Dell™ Latitude™ 13 7000 Series 2-in-1

Technical Guidebook

January 2015

Table of Contents

Latitude 13

7000 Series 2-in-

1 Product Views

and Technical Specifications

3 -

Weight, Dimensions, Top/Right View

Back/Left View

Undock View

Technical Specifications 7-

Marketing System Configurations

10 -

Operating Systems

Intel Architecture

Memory

Primary Storage and Intel Rapid Start

Technology

Connectivity Options

Security and Keyboard specifications

Detailed Engineering Specifications

17 –

Primary storage 18-

Ports and connectors

Webcam

Wireless LAN 23-

Mobile Broadband

Integrated Graphics Controller

Displays

Batteries

Power Adapters

Keyboards

Touchpad

Operating conditions

Product Views and

Technical Specifications

Starting weight:

Tablet: 904.1g (1.99lb),

Docking Base: 764.2g (1.68lb),

Total: 1668.3g (3.67lb) , including ballast.

Dimensions:

Tablet: 320.0mm(X) * 206.0mm(Y) * 10.525mm(Z)

Docking Base: 320.0mm(X) * 227.5mm(Y) * 8.5mm(Z)

Total : 320.0mm(X) * 229.73mm(Y) * 19.925mm(Z)

Latitude 13 7000 Series 2-in-1 : Weight, Dimensions, Top/

Right View

1. Microphone slot

2. ALS

3. Camera status light

4. Camera

5. Power button

6. Power button light

7. Windows key

8. Volume button

9. N-lock slot

10. Keyboard

11. SD slot w/ SD dummy card

12. Touch pad

13. Tablet Display

1234

Latitude 13 7000 Series 2-in-1: Back/Left View

1. Finger Printer reader (optional)

2. Tablet smart card reader slot (optional)

3. Tablet rear camera (optional)

4. Audio jack

5. Battery status light

6. DC-in connector

7. USB 3.0 w/ power share connector

8. N-lock slot

9. Mini DP connector

10. USB 3.0 connector

Crested Butte 13” Undock View

1. Speaker (left)

2. Tablet hinge pin slot (left)

3. USIM card tray w/ eject hole (optional)

4. Tablet Docking connector-40pin

5. Tablet DC-in connector

6. Tablet hinge pin slot(right)

7. Speaker(right)

8. Undock release button

9. Hinge pin(left)

10. Hinge hook(left)

11. Base docking connector-40pin

12. Hinge stop/ release pin

13. hinge pin(right)

14. Hinge hook(right)

956

12 13

Latitude 13 7000 Series 2-in-1 Technical Specifications

Feature

Technical Specification

Model Number

Latitude

13 7000 Series 2-in-1(7350)

Processor Options

Intel® Core

TM M & CoreTM M vPro

Operating System

Microsoft® Windows®

8.1 64-bit

Microsoft® Windows®

8.1 Pro 64-bit

Memory

2,5 Options

DDR3L

-RS SDRAM 1600MHz

Chipset

Integrated with the processor

(Wildcat Point-LP)

Intel Responsiveness Technologies

Optional Intel®

vPro™ technology with Active Management Technology 10.0

Graphics

Intel® Integrated HD Graphics 5300

Display

13.3

“FHD Anti-Glare LCD display with LED backlight display

Storage

5Options

Up to

512GB Solid State Drives

Optical Drive Options

None

Multimedia

High Quality

Stereo Speakers

Stereo global headset jack

Noise reducing

array microphones

2MP FHD

video webcam, optional 8MP FHD Rear webcam

Battery Options

Tablet

- 3cell (30Whr) Lithium Ion battery with ExpressCharge™

Key

board Base - 2cell (20Whr) Lithium Ion battery with ExpressCharge™

Latitude 13 7000 Series 2-in-1 Technical Specifications

Power Options

Watt AC Adapter

Connectivity options

Wireless

LAN Options:

Intel® Dual Band Wireless-AC 7265 802.11AC Wi-Fi + BT 4.0 LE Wireless Card

Optional Mobile Broadband & GPS Options:

Dell Wireless

TM DW5810 LTE M2 Card

Ports, Slots & Chassis

Stereo

global headset jack

Memory card

reader

Docking connector

, mDP, USB3.0 (2)

Network

connector, optional SIM card slot

2 M2 slots (WLAN

& WWAN)

Optional

SmartCard Reader and optional Fingerprint Reader , optional NFC

-Lock slot

Dimensions & Weight

Width:

13” / 320.0mm

Height:

0.8“ / 19.9mm (Touchscreen)

Depth:

9” / 229.73mm

Starting weight: 3.68lbs / 1.67kg (with 3

-cell battery and no-ODD)

Regulatory and Environmental

Compliance

Regulatory Model:

P58G

Regulatory Type:

P58G001

ENERGY STAR

6.1(Windows OS)

EPEAT Registered. For specific country participation and rating, please see www.epeat.net

BFR/PVC

free

Input

Single

Pointing backlit Keyboard

Precision

Touchpad

Systems Management

Intel®

vPro™ Technology’s advanced management features (optional, requires Intel WiFi

® Link

WLAN

)

Warranty and Service

Limited Hardware Warranty

4; Standard 3-year On Site Service after Remote Diagnosis11 (3-3-

3); Optional 3

-year Dell ProSupport™ for IT12 ; 4 year and 5 year service and support options

Latitude 13 7000 Series 2-in-1 Technical Specifications

Some items will be available post-RTS. Offering may also vary by country and by configuration. For complete details, refer to the

Technical Guidebook available on dell.com.

A 64-bit operating system is required to support 4GB or more of system

memory

Limited Hardware Warranty: For copy of Limited Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX

78682 or see www.dell.com/warranty

GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment a

nd will

be less.

Based on Dell lab testing using the following configuration: 3-cell battery, integrated Graphics, 4G DDR3 memory and M.2 SATA drive.

Weights vary depending on configuration and manufacturing variability.

6 Dell defines BFR/PVC Free as set forth in the

Inemi Position Statement on the "definition of Low-Halogen Electronics BFR-/CFR-/PVC-

free". Please see our corporate responsibility page at www.dell.com/environment for more information. Some external adapters,

power

cables and service parts are excluded from this definition unless specifically identified as BFR/PVC free.

Mobile Broadband: Available in certain countries only. Subject to wireless provider’s broadband subscription and coverage area;

additional charges apply.

Onsite Service after Remote Diagnosis: Remote Diagnosis is determination by online/phone technician of cause of issue; may involve

customer access to inside of system and multiple or extended sessions. If issue is covered by Limited Hardware Warranty

(www.dell.com/warranty) and not resolved remotely, technician and/or part will be dispatched, usually within 1 business day following

completion of Remote Diagnosis. Availability varies. Other conditions apply.

Dell Services: Availability and terms of Dell Services vary by region. For more information, visit www.dell.com/servicedescriptions.

Marketing System

Configurations
