Dell N2128PX-ON Manual de usuario

Dell Networking

N2128PX-ON/N3132PX-ON

Switches

Getting Started Guide

Guide de mise en route

Guia de Noções Básicas

Guía de introducción

Regulatory Model: N2128PX-ON/

N3132PX-ON

Regulatory Type: E05W003/E06W003

Dell Networking

N2128PX-ON/N3132PX-ON

Switches

Getting Started Guide

Regulatory Models: N2128PX-ON/

N3132PX-ON

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of

your switch.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of

data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

____________________

Dell™ and the Dell logo are trademarks of Dell Inc. in the United States and/or other jurisdictions.

All other marks and names mentioned herein may be trademarks of their respective companies.

Regulatory Models N2128PX-ON/N3132PX-ON

April 2016 P/N 1VT9M Rev. A00

Contents 3

Contents

1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . 7

N2128PX-ON Hardware Overview. . . . . . . . . . . . . 7

Power Consumption for N2128PX-ON

PoE Switches . . . . . . . . . . . . . . . . . . . . . 7

N2128PX-ON Model Summary. . . . . . . . . . . . . . . 8

2 N2128PX-ON Installation . . . . . . . . . . . . . . 9

Rack Mounting an N2128PX-ON Switch . . . . . . . . . 9

Installing in a Rack . . . . . . . . . . . . . . . . . . 9

Installing as a Free-standing Switch . . . . . . . . 10

Stacking Multiple N2128PX-ON Switches . . . . . . . 10

3 Starting and Configuring the

N2128PX-ON Switch . . . . . . . . . . . . . . . . 11

Connecting an N2128PX-ON Switch to a Terminal . . . 12

Connecting an N2128PX-ON Switch to a

Power Source . . . . . . . . . . . . . . . . . . . . . . 13

AC and DC Power Connection . . . . . . . . . . . 13

Booting the N2128PX-ON Switch . . . . . . . . . . . . 14

4Contents

Performing the N2128PX-ON Initial Configuration . . . 15

Enabling Remote Management. . . . . . . . . . . 15

Initial Configuration Procedure . . . . . . . . . . . 16

Example Session . . . . . . . . . . . . . . . . . . 17

Dell Easy Setup Wizard Console Example . . . . . 18

Next Steps . . . . . . . . . . . . . . . . . . . . . 22

4 N3132PX-ON Hardware Overview . . . . . 24

Power Consumption for N3132PX-ON PoE Switches . . . 24

Ventilation System . . . . . . . . . . . . . . . . . 26

N3132PX-ON Model Summary . . . . . . . . . . . . . . 27

5 N3132PX-ON Installation . . . . . . . . . . . . 28

Rack Mounting a N3132PX-ON Switch . . . . . . . . . 28

Rack Mounting Safety Considerations . . . . . . . 28

Installing the Dell ReadyRail System . . . . . . . . 29

Installing as a Free-standing Switch . . . . . . . . 33

Stacking Multiple N3132PX-ON Switches . . . . . . . 33

6 Starting and Configuring the

N3132PX-ON Switch . . . . . . . . . . . . . . . . 34

Connecting an N3132PX-ON Switch to a Terminal . . . 35

Connecting an N3132PX-ON Switch to a

Power Source . . . . . . . . . . . . . . . . . . . . . . 36

AC and DC Power Connection . . . . . . . . . . . 37

Booting the N3132PX-ON Switch . . . . . . . . . . . . 37

Contents 5

Performing the N3132PX-ON Initial Configuration . . . 38

Enabling Remote Management. . . . . . . . . . . 38

Initial Configuration Procedure. . . . . . . . . . . 39

Example Session . . . . . . . . . . . . . . . . . . 40

Dell Easy Setup Wizard Console Example . . . . . 41

Next Steps . . . . . . . . . . . . . . . . . . . . . 45

7 NOM Information (Mexico Only) . . . . . . . 47

6Contents

Getting Started Guide 7

Introduction

This document provides basic information about the Dell®Networking

N2128PX-ON/N3132PX-ON switches, including how to install a switch and

perform the initial configuration. For information about how to configure and

monitor switch features, refer to the User Configuration Guide, which is

available on the Dell Support website at dell.com/support, for the latest

updates on documentation and firmware.

NOTE: Switch administrators are strongly advised to maintain Dell Networking

switches on the latest version of the Dell Networking Operating System (DNOS).

Dell Networking continually improves the features and functions of DNOS based on

feedback from you, the customer. For critical infrastructure, pre-staging of the new

release into a non-critical portion of the network is recommended to verify network

configuration and operation with the new DNOS version.

N2128PX-ON Hardware Overview

This section contains information about device characteristics and modular

hardware configurations for the Dell Networking N2128PX-ON switch.

Power Consumption for N2128PX-ON PoE Switches

Table 1-1 describes the power consumption for N2128PX-ON PoE switches.

The system power consumption is 90 watt (W). The PoE power budget is

800W for the main power supply (PSU).

Table 1-1. Power Consumption for N2128PX-ON PoE Switches

Table 1-2 shows power consumption data for the PoE-enabled N2128PX-ON

switches operating from the Modular Power Supply (MPS) only. The PoE

power budget is 800W for MPS.

Model Input Voltage Power Supply

Configuration

Maximum Steady

Current

Consumption (A)

Maximum

Steady

Power (W)

N2128PX-ON 100V/60Hz Main PSU 9.73A 965.5W

110V/60Hz Main PSU 8.75A 960.4W

120V/60Hz Main PSU 8.03A 958.3W

220V/50Hz Main PSU 4.33A 931W

240V/50Hz Main PSU 3.97A 928.7W

8Getting Started Guide

Table 1-2. Power Consumption Data for N2128PX-ON Switches PoE (+ MPS)

Table 1-3 shows power consumption data for the PoE-enabled N2128PX-ON

switches. The PoE power budget is 1600W for the main power supply +

Modular Power Supply (MPS).

Table 1-3. Power Consumption for N2128PX-ON PoE Switches

N2128PX-ON Model Summary

Table 1-4. N2128PX-ON Switch Regulatory Numbers

Model Input

Voltage

Power Supply

Configuration

Maximum Steady

Current Consumption

(A)

Maximum

Steady

Power (W)

N2128PX-

ON 100V/60Hz MPS 9.92A 986.5W

110V/60Hz MPS 8.93A 975.7W

120V/60Hz MPS 8.01A 955.4W

220V/50Hz MPS 4.44A 945.4W

240V/50Hz MPS 4.08A 951.4W

Model Input Voltage Power Supply

Configuration

Maximum Steady

Current

Consumption (A)

Maximum

Steady

Power (W)

N2128PX-ON 100V/60Hz Main PSU + MPS 11.83A 1175W

110V/60Hz Main PSU + MPS 10.71A 1169W

120V/60Hz Main PSU + MPS 9.84A 1168.9W

220V/50Hz Main PSU + MPS 5.4A 1138.4W

240V/50Hz Main PSU + MPS 5.93A 1141W

Marketing

Model

Name

(MMN)

Description PowerSupply

Unit (PSU)

Regulatory

Model

Number

(RMN)

Regulatory

Type

Number

(RTN)

N2128PX-

ON 24x1G/4x2.5G/2x10G

SFP+/2xStacking/24x

PoE+/4xPoE 60W Ports

1000W E05W E05W003
