dehn DEHNrecord SD Manual de usuario
Publication No. 2086 / Update 01.00 Mat-No. 3015953 © Copyright 2021 DEHN SE + Co KG
DEHNrecord SD
Multifunctional measurement and analysis device
for monitoring power quality
Manual
Page 2 from 69
Imprint
Manufacturer
DEHN SE + Co KG
Hans-Dehn-Str. 1
92306 Neumarkt
Germany
Tel. +49 9181 906-0
www.dehn.de
Service Hotline – Technical Support
Tel. +49 9181 906-1750
Page 3 from 69
Table of contents
Imprint 2
Manufacturer 2
Service Hotline – Technical Support 2
1. Terms and abbreviations 6
2. Safety 7
2.1 Intended use 7
3. Scope of delivery 8
3.1 Accessories (optional) 8
4. Service description 9
4.1 Measuring the power quality according to EN 61000-4-30, class A 10
4.2 Additional measurement capabilities 10
4.3 Device variants 11
4.4 Measurement locations, measurement tasks 11
4.5 Measured values – recording 12
4.6 Measured values – evaluation of power quality (PQ) 13
4.7 Measurement site concept 14
4.8 Configuration 16
4.9 Events and output channels 17
5. Device description 18
6. Mounting 20
6.1 Mounting as a single device 20
6.2 Mounting with surge protective device and busbar 21
6.3 Use with overvoltage category IV 22
Page 4 from 69
Table of contents
* Variant with impulse current measurement expected to be available from Q4 - 2021
7. Connection 24
7.1 Connection DRC SD 1 1 – Part No. 910 920 24
7.2 Connection DRC SD 2 1 – Part No. 910 921 25
7.3 Impulse current sensor DRC SD ICS (Part No. 910 935) * 26
7.4 Current sensors 27
8. Commissioning 28
8.1 Step 1 – Apply the voltage 28
8.2 Step 2 – Connection to the web server 28
8.3 Step 3 – Check 28
8.4 Step 4 – Configuration 29
9. Functionality 30
9.1 User interface 30
9.2 Block diagram 32
9.3 Measured values 33
9.4 Modbus 34
9.5 Communication via the network 35
10.Device settings 36
10.1 Device settings expert mode 36
10.2 General 36
10.3 LED indicator 36
10.4 Digital inputs, digital outputs and logic 37
10.5 Network 41
10.6 Power frequency overvoltages according to EN 50550 - POP 43
10.7 Current measurement 45
10.8 Mains signalling voltages 47
10.9 Factory reset 47
Page 5 from 69
Table of contents
11.PQ Configuration 48
11.1 General 48
11.2 Voltage magnitude 48
11.3 Frequency 49
11.4 Flicker 49
11.5 Voltage dip, voltage swell, voltage interruption 50
11.6 Voltage dip 50
11.7 Voltage swell 50
11.8 Voltage interruption 51
11.9 Unbalance 51
11.10 Total harmonic distortion THD, harmonics, interharmonics 52
11.11 Mains signalling voltages 52
11.12 Rapid voltage changes 53
11.13 Values for PQ characteristics 54
12.Technical data 57
13.Maintenance 69
13.1 Check 69
13.2 Cleaning 70
13.3 Dismantling 70
13.4 Disposal 70
Page 6 from 69
1. Terms and abbreviations
PQ Power Quality
DRC SD DEHNrecord SD
SPD Surge Protective Device
POP Power frequency overvoltage protective device
UTC Coordinated Universal Time
MSRL Equipment for measurement, control, and laboratory use according to EN 61010-1
PLC Programmable logic controller
Page 7 from 69
2. Safety
WARNING
Risk of electric shock
Installation and connection of a DEHNrecord SD may only be carried out by a qualified electrician
in accordance with the installation standards of the country.
Before mounting, check the DEHNrecord SD (DRC SD) and the accessories for external damage.
If any damage or other defect is detected, do not mount the DRC SD.
Loads exceeding the specified values may destroy the DRC SD and the electrical equipment connected to it.
Tampering with and modifying the DRC SD will void the warranty.
If the DRC SD is used together with a surge protective device (SPD) in environments with overvoltage category IV,
make sure that the SPD is functional before accessing the device.
If the SPD indicates a defect, the SPD must first be repaired before the DRC SD can be accessed.
The installation instructions for the SPD must be observed for this purpose.
2.1 Intended use
The DRC SD is permitted for use in the control cabinet and only within the conditions specified in this manual.
If the device is used in a manner not specified, the protection supported by the device may be impaired.
Only approved accessories may be used.
An external time signal from a time server is required for synchronization (see chapter 9.5 Communication via the network)
Page 8 from 69
3. Scope of delivery
DEHNrecord SD *
Connector IO
Connector CM
Installation instructions
3.1 Accessories (optional)
Impulse current sensor DRC SD ICS 100, Part No. 910 935 *
Split core current sensors, Part No. 910 936
Current sensors (Rogowski coils), Part No. 910 937
Busbar (suitable for surge protective device)
for use in combination with a surge protective device (SPD)
Impulse current sensor DRC SD ICS
* Variant with impulse current measurement expected to be available from Q4 - 2021
L1
L2
L3
N/PEN
24 VDC
5
6 4
3
11 14 12
300 V CAT III
300 V CAT IV
L1
L2
L3
N/PEN
5
6 4
3
11 14 12
Publication No. 2084 / Update 01.03 Mat. No. 3015951 © Copyright 2021 DEHN SE + Co KG
DEHNrecord SD
Multifunctional measurement and analysis device
for monitoring power quality
Installation instructions
Connection
DRC SD 2 1 – Part No. 910 921
24 V DC external power supply
Detects interruptions and drop > 5 s
as per EN61000-4-30, class A for
24 VDC uninterruptible power supply.
Supply voltage UB: 24 VDC, max. 100 mA
Cross-sectional area L1/L2/L3/N: 1.5 - 6 mm2
Plug cross-sectional area: 0.25 - 1.5 mm2
Test
After applying the voltage:
LED 1 flashes green if power supply correct
LED 2
lights up green if voltage quality good (in factory configuration)
Commissioning
Connect DEHNrecord SD directly to computer
1. Configure computer: IP 192.168.0.10, Sub. 255.255.255.0
2.
Connect computer and DEHNrecord directly with network cable
3.
Activate Web server:Press button 2 briefly, LED 1 lights up blue
4. Access with browser: http://192.168.0.200
Connect DEHNrecord SD via network
1. Connect DEHNrecord SD with network (DHCP)
2.
Activate Web server:Press button 2 briefly, LED 1 lights up blue
3.
Access with browser: http://DRC-SD-serial no. (e.g. http://DRC-SD-FHA12345678)
Factory-set password: smartdevice
Testing
After successful registration, properties such as the following can be checked:
Rotational field direction of the voltage connections, Current measuring coil
connection, Impulse current sensor connection
Configuration
The DEHNrecord SD can be suitably configured via the Web server.
Access to
the cloud server is preconfigured (MQTT, port 8883).
LED 1 lights up green once access to the DEHNmonitor PQ is working.
Product registration
For product registration in the DEHNmonitor PQ,the serial number and the
four digits after the serial number are required. These are only printed on the
device itself! Example: „0000“ in „FHA12345678-0000“.
Example wiring of an SPD with remote
signalling contact:
· Connect SPD contact (connection 11) with
supply voltage 24 VDC (plug I/O tmnl 3)
· Feedback from SPD contact (connection 12 or 14)
to digital input I1.1 (plug I/O tmnl 5)
· Ground connection (plug I/O tmnl 4 and 6)
Installation
The device is installed on a 35 mm DIN rail as per EN 60715.
Backup fuse
The backup fuse
must be chosen to
match the connecting cable;
e.g. for 1.5 mm2-> B16 A
It can be installed together with a surge protective device (SPD).
There are matching busbars for the connection with an SPD.
The snap-on elements of the devices have a permanent unlock-
ing position to facilitate their joint attachment to and removal
from the DIN rail.
Backup fuse
The specifications of the
respective SPD
must be observed.
Connection
DRC SD 1 1 – Part No. 910 920
Power supply via L1 of the measuring voltage
The device can bridge interruptions of supply
for up to 5 s.
Supply voltage UB: 230 VAC (50 Hz), max. 30 mA
Cross-sectional area L1/L2/L3/N: 1.5 - 6 mm2
Plug cross-sectional area: 0.25 - 1.5 mm2
Example wiring of an SPD with remote signalling
contact:
· Connect SPD contact (connection 11) with
auxiliary voltage 12 VDC (plug I/O tmnl 3)
· Feedback from SPD contact (connection 12 or 14)
to digital input I1.1 (plug I/O tmnl 5)
· Ground connection (plug I/O tmnl 4 and 6)
Dehn DRC SD Einbauanleitung 01.03 DE+EN 9Juni2021.indd 1-3Dehn DRC SD Einbauanleitung 01.03 DE+EN 9Juni2021.indd 1-3 10.06.21 18:2210.06.21 18:22
Input Output
Digital
LED
Cloud
DEHNrecord SD
Ethernet
Modus TCP
MQTT
Page 9 from 69
4. Service description
Schematic overview of functions
front end
DEHN server
Measured value acquisition
Measured value evaluation Control center, PLC, PC, ...
Current
Voltage
Push button
Digital
Impulse current (ICS)
SPD monitoring
Web server
Page 10 from 69
4. Service description
4.1 Measuring the power quality according to EN 61000-4-30, class A
Monitored are: Voltage magnitude, frequency, flicker, voltage dips, voltage swells, interruption, unbalance, harmonics, interharmonics,
mains signalling voltages, rapid voltage changes.
Measurement/recording Analysis and evaluation
Power quality according to EN 61000-4-30:2015, class A According to standard EN 50160 and
at the same time according to individual specifications
4.2 Additional measurement capabilities
Measurement/recording Analysis and evaluation
Impulse current 8/20 µs and 10/350 µs to 100 kA * By maximum, duration, rise time, and single/sum charge.
Current, power, energy via up to 4 current sensors
(Rogowski coils or split core current transformers)
Limit values for current, power (P, Q, S), current direction, zero current
and energy (global) can be parameterized separately for each phase or
the neutral conductor
Power frequency overvoltages (POP) According to standard EN 50550 and also individually with differentia-
tion exceedance/undershot
Digital states at 3 inputs
According to state/change with counter function.
After status / change with counter function. The inputs can be logically
linked to one another and to other device functions.
* Variant with impulse current measurement expected to be available from Q4 - 2021
