Dell PowerEdge UPS 500T Manual de usuario

DelltTower External Battery Module

for use with

1000W and 1920/1500W

UPS models

Getting Started With

Your System

Démarrage avec votre système

Erste Schritte Mit Ihrem System

Начало работы c вашей системой

Inicio de su sistema



사용자의 시스템 시작하

はじめにシステムについて

K788N, H914N, J716N, K789N

K806N, H965N

w w w . d e l l . c o m | s u p p o r t . d e l l . c o m

DelltTower External Battery Module

for use with

1000W and 1920/1500W

UPS models

Getting Started

With Your System

K788N, H914N, J716N, K789N

K806N, H965N

w w w . d e l l . c o m | s u p p o r t . d e l l . c o m

Notes and Warnings

NOTE: A NOTE indicates important information that helps you make better use of your software.

CAUTION: A CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or

moderate injury or in property damage incidents.

WARNING: A WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or

injury.

DANGER: A DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or

serious injury.

DANGER: Observe the following instruction to help prevent an imminently hazardous situation which, if not

avoided, will result in death or serious injury:

SThis UPS contains LETHAL VOLTAGES. All repairs and service should be performed by

AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS

inside the UPS.

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their

products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

6/2012 • 164201813 2

Finding Information |

Finding Information

CAUTION: The Safety, Environmental, and Regulatory Information document provides important safety and

regulatory information.

What are You Looking For? Find It Here

SThe user's guide for my UPS

SThe user's guide for the Dell Network Management

Card

SDell UPS Management Software

NOTE: Documentation and software updates can be

found at support.dell.com.

Dell UPS Disc

SSpecifications

SHow to configure UPS settings

SHow to troubleshoot and solve problems

Dell UPS User's Guide

The user's guide is available on the Dell UPS disc and

on support.dell.com.

SSafety instructions

SRegulatory information

SRecycling information

Safety, Environmental, and Regulatory Information

SWarranty information

STerms and Conditions (U.S. only)

SEnd User License Agreement

Dell Warranty and Support Information

SSupport information Dell Support Website — support.dell.com

NOTE: Select your region or business segment to view

the appropriate support site.

4|Installation

Installation

CAUTION: Before performing the procedures in this document, read and follow the safety instructions and

important regulatory information in your Safety, Environmental, and Regulatory Information document.

Unpacking the External Battery Module

1Unpack the External Battery Module (EBM).

Discard or recycle the packaging in a responsible manner, or store it for future use.

Installation |

Removing the Battery Connector Cover

NOTE: A small amount of arcing may occur when connecting an EBM to the UPS. This is normal and will not

harm personnel. Insert the EBM cable into the UPS battery connector quickly and firmly.

NOTE: If the UPS is stored or used without an EBM, the battery connector cover must be installed as a safety

precaution.

2Remove the battery connector cover from the rear panel. Retain the cover and screws.

Installing the Strain Relief Bracket

6|Installation

3Install the battery connector cover under the EBM cable to provide strain relief.

Rotate the battery connector cover on its side and position under the EBM cable.

Connecting the EBM Cable

4Plug the EBM cable into the UPS battery connector.

5Secure the battery connector cover to the UPS rear panel using the screws removed in Step 2.

Configuring the UPS for an EBM

If the UPS is not configured for the EBM, the UPS reports less battery time remaining on the UPS front

panel and to any remote software. You may receive a shutdown warning prematurely. To ensure

maximum battery runtime when using power management software, configure the UPS for the EBM:

1Press the button for one second to go to the main menu selection and scroll down to the

Settings menu using the button.

2Press the button to enter the Settings menu.

3Use the button to scroll to the External Battery Module option and press the button.

The battery number value begins to flash.

Installation |

4Set the battery number value using the and buttons.

Configuration Setting

UPS only (internal batteries) 0 (default)

UPS + 1 EBM 1

NOTE: Runtime is automatically adjusted based on present load levels and whether an EBM is configured.

5Press the button to confirm.

CAUTION: Follow the instructions in the UPS Getting Started document or the Dell Line-Interactive Tower

UPS 500W, 1000W, and 1920/1500W User's Guide for instructions on installing the UPS.

8|Installation
