R330XL Honeywell Server Planning, Installation and

Service Guide

HWDOC-X452-en-D

August 2020

Disclaimer

This document contains Honeywell proprietary information. Information contained herein is to be used

solely for the purpose submitted, and no part of this document or its contents shall be reproduced,

published, or disclosed to a third party without the express permission of Honeywell International Sàrl.

While this information is presented in good faith and believed to be accurate, Honeywell disclaims the

implied warranties of merchantability and fitness for a purpose and makes no express warranties

except as may be stated in its written agreement with and for its customer.

In no event is Honeywell liable to anyone for any direct, special, or consequential damages. The

information and specifications in this document are subject to change without notice.

- 2 -

Contents 3

Chapter 1 - About this Document 6

Chapter 2 - Planning 9

2.1 Overview 9

2.1.1 Software requirement 9

2.1.2 BIOS configuration 10

2.2 Description 10

2.2.1 Honeywell server model number 10

2.2.2 Electronics configuration 10

2.2.3 Electronics module 10

2.2.4 Standard features of Dell R330XL 11

2.2.5 Slots configuration 11

2.2.6 Optional features 11

2.2.7 Power cords 12

2.3 Platform information 12

2.3.1 Honeywell documentation 12

2.3.2 Dell documentation 12

2.4 LCN node slot requirements 14

2.5 Experion nodes slot requirement 14

2.5.1 FTE supervisory (Default) 14

2.5.2 Cnet configuration using PCIC interface 14

2.6 Memory configuration for Dell R330XL 14

2.6.1 8GB, consisting of two 4GB ECC DDR4 UDIMM for Dell PowerEdge R330XL

server servers 15

2.6.2 16GB, consisting of two 4GB ECC DDR4 UDIMM for Dell PowerEdge R330XL

server servers 15

2.6.3 16GB,Consisting of two 8GB ECC DDR4 UDIMM for Dell PowerEdge R330XL

server servers 15

2.6.4 32GB, Consisting of four 8GB ECC DDR4 UDIMM for Dell PowerEdge R330XL

server servers 16

2.7 System specifications 16

2.7.1 Hard disk drive specifications 22

2.7.2 Removable media specifications 22

2.7.3 Storage and media devices 22

2.7.4 Mouse and keyboard 22

2.7.5 Monitor 22

2.7.6 Video cable 23

2.8 Industrial regulatory compliance 23

- 3 -

2.8.1 Electromagnetic Compatibility 23

2.8.2 Safety compliance 24

2.9 Light industrial regulatory compliance 24

2.9.1 Electromagnetic Compatibility 24

2.9.2 Safety compliance 25

Chapter 3 - Installation 26

3.1 Tasks for installing the server 26

3.1.1 Before you begin 26

3.2 Power and grounding requirements 26

3.3 Cabinet spacing requirements 27

3.4 Installing the server and connecting the cables 28

3.4.1 Honeywell server back panel connections 28

3.4.2 Installing the server 28

3.4.3 Connecting the cables 29

3.4.4 Install air duct baffles and blank panel front covers in cabinet 30

3.5 Starting the server 32

3.5.1 Turning on the power 32

3.5.2 Configuring RAID in Dell R330XL server 32

Chapter 4 - Operation 34

4.1 Server overview 34

4.1.1 Front view of Dell R330XL server 34

4.1.2 Rear view of Dell R330XL server 35

4.2 Network connections 35

4.2.1 Ethernet network 35

4.2.2 ControlNet Network 35

4.3 Configuring ControlNet interface card 36

4.3.1 Installing ControlNet card inside Magma chassis 36

Chapter 5 - Servicing 38

5.1 Servicing the hard disk drives and power supply 38

5.2 Adding additional memory in Dell R330XL 39

5.3 Installing hot spare hard drive 41

5.4 Servicing Honeywell options 42

5.4.1 Slot requirements for General Ethernet and FTE node setup 43

5.5 Verifying correct BIOS settings 43

5.5.1 Entering the BIOS 43

- 4 -

5.5.2 To enter the BIOS 43

5.5.3 BIOS settings for Tab 51156061-100 and 51156061-200 43

5.6 Spare parts 50

5.7 Troubleshooting 50

- 5 -

ABOUT THIS DOCUMENT

This document contains installation and service information for the Dell PowerEdge R330XL server.

The instructions and service information contained here address the server itself, and assumes that the

associated network communication equipment has been pre-installed by the Honeywell factory or has

manuals dedicated to its installation and service. This server is not a standard Dell model and you

cannot order it independently from Dell.

NOTE

If the Local Control Network (LCN) coaxial based system has been integrated with an Experion

Fault Tolerant Ethernet (FTE) based system, the node (server) may be upgraded to be an

Experion Local Control Network (ELCN) node, which has its ELCN Interface provided via FTE.

This node may be installed as a physical or virtual platform.

If the node is upgraded to an ELCN node, and the node is a physical (a.k.a. bare-metal)

platform, a Local Control Network Processor (LCNP) board coaxial interface to LCN is not used.

The LCN MAU is disconnected, and/or the LCNP board is removed.

Redundant ELCN Bridges are required if the ELCN node is communicating with any other

existing, coaxial-based LCN node.

Some LCN nodes may have been replaced by their ELCN equivalent nodes, and overall system

features/architecture will differ from that of a non-ELCN integrated system (classic LCN/TPN

system). In this case it may be necessary to refer to appropriate ELCN documentation, in

addition to the information provided herein.

The following table lists Honeywell ELCN/Experion publications that may be useful for references.

ELCN Reference Documents Table for Server/Workstation PSIG Documents

Publication Content Type

Experion LCN Hardware

Upgrade Kit Instructions

(51195195-415)

UEA installation

Experion LCN Quick Start

Guide (EPDOC-X480-en-

510A)

General hardware/software/migration information

Experion Software Installation

User's Guide (EPDOC-X136-

en-510A)

Experion software installation (various methods)

Experion LCN Overview and

Implementation Guide

Bridge hardware installation, software configuration,

operation, servicing/troubleshooting

- 6 -

CHAPTER

Publication Content Type

(EPDOC-X478-en-510A)

Experion LCN Planning,

Installation, and Service Guide

(HWDOC-X479-en-E)

ELCN system planning, hardware/software

installation, servicing/troubleshooting

Experion LCN Specification

(ELCN03)

General ELCN technical specifications

Fault Tolerant Ethernet

Installation and Service Guide

(EPDOC-XX36-en510A)

FTE system installation, servicing/troubleshooting

Universal Embedded

Appliance Hardware

Installation and Maintenance

Guide (HWDOC-X469-en-A)

General UEA planning, installation, and service

information before it is commissioned as an ELCN

appliance.

Integrated Experion-TPS

User's Guide (EPDOC-XX66-

en-510A)

Supplementary installation tasks needed before

using TPS Nodes on an Experion system. Describes

configuration tasks needed for TPS Nodes.

Virtualization Planning and

Implementation Guide

(EPDOC-X147-en-A)

Implementing networks, Preparing ESXi host,

Administering virtualization

Server and Client Planning

Guide (EPDOC-X128-en-

510A)

High-level planning/design for Experion servers,

clients, controllers

Process Operations Manual

(SW11-601)

Process operations, alarm/message handling,

reporting, history functions, system operations,

system menu functions, console/station peripheral

devices

Integrated Experion-TPS

User's Guide (EPDOC-XX66-

en-510A)

Supplementary installation and configuration tasks

for Experion TPS Nodes

Experion PKS R510.1

Migration Planning Guide

(EPDOC-XX70-en-5101A)

Planning information for migration of Experion

system from legacy R4xx system software to

Experion R510.1 software.

Switch Configuration Tool

User's Guide

(EPDOC-X246-en-510A)

Experion switch configuration information

- 7 -

Chapter 1 - About this Document

Publication Content Type

Experion Network Best

Practices (WP-07-02-ENG)

Best practices for planning the installation of Experion

FTE networks, and connecting them into plant IT

networks.

Experion R510 Software

Change Notice (EPDOC-

X166-en-510A)

Describes Experion R510 features/enhancements,

overall product, release interoperabilities, system

dependencies, problem resolutions, known issues,

special considerations

Customer Release Guide

R687 (CRG-687)

TPN/TPS Migration information (ELCN migration

Information included)

TPN R687 Software Change

Notice (TNDOC-X166-en-

6871A)

Document changes, compatibility and

migration/installation processes for the TPS Process

Network Release of R687 software.

Experion Control Building

User's Guide (EPDOC-XX19-

en-510A)

Procedures for basic tasks in the Control Builder

application (configuring hardware devices,

continuous control strategies, sequential control

strategies).

1.1 Revision history

Version Date Description

August 2020

Initial release of the document.

- 8 -

PLANNING

lOverview

lDescription

lPlatform information

lLCN node slot requirements

lExperion nodes slot requirement

lMemory configuration for Dell R330XL

lSystem specifications

lIndustrial regulatory compliance

lLight industrial regulatory compliance

2.1 Overview

Platforms sold by Honeywell are engineered for the process control mission of Experion and TPS

systems to provide consistent and robust performance. Through an extensive qualification process,

Honeywell defines specific peripheral devices, slot locations, and BIOS settings for best performance

and reliability, sometimes even adding cooling fans for longer service. Honeywell platforms are then

built to Honeywell specifications by the computer manufacturer.

Honeywell engineering has tested theDell PowerEdge R330XL serverwith other Honeywell hardware

and software and has qualified its use for specific configuration items as identified in the Software

Change Notice (SCN). The server is not a standard Dell model and cannot be ordered independently

from Dell. The Technical Assistance Center (TAC) is well trained and supports Honeywell platforms.

Use of any other server including a similar Dell model, is considered a project special and its TAC

support is limited according to the services policy.

The Honeywell-based Dell PowerEdge R330XL server provides the functionality of a server-based PC

running the Microsoft Windows server operating systems.

The release of this server is based upon RAID-5 and dual power supply design to provide computer-

based functionality for certain Experion systems and the TPS systems.

The Dell PowerEdge R330XL servers are shipped with the Tab number 51156061-100 8GB base

memory model & its replaced by 51156061-200 (16GB base memory model).

lSoftware requirement

lBIOS configuration

2.1.1 Software requirement

The server runs on the following operating system.

lMicrosoft Windows Server 2008 R2 (64-bit) for EPKS R41x.x and R43x.x release.

lMicrosoft Windows Server 2016 for EPKS R50x.x release.

The server platform runs the latest version of the following Experion server.

- 9 -

CHAPTER

lESV

lACE/SCE

lEAS

leServer

2.1.2 BIOS configuration

The BIOS version for the server depends on the Tab numbers. The Tab number for Dell R330XL is as

follows

lTab 51156061-100 with BIOS Version 1.2.5 or later.

2.2 Description

lHoneywell server model number

lElectronics configuration

lElectronics module

lStandard features of Dell R330XL

lSlots configuration

lOptional features

lPower cords

2.2.1 Honeywell server model number

The following models have been defined for the Honeywell-based Dell R330XL server platforms.

Model number Description

MZ-PCSV62 Intel Xeon E3-1270 V5 3.6 GHz,8M Cache,8.00GT/s

QPI,Turbo,HT,/ 16Gb(UDIMM (2x8GB)) / 300GB 15K RPM Serial-

Attach SCSI 12Gbps 2.5in Hot plug Hard Drive (QTY 4)/ PERC

H730 RAID Controller, 1GB Cache (RAID 5 configuration)

MZ-PCEH08 300GB 2.5” 15K RPM SAS HDD to use as a Hot Spare( not

supplied with Standard configuration customer need to buy it if hot

spare is required)

EP-COAR28 Windows Server 2008 R2 COA

EP-COAS16 Microsoft Windows Server 2016 (32-bit) COA

2.2.2 Electronics configuration

The Dell R330XL-based server is approved for installation in the Honeywell 1000 mm deep LCN

cabinet only, using the Sliding ReadyRail II kit included in the purchase of the server.

2.2.3 Electronics module

The tables in this section provides the electronics module for the Honeywell-based Dell R330XL server

platforms.

- 10 -

Chapter 2 - Planning

Tabla de contenidos

Otros manuales de Servidor de Dell

Dell

Dell External OEMR XL R720XD Guía de inicio rápido

Dell

Dell EMC PowerEdge XE8545 Manual de usuario

Dell

Dell PowerEdge T20 Manual de usuario

Dell

Dell PowerEdge 1955 Manual de usuario

Dell

Dell PowerEdge 1950 Manual técnico

Dell

Dell PowerEdge T610 Manual de usuario

Dell

Dell Force10 MXL Blade Manual de usuario

Dell

Dell POWEREDGE 4300 Manual de usuario

Dell

Dell PowerEdge systems 6300 Manual de lista de piezas

Dell

Dell PowerEdge R300 Manual de usuario

Dell

Dell PowerEdge R730 Manual de usuario

Dell

Dell PowerEdge T710 Manual de usuario

Dell

Dell 100 Series Manual

Dell

Dell PowerEdge 6400 Manual de usuario

Dell

Dell PowerEdge Cluster FE100 Manual de usuario

Dell

Dell XC6320 Manual de usuario

Dell

Dell PowerEdge 6850 Manual técnico

Dell

Dell PowerEdge C5220 Guía de inicio rápido

Dell

Dell PowerEdge R905 Manual técnico

Dell

Dell External OEMR R710 Guía de inicio rápido

Dell

Dell PowerEdge 1850 Manual técnico

Dell

Dell PowerEdge C6105 Guía de inicio rápido

Dell

Dell PowerEdge 2650 Manual de usuario

Dell

Dell PowerEdge T430 Manual de usuario

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario

Planet

Planet NAS-7410 Manual de usuario

Lenovo

Lenovo ThinkSystem SR635 V3 Manual de usuario

Fujitsu

Fujitsu PRIMERGY BX900 Manual de usuario

Asus

Asus RS700DA-E6 PS4 Manual de usuario
