System Overview: Dell PowerEdge 1600SC Systems Service Manual

Back to Contents Page

System Overview

Dell™ PowerEdge™ 1600SC Systems Service Manual

System Features

Supported Operating Systems

Power Protection Devices

Other Documents You May Need

Specifications

System Features

The system offers the following features:

●533-MHz front side bus systems:

❍Up to two Intel® Xeon™ microprocessors with an internal processing speed of at least

2.0 GHz, a 533-MHz front side bus speed, and a 512-KB Level 2 cache

●400-MHz front side bus systems:

❍Up to two Intel Xeon microprocessors with an internal processing speed of at least 1.8

GHz, a 400-MHz front side bus speed, and a 512-KB Level 2 cache

NOTE: Use the System Setup program to view microprocessor information. For more

information, see "Using the System Setup Program."

●A minimum of 128 MB of ECC DDR 266 SDRAM memory, upgradable to a maximum of 4 GB

by installing 128-, 256-, 512-MB, or 1-GB registered memory modules in the four memory

module sockets on the system board

●Support for the following internal hard-drive configurations:

❍Up to six 1-inch Ultra3 SCSI hot-plug hard drives

❍Up to four 1-inch non-hot-plug SCSI or IDE hard drives

●Integrated SCSI controller for SCSI hard drives and integrated IDE controller for IDE hard

drives, CD drive, and optional DVD and combination drives

●Optional single-channel RAID controller for SCSI RAID or optional quad-channel RAID

controller for IDE RAID

●Two 5.25-inch peripheral drive bays that support the following optional drives: CD, DVD,

http://support.jp.dell.com/docs/systems/pe1600sc/en/sm/overview.htm (1 av 7)2004-12-10 10:45:50

System Overview: Dell PowerEdge 1600SC Systems Service Manual

combination CD/DVD, or tape backup unit (SCSI or IDE)

The system board includes the following built-in features:

●Six PCI expansion slots: two 32-bit, 33-MHz PCI slots; two 64-bit, 66-MHz PCI slots; two 64-

bit, 100-MHz PCI-X slots.

●An integrated VGA-compatible video subsystem with an ATI RAGE XL video controller. This

video subsystem contains 8 MB of SDRAM video memory (nonupgradable). Maximum

resolution is 1280 x 1024 pixels and 16.7 million colors (noninterlaced).

●An integrated Gigabit Ethernet NIC, capable of supporting 10-Mbps, 100-Mbps, and 1000-

Mbps data rates.

●Systems management circuitry that monitors critical system voltages and temperatures. The

systems management circuitry works in conjunction with the systems management software.

●Optional remote access card for remote systems management (not supported on systems

with IDE hard drives).

●Optional hot-plug redundant power supplies.

●Chassis intrusion alarm, padlock tabs for internal security, and a bezel lock that prevents

access to the hot-plug hard drives.

Standard systems include a diskette drive and IDE CD drive, installed in an externally accessible

bay. An optional DVD or combination drive is also available.

The following software is included with the system:

●The System Setup program for quickly viewing and changing the system configuration

information for the system. For more information on this program, see "Using the System

Setup Program."

●Enhanced security features, including a system password and a setup password, available

through the System Setup program.

●Diagnostics for evaluating the system's components and devices. For information on using

the system diagnostics, see "Running the System Diagnostics."

●Optional tape backup software.

For a list of documents that provide more information on the system's features, see "Other

Documents You May Need."

Supported Operating Systems

The system supports the following operating systems:

●Microsoft® Windows® Server 2003 Standard Edition

http://support.jp.dell.com/docs/systems/pe1600sc/en/sm/overview.htm (2 av 7)2004-12-10 10:45:50

System Overview: Dell PowerEdge 1600SC Systems Service Manual

●Microsoft Windows 2000 Server

●Microsoft Windows 2000 SBS

●Red Hat Linux version 8.0

●Novell® NetWare® version 6.0 or later

Power Protection Devices

Certain devices protect the system from the effects of problems such as power surges and power

failures.

●PDU — Uses circuit breakers to ensure that the AC current load does not exceed the PDU's

rating.

●Surge protector — Prevents voltage spikes, such as those that may occur during an electrical

storm, from entering the system through the electrical outlet and network port. They do not

protect against brownouts, which occur when the voltage drops more than 20 percent below

the normal AC line voltage level.

●Line conditioner — Maintains a system's AC power source voltage at a moderately constant

level and provides protection from brownouts, but does not protect against a complete power

loss.

●UPS — Uses battery power to keep the system running when AC power is unavailable. The

battery is charged by AC power while it is available so that after AC power is lost, the battery

can provide power to the system for a limited amount of time—from 15 minutes to

approximately an hour. A UPS that provides only 5 minutes of battery power allows you to

shutdown the system. Use surge protectors and PDUs with all universal power supplies, and

ensure that the UPS is UL-safety approved.

Other Documents You May Need

The System Information Guide provides important safety and regulatory information.

Warranty information may be included within this document or as a separate document.

●The Setting Up Your System document provides an overview of initially setting up the

system.

●The Installation and Troubleshooting Guide describes how to troubleshoot the system and

install or replace system components.

●Systems management software documentation describes the features, requirements,

installation, and basic operation of the software.

●Operating system documentation describes how to install (if necessary), configure, and use

the operating system software.

http://support.jp.dell.com/docs/systems/pe1600sc/en/sm/overview.htm (3 av 7)2004-12-10 10:45:50

System Overview: Dell PowerEdge 1600SC Systems Service Manual

●Other documentation included on the CDs that came with the system describes the use of

advanced system features.

●Documentation for any components purchased separately provides information to configure

and install these options.

●Updates are sometimes included with the system to describe changes to the system,

software, and/or documentation.

NOTE: Always read the updates first because they often supersede information in other

documents.

●Release notes or readme files may be included to provide last-minute updates to the system

or documentation, or advanced technical reference material intended for experienced users

or technicians.

Specifications

Microprocessor

Microprocessor type:

533-MHz front side bus

systems Intel Xeon microprocessor with

an internal processing speed of

at least 2.0 GHz, a 533-MHz

front side bus speed, and a 512-

KB Level 2 cache

400-MHz front side bus

systems Intel Xeon microprocessor with

an internal processing speed of

at least 1.8 GHz, a 400-MHz

front side bus speed, and a 512-

KB Level 2 cache

Expansion Bus

Bus type PCI and PCI-X

Expansion slots two 32-bit, 33-MHz PCI slots (5

V); two 64-bit, 66-MHz PCI slots

(3.3 V); two 64-bit, 100-MHz

PCI-X slots (3.3 V)

Memory

http://support.jp.dell.com/docs/systems/pe1600sc/en/sm/overview.htm (4 av 7)2004-12-10 10:45:50

System Overview: Dell PowerEdge 1600SC Systems Service Manual

Architecture 72-bit ECC registered DDR 266

SDRAM

Memory module sockets four

Memory module capacities 128, 256, 512 MB, or 1 GB

Minimum memory capacity 128 MB

Maximum memory capacity 4 GB

Drives

Diskette drive 3.5-inch, 1.44-MB diskette drive

Hard drives up to six 1-inch hot-plug Ultra3

SCSI drives, up to four 1-inch

non-hot-plug Ultra3 SCSI

drives, or up to four 1-inch non-

hot-plug IDE drives

CD drive one EIDE CD drive

Optional DVD or combination

drive optional IDE DVD or

combination drive

Tape drive optional internal SCSI or IDE

tape backup unit

Externally Accessible Ports and Connectors

Serial one 9-pin connector

Parallel 25-pin connector

Video 15-pin connector

PS/2-style keyboard (with USB

support) 6-pin mini-DIN connector

PS/2-compatible mouse 6-pin mini-DIN connector

USB two USB-compliant 4-pin

connectors

NIC RJ-45 connector for integrated

NIC

Video

Video type ATI Rage XL video controller;

VGA connector

http://support.jp.dell.com/docs/systems/pe1600sc/en/sm/overview.htm (5 av 7)2004-12-10 10:45:50

System Overview: Dell PowerEdge 1600SC Systems Service Manual

Video memory 8 MB

Power

DC power supply (per power supply):

Wattage 450 W

Voltage 100–240 VAC, 50–60 Hz

Heat dissipation 2275 BTU/hr maximum

Output hold up time 20 ms minimum

Maximum inrush current Under typical line conditions and

over the entire system ambient

operating range, the inrush

current may reach 55 A at 10

ms or less or 25 A at 150 ms or

less.

System battery CR2032 3.0-V lithium coin cell

Physical

Height 44.7 cm (17.6 inches)

Width 21.8 cm (8.6 inches)

Depth 57.41 cm (22.6 inches)

Weight 33.11 kg (73 lb), maximum

configuration

Environmental

Temperature:

Operating 10° to 35°C (50° to 95°F)

Storage –40° to 65°C (–40° to 149°F)

Relative humidity:

Operating 20% to 80% (noncondensing)

Storage 5% to 95% (noncondensing)

Maximum vibration:

Operating 0.25 G (half-sine wave) at a

sweep of 3 to 200 MHz for 15

minutes

http://support.jp.dell.com/docs/systems/pe1600sc/en/sm/overview.htm (6 av 7)2004-12-10 10:45:50

System Overview: Dell PowerEdge 1600SC Systems Service Manual

Storage 0.5 G at 3 to 200 Hz for 15

minutes

Maximum shock:

Operating six consecutively executed

shock pulses in the positive and

negative x, y, and z axes (one

pulse on each side of the

system) of 36 G for up to 2.6 ms

Storage six consecutively executed

shock pulses in the positive and

negative x, y, and z axes (one

pulse on each side of the

system) of 71 G for up to 2 ms

Altitude:

Operating –16 to 3048 m (–50 to 10,000

ft)

Storage –16 to 10,668 m (–50 to 35,000

ft)

Back to Contents Page
