DE’LONGHI

COOKING

INSTALLATION and SERVICE INSTRUCTIONS

USE and CARE INSTRUCTIONS

NSM 90 N

FAN ASSISTED BUILT-IN OVEN

distributed by

ELBA Appliances Australia

(a Division of Fisher&Paykel Australia)

Dear Customer,

Thankyouforhavingpurchasedandgivenyourpreference

to our product.

The safety precautions and recommendations reported

below are for your own safety and that of others. They

will also provide a means by which to make full use of the

features oered by your appliance.

Please keep this booklet in a safe place. It may be useful

in future, either to yourself or to others in the event that

doubts should arise relating to its operation.

This appliance must be used only for the task it

has explicitly been designed for, that is for cooking

foodstus. Any other form of usage is to be considered

as inappropriate and therefore dangerous.

The manufacturer declines all responsibility in the

event of damage caused by improper, incorrect or

illogical use of the appliance or be faulty installation.

PRODUCT LABEL

This appliance has been designed and constructed in accordance with the following

codes and specications:

AS/NZS 60335.1 Household and similar electrical appliances - Safety General

requirements

AS/NSZ 60335.2.6

Safety Particular requirements for stationary cooking ranges, hobs,

ovens and similar appliances

AS/NZS CISPR 14.1 Electromagnetic Compatibility Requirements

IMPORTANT SAFETY PRECAUTIONSAND RECOMMENDATIONS

IMPORTANT: This appliance is designed and manufactured

solely for the cooking of domestic (household) food and is

not suitable for any non domestic application and therefore

should not be used in a commercial environment.

The appliance guarantee will be void if the appliance is used

within a non domestic environment i.e. a semi commercial,

commercial or communal environment.

Read the instructions carefully before installing and using

the appliance.

■This appliance has been designed and manufactured in

compliance with the applicable standards for the household

cooking products, including those for surface temperatures.

Some people with sensitive skin may have a more pronounced

temperature perception with some components although these

parts are within the limits allowed by the norms.

Thecompletesafetyof theappliance alsodepends onthe correct

use, we therefore recommend to always pay a extreme attention

while using the product, especially in the presence of children.

■After having unpacked the appliance, check to ensure that it is

not damaged and that the oven door closes correctly.

In case of doubt, do not use it and consult your supplier or a

professionally qualied technician.

■Packing elements (i.e. plastic bags, polystyrene foam, nails,

packing straps, etc.) should not be left around within easy reach

of children, as these may cause serious injuries.

■ Some appliances are supplied with a protective lm on steel and

aluminium parts. This lm must be removed before using the

appliance.

■ IMPORTANT: The use of suitable protective clothing/gloves is

recommended when handling or cleaning this appliance.

■Do not attempt to modify the technical characteristics of

the appliance as this may become dangerous to use. The

manufacturer declines all responsibility for any inconvenience

resulting from the inobservance of this condition.

■Do not operate your appliance by means of an external timer or

separate remote-control system.

■Do not carry out cleaning or maintenance operations on the

appliancewithouthavingpreviouslydisconnected it fromtheelectric

power supply.

■ WARNING: Ensure that the appliance is switched o󰀨 before

replacing the oven lamp to avoid the possibility of electric shock.

■Do not use a steam cleaner because the moisture can get into the

appliance therefore making it unsafe.

■Do not touch the appliance with wet or damp hands (or feet).

■Do not use the appliance whilst in bare feet.

■If you should decide not to use this appliance any longer (or

decide to substitute another model), before disposing of it, it is

recommended that it be made inoperative in an appropriate manner

in accordance to health and environmental protection regulations,

ensuring in particular that all potentially hazardous parts be made

harmless, especially in relation to children who could play with

unused appliances.

■The various components of the appliance are recyclable. Dispose

of them in accordance with the regulations in force in your country.

If the appliance is to be scrapped, remove the power cord.

■ After use, ensure that the knobs are in the o󰀨 position.

■Children less than 8 years of age shall be kept away unless

continuously supervised.

■This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in

a safe way and understand the hazards involved. Children shall not

play with the appliance. Cleaning and user maintenance shall not

be made by children without supervision.

■Themanufacturerdeclinesallliabilityforinjurytopersonsordamage

to property caused by incorrect or improper use of the appliance.

■ WARNING: During use the appliance and its accessible parts

become hot; they remain hot for some time after use.

– Care should be taken to avoid touching heating elements

inside the oven.

– The door is hot, use the handle.

– Toavoidburns and scalds,youngchildrenshould be keptaway.

■Make sure that electrical cables connecting other appliances in

the proximity of the oven cannot become entrapped in the oven

door.

■ WARNING: When correctly installed, your product meets all

safety requirements laid down for this type of product category.

However special care should be taken around the rear or the

underneath of the appliance as these areas are not designed or

intended to be touched and may contain sharp or rough edges,

that may cause injury.

■FIRST USE OF THE OVEN - it is advised to follow these

instructions:

– Furnish the interior of the oven as described in the chapter

“CLEANING AND MAINTENANCE”.

– Switch on the empty oven on max to eliminate grease from the

heating elements.

– Disconnect the appliance from the electrical power supply, let

the oven cool down and clean the interior of the oven with a

cloth soaked in water and neutral detergent; then dry carefully.

■ CAUTION: Do not use harsh abrasive cleaners or sharp metal

scrapers to clean the oven door glass since they can scratch the

surface, which may result in shattering of the glass.

■Donotlinetheovenwallswithaluminiumfoil. Do not placebaking

trays or the drip tray on the base of the oven chamber.

■ FIRE RISK! Do not store ammable material in the oven.

■Always use oven gloves when removing the shelves and food

trays from the oven whilst hot.

■Do not hang towels, dishcloths or other items on the appliance or

its handle – as this could be a re hazard.

■Clean the oven regularly and do not allow fat or oils to build up in

the oven base or tray. Remove spillages as soon as they occur.

■Do not stand on the open oven door.

■Always stand back from the appliance when opening the oven

door to allow steam and hot air to escape before removing the

food.

■ SAFE FOOD HANDLING: Leave food in the oven for as short

a time as possible before and after cooking. This is to avoid

contamination by organisms which may cause food poisoning.

Take particular care during warmer weather.

■ WARNING: Take care NOT to lift the appliance by the door

handle.

■The appliance must not be installed behind a decorative door in

order to avoid overheating.

■ The oven accessories (e.g. oven wire rack) must be tted

correctly as indicated at page 15.

■If the power supply cable is damaged, it must be replaced only

by an authorized service agent in order to avoid a hazard.

■ If the appliance is not tted with a supply cord and a plug, or with

other means for disconnection from the supply mains having a

contactseparationinallpolesthatprovidefulldisconnectionunder

overvoltage category III conditions, means for disconnection

must be incorporated in the xed wiring in accordance with the

wiring rules.

■ WARNING: The appliance and its accessible parts become hot

during use.

Care should be taken to avoid touching heating elements.

Children less than 8 years of age shall be kept away unless

continuously supervised.

INSTALLATION

CAUTION:

■This appliance must be installed in accordance with these installation instructions.

■This appliance shall only be serviced by authorised personnel.

■This appliance is to be installed only by an authorised person in compliance

with the current electrical regulations and in observation of the instructions

supplied by the manufacturer.

Failure to comply with this condition will render the guarantee invalid.

■Incorrect installation, for which the manufacturer accepts no responsibility, may

cause personal injury of damage.

■Always disconnect the appliance from mains power supply before carrying out

any maintenance operations or repairs.

FITTING REQUIREMENTS

■ The oven can be tted in standard units, width 90 cm and depth 60 cm.

■ Installation requires a compartment as illustrated in gures 1 and 2.

■On the lower side, the oven must lay on supports standing the oven weight.

■Remember the housing should not be free standing but be secured to the wall and/or

adjacent ttings.

■We would point out that the adhesive which bonds the plastic laminate to the

furnituremust withstand temperaturesnot less than150°C to avoiddelamination.

■The walls of the units must be capable of resisting temperatures of 75°C above

room temperature.

■Do not seal the oven into the cabinetry with silicone or glue; this makes future

servicing di󰀩cult. Elba Appl. AUS Service Agent will not cover the costs of

removing the oven, or of damage caused by this removal.

■The walls surrounding the oven must be made of heat-resistant material.

■WARNING: Taking care NOT to lift the oven by the door handle.

WARNING

When correctly installed, your product meets all safety requirements laid down for

this type of product category.

However special care should be taken around the rear or the underneath of the

appliance as these areas are not designed or intended to be touched and may

contain sharp or rough edges, that may cause injury.

IMPORTANT

Some environmental factors and cooking habits can cause condensation in and

around the oven during use. To protect surrounding cabinetry from possible damage

caused by frequent or excessive condensation, we recommend moisture-proong

the oven cavity.

853

896

478

544

min. 550

480

467

min. 860

Figure 1

853

896

478

544

min. 550

480

467

min. 860

min. 900

Figure 2

WARNING, VERY IMPORTANT:

The oven is supplied with no.6 rubber spacers xed at the bottom.

DO NOT install the oven without these spacers correctly in place.

If one or more rubber spacers are missing, please use the ones contained in the

separate kit supplied with this appliance and x them to the bottom of the oven as

indicated in the gure 3a on the next page.

Should you require assistance please contact our Customer Service Centre for your

nearest Authorised Elba Appl. AUS Service Agent Service Agent.

x 6

FIXING THE OVEN

Introduce the oven into the furniture opening and x it with 4 screws (not supplied) as

gure 3b. It is essential that the oven rests on a surface which will support its weight, as the

screw xing is only complementary.

Note

It is essential that when installing your oven adequate air circulation is allowed for within

the installation. See gures 1 - 2.

Inadequate air circulation may greatly impair the performance of your oven and may e󰀨ect

adjacent cabinets due to an increase in temperature.

Caution: Do not lift this oven by the door handle.

Adjust the hinges of furniture doors adjacent to the oven to allow a 4-5 mm gap between

the furniture door and the oven frame.

Figure 3b

Figure 3a

Fixing the rubber spacers to the

baseoftheoven(iftheyaremissing)

by using the ones contained in

the separate kit supplied with this

appliance.

1010

IMPORTANT:

Please take extra care not to damage the lower trim of the oven.

Ensure the oven sits on wooden blocks or similar supports when it is removed from the

carton as shown in above diagram. This will prevent any damage to the lower trim.

Should the lower trim become damaged, straighten the trim and ensure the oven door

opens fully without obstruction from the lower trim.

After installation check the lower trim is still undamaged.

The space between the bottom of the door & the lower trim is important to allow proper air

circulation into the oven.

The oven door should be opened slowly to it’s fully open position ensuring there is adequate

clearance between the bottom of the door and the lower trim.

The manufacturer does not accept responsibility for any damage to the oven

resulting from incorrect installation.

Figure 4

OVEN DOOR

LOWER TRIM

AIR FLOW

IMPORTANT:

When handling the oven, take care not

to damage the door sensor lever “L”

(near the top right corner of the oven

seal).

Figure 5

Tabla de contenidos

Otros manuales de Horno de DeLonghi

DeLonghi

DeLonghi XU400 Manual

DeLonghi

DeLonghi OVEN WITH ELECTRONIC CONTROLS Manual de usuario

DeLonghi

DeLonghi EO1200 Series Manual de usuario

DeLonghi

DeLonghi Oven Manual de usuario

DeLonghi

DeLonghi DOMFP/S Guía de instalación

DeLonghi

DeLonghi NSM 7 NL Guía rápida

DeLonghi

DeLonghi DO2058 Manual de usuario

DeLonghi

DeLonghi EO 2031 Manual de usuario

DeLonghi

DeLonghi Convection Toaster Oven with Broiler and... Manual de usuario

DeLonghi

DeLonghi DE908M Guía de instalación

DeLonghi

DeLonghi DOMFP Manual de funcionamiento

DeLonghi

DeLonghi DEBIGE DEBIGE 2440 E Instrucciones de operación

DeLonghi

DeLonghi DE609MP Guía rápida

DeLonghi

DeLonghi EO12 Series Manual de usuario

DeLonghi

DeLonghi MULTIFUNCTION BUILT-IN OVENS Guía rápida

DeLonghi

DeLonghi EO32 Series Manual de usuario

DeLonghi

DeLonghi EO40 Series Manual de usuario

DeLonghi

DeLonghi xu1837w Manual de usuario

DeLonghi

DeLonghi DE605MS Guía de referencia rápida

DeLonghi

DeLonghi EO241255MC Manual de usuario

DeLonghi

DeLonghi 24 E Manual de usuario

DeLonghi

DeLonghi EO14902.S Manual de usuario

DeLonghi

DeLonghi DEL6038D Guía rápida

DeLonghi

DeLonghi DSR 905-DF Instrucciones de funcionamiento

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
