Dell C Series Manual de usuario

Dell Networking

C-Series Systems

Quick Start Guide

Regulatory Model: C7004/C7008

Dell Networking

C-Series Systems

Quick Start Guide

Regulatory Model:C7004/C7008

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use

of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of

data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

If you purchased a Dell Series computer, any references in this publication to

Microsoft

Windows operating systems are not applicable.

____________________

Information in this publication is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the writtenpermissionof Dell Inc.

is strictly forbidden.

United States and/or other jurisdictions. All other marks and names mentioned herein may be

trademarks of their respective companies.

Regulatory Model: C7004/C7008

2014 - 01 P/N 0JVTD9 Rev. A02

About this Guide 3

About this Guide

This document is intended as a Quick Start Guide to get new systems up and

running and ready for configuration. For complete installation and configuration

information, refer to the following documents:

Documentation C7004/C150 C7008/C300

Hardware installation and

power-up instructions Installing and Maintaining

the C7004/C150 System Installing and Maintaining

the C7008/C300 System

Software configuration Dell Networking OS

Configuration Guide Dell Networking OS

Configuration Guide

Command line interface Dell Networking OS

Command Line Reference

Guide

Dell Networking OS

Command Line Reference

Guide

Latest updates Dell Networking OS

Release Notes for C-Series Dell Networking OS

Release Notes for C-Series

Installing the Hardware 5

Installing the Hardware

This guide assumes all site preparation has been performed before installing the

chassis.

Installing the Chassis

To install the C7004/C150 and the C7008/C300 chassis, Dell Networking

recommends completing the installation procedures in the order presented

below.

NOTE: Unless stated otherwise, the installation instructions apply to both the

C7004/C150 and C7008/C300 chassis.

Always handle the system and its components with care. Avoid dropping the

switch or its field replaceable units (FRUs).

CAUTION: Always wear an electrostatic discharge (ESD)-preventive wrist or

heel ground strap when handling the chassis and its components. As with all

electrical devices of this type, take all necessary safety precautions to prevent

injury when installing this system. ESD damage can occur if components are

mishandled.

Installing the Chassis in a Two-Post Rack

WARNING: Use an equipment lift or pallet jack when lifting or moving the

chassis. Install the chassis into the rack before inserting chassis components.

Lift the chassis only from the bottom. Lifting by the chassis shelves or power

supply openings might damage the chassis.

WARNING: To prevent bodily injury when mounting or servicing this unit in

a rack, take special precautions to ensure that the system remains stable. The

following guidelines are provided to ensure your safety:

• Mount this unit at the bottom of the rack if it is the only unit in the rack.

• When mounting this unit in a partially filled rack, load the rack from the

bottom to the top with the heaviest component at the bottom of the rack.

• If the rack is provided with stabilizing devices, install the stabilizers

before mounting or servicing the unit in the rack.

6Installing the Hardware

Follow these steps to install the chassis into a 19-inch equipment rack:

Step Task

1Determine the chassis mounting location in the equipment rack.

2Orient the bar with the arrows pointing upward. The smooth side of the

bar should face outward.

3Attach the bar to the equipment rack brackets using the mounting screws

provided by the rack manufacturer.

4Use an equipment lift to align the chassis rack-mount holes with the

equipment rack holes, and situate the chassis on top of the equipment

rack bar.

Installing the Hardware 7

5Insert screws (provided with your rack) through the chassis rack-

mounting bracket and into the equipment rack, and tighten them.

Rack Mounting the C7004/C150 Chassis

Rack Mounting the C7008/C300 Chassis

Step Task

8Installing the Hardware

Installing Power Modules

CAUTION: Do not install the Power Supply 1200W-AC and Power Supply

1600W-AC in the same chassis. The line cards will power down and data may

be lost.

If there is a failure in the power supply, you must replace it. Power supplies are

not field serviceable.

The C7004/C150 has six power supply slots at the front-bottom of the chassis.

The C7008/C300 has eight power supply slots at the front-bottom of the chassis.

The slots accept either the 1200W or 1600W AC power supply units (PSUs).

AC Power Supplies

•

There are two types of power supplies: Power Supply 1200W-AC and Power

Supply 1600W-AC. The minimum and redundant power supplies required to

operate are listed in the table below. Dell Networking recommends the

redundancy configuration.

• The following table lists the PSU requirements for Dell Networking OS

version 8.4.5.0 or prior. 1600W-AC PSU is recognized by version 8.4.5.0 or

later.

Voltage Minimum

PSUs Minimum with

Redundant

PSUs

C7004/C150 Power Supply 1200W-

AC/Power Supply

1600W-AC

100-120 Configuration

Dependent Configuration

Dependent

200-240 Configuration

Dependent Configuration

Dependent

C7008/C300 Power Supply 1200W-

AC/Power Supply

1600W-AC

100-120 Configuration

Dependent Configuration

Dependent

Power Supply 1200W-AC 200-240 Configuration

Dependent Configuration

Dependent

Power Supply 1600W-AC 200-240 Configuration

Dependent Configuration

Dependent

Installing the Hardware 9

For Dell Networking OS version 8.4.6.0, the minimum PSUs required for system power is based on

the power requirements of the RPMs, the line cards, and the type of fan tray present in the chassis.

System Power Required = Power required for 2 RSMs + Power Required for Fan Tray + Power

required for Line cards in the system.

Number of PSUs Required for System Power = System Power Required /90% of PSU power

For power requirements corresponding to different components, refer to Installing and Maintain-

ing the C7004/C150 System and Installing and Maintaining the C7008/C300 System.

If N PSUs are required for system power, then N+1 th PSU is reserved for redundant system power.

For details corresponding to PoE power availability, refer to Power Over Ethernet section of Dell

Networking OS Configuration Guide.

• To protect against high-voltage shock, install a power supply blank on all

unused power supply slots.

• Connect the AC power supply to the appropriate branch circuit protection as

defined by local electrical codes.

• Verify that the remote power source complies with the system input power

specifications.

WARNING: Use only the AC power cord supplied with the AC power supply.

Do not supply power to your system until you install the power supplies, fan

tray, route processor modules (RPMs), and line cards.

WARNING: This product relies on the building's installation for short-circuit

(overcurrent) protection. Ensure you use a fuse or circuit breaker no larger

than 120 VAC, 15A U.S. (240 VAC, 10A international) on the phase conductors

(all current-carrying conductors).

WARNING: The C7008/C300 does not have a main disconnect device

installed. It is the responsibility of the installer to provide a suitable

disconnecting device in the building installation and ensure that it is

located/installed near the equipment and is easily accessible.

WARNING: Do not install the Power Supply 1200W-AC and Power Supply

1600W-AC in the same chassis. The line cards will power down and data may

be lost.

10 Installing the Hardware

WARNING: The C7008/C300 and C7004/C150 operates in either of two

voltage ranges. The different power supplyconfiguration supported is listed in

the following table. As a safety precaution, do not install more than the

recommended maximum number of PSUs (shown below), as this causes high

leakage current. Install blank panels in all unused PSU slots.

NOTE: The higher power of power over Ethernet plus (PoE+) (30W/port) is

available only with Power Supply 1600W-AC and the PoE+ line card. When using

the PoE line card or PoE+ line card and the Power Supply 1200W-AC, only

15.4W/port power is available. The maximum power per port is listed in the

following table.

Voltage Frequency Maximum PSUs

C7004/C150 100-120 50/60Hz 5 primary + 1 redundant

200-240 50/60Hz 5 primary + 1 redundant

C7008/C300 100-120 50/60Hz 7 primary + 1 redundant

200-240 50/60Hz 7 primary + 1 redundant

Step Task

1Verify the power switch is in the OFF (left) position.

2Secure the retaining latch in the unlatched position by tightening the

screw into the threaded hole.

3Slide the power supply into the top left-most power supply slot.

Dell Networking recommends installing power supplies starting from

the left side, top row of the chassis, leaving no blank slots between units.

4Lower the retaining latch, and tighten it into place.

5Plug the AC power cord into the power receptacle in the face of the

power supply.

6Plug the power cord into an AC power outlet.

Power Supply

1200W-AC Power Supply

1600W-AC at

lowline (100-120V)

Power Supply

1600W-AC at

highline (200-240V)

PoE line card 15.4W/port 15.4W/port 15.4W/port

PoE+ line card 15.4W/port 30W/port 30W/port
