Dell SE2219H Manual de usuario

Dell SE2219H/SE2219HX

User’s Guide

Monitor Model: SE2219H/SE2219HX

Regulatory Model: SE2219Hf

Notes, Cautions and Warnings

NOTE: A NOTE indicates important information that helps you make better

use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of

data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

trademarks are of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.

2020 - 12

Rev. A03

Contents │ 3

Contents

About your monitor ...........................................5

Package contents ..................................................... 5

Product features....................................................... 6

Identifying features and controls................................ 7

Monitor specifications...............................................10

Pin assignments .......................................................15

Plug and play capability .............................................17

LCD monitor quality and pixel policy ...........................17

Maintenance guidelines .............................................17

Setting up the monitor ..................................... 18

Connecting the stand................................................18

Connecting your monitor .......................................... 20

Organizing cables .....................................................21

Removing the stand ..................................................21

Operating your monitor ....................................23

Turning on the monitor ............................................. 23

Using the front panel controls................................... 23

Using the On-Screen Display (OSD) menu.................. 25

Setting up display resolution on your monitor ............. 40

Using tilt................................................................. 42

4 │ Contents

Troubleshooting ...............................................43

Self-test ................................................................. 43

Built-in diagnostics .................................................. 45

Common problems ................................................... 46

Product-specific problems........................................ 48

Appendix .........................................................49

FCC Notices (U.S. Only) and Other Regulatory

Information ............................................................. 49

Contact Dell ............................................................ 49

EU product database for energy label and product

information sheet .................................................... 49

About your monitor │5

About your monitor

Package contents

Your monitor ships with the components indicated in the table. Ensure that you have received

all the components and see Contact Dell if anything is missing.

NOTE: Some items may be optional and may not ship with your monitor.

Some features may not be available in certain countries.

NOTE: To set up with any other stand, see the documentation that shipped

with the stand.

Display

Stand riser

Stand base

Power cable (varies by country)

VGA cable (SE2219H)

6│About your monitor

HDMI cable (SE2219HX)

• Quick Start Guide

• Safety and Regulatory Information

Product features

The Dell SE2219H/SE2219HX at panel display has an active matrix, Thin-Film Transistor

(TFT), Liquid Crystal Display (LCD), anti-static, and LED backlight.

The monitor features include:

• SE2219H/SE2219HX: 54.61 cm (21.5 in.) diagonal viewable area display (measured

diagonally). 1920 x 1080 resolution, with full-screen support for lower resolutions.

• Wide viewing angles of 178 degrees in vertical and horizontal directions.

• High dynamic contrast ratio (8,000,000:1).

• HDMI connectivity makes it simple and easy to connect with legacy and new systems.

• Plug and play capable if supported by your computer.

• On-Screen Display (OSD) adjustments is to easy setup and screen optimization.

• ≤ 0.3 W in Standby Mode.

• Optimize eye comfort with a ficker-free screen.

• Possible long-term effects if blue light emission from the monitor may cause damage

to the eyes, including eye fatigue or digital eye strain. ComfortView feature is

designed to reduce the amount of blue light emitted from the monitor to help optimize

eye comfort.

• Security-lock slot.

• Arsenic-free glass and mercury-free panel.

• BFR/PVC-Reduced (the circuit boards inside your monitor are made using BFR/PVC-

free laminates).

• RoHS Compliant.

About your monitor │7

Identifying features and controls

Front view

Label Description Use

1Function buttons To access the OSD menu and change the

settings if required. For more information,

see Using the front panel controls.

2Power On/Off button

(with LED indicator)

To turn the monitor On or Off.

Solid white light indicates that the

monitor is turned on and functioning

normally. Blinking white light indicates

that the monitor is in Standby Mode.

8│About your monitor

Back view

With monitor stand

Without monitor stand

Label Description Use

1Security-lock slot To secure the monitor using a security

lock (purchased separately).

2Regulatory label, barcode, serial

number, and Service Tag label

List of regulatory approvals. See this

label if you need to contact Dell for

technical support. The Service Tag is

a unique alphanumeric identifier that

enables Dell service technicians to

identify the hardware components in

your computer and access warranty

information.

3Regulatory information (engraved) List of regulatory approvals.

4Cable-management slot To organize the cables.

5Stand release button Release stand from monitor.

Side view

About your monitor │9

Bottom view, without monitor stand

SE2219H/SE2219HX

Label Description Use

1Power port To connect the monitor power cable.

2HDMI port For connecting the monitor to your computer using

HDMI cable.

3VGA port For connecting the monitor to your computer using

VGA cable.

10 │About your monitor

Monitor specifications

Description Values

Screen type Active matrix-TFT LCD

Panel type In-Plane Switching

Viewable area

Diagonal 546.10 mm (21.50 in.)

Active area:

Horizontal

Vertical

Area

476.06 mm (18.74 in.)

267.79 mm (10.54 in.)

1274.84 cm2(197.52 in.2)

Pixel pitch 0.24795 mm

Pixel per inch (PPI) 102

Viewing angle:

Horizontal

Vertical

178° (typical)

Brightness 250 cd/m2(typical)

Contrast ratio 1,000 to 1 (typical)

8,000,000 to 1 (Dynamic Contrast)

Faceplate coating Anti-glare with 3H hardness

Backlight LED light bar system

Response time (Gray to Gray):

Normal mode

Fast mode

8 ms

5 ms

Color depth 16.7 million colors

Color gamut CIE 1931 (72%)

Dell display manager

compatibility

Yes

Connectivity One VGA port and one HDMI 1.4 (HDCP 1.4) port with

SE2219H/SE2219HX monitors.

Bezel width (edge of monitor

to active area)

- Top: 6.4 mm (0.25 in.)

- Left/Right: 6.4 mm (0.25 in.)

- Bottom: 20.5 mm (0.81 in.)

Security Security-lock slot for cable lock (optional purchase)

Tilt angle -5° to 21°
