chapter 2 : Important Safety Instructions
2.1 Safety Instructions
• Servicing of batteries and battery packs must be performed or supervised by
qualified service personnel knowledgeable in batteries, battery packs and
the required precautions. Keep unauthorized personnel away from batteries
and battery packs.
• A battery can present a risk of electric shock and high short-circuit current.
• To reduce the risk of fire or electric shock, install the battery pack in a
temperature and humidity controlled indoor area free of conductive
contaminants.
• Forbid opening or removing the cover of the battery pack to avoid high
voltage electric shock.
• The risk of dangerous high voltage is possible when the batteries are still
connected to the UPS even though the UPS is disconnected from the mains.
• Do not forget to disconnect the battery cable to completely cut off the battery
source.
• Turn off the UPS and cut off the AC source before performing battery/
battery pack replacement.
• Only use the same type of batteries from the same supplier. Never use old,
new and different Ah batteries at the same time.
• Do not reverse or short circuit the polarity + and – when connecting the
batteries because this will destroy the device and constitute a risk of electric
shock or fire.
• The external slits and openings in the battery pack are provided for
ventilation.
• To ensure reliable operation of the battery pack and to protect the battery
pack from overheating, these slits and openings must not be blocked or
covered. Do not insert any object into the slits and openings that may hinder
ventilation.
• Do not allow liquid or any foreign object to enter the battery pack.
Cha
p
te
r
2 : Im
p
ortant Safet
y
Instructions
4
Amplon RT series
• Do not place beverages or any other liquid-containing vessels on or near the
battery pack.
• Do not dispose of the battery or batteries in a fire. The batteries may
explode.
• Do not open or mutilate the battery or batteries. The released electrolyte is
harmful to the skin and eyes and may be toxic.
• Observe the following before replacing batteries:
1. Remove watches, rings, or other metal objects.
2. Use tools with insulated handles.
3. Wear rubber gloves and boots.
4. Do not lay tools or metal parts on the top of batteries.
5. Disconnect charging source prior to connecting or disconnecting
batteries’ terminals.
•
The two figures above indicate there is high voltage circuit inside, and do not
open the cover of lithium-ion battery pack.
2.2 Standard Compliance
• CE
• CAN/ UL1973
• UN38.3
• PSE
• CB
• RCM
• Gost-R
• IEC/EN 62619
5
2.3 Storage
• Prior to installation
If the Lithium-ion battery pack needs to be stored prior to installation, it
should be placed in a dry area. The allowable storage temperature and
relative humidity (non-condensing) are -15°C ~ +50°C (5°F ~ 122°F) and 5 ~
95% respectively.
• After usage
Remove all equipment from the Lithium-ion battery pack, and store the
Lithium-ion battery pack in a dry and well-ventilated area at a temperature
between -15°C and +50°C (5°F ~ 122°F) and at a relative humidity (non-
condensing) between 5 ~ 95%.
2.4 Recycling and disposal
• Please follow the law of local government to handle Lithium-ion battery
pack.
6
Amplon RT series
Chapter 3 : Package list
The package contains the following items. Please check if any item is missing. If
there is anything missing, please contact the dealer immediately.
Models: RT-20K-LIB
No. Item Q’ty
1 Lithium-ion Battery Pack 1 pc
2 User Manual 1 pc
3 RS-485 Cable 1 pc
4 Ear Bracket Kit 1 set
5 Rear Panel for UPS 1 set
6 Tower Stand Extenders 4 pcs
7 Battery Cable 1 pc
NOTE:
1. If there is any damage or anything missing, please immediately contact
the dealer from whom you purchased the unit.
2. If the battery pack needs to be returned, carefully repack the UPS and
all of the accessories using the original packing material that came with
the unit.
Cha
p
te
r
3 : Packa
g
e List
7
Chapter 4 : Rear Panel
(Figure 4-1: the Rear View of the RT-20K-LIB)
No
. Item Function
1
External
Batt.
Connector
Connects with the UPS to supply power. Please note that
pin assignment of the battery connector is shown as
below.
2 RS-485
Port
The lithium-ion battery pack communicates with the UPS
via the RS-485 port.
3 Breaker Serves as a switch for safety protection.
4 Fan Ventilates the air to avoid overheat.
Cha
p
te
r
4 : The Rear Panel
8
Amplon RT series
Chapter 5 : Installation Procedure
5.1 Rack Mounting
You can rack-mount the UPS and the Delta lithium-ion battery pack RT-20K-LIB
in a standard 19-inch server rack. The UPS and the Delta lithium-ion battery
pack RT-20K-LIB should adopt the same mounting kits and mounting
procedures. The instruction below only shows the rack mounting of the Delta
lithium-ion battery pack RT-20K-LIB, if you want to check the rack mounting of
the UPS, please refer to the Delta Amplon RT Series UPS User Manual.
1. Attach the bracket ears provided in the package to the lateral mounting holes
of the Delta lithium-ion battery pack RT-20K-LIB. See Figure 5-1.
(Figure 5-1: Mount the Bracket Ears)
2. Follow step ❶ to ❹ to install the Delta lithium-ion battery pack RT-20K-LIB in
Delta’s rail kit (optional). See Figure 5-2.
Step ❶ : Adjust the length of the rails according to your rack.
Step ❷ : Tighten the rails’ nuts.
Step ❸ : Fix the rails on your rack.
Step ❹ : Insert the Delta lithium-ion battery pack RT-20K-LIB in your rack and
tighten the provided screws.
Cha
p
te
r
5 : Installation Procedure
9
