Dell P57G Manual de usuario

Views

Modes

Specifications

intellectual property laws. Dell™and the Dell logo are trademarks of Dell Inc. in the United States and/or other

jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies

2014 ‑ 11 Rev. A00

Regulatory model: P57G | Type: P57G001

Computer model: Inspiron 13‑7348

NOTE: The images in this document may differ from your computer

depending on the configuration you ordered.

7000 Series

Inspiron 13

1 Power/Battery status light

Indicates the power state and battery state of the

computer.

Solid white light — Power adapter is connected to the

computer and the battery is being charged.

Solid yellow light — Battery charge is low or critical.

Off— Power adapter is connected to the computer

and battery is fully charged or power adapter is not

connected to the computer.

Views

Specifications

Front

Left

Right

Base

Display

Front

1 Security-cable slot

Connect a security cable to prevent unauthorized

movement of your computer.

2 Power-adapter port

Connect a power adapter to provide power to your

computer and charge the battery.

3 HDMI port

Connect a TV or another HDMI‑in enabled device.

Provides video and audio output.

4 USB 3.0 port with PowerShare

Connect peripherals such as storage devices, printers,

and so on. Provides data transfer speeds up to 5 Gbps.

PowerShare allows you to charge your USB devices even

when your computer is turned off.

5 USB 3.0 port

Connect peripherals such as storage devices, printers,

and so on. Provides data transfer speeds up to 5 Gbps.

6 Headset port

Connect a headphone, a microphone, or a headphone

and microphone combo (headset).

7 Left speaker

Provides audio output from your computer.

5 6 7

123

Views

Specifications

Front

Left

Right

Base

Display

Left

1 Power button

Press to turn on the computer if it is turned off or in

Sleep state.

Press to put the computer in Sleep state if it is turned on.

Press and hold for 4 seconds to force shut‑down the

computer.

NOTE: You can customize the power‑button

behavior in Power Options. For more information, see

Me and My Dell at dell.com/support.

2 Volume-control buttons (2)

Press to increase or decrease the volume.

3 Right speaker

Provides audio output from your computer.

4 USB 2.0 port

Connect peripherals such as storage devices, printers,

and so on. Provides data transfer speeds up to

480 Mbps.

5 Media-card reader

Reads from and writes to media cards.

6 Passive stylus

Allows you to draw shapes, select items, and perform

touch gestures on the screen.

123

Views

Specifications

Front

Left

Right

Base

Display

Right

1 Left-click area

Press to left click.

2 Touchpad

Move your finger on the touchpad to move the mouse

pointer. Tap to left click and two finger tap to right click.

3 Right-click area

Press to right click.

321

Views

Specifications

Front

Left

Right

Base

Display

Base

1 Left microphone

Provides high‑quality digital sound input for audio

recording, voice calls, and so on.

2 Ambient-light sensor

Detects the ambient light and automatically adjusts the

display brightness.

3 Camera

Allows you to video chat, capture photos, and record

videos.

4 Camera-status light

Turns on when the camera is in use.

5 Right microphone

Provides high‑quality digital sound input for audio

recording, voice calls, and so on.

6 Windows button

Press to go to the Start screen.

1 3 4 5

Views

Specifications

Front

Left

Right

Base

Display

Modes

Notebook

Tablet Stand

Tablet

Tent

Specifications

Views

System

Information Memory Ports and

Connectors

Dimensions and

Weight

Computer

Environment

Storage

Touchpad Power AdapterCamera

Communications

Battery

Video Audio

Display

Media‑Card

Reader Keyboard

Dimensions and Weight

Height 19 mm (0.75 in)

Width 330 mm (13 in)

Depth 222 mm (8.74 in)

Weight (maximum) 1.67 kg (3.70 lb)

NOTE: The weight of your computer varies depending on the configuration

ordered and the manufacturing variability.

Specifications

Views

System

Information Memory Ports and

Connectors

Dimensions and

Weight

Computer

Environment

Storage

Touchpad Power AdapterCamera

Communications

Battery

Video Audio

Display

Media‑Card

Reader Keyboard

System Information

Computer model Inspiron 13‑7348

Processor • 5th generation Intel Core i3

• 5th generation Intel Core i5

• 5th generation Intel Core i7

Chipset Integrated in the processor

Specifications

Views

System

Information Memory Ports and

Connectors

Dimensions and

Weight

Computer

Environment

Storage

Touchpad Power AdapterCamera

Communications

Battery

Video Audio

Display

Media‑Card

Reader Keyboard

Memory

Slot One SODIMM slot

Type DDR3L

Speed 1600 MHz

Configurations supported 4 GB and 8 GB
