instructions

CERAMIC FAN HEATER

DCH1030

Please retain these instructions for future reference

DCH1030 2

Mode selector On light Thermostat

Thank you for choosing this De’Longhi heater. To get the

very best out of your new heater it is advisable to read

these instructions before using it.This will ensure that you

gain optimum results and use the appliance safely.

Electrical connection

- Before plugging the appliance into the mains, check that your

supply voltage is the same as that shown on the rating plate of

the appliance.

-If using more than one appliance at a time, it is important to

ensure that the ring main is adequate to cope with the power

requirements.

- It is important to ensure that the socket is adequately earthed.

- This appliance complies with EEC directive 89/336 regarding

electromagnetic compatibility.

INSTALLATION

The appliance can be used on any horizontal surface.

Do not overload the electrical circuit. Avoid using the same socket

for other appliances.

OPERATION AND USE

1. Make sure the appliance is off before plugging into the mains

2. Turn the appliance on by placing the thermostat in the Max position

and the mode selector in one of the following positions: 1/2.

-Summer mode (fan only): turn the mode selector to the

position.

-Minimum mode: turn the mode selector to the "1" position.

The red light comes on.

- Maximum mode: turn the mode selector to the "2" position.

- To turn the appliance off: turn the mode selector to the "●"

position.

Adjusting the thermostat

When the room has reached the required temperature, turn the

thermostat slowly until the red light goes off and no further.

The thermostat will then keep room temperature at the selected

level automatically.

Frost prevention mode

With the thermostat dial at minimum and the mode selector on

"2", the appliance maintains room temperature at about 5°C, pre-

venting freezing with minimal energy consumption.

DCH1030

Cleaning and maintenance

The heater should not required any maintenance. However before

attempting to clean the heater, remove the plug from the power

socket and allow the heater to cool. After the heater has cooled,

clean it with a soft damp cloth, do not use detergents or abrasives.

Periodically clean the air intake and outlet grilles during the period

in which the heater is in use with a vacuum cleaner. Should the

heater not be in use for a length of time, store it in a dry place.This

appliance has been built to provide many years of trouble free serv-

ice.

In case of malfunction, do not try to repair the heater yourself: it may

result in fire hazard or electric shock.

Warnings

-Do not use the heater in a bathroom or in the vicinity of bath-

tubs, wash basins, showers or swimming pools.

- Never use the heater to dry laundry.

-Only use the heater in an upright position.

-The heater must be positioned at least 50cm from walls, curtains,

furniture or other objects.

-If the supply cord is damaged, it must be replaced by the manu-

facturer, its service agent or similarly qualified persons in order

to avoid a hazard.

-Do not use this appliance in rooms which have a floor area small-

er than 4m2as this may lead to overheating.

- The heater must never be placed immediately under a fixed mains

socket.

- Never obstruct the heaters intake and outlet grilles as this could

cause dangerous overheating.

- IMPORTANT: Never for any reason cover the appliance during

operation as this could lead to dangerous overheating.

- A safety device intervenes and turns the appliance off and the pilot

light will switch on in the event of overheating. To reactivate the

heater, remove the plug from the mains, allow the appliance to

cool (for about 10 minutes), remove the cause of the overheating

and then plug the appliance back into the mains and turn it back

on.

- The use of an extension lead is not recommended, however if it is

necessary then follow carefully the extension lead’s instructions,

and most importantly ensure that the extension lead is carefully

rated in accordance with the radiator being used and NEVER

overloaded.

- In order to avoid any danger caused by an accidental resetting of

the safety system, this appliance must not be powered through an

external timer.

DCH1030 4

- As with any electrical appliance, whilst the instructions aim to

cover as many eventualities as possible, caution and common

sense should be applied when operating your appliance, particu-

larly in the vicinity of young children.

WARNING: In order to avoid overheating, never under

any circumstances cover the appliances during operation, as

this would lead to dangerous overheating.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL

OF THE PRODUCT IN ACCORDANCE WITH EC

DIRECTIVE 2002/96/EC.

At the end of its working life, the product must not be

disposed of as urban waste. It must be taken to a special

local authority differentiated waste collection centre or

to a dealer providing this service. Disposing of a house-

hold appliance separately avoids possible negative conse-

quences for the environment and health deriving from

inappropriate disposal and enables the constituent mate-

rials to be recovered to obtain significant savings in

energy and resources. As a reminder of the need to dis-

pose of household appliances separately, the product is

marked with a crossed-out wheeled dustbin.

DCH1030

DCH1030 6

Electrical requirements

Before using this appliance ensure that the voltage indicated

on the product corresponds with the main voltage in your

home, if you are in any doubt about your supply contact your

local electricity company.

The flexible mains lead is supplied connected to a B.S. 1363 fused plug

having a fuse of 13 amp capacity. Should this plug not fit the socket out-

lets in your home, it should be cut off and replaced with a suitable plug,

following the procedure outlined below.

Note: Such a plug cannot be used for any other appliance and should

therefore be properly disposed of and not left where children might find

it and plug it into a supply socket - with the obvious consequent danger.

N.B. We recommend the use of good quality plugs and wall sockets that

can be switched off when the machine is not in use.

important: the wires in the mains lead fitted to this appliance are

coloured in accordance with the following code:

As the colours of the wires in the mains lead of this appliance may not

correspond with the coloured markings identifying the terminals in your

plug, proceed as follows:

The wire which is coloured green and yellow must be connected to the

terminal in the plug which is marked with the letter E or by the earth

symbol or coloured green or green and yellow.

The wire which is coloured blue must be connected to the terminal

which is marked with the letter N or coloured black.

The wire which is coloured brown must be connected to the terminal

which is marked with the letter L or coloured red.

When wiring the plug, ensure that all strands of wire are securely

retained in each terminal. Do not forget to tighten the mains lead clamp

on the plug. If your electricity supply point has only two pin socket out-

lets, or if you are in doubt, consult a qualified electrician.

Should the mains lead ever require replacement, it is essential that this

operation be carried out by a qualified electrician and should only be

replaced with a flexible cord of the same size.

After replacement of a fuse in the plug, the fuse cover must be refitted.

If the fuse cover is lost, the plug must not be used until a replacement

cover is obtained. The colour of the correct replacement fuse cover is

that of the coloured insert in the base of the fuse recess or elsewhere

on the plug. Always state this colour when ordering a replacement fuse

cover.

Only 13amp replacement fuses which are asta approved to B.S. 1362

should be fitted.

This appliance conforms to the Norms EN 55014 regarding the sup-

pression of radio interference.

GREEN ANDYELLOW

BLUE

BROWN

EARTH

NEUTRAL

LIVE

Green and Yellow to Earth

Blue to

Neutral

13 amp

Fuse

Brown

to Live

Cord Clamp

Warning - this appliance

must be earthed

514IDL/03.06
