Deﬁnitive Technology

Deﬁnes the Future!

New High Performance

Sonic Excitement

•New Mythos®Gem Sub/Sat System

•New SuperCube®III Subwoofer

•New Mythos®Gem Sat/Surround

•New Mythos®Solo Three-in-One

Front Speaker Array

•New Mythos®Eight On-Wall

Plasma Solution®

•New IWSub™Reference In-Wall

Powered Subwoofer

•New UIW™Reference Line Source

Ultimate In-Wall Speaker

State-of-the-Art Performance for Your Lifestyle

eﬁnitive Technology deﬁnes

the future with signiﬁcant new

loudspeakers for custom installation,

plus important new additions

to the elegant Mythos Series of home

theater speakers and an amazing

new SuperCube subwoofer.

New Mythos Gem System:

Deﬁning Sub/Sat Perfection

This Mythos Gem/SuperCube based system elevates the sub/sat concept to a new plateau

of style and performance. Deﬁnitive’s engineers have combined four new Mythos Gem loud-

speakers with a Mythos Seven Center Channel Speaker and a new SuperCube III Subwoofer

to build a remarkably compact, exquisitely elegant, ultra high performance sub/sat system!

A Mythos Gem System is the perfect choice for listeners who desire the application

versatility of a compact sub/sat system combined with the cutting-edge styling and state-of-the-

art sonic performance that’s won Deﬁnitive’s Mythos Series and SuperCube Subwoofers the

industry’s most coveted rave reviews and awards, including “New Audio Product of The Year”

and Sound & Vision’s “Critic’s Choice Award.”

New Mythos Gem:

Small Size, Big Sound and Drop-Dead Gorgeous

Mythos Gem loudspeakers take the style and elegance of the

Mythos Series, with curved, hand-polished aluminum enclosures,

and deliver it up in a compact, high performance model that is

perfect for use as a surround speaker in a Mythos system, or

as the main left and right channels in a compact sub/sat system.

The Gem, which utilizes an angled baffle design and complex

Linkwitz-Riley Crossover Network, delivers wide dispersion and

excellent imaging with a deep soundstage. The small Gem is

extremely versatile, and can be wall mounted using its stainless

steel mounting plate (included), pivoting wall mount brackets

(optional) or used with the beautiful custom-

designed matching aluminum and glass

GemStand (optional). Speciﬁcations:

Dimensions: 4

"W x 10

"H x 4

"D.

Magnetically-Shielded Driver

Complement:

two 3

" bass/mid drivers, one 1" pure aluminum

dome tweeter. Frequency Response: 60 Hz – 30 kHz. Recommended

Ampliﬁcation: 10 – 200 Watts/channel. Finish: polished silver or

polished black.

New SuperCube III:

Super-Compact Super-Bass

The SuperCube III’s affordable price and remarkably compact

size will bring matchless SuperCube based performance to

many more lucky listeners. This newest member of Deﬁnitive

Technology’s SuperCube Subwoofer family shares the

SuperCubes’ award-winning ultra compact, ultra deep bass,

ultra high power heritage. At 10

" cubed, it’s also the smallest!

The remarkable engineering feat that combined SuperCube III’s

incredible sound quality with its vanishingly small size took over

two years of dedicated R&D at DTARF (The Deﬁnitive

Technology Advanced Research Facility), using the world’s most

advanced proprietary Finite Element Magnetic Analysis program.

SuperCube III features a 7

" high-deﬁnition long-throw

active driver coupled to two 7

" low-resonance pressure-driven

infrasonic radiators, powered by a 650-Watt Digital Switching

Ampliﬁer for tremendous subsonic impact as well as astoundingly

delicate musicality. Amp features include speaker level inputs/

outputs with built-in high-pass ﬁlter, left/right and unﬁltered LFE

low-level inputs, continuously variable level, phase and low-pass

controls as well as signal sensing auto ON/OFF circuitry.

Speciﬁcations: Dimensions: 10

"W x 10

"H x 10

"D. Driver

Complement: one 7

" long throw driver, two 7

" pressure-driven

infrasonic bass radiators. Frequency Response: 16 Hz – 200 Hz.

“Built to Appease the Gods

of Great Sound and Stylish Decor”

— Home Theater Magazine

New Mythos Solo:

Left/Center/Right in One Elegant Loudspeaker

The Mythos Solo is an elegantly simple Plasma Solution

that builds on

and extends the Mythos tradition of combining high performance sound

quality with cutting-edge styling. It is a combination Left, Center and

Right channel loudspeaker with all three driver arrays together in one

sleek and elegant enclosure that looks amazing when placed with today’s

high-tech televisions. The enclosure’s beautiful styling matches the Mythos

signature look of curved, hand-polished, aircraft grade aluminum, and it

can be either wall mounted (using the strong stainless steel wall mounting

brackets, included), placed on a shelf below or above the television, or

placed directly atop the television.

The unique curved D’Appolito driver arrays on the left and right main

speaker modules deliver wider dispersion and an expanded image size.

Use the Mythos Solo as your complete front stage speaker array. Match it

with a Deﬁnitive Technology Subwoofer and a pair of surround speakers

(such as the new compact Mythos Gem Speakers) to build a complete,

compact super clean-looking ultra high performance home theater system.

Speciﬁcations: Dimensions: 40"W x 4

"H x 4

"D. Magnetically-Shielded

Driver Complement: L & R Channel Modules: two 3

" bass/mid drivers,

one 1" pure aluminum dome tweeter, Center Channel Module: two 3

bass/mid drivers, two 3

" pressure-driven bass radiators, one 1" pure

aluminum dome tweeter. Power Handling: 10 – 175 Watts x 3. Frequency

Response: 60 Hz – 30 kHz. Finish: polished silver or polished black.

New Mythos Eight:

Larger On-Wall Loudspeakers

for Bigger On-Wall Televisions

The Mythos Eight loudspeaker is another

Plasma Solution

from Deﬁnitive Technology

designed to complement larger on-wall televisions

(50" and up) with gorgeous Mythos curved-

aluminum styling and award-winning sonic

performance. Mythos Eight is engineered to

be mounted vertically or horizontally (using its

stainless steel wall mounting bracket, included)

for use as sublimely beautiful Left and Right

Main Loudspeakers, or as a high performance

Center Channel Speaker (for use with Mythos

Eight or Mythos One Loudspeakers, etc., as

Mains). Speciﬁcations: Dimensions: 6

"W x

"H x 4

"D. Magnetically-Shielded Driver

Complement: two 5

" bass/mid drivers, two 5

pressure-driven bass radiators, one 1" pure

aluminum dome tweeter. Frequency Response:

38 Hz – 30 kHz. Recommended Ampliﬁcation:

10 – 250 Watts/channel. Finish: polished silver

or polished black.

New Mythos Series Plasma Solutions®

11433 Cronridge Drive, Owings Mills, Maryland 21117, U.S.A.

(410) 363-7148 • www.deﬁnitivetech.com

New IWSub Reference:

In-Wall Thunder for “Stealth” Home Theater

Like Deﬁnitive’s ﬁrst in-wall super sub, the IWSub 10/10, the IWSub Reference is a

completely self-enclosed in-wall subwoofer for use in whole house distributed music or

“stealth” home theater installations. It incorporates Deﬁnitive Technology’s exclusive

SuperCube Subwoofer Technology in a sensibly sized, compact enclosure that installs

easily in new construction or existing walls. The non-resonant sealed medite enclosure

ﬁts ﬂush into a standard stud bay. The paintable bezel and grille allow you to customize

your IWSub Reference to match your home décor and virtually disappear into your room.

Inside the precisely conﬁgured box is a specially-engineered shallow-depth, long

excursion 13" subwoofer driver coupled to a 13" pressure-driven infrasonic bass radiator.

This SuperCube technology allows the IWSub Reference to achieve remarkable bass

performance from a cabinet enclosure of modest internal volume. In fact, the perform-

ance of the IWSub Reference In-Wall Subwoofer goes well beyond the output level,

impact and low frequency limits of even its superb smaller cousin the IWSub 10/10,

all the while maintaining its fast, tight musical quality. Mounting Dimensions—Outer

Flange: 151/2"W x 263/16"H. Cut Out Size: 143/8"W x 251/8"H x 4"D. Driver Complement:

one 13" long-exercusion woofer coupled to a 13" infrasonic radiator. Frequency

Response: 14 Hz – 200 Hz.

The IWSub’s matching high power ampliﬁer, the SubAmp 600, is a separate unit

designed for shelf, cabinet or rack placement. It is a powerhouse engineered to effort-

lessly drive one or two IWSub Reference In-Wall Subwoofers, for easily conﬁgured

multi-subwoofer or multi-room systems.

It features speaker level inputs/outputs with

built-in high-pass ﬁlter, left/right and unﬁltered LFE low-level inputs, continuously

variable level, phase and low-pass controls, signal sensing auto ON/OFF circuitry

and a 12-volt trigger.

Speciﬁcations: Dimensions (with brackets, feet removed):

191/16"W x 37/16"H x 95/8"D . Dimensions (without brackets, including feet): 171/16"W x

311/16"H x 95/8"D. Output: one channel operation: 275 Watts, two channels driven: 230

Watts each, 460 Watts total.

Extraordinary New Custom Installation Solutions

New UIW RLS II:

Reference Line Source Ultimate In-Wall Speaker

The UIW RLS 2 is an enclosed full range loudspeaker engineered for ﬂush mount vertical or

horizontal in-wall installation. The sealed non-resonant medite enclosure houses a line source

array composed of two high deﬁnition bass/mid drivers with cast baskets for natural midrange,

surrounding a pure aluminum dome tweeter for silky smooth high frequency response, plus two

pressure-driven bass radiators for deep powerful low frequency extension. Use the UIW RLS 2

as a main Left, Right, Center or Surround Loudspeaker in a “stealth” high performance home

theater or multichannel music system.

The UIW RLS 2 is capable of extraordinary sonic performance, comparable to that of even

the ﬁnest freestanding loudspeakers, yet it remains hidden within your walls and takes up

no ﬂoor space! Add a Deﬁnitive Technology subwoofer, such as one of our IWSubs, for the

addition of even more high impact perfectly blended deep bass response. Speciﬁcations:

Mounting Dimensions—Outer Flange: 81/8"W x 293/4"H. Cut Out Size: 7"W x281/2"H x 37/8"D.

Driver Complement: two 61/2"bass/mid drivers, two 61/2"pressure-driven bass radiators,

one 1" pure aluminum dome tweeter. Frequency Response: 22 Hz – 30 kHz. Recommended

Ampliﬁcation: 10 – 350 Watts.

Este manual sirve para los siguientes modelos

Otros manuales de Sistema de altavoces de Definitive Technology

Definitive Technology

Definitive Technology ProCinema 100 Manual de usuario

Definitive Technology

Definitive Technology MYTHOS XTR-SSA5 Manual de usuario

Definitive Technology

Definitive Technology StudioMonitor 350 Manual de usuario

Definitive Technology

Definitive Technology ProCinema 60 Manual de usuario

Definitive Technology

Definitive Technology Mythos Gem Manual de usuario

Definitive Technology

Definitive Technology Studio 3D Mini Manual de usuario

Definitive Technology

Definitive Technology W Studio Micro Manual de usuario

Definitive Technology

Definitive Technology BPX Manual de usuario

Definitive Technology

Definitive Technology BPVX Manual de usuario

Definitive Technology

Definitive Technology ProCinema 80 Manual de usuario

Definitive Technology

Definitive Technology C/L/R 2300 Manual de usuario

Definitive Technology

Definitive Technology SuperTower BP7000SC Manual de usuario

Definitive Technology

Definitive Technology Mythos XTR-SSA3 Manual de usuario

Definitive Technology

Definitive Technology PowerMonitor 500 Manual de usuario

Definitive Technology

Definitive Technology BP-2002 Manual de usuario

Definitive Technology

Definitive Technology Mythos Four Manual de usuario

Definitive Technology

Definitive Technology Mythos Six Manual de usuario

Definitive Technology

Definitive Technology PowerMonitor 700 Manual de usuario

Definitive Technology

Definitive Technology Mythos XTR 60 Manual de usuario

Definitive Technology

Definitive Technology SuperTower BP7000SC Manual de usuario

Definitive Technology

Definitive Technology SR-8080BP Manual de usuario

Definitive Technology

Definitive Technology Mythos Gem XL Manual de usuario

Definitive Technology

Definitive Technology ProCenter 1000 Manual de usuario

Definitive Technology

Definitive Technology Mythos XTR Series Manual de usuario

Manuales populares de Sistema de altavoces de otras marcas

JVC

JVC CA-MXK5R Manual de usuario

LG NB4532B Manual de usuario

JVC

JVC CA-FSH100 Manual de usuario

5Core

5Core Pro Series Manual de usuario

EAW

EAW MQV1394e Manual de usuario

Lynx

Lynx GXR-LA10A Manual de usuario

iLive

iLive ITB066B Manual de usuario

RDX

RDX QuickStation 4 Manual de usuario

Electro-Voice

Electro-Voice S-122 Manual de usuario

Sven

Sven SPS-619 GOLD Manual de usuario

Pioneer

Pioneer CS-7070 Manual de usuario

EAW

EAW UB82e Manual de usuario

Sondpex

Sondpex Active Speaker System and Digital Music... Manual de usuario

JVC

JVC NX-PN7 Manual de usuario

Marshall Amplification

Marshall Amplification AR-DM61-BT Manual de usuario

Yamaha

Yamaha NX-A01 - Speaker Sys Manual de usuario

SE Audiotechnik

SE Audiotechnik I-LINE Manual de usuario

Gemini

Gemini WRX-843 Series Manual de usuario
