DE’LONGHI

COOKING

USER & INSTALLATION INSTRUCTIONS

DDC 606-DF

GAS COOKER WITH ELECTRIC DOUBLE OVEN

CONTENTS

Page Number

Introduction............................................... 3

Important Safeguards & Recommendations..................... 4-8

Cooking Hob ............................................. 9

Control Panel............................................. 10

Use of hob burners ........................................11 - 13

Top conventional electric oven ...............................14 - 15

Bottom main oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Cooking guide ............................................17

Electronic programmer......................................18 - 23

Cleaning & maintenance ....................................24 - 36

Advice For The Installer ....................................37

Installation ...............................................38 - 40

Gas installation ...........................................41 - 46

Electrical section ..........................................47 - 48

Guarantee & After Sales Service .............................49

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT

IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EC.

At the end of its working life, the product must not be disposed of as

urban waste. It must be taken to a special local authority differentiated

waste collection centre or to a dealer providing this service.

Disposing of a household appliance separately avoids possible

negative consequences for the environment and health deriving from

inappropriate disposal and enables the constituent materials to be

recovered to obtain signicant savings in energy and resources. As a

reminder of the need to dispose of household appliances separately,

the product is marked with a crossed-out wheeled dustbin.

Dear Customer,

Thank you for purchasing the DeLonghi DDC 606-DF

double oven dual fuel cooker.

The safety precautions and recommendations listed

below are for your own safety and that of others. They

will also provide a means by which to make full use of the

features offered by your appliance.

Please retain this booklet for future reference.

This appliance must be used only for the task it

has explicitly been designed for, that is for cooking

foodstuffs.Anyotherformof usageistobeconsidered

as inappropriate and therefore potentially dangerous.

The manufacturer declines all responsibility in the

event of damage caused by improper, incorrect or

illogical use of the appliance.

DECLARATION OF CE CONFORMITY

• This appliance has been designed to be used only for cooking.Any other use (such as

heating a room) is improper and dangerous.

• This appliance has been designed, constructed, and marketed in compliance with:

- Safety requirements of the “Gas” Directive 2009/142/EC;

- Safety requirements of the “Low voltage” Directive 2014/35/EU;

- Safety requirements of the “EMC” Directive 2014/30/EU;

- Requirements of EU Directive 93/68/EEC;

- Requirements of EU Directive 2011/65/EU.

IMPORTANT SAFETY PRECAUTIONSAND RECOMMENDATIONS

IMPORTANT: This appliance is designed and manufactured

solely for the cooking of domestic (household) food and is

not suitable for any non domestic application and therefore

should not be used in a commercial environment.

The appliance guarantee will be void if the appliance is used

within a non domestic environment i.e. a semi commercial,

commercial or communal environment.

Read the instructions carefully before installing and using

the appliance.

• After having unpacked the appliance, check to ensure that it is

not damaged and that the oven door closes correctly.

In case of doubt, do not use it and consult your supplier or a

professionally qualied technician.

• Packing elements (i.e. plastic bags, polystyrene foam, nails,

packing straps, etc.) should not be left around within easy reach

of children, as these may cause serious injuries.

• Some appliances are supplied with a protective lm on steel and

aluminium parts. Thislmmustberemovedbeforeusingthe

appliance.

• IMPORTANT: The use of suitable protective clothing/gloves is

recommended when handling or cleaning this appliance.

• Do not attempt to modify the technical characteristics of

the appliance as this may become dangerous to use. The

manufacturer declines all responsibility for any inconvenience

resulting from the inobservance of this condition.

• CAUTION: this appIiance must only be installed in a permanently

ventilated room in compliance with the applicable regulations.

• Do not operate your appliance by means of an external timer or

separate remote-control system.

• Do not carry out cleaning or maintenance operations on the

appliance without having previously disconnected it from the

electric power supply.

• WARNING: Ensure that the appliance is switched off before

replacing the oven lamp to avoid the possibility of electric shock.

• Do not use a steam cleaner because the moisture can get into

the appliance therefore making it unsafe.

• Do not touch the appliance with wet or damp hands (or feet).

• Do not use the appliance whilst in bare feet.

• If you should decide not to use this appliance any longer (or

decide to substitute another model), before disposing of it, it

is recommended that it be made inoperative in an appropriate

manner in accordance to health and environmental protection

regulations, ensuring in particular that all potentially hazardous

parts be made harmless, especially in relation to children who

could play with unused appliances.

• Thevariouscomponentsoftheappliancearerecyclable.Dispose

oftheminaccordancewiththeregulationsinforceinyourcountry.

If the appliance is to be scrapped, remove the power cord.

• After use, ensure that the knobs are in the off position.

• Children less than 8 years of age shall be kept away unless

continuously supervised.

• This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

• The manufacturer declines all liability for injury to persons or

damage to property caused by incorrect or improper use of the

appliance.

• WARNING: During use the appliance and its accessible parts

become hot; they remain hot for some time after use.

– Care should be taken to avoid touching heating elements (on

the hob and inside the oven).

– The door is hot, use the handle.

– Toavoidburnsandscalds,young childrenshouldbekeptaway.

• Make sure that electrical cables connecting other appliances in

the proximity of the cooker cannot come into contact with the hob

or become entrapped in the oven door.

• WARNING: Unattended cooking on a hob with fat or oil can be

dangerous and may result in re. NEVER try to extinguish a re

with water, but switch off the appliance and then cover ame e.g.

with a lid or a re blanket.

• WARNING: Danger of re: do not store items on the cooking

surfaces.

• WARNING: When correctly installed, your product meets all

safety requirements laid down for this type of product category.

However special care should be taken around the rear or the

underneath of the appliance as these areas are not designed or

intended to be touched and may contain sharp or rough edges,

that may cause injury.

• FIRST USE OF THE OVEN - it is advised to follow these

instructions:

– Furnish the interior of the oven as described in the chapter

“CLEANING AND MAINTENANCE”.

– Switch on the empty oven on max to eliminate grease from the

heating elements.

– Disconnect the appliance from the electrical power supply, let

the oven cool down and clean the interior of the oven with a

cloth soaked in water and neutral detergent; then dry carefully.

• CAUTION: Do not use harsh abrasive cleaners or sharp metal

scrapers to clean the oven door glass since they can scratch the

surface, which may result in shattering of the glass.

• Donotlinetheovenwallsorbasewithaluminiumfoil.Donotplace

baking trays or the drip tray on the base of the oven chamber.

• FIRE RISK! Do not store ammable material in the oven

• Always use oven gloves when removing the shelves and food

trays from the oven whilst hot.

• Do not hang towels, dishcloths or other items on the appliance or

its handle – as this could be a re hazard.

• Clean the oven regularly and do not allow fat or oils to build up in

the oven base or tray. Remove spillages as soon as they occur.

• Do not stand on the cooker or on the open oven door.

• Always stand back from the appliance when opening the oven

door to allow steam and hot air to escape before removing the

food.

• SAFE FOOD HANDLING: Leave food in the oven for as short

a time as possible before and after cooking. This is to avoid

contamination by organisms which may cause food poisoning.

Take particular care during warmer weather.

• WARNING: Take care NOT to lift the cooker by the door handle.

• CAUTION: The cooking process has to be supervised. A short

term cooking process has to be supervised continuously.

• The appliance must not be installed behind a decorative door in

order to avoid overheating.

• The oven accessories (e.g. oven wire rack) must be tted

correctly as indicated at page 27.

• If the power supply cable is damaged, it must be replaced only

by an authorized service agent in order to avoid a hazard.

ENERGY LABELLING/ECODESIGN

• Commission delegated regulation (EU) No 65/2014 (supplementing Directive 2010/30/EU

of the European Parliament and of the Council).

• Commission regulation (EU) No 66/2014 (implementing Directive 2009/125/EC of the

European Parliament and of the Council).

Reference to the measurement and calculation methods used to establish compliance with

the above requirements:

• Standard EN 60350-1 (electric ovens).

• Standard EN30-2-1 (hobs: gas red burners).

USE OF THE APPLIANCE, ENERGY SAVING TIPS

OVEN

• Check the oven door always closes properly and the door gasket is clean and in order.

During use, open the oven door only when strictly necessary to avoid heat losses (for

some functions it may be necessary to use the oven with the door half-closed, check

the oven operating instructions).

• Turn off the oven 5-10 minutes before the end of the theoretical cooking time to

recuperate the stored heat.

• We recommend using oven proof dishes and adjusting the oven temperature during

cooking if necessary.

HOB

GAS FIRED BURNERS

• It is important that the diameter of the pot be suitable to the size of the burner so as

not to compromise the high output of the burners and therefore energy waste. A small

pot on a large burner does not give you a boiling point in a shorter amount of time

since the capacity of heat absorption of a liquid mass depends on the volume and the

surface of the pot.

• Avoid keeping a burner on without something on it (without pot).

GAS BURNERS

1. Auxiliary burner (A) 1,00 kW

2. Semi-rapid burner (SR) 1,75 kW

3. Triple-ring burner (TR) 3,50 kW

1 - COOKING HOB

Fig. 1.1

2 2

Notes:

• The electric ignition is incorporated in the knobs.

• The appliance has a safety valve system tted, the ow of gas will be stopped if and

when the ame should accidentally go out.

CAUTION:

If the burner is accidentally extinguished, turn the gas off at the control knob and wait at

least 1 minute before attempting to relight.

CAUTION:

Gas hobs produce heat and humidity in the environment in which they are installed.

Ensure that the cooking area is well ventilated by opening the natural ventilation grilles or

by installing an extractor hood connected to an outlet duct that vents to the outside.

CAUTION:

If the hob is used for a prolonged time it may be necessary to provide further ventilation

by opening a window or by increasing the suction power of the extractor hood if tted and

vented to the outside.

12345678

910

Controls description

1. Front right burner control knob

2. Rear right burner control knob

3. Rear left burner control knob

4. Front left burner control knob

5. Conventional oven temperature knob (Top oven)

6. Conventional oven function selector knob (Top oven)

7. Fan oven switch and temperature knob (Bottom main oven)

8. Electronic programmer (main oven only)

Pilot lamps:

9. Main oven temperature light

10. Conventional oven temperature light

2 - CONTROL PANEL

Fig. 2.1

Please note: This appliance incorporates a safety cooling fan which you will hear operating

whenever the oven or grill is being used.

The cooling fan may even run on after the appliance has been switched off.

The duration of this time is dependent on several factors, including previous cooking

temperature, duration and ambient temperature. Times in excess of 30 minutes are not

uncommon.

Tabla de contenidos

Otros manuales de Horno de DeLonghi

DeLonghi

DeLonghi EO141150 Manual de usuario

DeLonghi

DeLonghi DSR 905-DF Instrucciones de funcionamiento

DeLonghi

DeLonghi Sfornatutto Midi EO2475 Manual de usuario

DeLonghi

DeLonghi OVEN WITH ELECTRONIC CONTROLS Manual de usuario

DeLonghi

DeLonghi EO12 Series Manual de usuario

DeLonghi

DeLonghi DESM463 Series Instrucciones de operación

DeLonghi

DeLonghi EO241150 Manual de usuario

DeLonghi

DeLonghi DO 420 Manual de usuario

DeLonghi

DeLonghi EO14902.S Manual de usuario

DeLonghi

DeLonghi EO241250 Manual de usuario

DeLonghi

DeLonghi EO32852 Manual de usuario

DeLonghi

DeLonghi EO 420 Manual de usuario

DeLonghi

DeLonghi DE904PSC Guía rápida

DeLonghi

DeLonghi NSM 90 N Guía rápida

DeLonghi

DeLonghi EO1200 Series Manual de usuario

DeLonghi

DeLonghi DEL8510 Guía de referencia rápida

DeLonghi

DeLonghi DO32852 Manual de usuario

DeLonghi

DeLonghi DEBIGE DEBIGE 2440 E Instrucciones de operación

DeLonghi

DeLonghi DE6038MD Guía de referencia rápida

DeLonghi

DeLonghi DEP909M Guía de instalación

DeLonghi

DeLonghi DEP7410P Guía rápida

DeLonghi

DeLonghi DTR 900-DF Instrucciones de funcionamiento

DeLonghi

DeLonghi EOI406 Manual de usuario

DeLonghi

DeLonghi MULTIFUNCTION BUILT-IN OVENS Guía de instalación

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
