GBIC-1250 Long Distance Series

DELTA ELECTRONICS, INC.

1 01/23/2008

Rev. 0F

www.deltaww.com

RoHS Compliant 1250Mbps Gigabit Interface Converters (GBIC)

Transceiver Module for Gigabit Ethernet

Features

zCompliant with Gigabit Interface

Converter (GBIC) Revision 5.4

zCompliant with proposed specifications

for IEEE 802.3z/Gigabit Ethernet.

zDual 5V and 3.3V Power Supply

Operation

zTTL Logic TX_DISABLE / TX_FAULT /

RX_LOS functions

zClass 1 Laser Product Compliant with

the Requirements of IEC 60825-1 and

IEC 60825-2

zHot-Pluggable

zRoHS Compliant per Directive

2002/95/EEC

Description

The GBIC-1250xxxx families are compliant with GBIC

interface converters specification Rev. 5.4. as well as

Gigabit Ethernet standard as specified in IEEE 802.3.

Delta’s GBIC transceiver family uses a 20-pin connector

to allow hot plug capability. The system designer can

make configuration changes or maintenance simply by

plugging in different type of converters without removing

the power supply from the host system.

Applications

z1.25 Gigabit Ethernet

zFiber Channel

Performance

GBIC-1250B5LR:

1310nm MQW DFB laser, up to 25km in SMF

GBIC-1250D5MR:

1550nm MQW DFB laser, up to 40km in SMF

GBIC-1250D5WR:

1550nm MQW DFB laser, up to 70km in SMF

GBIC-1250D5RR:

1550nm MQW DFB laser, up to 80km in SMF

GBIC-1250D5VR:

1550nm MQW DFB laser, up to 100km in SMF

GBIC-1250 Long Distance Series

DELTA ELECTRONICS, INC.

2 01/23/2008

Rev. 0F

www.deltaww.com

Absolute Maximum Ratings

Parameter Symbol Min. Typ. Max. Unit Notes

Storage Temperature Ts -40 85 ºC

Supply Voltage VCC 0 6 V

Recommended Operating Conditions

Parameter Symbol Min. Typ. Max. Unit

Notes

Ambient Operating Temperature TA-5 70

℃

Supply voltage Vcc 3.15 / 4.75 3.3 / 5 3.45 / 5.25 V

Total Supply Current IS300 mA

Data Output Load RDL 75

Transmitter Electro-Optical Performance Specifications:

(TA=-5 °C to 70 °C, VCC=3.15V to 3.45V or VCC=4.75V to 5.25V)

Parameter Symbol Min. Typ. Max. Unit Note

Transmitter

Transmitter Differential Input Voltage VDT 0.5 2.4 V 1

Transmitter Disable Input-High VDISH 2 VCC+0.3 V

Transmitter Disable Input-Low VDISL 0 0.8 V

Transmitter Fault Pull up Resistor RTX_FAULT 4.7 10 kΩ2

Transmitter Fault Output-High VTXFH 2 VCC+0.3 V 2

Transmitter Fault Output-Low VTXFL 0 0.8 V 2

Receiver

Receiver Differential Output Voltage VDR 0.35 2 V 3

Receiver LOS Load RRXLOS 4.7 10 kΩ2

LOS Output Voltage-High VLOSH 2 VCC+0.3 V 2

LOS Output Voltage-Low VLOSL 0 0.8 V 2

Output Dara Rise / Fall Time tr/ tf220 psec 4

Notes:

1. Internally AC coupled and terminated to 150Ohm differential load.

2. Pull up to VCC on host Board

3. Internally AC coupled, but requires a 150Ohm differential termination at or internal to Serializer/

Deserializer.

4. These are 20%~80% values.

GBIC-1250 Long Distance Series

DELTA ELECTRONICS, INC.

3 01/23/2008

Rev. 0F

www.deltaww.com

Optical Characteristics

(TA=-5 °C to 70 °C, VCC=3.15V to 3.45V or VCC=4.75V to 5.25V, Data Rate=1250Mb/sec, PRBS=27-1NRZ)

Parameter Symbol Min. Typ. Max. Unit Note

Transmitter

Output Optical Power (Avg.)

GBIC-1250B5LR

GBIC-1250D5MR

GBIC-1250D5WR

GBIC-1250D5RR

GBIC-1250D5VR

-4

-5

-3

dBm

Optical Extinction Ratio ER 9 dB

Center Wavelength

GBIC-1250B5 Series

GBIC-1250D5 Series

λC

1274

1530

1310

1550

1355

1570

Spectral Width σ1 nm

Optical Rise/ Fall Time tr/tf260 psec 2

Receiver

Optical input sensitivity (avg.)

GBIC-1250B5LR

GBIC-1250D5MR

GBIC-1250D5WR

GBIC-1250D5RR

GBIC-1250D5VR

-23

-22

-24

-29

dBm 1

Optical input saturation (avg.)

GBIC-1250B5 Series

GBIC-1250D5 Series

GBIC-1250D5VR

PSAT

-1

-9

dBm

Optical Wavelength λ1270 1570 nm

LOS - Deasserted (avg.)

GBIC-1250B5LR

GBIC-1250D5MR

GBIC-1250D5WR

GBIC-1250D5RR

GBIC-1250D5VR

-23

-22

-24

-29

dBm

LOS - Asserted (avg.) PD-40 dBm

LOS - Hysteresis PA-PD0.5 dB

Note:

1. The sensitivity is provided at a BER of 1×10-12 or better with an input signal consisting of 1250Mb/s, 27

-1 PRBS and ER=9dB.

0XX 1X

ormalized 1X

1Y3

-Y

2. These are 20%~80% values

Normalized

GBIC-1250 Long Distance Series

DELTA ELECTRONICS, INC.

4 01/23/2008

Rev. 0F

www.deltaww.com

Pin Out Table

Pin Name Pin# Sequence Sequence Pin# Pin Name

RX_LOS 1 2 1 11 RGND

RGND 2 2 1 12 -RX_DAT

RGND 3 2 1 13 +RX_DAT

MOD_DEF(0) 4 2 1 14 RGND

MOD_DEF(1) 5 2 2 15 VDDR

MOD_DEF(2) 6 2 2 16 VDDT

TX_DISABLE 7 2 1 17 TGND

TGND 8 2 1 18 +TX_DAT

TGND 9 2 1 19 -TX_DAT

TX_FAULT 10 2 1 20 TGND

Overview of internal interface signal Definition

Pin Name Pin # Name/Function Signal Specification

Receiver Signals

RGND 2,3,11,14 Receiver Ground (may be connected with TGND in GBIC) Ground, to GBIC

VDDR 15 Receiver +5 volt (may be connected with VDDT in GBIC) Power, to GBIC

-RX_DAT 12 Receive Data, Differential PECL High speed serial, from

GBIC

+RX_DAT 13 Receive Data, Differential PECL High speed serial, from

GBIC

RX_LOS 1

Receiver Loss of Signal, logic high, open collector

compat-ible,4.7 K to 10 K Ohm pullup to VDDT on host Low speed, from GBIC

Transmitter Signals

TGND 8,9,17,20 Transmitter Ground (may be connected with RGND internally) Ground, to GBIC

VDDT 16 Transmitter +5 volt (may be connected with VDDR in GBIC) Power, to GBIC

+TX_DAT 18 Transmit Data, Differential PECL High speed serial, to GBIC

-TX_DAT 19 Transmit Data, Differential PECL High speed serial, to GBIC

TX_DISABLE 7 Transmitter Disable, logic high, open collector compatible,4.7

K to 10 K Ohm pullup to VDDT on GBIC Low speed, to GBIC

TX_FAULT 10

Transmitter Fault, logic high, open collector compatible,4.7 K

to 10 K Ohm pullup to VDDT on host Low speed, from GBIC

Control Signals

MOD_DEF(0) 4 GBIC module definition and presence, bit 0,4.7 K to 10 K Ohm

pullup to VDDT on host Low speed, from GBIC

MOD_DEF(1) 5 GBIC module definition and presence, bit 1,4.7 K to 10 K Ohm

pullup to VDDT on host Low speed, from GBIC

MOD_DEF(2) 6 GBIC module definition and presence, bit 2,4.7 K to 10 K Ohm

pullup to VDDT on host Low speed, from GBIC

GBIC-1250 Long Distance Series

DELTA ELECTRONICS, INC.

5 01/23/2008

Rev. 0F

www.deltaww.com

Recommend Circuit Schematic

GBIC-1250 Long Distance Series

DELTA ELECTRONICS, INC.

6 01/23/2008

Rev. 0F

www.deltaww.com

GBIC module definition parameters

Module

Definition MOD_DEF(0)

Pin 4 MOD_DEF(1)

Pin 5 MOD_DEF(2)

Pin 6 Interpretation by host Reference

0 NC NC NC GBIC not present clause

1 NC NC TTL LOW

Copper Style 1 or Style 2 connector, 1.0625 Gbd,

100-TW-EL-S or 100-TP-EL-S, active

inter-enclosure connection and IEEE802.3

1000BASE-CX

2 NC TTL LOW NC

Copper Style 1 or Style 2 connector, 1.0625 Gbd,

100-TW-EL-S, or 100-TP-EL-S, active or passive

intra-enclosure connection

3 NC TTL LOW TTL LOW Optical LW, 1.0625 Gbd 100-SM-LC-L

4 TTL LOW SCL SDA Serial module definition protocol

5 TTL LOW NC TTL LOW

Optical SW, 1.0625 Gbd 100-M5-SN-I or

100-M6-SN-I

6 TTL LOW TTL LOW NC

Optical LW, 1.0625 Gbd 100-SM-LC-L and similar

to 1.25 Gbd IEEE802.3z 1000BASE-LX, single

mode

7 TTL LOW TTL LOW TTL LOW

Optical SW, 1.0625 Gbd 100-M5-SN-I or

100-M6-SN-I and 1.25 Gbd, IEEE 802.3z,

1000BASE-SX

GBIC timing parameters for GBIC management

Parameter Symbol Min. Max. Unit Unit Conditions

TX_DISABLE assert time t_off 10 µsec Rising edge of TX_DISABLE to fall of output signal

below 10% of nominal

TX_DISABLE negate

time t_on 1 mec Falling edge of TX_DISABLE to rise of output

signal above 90% of nominal

Time to initialize,

includes reset of

TX_FAULT

t_init 300 msec

From power on or hot plug fter V DD T > 4.75 volts

or From negation of TX_DISABLE during reset of

TX_FAULT.

TX_FAULT from fault to

assertion t_fault 100 µsec From occurrence of fault (out-put safety violation or

V DD T < 4.5 volts)

TX_DISABLE time to

start reset t_rest 10 µsec TX_DISABLE HIGH before TX_DISABLE set LOW

RX_LOS assert delay t_loss_on 100 µsec From detection of loss of signal to assertion of

RX_LOS

RX_LOS negate delay t_loss_off 100 µsec From detection of presence of signal to negation of

RX_LOS

GBIC-1250 Long Distance Series

DELTA ELECTRONICS, INC.

7 01/23/2008

Rev. 0F

www.deltaww.com

GBIC timing parameters:

GBIC-1250 Long Distance Series

DELTA ELECTRONICS, INC.

8 01/23/2008

Rev. 0F

www.deltaww.com

GBIC-1250B5LR EEPROM Serial ID Memory Contents (2-Wire Address A0h)

Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII

00 01 25 20 50 35 5 75 SN 100 00 125 00

01 04 26 20 51 4C L 76 SN 101 00 126 00

02 01 27 20 52 52 R 77 SN 102 00 127 00

03 00 28 20 53 20 78 SN 103 00

04 00 29 20 54 20 79 SN 104 00

05 00 30 20 55 20 80 SN 105 00

06 02 31 20 56 41 A 81 SN 106 00

07 80 32 20 57 20 82 SN 107 00

08 10 33 20 58 20 83 SN 108 00

09 01 34 20 59 20 84 DC Note 3 109 00

10 01 35 20 60 05 85 DC 110 00

11 01 36 00 61 1E 86 DC 111 00

12 0D 37 00 62 00 87 DC 112 00

13 00 38 00 63 C8 Note 1 88 DC 113 00

14 19 39 00 64 00 89 DC 114 00

15 FA 40 47 G 65 1A 90 DC 115 00

16 00 41 42 B 66 05 91 DC 116 00

17 00 42 49 I 67 05 92 00 117 00

18 00 43 43 C 68 SN Note 2 93 00 118 00

19 00 44 2D - 69 SN 94 00 119 00

20 44 D 45 31 1 70 SN 95 CS2 Note 4 120 00

21 45 E 46 32 2 71 SN 96 00 121 00

22 4C L 47 35 5 72 SN 97 00 122 00

23 54 T 48 30 0 73 SN 98 00 123 00

24 41 A 49 42 B 74 SN 99 00 124 00

GBIC-1250D5MR EEPROM Serial ID Memory Contents (2-Wire Address A0h)

Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII

00 01 25 20 50 35 5 75 SN 100 00 125 00

01 04 26 20 51 4D M 76 SN 101 00 126 00

02 01 27 20 52 52 R 77 SN 102 00 127 00

03 00 28 20 53 20 78 SN 103 00

04 00 29 20 54 20 79 SN 104 00

05 00 30 20 55 20 80 SN 105 00

06 02 31 20 56 41 A 81 SN 106 00

07 80 32 20 57 20 82 SN 107 00

08 10 33 20 58 20 83 SN 108 00

09 01 34 20 59 20 84 DC Note 3 109 00

10 01 35 20 60 06 85 DC 110 00

11 01 36 00 61 0E 86 DC 111 00

12 0D 37 00 62 00 87 DC 112 00

13 00 38 00 63 D0 Note 1 88 DC 113 00

14 28 39 00 64 00 89 DC 114 00

15 FF 40 47 G 65 1A 90 DC 115 00

16 00 41 42 B 66 05 91 DC 116 00

17 00 42 49 I 67 05 92 00 117 00

18 00 43 43 C 68 SN Note 2 93 00 118 00

19 00 44 2D - 69 SN 94 00 119 00

20 44 D 45 31 1 70 SN 95 CS2 Note 4 120 00

21 45 E 46 32 2 71 SN 96 00 121 00

22 4C L 47 35 5 72 SN 97 00 122 00

23 54 T 48 30 0 73 SN 98 00 123 00

24 41 A 49 44 D 74 SN 99 00 124 00

Notes:

1) Byte 63: Check sum of bytes 0-62.

2) Byte 68-83 (SN): Serial number.

3) Byte 84-91 (DC): Date code.

4) Byte 95 (CS2): Check sum of bytes 64-94.

GBIC-1250 Long Distance Series

DELTA ELECTRONICS, INC.

9 01/23/2008

Rev. 0F

www.deltaww.com

GBIC-1250D5WR EEPROM Serial ID Memory Contents (2-Wire Address A0h)

Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII

00 01 25 20 50 35 5 75 SN 100 00 125 00

01 04 26 20 51 57 W 76 SN 101 00 126 00

02 01 27 20 52 52 R 77 SN 102 00 127 00

03 00 28 20 53 20 78 SN 103 00

04 00 29 20 54 20 79 SN 104 00

05 00 30 20 55 20 80 SN 105 00

06 02 31 20 56 41 A 81 SN 106 00

07 80 32 20 57 20 82 SN 107 00

08 10 33 20 58 20 83 SN 108 00

09 01 34 20 59 20 84 DC Note 3 109 00

10 01 35 20 60 06 85 DC 110 00

11 01 36 00 61 0E 86 DC 111 00

12 0D 37 00 62 00 87 DC 112 00

13 00 38 00 63 F8 Note 1 88 DC 113 00

14 46 39 00 64 00 89 DC 114 00

15 FF 40 47 G 65 1A 90 DC 115 00

16 00 41 42 B 66 05 91 DC 116 00

17 00 42 49 I 67 05 92 00 117 00

18 00 43 43 C 68 SN Note 2 93 00 118 00

19 00 44 2D - 69 SN 94 00 119 00

20 44 D 45 31 1 70 SN 95 CS2 Note 4 120 00

21 45 E 46 32 2 71 SN 96 00 121 00

22 4C L 47 35 5 72 SN 97 00 122 00

23 54 T 48 30 0 73 SN 98 00 123 00

24 41 A 49 44 D 74 SN 99 00 124 00

GBIC-1250D5RR EEPROM Serial ID Memory Contents (2-Wire Address A0h)

Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII

00 01 25 20 50 35 5 75 SN 100 00 125 00

01 04 26 20 51 52 R 76 SN 101 00 126 00

02 01 27 20 52 52 R 77 SN 102 00 127 00

03 00 28 20 53 20 78 SN 103 00

04 00 29 20 54 20 79 SN 104 00

05 00 30 20 55 20 80 SN 105 00

06 02 31 20 56 41 A 81 SN 106 00

07 80 32 20 57 20 82 SN 107 00

08 10 33 20 58 20 83 SN 108 00

09 01 34 20 59 20 84 DC Note 3 109 00

10 01 35 20 60 06 85 DC 110 00

11 01 36 00 61 0E 86 DC 111 00

12 0D 37 00 62 00 87 DC 112 00

13 00 38 00 63 FD Note 1 88 DC 113 00

14 50 39 00 64 00 89 DC 114 00

15 FF 40 47 G 65 1A 90 DC 115 00

16 00 41 42 B 66 05 91 DC 116 00

17 00 42 49 I 67 05 92 00 117 00

18 00 43 43 C 68 SN Note 2 93 00 118 00

19 00 44 2D - 69 SN 94 00 119 00

20 44 D 45 31 1 70 SN 95 CS2 Note 4 120 00

21 45 E 46 32 2 71 SN 96 00 121 00

22 4C L 47 35 5 72 SN 97 00 122 00

23 54 T 48 30 0 73 SN 98 00 123 00

24 41 A 49 44 D 74 SN 99 00 124 00

Notes:

1) Byte 63: Check sum of bytes 0-62.

2) Byte 68-83 (SN): Serial number.

3) Byte 84-91 (DC): Date code.

4) Byte 95 (CS2): Check sum of bytes 64-94.

GBIC-1250 Long Distance Series

DELTA ELECTRONICS, INC.

10 01/23/2008

Rev. 0F

www.deltaww.com

GBIC-1250D5VR EEPROM Serial ID Memory Contents (2-Wire Address A0h)

Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII

00 01 25 20 50 35 5 75 SN 100 00 125 00

01 04 26 20 51 56 V 76 SN 101 00 126 00

02 01 27 20 52 52 R 77 SN 102 00 127 00

03 00 28 20 53 20 78 SN 103 00

04 00 29 20 54 20 79 SN 104 00

05 00 30 20 55 20 80 SN 105 00

06 02 31 20 56 41 A 81 SN 106 00

07 80 32 20 57 20 82 SN 107 00

08 10 33 20 58 20 83 SN 108 00

09 01 34 20 59 20 84 DC Note 3 109 00

10 01 35 20 60 06 85 DC 110 00

11 01 36 00 61 0E 86 DC 111 00

12 0D 37 00 62 00 87 DC 112 00

13 00 38 00 63 15 Note 1 88 DC 113 00

14 64 39 00 64 00 89 DC 114 00

15 FF 40 47 G 65 1A 90 DC 115 00

16 00 41 42 B 66 05 91 DC 116 00

17 00 42 49 I 67 05 92 00 117 00

18 00 43 43 C 68 SN Note 2 93 00 118 00

19 00 44 2D - 69 SN 94 00 119 00

20 44 D 45 31 1 70 SN 95 CS2 Note 4 120 00

21 45 E 46 32 2 71 SN 96 00 121 00

22 4C L 47 35 5 72 SN 97 00 122 00

23 54 T 48 30 0 73 SN 98 00 123 00

24 41 A 49 44 D 74 SN 99 00 124 00

Notes:

5) Byte 63: Check sum of bytes 0-62.

6) Byte 68-83 (SN): Serial number.

7) Byte 84-91 (DC): Date code.

8) Byte 95 (CS2): Check sum of bytes 64-94.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Transceptor de Delta Electronics

Delta Electronics

Delta Electronics LCP-200A4HSR Manual de usuario

Delta Electronics

Delta Electronics 10GBASE-SR SFP+ Optical Transceiver... Manual de usuario

Delta Electronics

Delta Electronics OPT-1250xxxx Series Manual de usuario

Delta Electronics

Delta Electronics LCP-2125 Series Manual de usuario

Delta Electronics

Delta Electronics SFBD-1250A4Q1R Manual de usuario

Delta Electronics

Delta Electronics SPBD-1250A4Q1RT Manual de usuario

Delta Electronics

Delta Electronics Multi-Rate CWDM SFP Transceiver LCP-1250... Manual de usuario

Delta Electronics

Delta Electronics SFP Bi-Directional Transceiver Module... Manual de usuario

Delta Electronics

Delta Electronics LCP-155B4MSRx Series Manual de usuario

Delta Electronics

Delta Electronics SFBD-155F2J1RM Manual de usuario

Delta Electronics

Delta Electronics SPBD-155F4J1RD Manual de usuario

Delta Electronics

Delta Electronics Multimode SFP Transceiver LCP-1250A4FDRx Manual de usuario

Delta Electronics

Delta Electronics SFP Transceiver LCP-2488B4HDRx Manual de usuario

Delta Electronics

Delta Electronics LCP-8500A4EDR Manual de usuario

Delta Electronics

Delta Electronics LCP-1250RJ3SR-L Manual de usuario

Delta Electronics

Delta Electronics LCP-155B4JSRx Series Manual de usuario

Delta Electronics

Delta Electronics Single Mode SFP Transceiver LCP-1250B4QDRx Manual de usuario

Delta Electronics

Delta Electronics LCP-1250RJ3SR-S Manual de usuario

Delta Electronics

Delta Electronics SPBD-1250B4Q1RT Manual de usuario

Delta Electronics

Delta Electronics Multi-Rate CWDM SFP Transceiver LCP-1250... Manual de usuario

Delta Electronics

Delta Electronics SFBD-155E2J1RM Manual de usuario

Delta Electronics

Delta Electronics 10GBASE-LRM SFP+ Optical Transceiver... Manual de usuario

Delta Electronics

Delta Electronics LCP-4250A4CDR Series Manual de usuario

Delta Electronics

Delta Electronics Sonet OC-48/SDH Manual de usuario

Manuales populares de Transceptor de otras marcas

Yaesu

Yaesu FT-7B Manual de usuario

Kenwood

Kenwood ProTalk TK-3201 Manual de usuario

Texas Instruments

Texas Instruments TLK10232 Manual de usuario

Mizuho

Mizuho MX-2 Guía del producto

Kenwood

Kenwood TK-3180 Manual de operación y mantenimiento

Blitz

Blitz MJ-398U Manual de usuario

Utilicom

Utilicom LongRanger 2050 Manual de usuario

Standart

Standart HX290UKA Manual de usuario

Altronix

Altronix Pace1PTM Manual de usuario

Kirisun

Kirisun PT2208 Manual de usuario

ELECRAFT

ELECRAFT KX2 Manual de usuario

Zodiac

Zodiac K3 Manual de usuario

Assa Abloy

Assa Abloy SecureComm HKC GSM-WIFI U Manual de usuario

Kenwood

Kenwood TK-2217 Manual de usuario

Siemens

Siemens PSO 4000 Manual de usuario

Kenwood

Kenwood TS-590SG Manual de usuario

Midland

Midland G8E-BT Manual

ComNav

ComNav Mariner X2 Manual de usuario
