Dell OptiPlex 3080 Small Form Factor Cable

Cover

User Guide

June 2020

Rev. A00

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use of your product.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid

the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

trademarks may be trademarks of their respective owners.

Chapter 1: Dell OptiPlex Small Form Factor Cable Cover................................................................4

Chapter 2: Getting help.................................................................................................................8

Contacting Dell.....................................................................................................................................................................8

Contents

Contents 3

Dell OptiPlex Small Form Factor Cable Cover

The cable cover for the Dell OptiPlex Small Form Factor system helps protect the ports and cables that are connected to the

system.

About this task

Follow these steps to install the cable cover.

NOTE: Images that are shown below may vary depending on your system configuration.

Steps

1. Route the cables through the slot at the bottom of the cable cover.

2. Draw out the cables from the other side of the cable cover.

3. Connect the cables to their respective ports and turn the antenna (if available/applicable) outwards to pass through the

antenna slot at the top of the cable cover.

4 Dell OptiPlex Small Form Factor Cable Cover

4. Align the cable cover retaining hooks into their slots on the Dell OptiPlex Tower chassis.

CAUTION: Take care not to bend or break the delicate plastic hooks.

Dell OptiPlex Small Form Factor Cable Cover 5

5. Gently press down on the cable cover until it clicks into place.

6. Slide the latch to lock the cable cover in place.

6Dell OptiPlex Small Form Factor Cable Cover

NOTE: For added security, use the Noble Wedge slot to secure the system.

Dell OptiPlex Small Form Factor Cable Cover 7

Getting help

Topics:

•Contacting Dell

Contacting Dell

Prerequisites

NOTE: If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing

slip, bill, or Dell product catalog.

About this task

Dell provides several online and telephone-based support and service options. Availability varies by country and product, and

some services may not be available in your area. To contact Dell for sales, technical support, or customer service issues:

Steps

1. Go to Dell.com/support.

2. Select your support category.

3. Verify your country or region in the Choose a Country/Region drop-down list at the bottom of the page.

4. Select the appropriate service or support link based on your need.

8 Getting help
