Dell H955N Manual de usuario

DelltRack External Battery Module

for use with

5600W UPS models

Getting Started With

Your System

Démarrer Avec Votre Système

Erste Schritte mit Ihrem System

Начало работы c системой

Inicio de su sistema



사용자의 시스템 시작하

はじめにおいのシステム

H955N, J731N, 96K3Y, 42KP9

K812N

w w w . d e l l . c o m | s u p p o r t . d e l l . c o m

DelltRack External Battery Module

for use with

5600W UPS models

Getting Started

With Your System

H955N, J731N, 96K3Y, 42KP9

K812N

w w w . d e l l . c o m | s u p p o r t . d e l l . c o m

Notes and Warnings

NOTE: A NOTE indicates important information that helps you make better use of your software.

DANGER: A DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or

serious injury.

WARNING: A WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or

injury.

CAUTION: A CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or

moderate injury or in property damage incidents.

DANGER: Observe the following instruction to help prevent an imminently hazardous situation which, if not

avoided, will result in death or serious injury:

SThis UPS contains LETHAL VOLTAGES. All repairs and service should be performed by

AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS

inside the UPS.

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their

products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

August 2009

Finding Information |

Finding Information

CAUTION: The Safety, Environmental, and Regulatory Information document provides important safety and

regulatory information.

What are You Looking For? Find It Here

SThe user's guide for my UPS

SThe user's guide for the Dell Network Management

Card

SDell UPS Management Software

NOTE: Documentation and software updates can be

found at support.dell.com.

Dell UPS Disc

SSpecifications

SHow to configure UPS settings

SHow to troubleshoot and solve problems

SHow to install REPO control

Dell UPS User's Guide

The user's guide is available on the Dell UPS disc and

on support.dell.com.

SSafety instructions

SRegulatory information

SRecycling information

Safety, Environmental, and Regulatory Information

SWarranty information

STerms and Conditions (U.S. only)

SEnd User License Agreement

Dell Warranty and Support Information

SSupport information Dell Support Website — support.dell.com

NOTE: Select your region or business segment to view

the appropriate support site.

2|Installation and Startup

Installation and Startup

CAUTION: Before performing the procedures in this document, read and follow the safety instructions and

important regulatory information in your Safety, Environmental, and Regulatory Information document.

Unpacking the External Battery Module

1Open the outer carton and remove the accessories packaged with the cabinet.

Installation and Startup |

Lifting the Cabinet

CAUTION: The cabinet is heavy (65 kg/143 lb). Lifting the cabinets into the rack requires a minimum of two

people.

1With one person on each side, carefully lift the cabinet out of the outer carton using the handles

on the cardboard and set it on a flat, stable surface.

2Discard or recycle the packaging in a responsible manner, or store it for future use.

4|Installation and Startup

Rackmount Setup

CAUTION: The cabinet is heavy (65 kg/143 lb). Lifting the cabinets into the rack requires a minimum of two

people.

Installing the Rails

NOTE: The instructions are the same for square-hole racks and unthreaded, round-hole racks. The rails fit both

rack styles. The round-hole rack is shown in the illustrations.

1Select the proper holes in the rail for positioning the cabinet in the desired location in the rack.

The rails should be located at the bottom of the 3U space allocated for the EBM.

2Position the end of the left and right rails labeled FRONT facing inward.

Installation and Startup |

3Attach the rails to the rack:

Engage the back end of the rail until it fully seats on the vertical rack flange and the hook latch

locks in place.

Pull the rail toward the front.

Push the front end of the rail until it fully seats on the vertical rack flange and the hook latch locks

in place.

Installing the Cabinet

NOTE: Install the EBM directly below the UPS.

4Slide the cabinet into the rack.

6|Installation and Startup

Securing the Cabinet

5Secure the front of the cabinet to the rack using the thumbscrews on the mounting brackets.

Tighten by hand; do not use power tools.

Installing the EBM Front Cover

6Install the EBM front cover.
