Dell Vostro 1220 Manual de usuario

Dell Projector 1220/1450

User’s Guide

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make

better use of your projector

CAUTION: A CAUTION indicates potential damage to hardware or

loss of data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written

permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; DLP

and DLP logo are trademarks of TEXAS INSTRUMENTS INCORPORATED; Microsoft and

Windows are either trademarks or registered trademarks of Microsoft Corporation in

the United States and/or other countries.

Other trademarks and trade names may be used in this document to refer to either

the entities claiming the marks and names or their products. Dell Inc. disclaims any

proprietary interest in trademarks and trade names other than its own.

Model: Dell Projector 1220/1450

June 2015 Rev. A02

Contents | 3

Contents

1 About Your Dell Projector . . . . . . . . . . . . . . . . . 4

Projector Box Contents . . . . . . . . . . . . . . . . . . . . 4

Projector Top and Bottom View . . . . . . . . . . . . . . . 5

Projector Connections . . . . . . . . . . . . . . . . . . . . . 6

2 Setting Up Your Projector . . . . . . . . . . . . . . . . . 8

Adjusting Projected Image . . . . . . . . . . . . . . . . . . 8

Using Remote Control . . . . . . . . . . . . . . . . . . . . 13

Connecting Projector. . . . . . . . . . . . . . . . . . . . . 18

3 Using Your Projector . . . . . . . . . . . . . . . . . . . . 23

Turning Projector On . . . . . . . . . . . . . . . . . . . . . 23

Turning Projector Off . . . . . . . . . . . . . . . . . . . . . 23

Menu Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4 Troubleshooting Your Projector . . . . . . . . . . . 39

Guiding Signals . . . . . . . . . . . . . . . . . . . . . . . . . 43

Changing the Lamp . . . . . . . . . . . . . . . . . . . . . . 44

5 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Compatibility Modes (Analog/Digital) . . . . . . . . . . 49

6 Contacting Dell . . . . . . . . . . . . . . . . . . . . . . . . 51

7 Appendix: Glossary . . . . . . . . . . . . . . . . . . . . . 52

4About Your Dell Projector

Your projector comes with all the items shown below. Ensure that you have

all the items, and contact Dell if anything is missing.

Projector Box Contents

1About Your Dell Projector

1220/1450 Package Contents

Power cable VGA cable (VGA to VGA)

Remote control AAA Batteries (2)

CD User’s Guide and Documentation

ZOOMZOOM INFO

VIDEOVGA HDMI

FREEZE

AUTO ADJ.

KEYSTONE

SOURCE VIDEO MODE

ASPECT

POWER

PAGE

BLANK

VOL

MUTE

AAA

Dell

Projector s

oduct Information Guide

Informacion Importante

Dell™ Projector

1220/1450

Contents:

•User's Guide

Documentation

P/N0F0VC

Rev.A02

P/N 36.70A01G002

June 2015

Madein China

Dell

™

Projector 1220/1450

00F0VCA02

About Your Dell Projector 5

Projector Top and Bottom View

NOTE: Ceiling mount screw hole M3 x 6.5mm depth.

Recommended torque <15 kgf-cm.

1 Status indicators

2IRreceivers

32WSpeaker

4 Lens

5Focusring

6 Zoom tab

7 Power button

8 Lamp cover

9 Mounting holes for ceiling mount

10 Tilt adjustment wheel

910

82.30

110.00

55.00

Top View Bottom View

6About Your Dell Projector

Projector Connections

CAUTION: Before you begin any of the procedures in this section,

follow the Safety Instructions as described on page 7.

NOTE: 5 V DC out connector ONLY available in 1450 projector.

1 +5 V DC out connector 6 HDMI connector

2 VGA output (monitor loop

through) connector

7 Audio input connector

3 VGA input (D-sub) connector 8 Composite Video connector

4 Power cord connector 9 Audio output connector

5 Mini USB (mini type B)

connector for remote mouse

and firmware upgrade

5679

12 3 4

About Your Dell Projector 7

CAUTION: Safety Instructions

Do not use the projector near appliances that generate a lot of heat.

Do not use the projector in areas where there is an excessive amount of

dust. The dust may cause the system to fail and the projector will

automatically shutdown.

Ensure that the projector is mounted in a well-ventilated area.

Do not block the ventilation slots and openings on the projector.

Ensure the projector operates between ambient temperatures (5 °C to

40 °C).

Do not try to touch the ventilation outlet as it can become very hot after

the projector has been turned on or immediately after it is turned off.

Do not look into the lens while the projector is on as it may cause injury to

your eyes.

Do not place any objects near or in front of the projector or cover its lens

while the projector is on as the heat may cause the object to melt or burn.

Do not use alcohol to wipe the lens.

NOTE:

•

Do not attempt to ceiling mount the projector by yourself. It should be

installed by a qualified technician.

•

Recommended Projector Ceiling Mount Kit (P/N: C3505). For more

information, see the Dell Support website at

dell.com/support

•

For more information, see the Safety Information that shipped with

your projector.

•

The 1220/1450 projector can only be used indoors.

8Setting Up Your Projector

Adjusting Projected Image

Raising the Projector Height

Raise the projector to the desired display angle, and use the front tilt

adjustment wheel to fine-tune the display angle.

Use the tilt adjustment wheels to fine-tune the display angle.

Lowering the Projector Height

Lower the projector, and use the front tilt adjustment wheel to fine-tune

the display angle.

2Setting Up Your Projector

1 Front tilt adjustment wheel

(Angle of tilt: -5 to 5 degrees)

2 Tilt adjustment wheel

Setting Up Your Projector 9

Adjusting Projector Focus

Rotate the focus ring until the image is clear. The projector focuses at

distances ranging between 3.94 ft to 32.81 ft (1.2 m to 10 m).

1 Zoom tab

2Focusring

10 Setting Up Your Projector

Adjusting Image Size

229"

(581.66 cm)

206"

(523.24 cm)

160"

(406.4 cm)

114"

(289.56 cm)

69"

(175.26 cm)

27.4"

(69.60 cm)

252.4" (641.1 cm)

227" (576.58 cm)

177"(449.58 cm)

126"(320.04 cm)

76"(193.04 cm)

30" (76.2 cm)

32.81' (10.0 m)

29.53' (9.0 m)

22.97' (7.0 m)

16.4' (5.0 m)

9.84' (3.0 m)

3.94' (1.2 m)

Projector to screen distance
