USER MANUAL

MELODY 3

OVERVIEW........................................3

PRODUCTRANGE................................4-5

FIRST USE.........................................6

PREPARING A BEVERAGE.............................7

RECOMMENDATIONS FOR A SAFE USE / ECONOMY MODE .8

CLEANING........................................9

DESCALING AT LEAST EVERY 3-4 MONTHS............12-13

IF NO LIQUID COMES OUT... . . . . . . . . . . . . . . . . . . . . . . . 10-11

TROUBLESHOOTING.............................14-15

SAFETY PRECAUTIONS..............................16

TABLE OF CONTENTS

OVERVIEW

1.3 l 5-45 °C

41-113 °F

~3 kg

A = 20.0 cm

230 V / 50 Hz / max. 1500 W

max. 15 bar

NO, SE, FI, DK, ES, IT, CH, UK, DE

B = 30.4 cm

C = 31.5 cm

1 4 7 10

2 5 8 11

3 6 9

Water tank

Hot

Cold

Selection lever

Locking handle

Power button Capsule bin

Stop Capsule holder Drip tray

Drip grid

17/23mm

17/18mm

17/23mm

0-12

OFF

STOP

3 4 5

PRODUCT RANGE

Espresso

Espresso Intenso

60 ml

Espresso Ristretto

40 ml

Latte Macchiato

220 ml

50 ml

170 ml

Espresso Intenso

40 ml

Cappuccino

240 ml

40 ml200 ml

Lungo

120 ml

Chococino®

210 ml

110 ml

100 ml

Hot Beverage

ESPRESSO

LUNGO

CAPPUCCINO

Espresso

Espresso Intenso

60 ml

Espresso Ristretto

40 ml

Latte Macchiato

220 ml

50 ml

170 ml

Espresso Intenso

40 ml

Cappuccino

240 ml

40 ml200 ml

Lungo

120 ml

Chococino®

210 ml

110 ml

100 ml

Espresso

Espresso Intenso

60 ml

Espresso Ristretto

40 ml

Latte Macchiato

220 ml

50 ml

170 ml

Espresso Intenso

40 ml

Cappuccino

240 ml

40 ml200 ml

Lungo

120 ml

Chococino®

210 ml

110 ml

100 ml

Espresso

Espresso Intenso

60 ml

Espresso Ristretto

40 ml

Latte Macchiato

220 ml

50 ml

170 ml

Espresso Intenso

40 ml

Cappuccino

240 ml

40 ml200 ml

Lungo

120 ml

Chococino®

210 ml

110 ml

100 ml

CHOCOCINO

PRODUCT RANGE

LATTE MACCHIATO

AROMA / GRANDE CAFFÈ CREMA

CAPPUCCINO ICE

Latte Macchiato

220 ml

50 ml

170 ml

Aroma

200 ml

GrandeCaﬀèCrema

200 ml

Aroma

200 ml

Latte Macchiato

220 ml

50 ml

170 ml

Aroma

200 ml

CaﬀèCremaGrande

200 ml

Aroma

200 ml

CappuccinoIce

240 ml

105 ml135 ml

Latte Macchiato

220 ml

50 ml

170 ml

Aroma

200 ml

GrandeCaﬀèCrema

200 ml

Aroma

200 ml

Cold Beverage

FIRST USE

STOP

Rinse water tank at rst.

Fill water tank with fresh, drinking water. Place

cap and insert water tank to machine.

Switch machine on. Power button starts

blinking red while machine is heating up for

approx. 30 seconds. Afterwards power button

lights steady green and machine is ready.

30 sec

Push selection lever to the “HOT” position.

Machine starts rinsing.

Open locking handle and insert empty capsule

holder. Close locking handle.

Place capsule bin under outlet.

Push selection lever to the “COLD” position.

Machine starts rinsing.

After approx. 60 seconds push selection lever

to the “STOP” position. Empty capsule bin and

rell water tank with fresh, drinking water.

Make sure that the selection lever is in “STOP”

position. Then plug the power plug into a

mains power socket.

After approx. 60 seconds push selection lever

to the “STOP” position. Machine stops rins-

ing and power button blinks red for about 5

seconds.

Remove protection foil from drip grid. Place

drip grid on drip tray. Then insert drip tray at

desired position of machine.

~60 sec

PREPARING A BEVERAGE

STOP

Push selection lever to the “HOT” position.

Beverage preparation starts.

Take cup from drip tray. Open locking handle.

Adjust drip tray position according to the

chosen beverage (see page 4-5). Place cup on

drip tray.

After reaching the desired level push selection

lever to the “STOP” position. Machine stops

preparation.

Pull out capsule holder and remove used cap-

sule. Put used capsule in capsule bin.

Open locking handle and pull out capsule

holder. Insert capsule in capsule holder and

insert it back in machine. Close locking handle.

After nishing preparation the power button

blinks red for about 5 seconds. During that

time do not open locking handle!

Rinse and dry capsule holder with water from

both sides. Insert capsule holder to machine.

Enjoy your beverage!

Switch machine on. Power button starts

blinking red while machine is heating up for

approx. 30 seconds. Afterwards power button

lights steady green and machine is ready.

30 sec

5 sec

Never ll hot water into the water tank! Never open the locking handle during

beverage preparation!

After nishing preparation the power

button blinks red for about 5 seconds.

During that time do not open locking

handle!

ECONOMY MODE

RECOMMENDATIONS FOR A SAFE USE

Never push selection lever while locking

handle is opened!

Do not touch used capsule after

beverage preparation! Hot surface, risk

of burns!

5 sec

After 5 minutes of non-usage the machine

automatically shuts down (Economy Mode).

5 min

ON OFF

CLEANING

Rinse drip tray with water and clean it with a

brush. You can also put it in a dishwasher.

Rinse and dry capsule holder with water from

both sides. You can also put it in a dishwasher.

Rinse and clean water tank. Afterwards rell

with fresh, drinking water and insert it to ma-

chine. The water tank is not dishwasher proof!

Switch machine on. Power button starts

blinking red while machine is heating up for

approx. 30 seconds. Afterwards power button

lights steady green and machine is ready.

30 sec

Place drip grid on drip tray. Then insert drip

tray at desired position of machine. Clean ma-

chine with a soft damp cloth. Dry it afterwards

with a soft dry cloth.

Open locking handle and insert empty capsule

holder. Close locking handle and place cap-

sule bin.

STOP

After approx. 10 seconds push selection lever

to the “STOP” position. Empty and clean cap-

sule bin. You can also put it in a dishwasher.

Push selection lever to the “HOT” position.

Machine starts rinsing.

~10 sec

IF NO LIQUID COMES OUT...

STOP

Turn selection lever to neutral position.No liquid comes out and the machine makes

a loud noise.

The capsule may be blocked and under pres-

sure.

Then lift the locking handle and remove the

capsule holder.

Check if there is water in the water tank: if not,

rell and move lever again to hot/cold posi-

tion to continue preparation; if yes proceed as

follows:

Do not use force to lift the locking handle.

Throw away the capsule.

Wait for 20 minutes to reduce the pressure.

20 min

Check if locking handle can be lifted easily: NO - see section A (below) / YES – see section B (next page)
