Dell PowerEdge C8220X Manual de usuario
Dell PowerEdge C8220X
Xeon Phi 5110P/7120P
MIC Card
Installation Guide
Regulatory Model: B06B
Regulatory Type: B06B001
C8220X_MIC5110P7120P_IG.book Page 1 Monday, August 12, 2013 5:42 PM
Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of
your computer.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of
data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal
injury, or death.
____________________
Information in this publication is subject to change without notice.
© 2013 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.
is strictly forbidden.
Trademarks used in this text: Dell™, the DELL logo, and PowerEdge™ are trademarks of Dell Inc.
Intel®, Xeon®, and Intel® Xeon Phi™ are trademarks of Intel Corporation in the U.S. and/or other
countries.
Other trademarks and trade names may be used in this publication to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
Regulatory Model B06B
Regulatory Type: B06B001
2013 - 08 P/N X8N2G Rev. A00
C8220X_MIC5110P7120P_IG.book Page 2 Monday, August 12, 2013 5:42 PM
Contents 3
Contents
Important Safety Information . . . . . . . . . . . . . . . . . . . . . 5
Recommended Tools . . . . . . . . . . . . . . . . . . . . . . . . . 5
Information You May Need . . . . . . . . . . . . . . . . . . . . . . 6
Xeon Phi 5110P/7120P MIC Cards . . . . . . . . . . . . . . . . . . 6
Installing the Front Xeon Phi 5110P/7120P MIC card . . . 7
Installing the Back Xeon Phi 5110P/7120P MIC card . . 11
Cable Routing Diagram . . . . . . . . . . . . . . . . . . . . . . . 16
C8220X_MIC5110P7120P_IG.book Page 3 Monday, August 12, 2013 5:42 PM
4Contents
C8220X_MIC5110P7120P_IG.book Page 4 Monday, August 12, 2013 5:42 PM
Installation Guide 5
Important Safety Information
Observe the following safety precautions when installing Intel Xeon Phi 5110P/7120P Many
Integrated Core (MIC) cards in the PowerEdge C8220X sled.
WARNING: Working on systems that are still connected to a power supply can be
extremely dangerous.
CAUTION: The sled must be operated with the cover installed to ensure proper cooling.
CAUTION: To ensure proper airflow in the PowerEdge C8000 server enclosure, if a sled
module is removed it should be immediately replaced with another sled or sled blank.
CAUTION: Operating the system for extended periods of time without a sled blank
installed can cause the PowerEdge C8000 server enclosure to overheat.
CAUTION: MIC cards can only be installed in the slots on the GPGPU card riser. Do not
attempt to install MIC cards directly into the riser connector on the system board.
NOTE: It is recommended that you always use a static mat and static strap while working on
components in the interior of the system.
To avoid injury to yourself or damage to your system, follow these guidelines:
• Always disconnect the system from the power outlet whenever you are working inside the
system.
• If possible, wear a grounded wrist strap when you are working inside the system.
Alternatively, discharge any static electricity by touching the bare metal chassis of the
system case, or the bare metal body of any other grounded appliance.
• Hold electronic circuit boards by the edges only. Do not touch the components on the
board unless it is necessary to do so. Do not flex or stress the circuit board.
• Leave all components inside the static-proof packaging until you are ready to use the
component for the installation.
• Some cables have a connector with locking tabs; if you are disconnecting this type of cable,
press in on the locking tabs before you disconnect the cable. As you pull connectors apart,
keep them evenly aligned to avoid bending any connector pins. Also, before you connect a
cable, ensure that both connectors are correctly oriented and aligned.
Recommended Tools
You may need the following items to install Intel Xeon Phi 5110P/7120P MIC cards in the
PowerEdge C8220X sled.
• #1 or #2 Phillips screwdriver
• Static mat
• Static strap
C8220X_MIC5110P7120P_IG.book Page 5 Monday, August 12, 2013 5:42 PM
6Installation Guide
Information You May Need
For information about system features, troubleshooting, and component replacement, see the
PowerEdge C8220X Hardware Owner’s Manual. This document is available at
dell.com/support/manuals.
Xeon Phi 5110P/7120P MIC Cards
1
Remove the sled from the PowerEdge C8000 server enclosure. For detailed information on
removing the sled, see the
PowerEdge C8220X Hardware Owner’s Manual
.
2
Place the sled on a flat, stable surface.
3
Open the sled. For detailed information on opening the sled, see the
PowerEdge C8220X
Hardware Owner’s Manual
.
4
Remove the five M3 screws securing the top cover.
5
Lift the top cover away from the sled cover.
NOTE: Be careful not to damage the twin axial cable on the back GPGPU card riser
when removing the top cover.
Figure 1-1. Removing the Top Cover
1 top cover 2 M3 screws (5)
1
2
C8220X_MIC5110P7120P_IG.book Page 6 Monday, August 12, 2013 5:42 PM
Installation Guide 7
Installing the Front Xeon Phi 5110P/7120P MIC card
1
Remove the four M3 screws securing the air baffles.
2
Lift the air baffles out of the sled cover.
Figure 1-2. Removing the Air Baffles
3
Remove the four M3 screws securing the mounting brackets.
4
Lift the mounting brackets away from the GPGPU blank. Save the mounting brackets.
5
Lift the GPGPU blank out of the sled cover. Save the GPGPU blank for future use.
Figure 1-3. Removing the Mounting Brackets and GPGPU Blank
1M3screws(4) 2right air baffle
3 left air baffle 4 GPGPU blank
1 M3 screws (4) 2 front mounting bracket
3 back mounting bracket 4 GPGPU blank
12
3
4
12
3
4
C8220X_MIC5110P7120P_IG.book Page 7 Monday, August 12, 2013 5:42 PM
8Installation Guide
6
Align the right air baffle with the screw holes on the front of the sled cover.
7
Secure the right air baffle to the sled cover using the two M3 screws. Tighten the screws to
5.21 in-lbs.
Figure 1-4. Installing the Right Air Baffle
8
Remove the four screws securing the MIC card bracket.
9
Lift the bracket from the MIC card. Save the bracket for future use.
Figure 1-5. Removing the MIC Card Bracket
1 M3 screws (2) 2 right air baffle
1 screws (4) 2 MIC card bracket
3MICcard
12
1
2
3
C8220X_MIC5110P7120P_IG.book Page 8 Monday, August 12, 2013 5:42 PM
Installation Guide 9
10
Align the front mounting bracket with the screw holes on the left of the MIC card and secure
with four M3 screws. Tighten the screws to 5.21 in-lbs.
11
Align the back mounting bracket with the screw holes on the right of the MIC card and
secure with four M3 screws. Tighten the screws to 5.21 in-lbs.
Figure 1-6. Installing the Mounting Brackets
12
Connect the power cables to the MIC card. Ensure the cables are properly attached. See
Figure 1-19 for the cable routing diagram.
Figure 1-7. Connecting the Power Cables
1 M3 screws (4) 2 front mounting bracket
3 back mounting bracket 4 MIC card
1, 2 power cables
12
3
4
1
2
C8220X_MIC5110P7120P_IG.book Page 9 Monday, August 12, 2013 5:42 PM
10 Installation Guide
13
Align and insert the MIC card assembly into the front GPGPU card riser connector until the
card is fully seated.
14
Secure the MIC card to the front of the sled cover using the four M3 screws, working in a
clockwise sequence. Tighten the screws to 5.21 in-lbs.
Figure 1-8. Installing the Front MIC Card Assembly
15
Align the left air baffle with the screw holes on the front of the sled cover.
16
Secure the left air baffle to the sled cover using the two M3 screws. Tighten the screws to
5.21 in-lbs.
Figure 1-9. Installing the Left Air Baffle
1 M3 screws (4) 2 MIC card assembly
3 front GPGPU card riser
1 left air baffle 2 M3 screws (2)
3 MIC card assembly
2
3
1
1
2
3
C8220X_MIC5110P7120P_IG.book Page 10 Monday, August 12, 2013 5:42 PM
