Dell S3222HN Manual de usuario

Model :S3222HN

Regulatory model : S3222HNc

Dell S3222HN Monitor

Dell Display Manager

User’s Guide

NOTE: A NOTE indicates important information that helps you make

better use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of

data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective

owners.

2021 – 08

Rev. A00

Contents | 3

Contents

Overview ....................................................... 4

Selecting Quick Settings options..................... 5

Setting basic display options........................... 7

Assigning preset modes to applications............ 9

Organizing windows with Easy Arrange ...........10

Managing Multiple Video Inputs...................... 13

Restoring Application Positions...................... 14

Attach DDM to active window (Windows 10 only)

.................................................................... 16

Setting energy conservation options............... 17

Other Shortcut Keys ..................................... 18

Troubleshooting............................................ 19

4| Overview

Overview

Dell Display Manager is an application that allows users to configure their supported

Dell monitor settings such as brightness, contrast, and preset modes. After its

installation, Dell Display Manager is accessible from the notification tray. Information

about monitors connected to the system is available when the mouse is hovered

over the notification tray icon.

Dell S3222HN - Standard

2021/06/10

4:56 PM

NOTE: Dell Display Manager uses Display Data Channel Command

Interface (DDC/CI) channel to communicate with your monitor. Ensure

that DDC/CI is enabled in the menu as follows:

Input Source

Color

Display

Personalize

Dell 32 Monitor

Brightness / Contrast

Others

DDC/CI On

Display Info

LCD Conditioning

Reset Others

Factory Reset

Service Tag

Firmware

Selecting Quick Settings options | 5

Selecting Quick Settings options

Clicking Dell Display Manager’s notification tray opens the Quick Setings window.

If more than one supported Dell monitor is connected to the system, a specific

target monitor can be selected from the Display drop-down list.

In the Quick Settings window, you can also change the following:

* Resolution

* Auto Mode or Manual Mode the screen appearance

* Brightness and contrast levels

* Easy Arrange window layouts for the monitor

Dell S3222HN

1920x1080

In the Quick Settings window, you can also click Open Dell Display Manager for

more advanced settings.

6| Selecting Quick Settings options

NOTE:

Feature Function Description

Quick DDM Access Quick key to call up

DDM UI.

Ctrl+Shift+D

Control individual

monitor in multi-

monitor setup

From dropdown box to select monitor,

selected monitor has Dell logo shown.

Move DDM UI to the monitor to be

controlled.

Press Ctrl+Shift+D to bring up the mini

UI under the mouse pointer.

Setting basic display options | 7

Setting basic display options

You can select Manual Mode to manually select a preset mode or select Auto

Mode that applies a preset mode based on the active application. An on-screen

message displays the current preset mode whenever it changes. The selected

monitor’s brightness and contrast levels can also be directly adjusted from the

Basic tab.

1920x1080

Dell S3222HN

NOTE: When multiple Dell monitors are connected, select “Enable

display matrix control” to apply brightness, contrast, and color presets

controls to all monitors.

8| Setting basic display options

Dell S3222HN

Standard

Assigning preset modes to applications | 9

Assigning preset modes to applications

The Auto Mode tab enables you to associate a specific Preset Mode with a specific

application, and apply it automatically. When Auto Mode is enabled, Dell Display

Manager will automatically switch to the corresponding Preset Mode whenever

the associated application is activated. The Preset Mode assigned to a particular

application may be the same on each connected monitor, or it can vary from one

monitor to the next.

Dell Display Manager is pre-configured for many popular applications. To add a new

application to the assignment list, simply drag the application from the desktop,

Windows Start Menu or elsewhere, and drop it onto the current list.

NOTE: Preset Mode assignments for batch les, scripts, loaders,

and non-executable les such as zip archives or packed les, are not

supported.

You can also configure the Game preset mode to be used whenever a Direct3D

application runs in full-screen mode. To prevent an application from using mode,

assign a different preset mode to it.

Dell S3222HN

Standard

Warm

Standard

10 | Organizing windows with Easy Arrange

Organizing windows with Easy Arrange

On supported Dell monitors, the Easy Arrange tab enables you to easily arrange the

open windows in one of the predefined layouts by dragging them in the zones. Press

“>” or use Page Up/Page Down key to find more layouts. To create a custom layout,

arrange the open windows and then click Save.

To get started with Easy Arrange, choose a target monitor and select one of

the predefined layouts. The regions for that layout are displayed momentarily on

the monitor. Next, drag an open window across the monitor. While the window is

being dragged, the current window layout is displayed and an active region gets

highlighted as the window passes over it. At any time, drop the window into the

active region to place the window in that region.

Dell S3222HN

To create a custom window layout, size and position the windows on the desktop

and then click the Save link in Easy Arrange. The size and position of the windows

is saved as a custom layout and the custom layout icon is created.

NOTE: This option does not save or remember the applications that are

open. Only the size and position of the windows is saved.
