TRV Series

OIL FILLED RADIATOR

Instructions for use

IMPORTANT WARNINGS

Read all the Instruction for Use carefully before using

the appliance. Keep this Instructions for Use.

Danger!

Failure to observe the warning may result in life threatening

injury by electric shock.

- Do not use the heater in the vicinity of

bathtubs, wash basins, showers, sinks

and swimming pools.

- Never use the heater to dry laundry.

- If the power cable has been damaged,

it must be replaced by the manufac-

turer or the technical service centre or

by a qualied person so as to avoid all

risks.

Important!

Failure to observe the warning could result in injury or dam-

age to the appliance.

-This appliance can be used by children

aged from 8 years and above and per-

sons with reduced physical, sensory

or mental capabilities or lack of ex-

perience and knowledge if they have

been given supervision or instruction

concerning use of the appliance in a

safe way and understand the hazards

involved.

Children shall not play with the appli-

ance. Cleaning and user maintenance

shall not be made by children without

supervision.

- Children of less than 3 years should be

kept away unless continuously super-

vised.

- Children aged from 3 years and less

than 8 years shall only switch on/o

the appliance provided that it has been

placed or installed in its intended nor-

mal operating position and they have

been given supervision or instruction

concerning use of the appliance in a

safe way and understand the hazards

involved. Children aged from 3 years

and less than 8 years shall not plug

in, regulate and clean the appliance or

perform user maintenance.

CAUTION — Some parts of this

product can become very hot and

cause burns. Particular attention

has to be given where children

and vulnerable people are pres-

ent.

- WARNING: Do not use this heater in

small rooms when they are occupied

by persons not capable of leaving the

room on their own, unless constant

supervision is provided.

- The body of this radiator is lled with

a precise quantity of special oil, so that

repairs requiring the opening of the oil

body must only be made by the service

agent. Any oil leakage must be report-

ed to the Customer Experience, see en-

closed guarantee for details.

- When scrapping the heater, follow the

regulations concerning the disposal of

oil.

- The appliance must not be located im-

mediately below a xed socket-outlet.

- CAUTION: in order to avoid any dan-

ger caused by an accidental resetting

of the safety system, this appliance

must not be powered through an ex-

ternal timer.

- Do not obstruct the air intake and out-

let area (danger of overheating).

Danger of burns!!

Failure to observe the warning could result in burns or scalds.

- WARNING: In order to avoid

overheating, never under any

circumstances cover the appliances

during operation, as this would lead

to dangerous overheating.

- The use of an extension lead is not

recommended, as overheating of the

extension lead may occur during the

operation of the heater.

- Never place the power cable on top of

the heater while it is hot.

- Do not rest anything on the appliance.

- WARNING: To reduce the risk of re,

keep textiles, curtains, or any other

ammable material a minimum dis-

tance of 1 m from the air outlet.

Please note:

This symbol indicates recommendations and important infor-

mation for the user.

- We recommend that you not place the

heater in a draught, because strong

draughts of air may adversely aect

the equipment’s operational ecien-

cy.

Only

use this heater on a horizontal

and stable surface.

- Always use the appliance in an upright

position.

- Do not use this heater if it has been

dropped.

- Do not use if there are visible signs of

damage to the heater.

- In order to eliminate the radiator's

“new”smell , set it to maximum power

for at least two hours when used for the

rst time. During this operation, the

room in which the radiator is located

must be ventilated. A little smoke due

to the protective substances applied to

the heating element before transport

may be given o.

- Position the appliance so that the plug

and the outlet can be easily reached.

- Do not use the appliance in rooms less

than 4 m2in area.

- The appliance is tted with a safety

device which will switch o it in case

of accidental overheating.

To reset, please contact Customer Ex-

perience, see enclosed guarantee.

- Before putting the appliance away,

make sure it is completely cooled and

unplugged from the mains socket.

Do not store in dusty atmospheres.

- The appliance must not be hung.

Fundamental safety warnings

Dear customer - the plug on the

appliance heats up during use. This is

completely normal. This HIGH POWER

HEATING APPLIANCE complies with our

usual high standards. You should,

however, make sure that your power

socket is in good condition and that the

plug on the appliance is plugged into the

socket correctly to avoid accidental

overheating. If the appliance is used for

long periods of time, we recommend

checking the plug and mains socket

regularly. If in doubt, consult an

electrician.

For non-EU countries only:

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or in-

struction concerning use of the appliance

by a person responsible for their safety.

Children should be supervised to ensure

that they do not play with the appliance.

DESCRIPTION

A Thermostat pointer

B Indicator light

C Power selector

DTimer

E Cord holder

F Wheel

USE

“Easy wheel” system

Turn the radiator upside down and rest it on a piece of cloth or

other soft surface to avoid damaging the paint.

Open the wheels completely by rotating them outwards (g.

1). Turn the radiator upright.

Important

When in use, the radiator should always be kept vertical

(wheels at the bottom, controls at the top). Any other

position could be dangerous!

Connection

- Before using the appliance check that your supply

voltage is the same of that shown on the rating label

of the unit and that the power socket and power supply

line correspond to the load specied.

- Check also the current capacity of your fuses. CONNECT

YOUR HEATER TO EARTH PROVIDED SOCKET ONLY.

The radiator must be connected to a perfectly functioning

230-240 V AC socket with correct poles. Avoid contact

between clothing, household linen, furniture, inammable

material and the socket providing power to the radiator.

TURNING ON

Plug into the mains, turn the thermostat pointer as far as it

will go to maximum and turn the radiator on using the power

selector as described below:

• Turn the power selector to 1 (minimum power) (the

light comes on).

• Turn the power selector to 2 (medium power) (the light

comes on).

• Turn the power selector to 3 (maximum power) (the

light comes on).

Please note: For economic operation, once the

appliance has reached working temperature, you can use

minimum or medium power (1 or 2).

Adjusting the thermostat

When the room has reached the required temperature, turn

the thermostat slowly clockwise until a "click" is heard and

no further. The thermostat will automatically regulate the

temperature set and keep it constant. If your model has three

power levels, in the spring or autumn or on mild days, you can

further save energy by using minimum power.

Frost protection function

Turn the thermostat dial to the and select the maximum

power, the appliance maintains room temperature at about

5°C, preventing freezing with minimal energy consumption.

Please note: To turn the appliance o completely, turn

the power selector to "0".

THE TIMER

As with all clocks, the timer must be set to the exact time.

For example, if it is 9.30 in the morning, turn the dial of the

timer clockwise (in the direction of the arrow) until 9.30 is

lined up with the pointer

IMPORTANT: DO NOT TURN THE DIAL OF THE TIMER

ANTICLOCKWISE.

The timer is an electric clock and works only if plugged into

a socket. If disconnected, the timer stops and must be reset.

See gure below:

Period of

operation Tooth

Pointer

Selector (some models only)

Manual mode

Programme mode

Appliance o

TROUBLESHOOTING

PROBLEM CAUSE SOLUTION

The appliance doesn't work Be sure it is plugged in and that the

electrical outlet is working.

Check for any obstruction.

The temperature may be set too low.

Plug into the power outlet.

Remove the obstruction and let the

appliance cool down. If the appliance

doesn't work please contact the nearest

De'Longhi Customer Service.

Set the temperature to a higher position.

IMPORTANT: the timer consists of 96 teeth, each representing

a 15-minute period. The appliance can be programmed to

come on and go o at set times. With the timer, the appliance

is programmed to within 15 minute intervals and you can

programme up to 48 cycles (each cycle consists of a coming

on and a going o time) during a 24 hour period). The teeth

can be pushed or pulled with your ngers. When a tooth is

pushed towards the centre of the dial, the radiator remains in

operation for those 15 minutes. If the tooth is pulled out, the

radiator is o during that period.

Using the timer

A) Plug into the mains socket.

B) Turn the dial clockwise to set the current time (see

SETTING THE CLOCK).

C) Push the teeth corresponding to the period you do not

want the radiator to operate towards the outside. For

example, the radiator in the gure will be on from 2.00

to 5.00.

D) Turn the power selector to the required position (1, 2 or

3).

E) Once the teeth have been set for the desired periods of

heating, the radiator will come on and go o as set.

F) While the radiator remains plugged into the socket, the

timer retains the correct time.

OPERATION WHITOUT TIMER

To operate whitout timer, place the selector in the I position

(see gure).

To go back to programmed operation, place the selector in

the position.

Please note: when the selector is in the 0 position, the

appliance is o. In the I and 0 positions, the timer is still set

to the current time.

Safety device

A safety device shuts the radiator down in the case of

overheating. To start the radiator up again, call the nearest

service centre.

MAINTENANCE AND SERVICE

Before performing any operations on the appliance, always

unplug from the mains socket and leave to cool.

Dust the radiator with a soft damp cloth without using

detergents or abrasives.

If the radiator is not used for a long period of time, wrap

the cable around the cable tidy and store the appliance in a

dry place. This appliance has been made to last many years

without problems.

In the event of malfunction or doubt, do not try and repair on

your own.There would be the danger of re or electric shock.

Call the nearest service centre (see list of service centres).

TECHNICAL CHARACTERISTICS

Power supply See rating plate

Absorbed power “

5710910471_01_1219

De’Longhi Appliances via Seitz, 47 31100 Treviso Italia www.delonghi.com

Proudly distributed by

De’Longhi Australia Pty Limited

P.O. BOX 4540

CASULA MALL NSW 2170

Customer Service Ph: 1800 126 659

Fax: 1800 706932

www.delonghi.com.au

e-mail: info[email protected]

De’Longhi New Zealand Limited

99 Khyber Pass Road

Grafton 1023

Auckland, New Zealand

P.O. Box 58-056 Botany

MANUKAU 2163

Customer Service Ph: 0508 200 300

Fax: 0508 200 301

www.delonghi.co.nz

e-mail: info[email protected]

Tabla de contenidos

Otros manuales de Calentador de DeLonghi

DeLonghi

DeLonghi Electric oil filled radiator Manual de usuario

DeLonghi

DeLonghi DCH4120 Manual de usuario

DeLonghi

DeLonghi DCH5090EL Manual de usuario

DeLonghi

DeLonghi HMH 550R Manual de usuario

DeLonghi

DeLonghi Electric oil filled radiator Manual de usuario

DeLonghi

DeLonghi HX65L22 Manual de usuario

DeLonghi

DeLonghi TRD4 Manual de usuario

DeLonghi

DeLonghi TRD0715T Manual de instrucciones de instalación

DeLonghi

DeLonghi HVA1120 Manual de usuario

DeLonghi

DeLonghi BBH200 Manual de usuario

DeLonghi

DeLonghi ELECTRIC PANEL HEATER Manual de usuario

DeLonghi

DeLonghi FAN HEATER Manual de usuario

DeLonghi

DeLonghi TRH0715ECA Manual de usuario

DeLonghi

DeLonghi RADIANT LPG GAS HEATER Guía rápida

DeLonghi

DeLonghi HCA324FS Manual de usuario

DeLonghi

DeLonghi TRRS0715E Manual de usuario

DeLonghi

DeLonghi DR18TQP Manual de instrucciones de instalación

DeLonghi

DeLonghi Dragon HM3 Manual de usuario

DeLonghi

DeLonghi HOR KH770715CB Manual de usuario

DeLonghi

DeLonghi DR 18TTW Manual de usuario

DeLonghi

DeLonghi HM24 Manual de instrucciones de instalación

DeLonghi

DeLonghi HCX Series Manual de usuario

DeLonghi

DeLonghi HTN Series Manual de usuario

DeLonghi

DeLonghi HSX4324E Manual de usuario

Manuales populares de Calentador de otras marcas

oventrop

oventrop Regucor Series Manual de usuario

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manual de usuario

ELMEKO

ELMEKO ML 150 Manual de usuario

BN Thermic

BN Thermic 830T Manual de usuario

KING

KING K Series Guía

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guía de inicio rápido

Well Straler

Well Straler RC-16B Manual de usuario

EUROM

EUROM 333299 Manual de usuario

Heylo

Heylo K 170 Manual de usuario

Eterna

Eterna TR70W Manual de usuario

Clarke

Clarke GRH15 Manual de instrucciones

IRSAP

IRSAP The Radiator Company Ovali Manual de usuario

Empire Heating Systems

Empire Heating Systems WCC65 Manual de usuario

Wetekom

Wetekom 92 86 43 Manual de usuario

Desa

Desa SPC170-F Manual de usuario

Watlow

Watlow Watrod Electric Tubular Heaters Manual de usuario

Haverland

Haverland ECO-DRY GPS Series Manual de lista de piezas

Stelpro

Stelpro ASILVC2060 Series Manual de usuario
