Dell™ Inspiron™ 1012:

Comprehensive Specifications

This document provides information that you may need when setting up,

updating drivers for, and upgrading your computer.

NOTE: Offerings may vary by region. For more information regarding the configuration

of your computer, click Start → Help and Support and select the option to view

information about your computer.

Processor

Ty p e I n t e l ®Atom™single core

L2 cache 512 KB

External bus frequency 533 MHz and 667 MHz

Computer Information

System chipset Intel NM10 Express Chipset

Data bus width 64 bits

DRAM bus width single channel 64-bit buses

Flash EPROM 2 MB

Processor address bus 32 bits

Graphic bus 32 bits

Samos Comprehensive Specs .fm Page 1 Thursday, December 17, 2009 3:24 PM

Memory Card Reader

Card reader controller RealTek RTS5159

Card reader connector 3-in-1

Flash cards supported

• Secure Digital (SD) memory card

• Secure Digital High Capacity (SDHC)

card

• Multimedia Card (MMC)

•MemoryStick

•MemoryStickPRO

Memory

Memory connector one user accessible SODIMM connector

Memory capacities 1 GB and 2 GB

Memory type 800 MHz DDR2

(operates at 667 MHz)

Memory configurations 1 GB and 2 GB

NOTE: For instructions on upgrading memory, see the Service Manual at

support.dell.com/manuals.

Connectors

Audio one microphone-in connector and

one stereo headphone/speaker connector

Mini-Card one full Mini-Card slot and two half

Mini-Card slots

Network adapter one RJ45 connector

USB three 4-pin USB 2.0-compliant

connectors

VGA one 15-hole connector

Antenna in (optional) one MCX connector

Samos Comprehensive Specs .fm Page 2 Thursday, December 17, 2009 3:24 PM

Communications

Modem interface external V.92 56K USB (optional)

Network adapter 10/100 Mbps Ethernet

Wireless Wireless LAN, Bluetooth wireless

technology, WWAN/GPS, WiMax

Video

Video type integrated on system board

Video controller Intel GMA 3150

Video memory 8 MB system memory (shared)

LCD interface LVDS

Video decoder (optional) Crystal HD Media Accelerator

Frame rate

Upto 30 fps

Resolution Upto 1080p or 1920x1088

Formats Codec Support

MPEG-4, DIvX(MPEG-4),

AVC(H.264), VC-1(WMV-9)

Audio

Audio type 2-channel High Definition Audio

Audio controller Realtek ALC272

Stereo conversion 24-bit (analog-to-digital and digital-to-

analog)

Internal interface Intel High Definition audio

Speakers two 1.0 watt speakers

Volume controls keyboard function keys and program

Samos Comprehensive Specs .fm Page 3 Thursday, December 17, 2009 3:24 PM

Camera

Camera resolution 1.3 megapixel

Video resolution 640 x 480 at 30 fps

Diagonal viewing angle 66°

Display

Type (WLED) 10.1 inch WSVGA TrueLife™

10.1 inch HD TrueLife

Height 222.72 mm (8.77 inches)

Width 125.28 mm (4.93 inches)

Diagonal 255.52 mm (10.10 inches)

Luminance

WSVGA

200 cd/m2

250 cd/m2

Maximum resolution

WSVGA

1024 x 600

1366 x 768

Refresh rate 60 Hz

Operating angle 0° (closed) to 135°

Horizontal viewing angle ±40° (LED) minimum

Vertical viewing angle +10°/-30° (LED) minimum

Pixel pitch

WSVGA

0.2175 x 0.2088 mm

0.16305 x 0.16305mm

Controls brightness can be controlled through

keyboard shortcuts (see the Dell

Te c h n o l og y G u id e for more information)

Samos Comprehensive Specs .fm Page 4 Thursday, December 17, 2009 3:24 PM

Keyboard

Number of keys 82 (Korea, U.S, and Canada); 83

(Europe); 86 (Japan)

Layout QWERTY/AZERTY/Kanji

Touch Pad

X/Y position resolution (graphics table

mode)

240 cpi

Width 38 mm (1.49 inches) sensor-active area

Height 78.5 mm (3.09 inches) rectangle

Battery

Ty p e

3-cell “smart” lithium ion

2.6Ahr, 28Whr

6-cell “smart” lithium ion

2.6Ahr, 56Whr or 2.8Ahr, 60Whr

Dimensions

Depth

60.62 mm (2.39 inches)

Height

22.56 mm (0.89 inches)

Width

206 mm (8.11 inches)

Weight 0.23 kg (0.50 lb) (3-cell)

0.36 kg (0.79 lb) (6-cell)

Voltage 11.1 VDC

Charge time when the computer is

turned off (approximate)

3.0 hours (3-cell)/4.0 hours (6-cell)

Life span (approximate) 300 discharge/charge cycles

Temperature range

Operating

0° to 35°C (32° to 95°F)

Storage

–40° to 65°C (–40° to 149°F)

Coin-cell battery CR-2032

Samos Comprehensive Specs .fm Page 5 Thursday, December 17, 2009 3:24 PM

AC Adapter

Input voltage 100–240 VAC

Input current 0.8 A or 1.0 A

Input frequency 50–60 Hz

Output power 30 W

Output current 1.58 A

Rated output voltage 19.0 VDC

Temperature range

Operating

0° to 40°C (32° to 104°F)

Storage

–20° to 70°C (–4° to 158°F)

Physical

Height 25.5 mm to 32.8 mm(0.98 inches to

1.29 inches)

Width 268 mm (10.6 inches)

Depth 196.6 mm (7.74 inches)

Weight (with 3-cell battery) configurable to less than 1.25 kg

(2.75 lb)

Computer Environment

Temperature range

Operating

0° to 35°C (32° to 95°F)

Storage

–40° to 65°C (–40° to 149°F)

Relative humidity (maximum)

Operating

10% to 90% (non-condensing)

Storage

5% to 95% (non-condensing)

Maximum vibration (using a random vibration spectrum that simulates user

environment)

Operating

0.66 GRMS

Non-Operating

1.30 GRMS

Samos Comprehensive Specs .fm Page 6 Thursday, December 17, 2009 3:24 PM

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is

strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, TrueLife, and Inspiron are trademarks of Dell Inc.; Intel

is a registered trademark and Atom is a trademark of Intel Corporation in the U.S. and other countries;

Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in the

United States and/or other countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the

marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade

names other than its own.

Model: P04T series Type: P04T001 December 2009 Rev. A00

Maximum shock (for operating — measured with Dell Diagnostics running on the

hard drive and a 2-ms half-sine pulse; for non-operating — measured with hard

drive in head-parked position and a 2-ms half-sine pulse)

Operating

110 GRMS

Non-Operating

160 GRMS

Altitude (maximum)

Operating

–15.2 to 3048 m (–50 to 10,000 ft)

Storage

–15.2 to 10,668 m (–50 to 35,000 ft)

Airborne contaminant level G2 or lower as defined by

ISA-S71.04-1985

Computer Environment

(continued)

Samos Comprehensive Specs .fm Page 7 Thursday, December 17, 2009 3:24 PM
