Dell E2218HN Manual de usuario

Regulatory model: E2218HNf

User‘s Guide

Dell E2218HN

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

Information in this document is subject to change without notice. Reproduction of these materials

in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell™ and the DELL logo are trademarks of Dell Inc.; Microsoft®,

Windows®, and the Windows start button logo are either trademarks or registered trademarks of

Microsoft Corporation in the United States and/or other countries.

Other trademarks and trade names may be used in this document to refer to either the entities

claiming the mark and names or their products. Dell Inc. disclaims any proprietary interest in

trademarks and trade names other than its own.

2019 – 9Rev. A03

Contents

About Your Monitor ..................................... 5

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Identifying Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . 7

Monitor Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Plug and Play Capability . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Maintenance Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Setting Up the Monitor...................................17

Attaching the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Organizing Your Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Removing the Monitor Stand . . . . . . . . . . . . . . . . . . . . . . . . 19

Wall Mounting (Optional). . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Operating the Monitor .................................. 21

Power On the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Using the Front-Panel Controls . . . . . . . . . . . . . . . . . . . . . . . 21

Using the On-Screen Display (OSD) Menu. . . . . . . . . . . . . . . . . 22

Setting the Maximum Resolution . . . . . . . . . . . . . . . . . . . . . . 34

Using the Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Troubleshooting ....................................... 37

Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Built-in Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Common Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Product-Specific Problems. . . . . . . . . . . . . . . . . . . . . . . . . . 42

Dell Soundbar Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Appendix .............................................. 45

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

FCC Notices (U.S. Only) and Other Regulatory Information . . . . . . 45

Contact Dell. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

About Your Monitor 5

About Your Monitor

Package Contents

Your monitor ships with all the components shown below. Ensure that you have

received all the components and Contact Dell if anything is missing.

NOTE: Some items may be optional and may not ship with your monitor. Some

features or media may not be available in certain countries.

•Monitor

•Stand Riser

•Stand Base

•VESA™ Screw Cover

•Power Cable (varies with countries)

•HDMI Cable

•VGA Cable (Europe, the Middle East

and Africa only)

6 About Your Monitor

•Quick Setup Guide

•Safety and Regulatory Information

Product Features

at-panel display has an active matrix, Thin-Film Transistor, Liquid

Crystal Display and LED backlight. The monitor’s features include:

•

•Tilt adjustment capability.

•Removable pedestal and Video Electronics Standards Association (VESA) 100 mm

mounting holes f

•Plug and play capability if supported by your system.

•On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.

•Security lock slot.

•

•CECP (for China).

•RoHS compliant.

•TC

•Energy Gauge shows the energy level being consumed by the monitor in real time.

•Optimize eye comf ker-free screen.

• ects of blue light emission from the monitor may cause

damage to the eyes, including eye fatigue or digital eye strain. ComfortView

feature is designed to reduce the amount of blue light emitted from the monitor to

optimize eye comfort.

Asset Management Capability.

E2218HN: 54.61 cm (21.5 in.) agonal viewable image size, 1920 x 1080

resolution, plus full-screen support for lower resolutions.

About Your Monitor 7

Identifying Parts and Controls

Front View

1 Function buttons (For more information, see Operating the Monitor)

2 Power On/Off button (with LED indicator)

Back View

Back View with Monitor Stand

Label Description Use

1 VESA mounting holes (100

mm)

To mount the monitor.

2 Regulatory rating label Lists the regulatory approvals.

3 Security lock slot Secures monitor with security lock

(security lock not included).

4 Barcode serial number label Refer to this label if you need to contact

Dell for technical support.

5 Cable management slot Use to organize cables by placing them

through the slot.

8About Your Monitor

Side View

Right Side

Bottom View

Label Description Use

1 AC power connector To connect the monitor power cable.

2 HDMI connector To connect your computer to the monitor using

a HDMI cable.

3 VGA connector To connect your computer to the monitor using

a VGA cable.

4 Dell soundbar

mounting slots

To attach the optional Dell Soundbar.

Monitor Specifications

Flat-Panel Specifications

Model number E2218HN

Screen type Active matrix - TFT LCD

Panel Technology TN

About Your Monitor 9

Viewable image

Diagonal

Horizontal Active Area

Vertical Active Area

Area

546.1 mm (21.5 in.)

476.06 mm (18.74 in.)

267.79 mm (10.54 in.)

127484.10 mm2(197.52 in.2)

Pixel pitch 0.248 x 0.248 mm

Pixel per inch (PPI) 102

Viewing angle

Horizontal 170° typical

Vertical 160° typical

Brightness 250 cd/m² (typical)

Contrast ratio 1000 to 1 (typical)

Display screen coating Antiglare with hard-coating 3H

Backlight White LED edgelight system

Response Time 5 ms typical (white to black, black to white)

Color Depth 16.7 mil colors

Color Gamut 84 % (typical) *

Backlight Lamp Life (to

half initial brightness) 30K hours (typical)

Built-in devices N/A

Connectivity 1 x HDMI 1.4, 1 x VGA

Border width (edge of

monitor to active area)

17.80 mm (Top/Bottom/Left/Right)

Adjustability

Height adjustable stand N/A

Tilt -5° to 21°

Swivel N/A

Pivot N/A

Dell Display Manager

Compatibility Yes

10 About Your Monitor

Security Security lock slot (cable lock sold separately)

* E2218HN color gamut (typical) is based on CIE1976 (84 %) and CIE1931 (72 %) test

standards.

Resolution Specifications

Model number E2218HN

Scan range

•Horizontal 30 kHz to 83 kHz (automatic)

•Vertical 50 Hz to 75 Hz (automatic)

Maximum preset resolution 1920 x 1080 at 60 Hz

Supported Video Modes

Model number E2218HN

Video display capabilities

(VGA & HDMI playback)

480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Preset Display Modes

The following table lists the preset modes for which Dell guarantees image size and

centering:

Display Mode

Horizontal

Frequency

(kHz)

Vertical

Frequency

(Hz)

Pixel Clock

(MHz)

Sync Polarity

(Horizontal/

Vertical)

VESA, 720 x 400 31.5 70.1 28.3 -/+

VESA, 640 x 480 31.5 59.9 25.2 -/-

VESA, 640 x 480 37.5 75.0 31.5 -/-

VESA, 800 x 600 37.9 60.3 40.0 +/+

VESA, 800 x 600 46.9 75.0 49.5 +/+

VESA, 1024 x 768 48.4 60.0 65.0 -/-

VESA, 1024 x 768 60.0 75.0 78.8 +/+

VESA, 1152 x 864 67.5 75.0 108.0 +/+

VESA, 1280 x 1024 64.0 60.0 108.0 +/+

VESA, 1280 x 1024 80.0 75.0 135.0 +/+

VESA, 1600 x 900 60.0 60.0 108.0 +/+

VESA, 1920 x 1080 67.5 60.0 148.5 +/+
