DE’LONGHI

COOKING

INSTALLATION and SERVICE INSTRUCTIONS

USE and CARE INSTRUCTIONS

DEL8510

ELECTRIC BUILT-IN OVENS

distributed by

DeLonghi Australia Pty Ltd

DeLonghi New Zealand Ltd

Dear Customer,

Thank you for having purchased and given your preference

to our product.

The safety precautions and recommendations reported

below are for your own safety and that of others. They

will also provide a means by which to make full use of the

features offered by your appliance.

Please keep this booklet in a safe place. It may be useful

in future, either to yourself or to others in the event that

doubts should arise relating to its operation.

This appliance must be used only for the task it

has explicitly been designed for, that is for cooking

foodstuffs. Any other form of usage is to be considered

as inappropriate and therefore dangerous.

The manufacturer declines all responsibility in the

event of damage caused by improper, incorrect or

illogical use of the appliance or be faulty installation.

PRODUCT LABEL

This appliance has been designed and constructed in accordance with the following

codes and specications:

AS/NZS 60335.1 General Requirements for Domestic electrical appliances

AS/NSZ 60335.2.6

Particular Requirements for Domestic electrical cooking appliances

AS/NZS CISPR 14.1 Electromagnetic Compatibility Requirements

IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS

IMPORTANT: This appliance is designed and manufactured

solely for the cooking of domestic (household) food and is

not suitable for any non domestic application and therefore

should not be used in a commercial environment.

The appliance guarantee will be void if the appliance is used

within a non domestic environment i.e. a semi commercial,

commercial or communal environment.

Read the instructions carefully before installing and using

the appliance.

■This appliance has been designed and manufactured in

compliance with the applicable standards for the household

cooking products and it fullls all the safety requirements shown

in this manual, including those for surface temperatures.

Some people with sensitive skin may have a more pronounced

temperature perception with some components although these

parts are within the limits allowed by the norms.

The complete safety of the appliance also depends on the correct

use, we therefore recommend to always pay a extreme attention

while using the product, especially in the presence of children.

■After having unpacked the appliance, check to ensure that it is

not damaged and that the oven door closes correctly.

In case of doubt, do not use it and consult your supplier or a

professionally qualied technician.

■Packing elements (i.e. plastic bags, polystyrene foam, nails,

packing straps, etc.) should not be left around within easy reach

of children, as these may cause serious injuries.

■ Some appliances are supplied with a protective lm on steel and

aluminium parts. This lm must be removed before using the

appliance.

■ IMPORTANT: The use of suitable protective clothing/gloves is

recommended when handling or cleaning this appliance.

■Do not attempt to modify the technical characteristics of

the appliance as this may become dangerous to use. The

manufacturer declines all responsibility for any inconvenience

resulting from the inobservance of this condition.

■Do not operate your appliance by means of an external timer or

separate remote-control system.

■Do not carry out cleaning or maintenance operations on the

appliance without having previously disconnected it from the

electric power supply.

■ WARNING: Ensure that the appliance is switched off before

replacing the oven lamp to avoid the possibility of electric shock.

■Do not use a steam cleaner because the moisture can get into

the appliance therefore making it unsafe.

■Do not touch the appliance with wet or damp hands (or feet).

■Do not use the appliance whilst in bare feet.

■If you should decide not to use this appliance any longer (or

decide to substitute another model), before disposing of it, it

is recommended that it be made inoperative in an appropriate

manner in accordance to health and environmental protection

regulations, ensuring in particular that all potentially hazardous

parts be made harmless, especially in relation to children who

could play with unused appliances.

■The various components of the appliance are recyclable. Dispose

of them in accordance with the regulations in force in your country.

If the appliance is to be scrapped, remove the power cord.

■After use, ensure that the knobs are in the off position.

■Children less than 8 years of age shall be kept away unless

continuously supervised.

■This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

■The manufacturer declines all liability for injury to persons or

damage to property caused by incorrect or improper use of the

appliance.

■ WARNING: During use the appliance and its accessible parts

become hot; they remain hot for some time after use.

– Care should be taken to avoid touching heating elements

inside the oven.

– The door is hot, use the handle.

– To avoid burns and scalds, young children should be kept

away.

■Make sure that electrical cables connecting other appliances in

the proximity of the oven cannot become entrapped in the oven

door.

■ WARNING: When correctly installed, your product meets all

safety requirements laid down for this type of product category.

However special care should be taken around the rear or the

underneath of the appliance as these areas are not designed or

intended to be touched and may contain sharp or rough edges,

that may cause injury.

■FIRST USE OF THE OVEN - it is advised to follow these

instructions:

– Furnish the interior of the oven as described in the chapter

“CLEANING AND MAINTENANCE”.

– Switch on the empty oven on max to eliminate grease from the

heating elements.

– Disconnect the appliance from the electrical power supply, let

the oven cool down and clean the interior of the oven with a

cloth soaked in water and neutral detergent; then dry carefully.

■ CAUTION: Do not use harsh abrasive cleaners or sharp metal

scrapers to clean the oven door glass since they can scratch the

surface, which may result in shattering of the glass.

■Do not line the oven walls with aluminium foil. Do not place baking

trays or the drip tray on the base of the oven chamber.

■ FIRE RISK! Do not store ammable material in the oven.

■Always use oven gloves when removing the shelves and food

trays from the oven whilst hot.

■Do not hang towels, dishcloths or other items on the appliance or

its handle – as this could be a re hazard.

■Clean the oven regularly and do not allow fat or oils to build up in

the oven base or tray. Remove spillages as soon as they occur.

■Do not stand on the open oven door.

■Always stand back from the appliance when opening the oven

door to allow steam and hot air to escape before removing the

food.

■ SAFE FOOD HANDLING: Leave food in the oven for as short

a time as possible before and after cooking. This is to avoid

contamination by organisms which may cause food poisoning.

Take particular care during warmer weather.

■ WARNING: Take care NOT to lift the appliance by the door

handle.

■The appliance must not be installed behind a decorative door in

order to avoid overheating.

■ The oven accessories (e.g. oven wire rack) must be tted

correctly as indicated at page 14.

■If the power supply cable is damaged, it must be replaced only

by an authorized service agent in order to avoid a hazard.

INSTALLATION

CAUTION:

■This appliance must be installed in accordance with these installation instructions.

■This appliance shall only be serviced by authorised personnel.

■This appliance is to be installed only by an authorised person in compliance

with the current electrical regulations and in observation of the instructions

supplied by the manufacturer.

Failure to comply with this condition will render the guarantee invalid.

■Incorrect installation, for which the manufacturer accepts no responsibility, may

cause personal injury of damage.

■Always disconnect the appliance from mains power supply before carrying out

any maintenance operations or repairs.

FITTING REQUIREMENTS

■ The oven can be tted in standard units, 60 cm width and depth.

■ Installation requires a compartment as illustrated in gures 1 and 2.

■On the lower side, the oven must lay on supports standing the oven weight.

■Remember the housing should not be free standing but be secured to the wall and/or

adjacent ttings.

■We would point out that the adhesive which bonds the plastic laminate to the

furniture must withstand temperatures not less than 150° C to avoid delamination.

■The walls of the units must be capable of resisting temperatures of 75 °C above

room temperature.

■Do not seal the oven into the cabinetry with silicone or glue; this makes future

servicing difcult. Delonghi will not cover the costs of removing the oven, or of

damage caused by this removal.

■The walls surrounding the oven must be made of heat-resistant material.

■WARNING: Taking care NOT to lift the oven by the door handle.

WARNING

When correctly installed, your product meets all safety requirements laid down for

this type of product category.

However special care should be taken around the rear or the underneath of the

appliance as these areas are not designed or intended to be touched and may

contain sharp or rough edges, that may cause injury.

IMPORTANT

Some environmental factors and cooking habits can cause condensation in and

around the oven during use. To protect surrounding cabinetry from possible damage

caused by frequent or excessive condensation, we recommend moisture-proong

the oven cavity.

560

550 min

085

595

545

556

600

560

085

600

Figure 2

Figure 1

FIXING THE OVEN

Introduce the oven into the furniture opening and x it with 2 screws (not supplied) as gure 3.

Before xing the 2 screws, t the 2 plastic bushes (supplied with the appliance in a separate

kit) into the xing holes. Take care to t the bushes in the correct way, they must lie at.

It is essential that the oven rests on a surface which will support its weight, as the screw

xing is only complementary.

Note:

It is essential that when installing your oven adequate air circulation is allowed for within

the installation. See gures 1, 2.

Inadequate air circulation may greatly impair the performance of your oven and may effect

adjacent cabinets due to an increase in temperature.

Caution!

Do not lift this oven by the door handle.

Adjust the hinges of furniture doors adjacent to the oven to allow a 4-5 mm gap between

the furniture door and the oven fra me.

Figure 3

ELECTRICAL REQUIREMENTS

■The appliance must be connected to the mains checking that the voltage corresponds

to the value given in the rating plate and that the electrical cable sections can withstand

the load specied on the plate.

■A suitable isolating switch providing full disconnection from the mains power supply

shall be incorporated in the permanent wiring, mounted and positioned to comply with

the local wiring rules and regulations. The isolating switch must be of an approved

type and provide a 3 mm air gap contact separation in all poles (or in all active [phase]

conductors if the local wiring rules allow for this variation of the requirements).

■The isolating switch shall be easily accessible to the customer with the oven installed.

■If the electrical supply is restricted, means of all-pole disconnection must be accessible

and incorporated in the xed wiring in accordance with the wiring rules.

■The power supply cable must not touch the hot parts and must be positioned so that it

does not exceed 75°C above ambient.

■The oven is supplied without a power supply plug and therefore if you are not connecting

directly to the mains, a standardized plug suitable for the load must be tted.

■The plug must be connected to an earthed socket in compliance with safety standards.

■To connect the appliance to the mains electricity supply, do not use adapters, reducers

or branching devices as they can cause overheating and burning.

■Once the appliance has been installed, the switch or socket must always be accessible.

■If the supply cord is damaged it must be replaced by the manufacturer or it’s Service

Agent or a similarly qualied person in order to avoid a hazard.

N.B. The connection of the appliance to earth is mandatory.

If the installation requires alterations to the domestic electrical system call a qualied

electrician. He should also check that the domestic electrical system is suitable for the

power drawn by the appliance.

Replacing the power cord must be done by a qualied electrician in accordance with

the instructions supplied by the manufacturer and in compliance with established

electrical regulations.

Tabla de contenidos

Otros manuales de Horno de DeLonghi

DeLonghi

DeLonghi DEL604M Guía rápida

DeLonghi

DeLonghi DGS 61 ST Instrucciones de operación

DeLonghi

DeLonghi XU12 Manual

DeLonghi

DeLonghi DE6038MD Guía de referencia rápida

DeLonghi

DeLonghi ELECTRIC OVEN Manual de usuario

DeLonghi

DeLonghi EOI406 Manual de usuario

DeLonghi

DeLonghi Sfornatutto Midi EO2475 Manual de usuario

DeLonghi

DeLonghi EO12 Series Manual de usuario

DeLonghi

DeLonghi ESM 460 Instrucciones de operación

DeLonghi

DeLonghi DO 420 Manual de usuario

DeLonghi

DeLonghi EMFPS 60 B Guía rápida

DeLonghi

DeLonghi OVEN WITH ELECTRONIC CONTROLS Manual de usuario

DeLonghi

DeLonghi ESM 495 ST Instrucciones de operación

DeLonghi

DeLonghi EO40 Series Manual de usuario

DeLonghi

DeLonghi DEFV908R Guía de referencia rápida

DeLonghi

DeLonghi EO2058 Manual de usuario

DeLonghi

DeLonghi EO2060 Manual de usuario

DeLonghi

DeLonghi EO241255MC Manual de usuario

DeLonghi

DeLonghi EO24752 Manual de usuario

DeLonghi

DeLonghi DEBIG24 Instrucciones de operación

DeLonghi

DeLonghi DDC 606-DF Instrucciones de funcionamiento

DeLonghi

DeLonghi DTC 95 DF Manual de usuario

DeLonghi

DeLonghi EO32502.WG Manual de usuario

DeLonghi

DeLonghi EO14 Series Manual de usuario

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
