Information Update 3

This document provides updated information for your system on the following topics:

• Expansion-card slot restrictions

–Intel

PRO/1000 MT dual-port server adapter expansion-card slot 2 restriction

– Adaptec SCSI Card 39160 expansion-card slot restriction

• System start-up behavior

• Integrated NIC IPMI port functionality

• Remote Access Controller card interaction with integrated video

• System and status messages

– System screen messages

– LCD status messages

• IRQ5 availability

• Environmental data sheets

• Removing and installing a hot-pluggable memory riser card

• Hot-adding a memory riser card

• Processor upgrades

• Memory test at system startup

• Linux operating system information

– Booting Red Hat

Enterprise Linux AS (Version 4) for Intel x86 with more than eight logical

processors

– Using more than eight logical processors with Red Hat Enterprise Linux (Version 4)

for Intel Extended Memory 64 Technology (Intel EM64T)

– Rebooting Red Hat Enterprise Linux AS (Version 4) for Intel EM64T

– NIC device names

• Microsoft

Windows Server

™

2003 installation with more than eight logical processors

• Microsoft Windows

2000 installation

• Console redirection—escape key sequences

4Information Update

Expansion-Card Slot Restrictions

Intel PRO/1000 MT Dual-Port Server Adapter Expansion-Card Slot 2 Restriction

Do not install an Intel PRO/1000 MT dual-port server adapter card in expansion-card slot 2. Your

system’s expansion-card slot 2 is a hot-pluggable PCI-X connector, and the Intel PRO/1000 MT dual-port

server adapter card does not support hot-pluggable slot capabilities. If this adapter model is installed in

slot 2 and the AC power cord is disconnected from the system or if AC power is lost, the card is not

detected by BIOS when the system is turned on.

NOTE: Although the slot 2 indicator is green after the system is turned on following an AC power loss,

the Intel PRO/1000 MT dual-port server adapter card is not detected by BIOS.

This restriction does not apply to the Intel PRO/1000 MT single-port server adapter card.

Adaptec SCSI Card 39160 Expansion-Card Slot Restriction

If you add an Adaptec SCSI Card 39160 to a system running the Microsoft Windows 2000 Server

operating system, and a Dell™ Remote Access Controller 4/P (DRAC 4/P) card is installed in expansion-

card slot 7, the Adaptec 39160 card must be installed in expansion-card slot 2.

System Start-Up Behavior

The following system behaviors during system start-up are normal and do not indicate a problem with

the system:

• When AC power is applied to the system, if the System Setup program’s

AC Power Recovery

option is

not set to allow the system to power up when AC power is applied, the cooling fans will spin-up briefly

and then stop. (See your

User’s Guide

for information on the System Setup program.)

• It may take 30 seconds or longer for video to display after the system is powered on.

Integrated NIC IPMI Port Functionality

If you configure the integrated NIC for Intelligent Platform Management Interface (IPMI) pass-through

traffic, and you also configure the system to boot from the network using the same IPMI port, the NIC

will not be available for management traffic during system boot. After system boot is completed, IPMI

functionality is automatically restored.

In addition, if you configure the NIC to support IPMI management traffic, the NIC driver’s

Large-Send Offload (LSO) feature will be disabled on that port.

Remote Access Controller Card Interaction With Integrated Video

If you install an optional remote access controller card for remote systems management, the system’s

front and back panel video ports will be disabled.

Information Update 5

System and Status Messages

System Screen Messages

Table 1-1 provides an additional system message that your system may display on the screen.

See "System Messages" in your Installation and Troubleshooting Guide for information about

other system messages.

LCD Status Messages

Table 1-2 provides an updated list of system status messages that the system’s front-panel LCD may

display at system startup if a memory error occurs. See "System Messages" in your Installation

and Troubleshooting Guide for additional information about system messages.

Table 1-1. System Messages

Line 1

Message

Line 2

Message

Causes

E1000 FAIL SAFE Failsafe event.

Table 1-2. LCD Status Messages

Line 1

Message

Line 2

Message

Causes Corrective Actions

SYSTEM

SYSTEM NAME SYSTEM ID is a unique name,

five characters or less, defined

by the user.

SYSTEM NAME is a unique

name, 16 characters or less,

defined by the user.

The system ID and name display

under the following conditions:

• The system is powered on.

• The power is off and active

POST errors are displayed.

This message is for information

only.

You can change the system ID

and name in the System Setup

program. See your User's Guide

for instructions.

E0000 OVRFLW CHECK LOG LCD overflow message.

A maximum of three error

messages can display sequentially

on the LCD. The fourth message

displays as the standard overflow

message.

Check the SEL for details

on the events.

6Information Update

E1000 FAIL SAFE Failsafe event. Capture the event log and

see "Getting Help" in your

Installation and Troubleshooting

Guide.

E1000 MISCONFIG Missing or improperly installed

VRMs.

See "Installing a Processor VRM"

in your Installation

and Troubleshooting Guide. If the

VRMs appear to be properly

configured and installed, see

"Getting Help" in your

Installation and Troubleshooting

Guide.

E0119 TEMP AMBIENT Ambient system temperature is

out of acceptable range.

See "Troubleshooting System

Cooling Problems" in your

Installation and Troubleshooting

Guide.

E0119 TEMP PROC # The specified processor is out of

acceptable temperature range.

See "Troubleshooting System

Cooling Problems" in your

Installation and Troubleshooting

Guide.

E0119 TEMP PLANAR System board temperature is out

of acceptable temperature range.

See "Troubleshooting System

Cooling Problems" in your

Installation and Troubleshooting

Guide.

E0212 PROC VTT Processor VTT voltage is out

of acceptable voltage range.

See "Troubleshooting Power

Supplies" in your Installation

and Troubleshooting Guide.

E0212 VOLT PG nSystem power supply is out of

acceptable voltage range; faulty

or improperly installed power

supply.

See "Troubleshooting Power

Supplies" in your Installation

and Troubleshooting Guide.

E0212 VOLT PG nVideo Video voltage is out of acceptable

voltage range.

See "Getting Help" in your

Installation and Troubleshooting

Guide.

E0212 VOLT BATT ROMB Faulty RAID battery. Replace the RAID battery.

See "Activating the Optional

Integrated RAID Controller"

in your Installation

and Troubleshooting Guide.

Table 1-2. LCD Status Messages (continued)

Line 1

Message

Line 2

Message

Causes Corrective Actions

Information Update 7

E0212 VOLT BATT CMOS Faulty system battery. See "Troubleshooting the System

Battery" in your Installation

and Troubleshooting Guide. If the

problem persists, see "Getting

Help" in your Installation

and Troubleshooting Guide.

E0276 PROC # STATUS Faulty or improperly installed

processor.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide.

E0276 PROC # VCORE The VCORE voltage of the

specified processor is out of

acceptable range.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide. If the problem still

persists, see "Getting Help"

in your Installation

and Troubleshooting Guide.

E0276 VRM # PG The voltage of the specified VRM

is out of acceptable range.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide. If the problem still

persists, see "Getting Help"

in your Installation

and Troubleshooting Guide.

E0276 VCACHE # PG The voltage of the specified

VCACHE is out of acceptable

range.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide. If the problem still

persists, see "Getting Help"

in your Installation

and Troubleshooting Guide.

E0276 PS AC CURRENT Power supply AC current is out

of acceptable range.

See "Troubleshooting Power

Supplies" in your Installation

and Troubleshooting Guide.

E0276 PS OVER CURRENT Power supply current is out

of acceptable range.

See "Troubleshooting Power

Supplies" in your Installation

and Troubleshooting Guide.

Table 1-2. LCD Status Messages (continued)

Line 1

Message

Line 2

Message

Causes Corrective Actions

8Information Update

E0412 RPM FAN PS BLANK Power supply fan RPM is out

of acceptable range.

See "Troubleshooting System

Cooling Problems" in your

Installation and Troubleshooting

Guide.

E0412 RPM FAN n

FAN REDUNDANCY

LOST

Specified cooling fan is faulty,

improperly installed, or missing.

See "Troubleshooting System

Cooling Problems" in your

Installation and Troubleshooting

Guide.

E0780 PROC # CONFIG

ERR

The specified processor has a

configuration error.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide.

E0780 PROC # DISABLED The specified processor is

disabled.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide.

E0780 PROC nPRESENCE Microprocessor is not installed

in socket n.

Install a microprocessor in socket

n. See "Installing a Processor"

in your Installation

and Troubleshooting Guide.

E07F0 PROC nIERR Faulty or improperly installed

microprocessor.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide.

Table 1-2. LCD Status Messages (continued)

Line 1

Message

Line 2

Message

Causes Corrective Actions

Otros manuales para PowerEdge 6850

Tabla de contenidos

Idiomas:

Otros manuales de Servidor de Dell

Dell

Dell Poweredge el Manual de usuario

Dell

Dell PowerEdge 2650 Instrucciones de funcionamiento y seguridad

Dell

Dell EMC PowerEdge M640 Manual

Dell

Dell PowerEdge 6400 Manual de usuario

Dell

Dell PowerEdge SC420 Manual de lista de piezas

Dell

Dell PowerEdge Manual de usuario

Dell

Dell PowerEdge R210 II Manual de usuario

Dell

Dell PowerEdge T105 Systems Manual de usuario

Dell

Dell PowerEdge 4200 Series Manual de usuario

Dell

Dell PowerEdge T620 Manual de usuario

Dell

Dell PowerEdge R320 Manual de usuario

Dell

Dell PowerEdge R330 Manual de usuario

Dell

Dell PowerEdge T610 Manual de usuario

Dell

Dell PowerEdge MX760c Manual

Dell

Dell PowerEdge R620 Manual de usuario

Dell

Dell PowerEdge M710 Manual de usuario

Dell

Dell PowerEdge MP148 Manual de usuario

Dell

Dell HHB Manual de usuario

Dell

Dell PowerVault MD3200i Series Manual de usuario

Dell

Dell PowerEdge 1955 Manual de usuario

Dell

Dell PowerEdge C6220 Manual de usuario

Dell

Dell EMC XC Core XC7525 Manual

Dell

Dell PowerEdge R610 Instrucciones de montaje

Dell

Dell PowerEdge PDU Managed LED Manual de usuario

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario

Planet

Planet NAS-7410 Manual de usuario

Lenovo

Lenovo ThinkSystem SR635 V3 Manual de usuario

Fujitsu

Fujitsu PRIMERGY BX900 Manual de usuario

Asus

Asus RS700DA-E6 PS4 Manual de usuario
