DV-IP RT

Installation and

Operation Guide

Intelligent Security & Fire Ltd

DV-IP RT

Whilst every attempt is made to ensure these manuals are accurate and current, Dedicated Micros reserve the right to alter or

modify the specication of the machine described herein without prejudice.

Contents

Introduction .......................................................................................................3

Features ...........................................................................................................4

Important Safeguards .......................................................................................6

Installing the Unit ..............................................................................................8

Conguring the Unit ........................................................................................22

Remote Control ..............................................................................................24

Main Menu ......................................................................................................26

Navigating The Conguration Menus .............................................................27

System Settings ..............................................................................................30

Console Settings ............................................................................................43

Camera Settings .............................................................................................54

Record Settings ..............................................................................................59

Alarm Settings ...................................................................................................... 69

Network Settings ............................................................................................84

Analytics & Text ..............................................................................................98

Archive ..........................................................................................................103

Oracle Dome Conguration ..........................................................................104

Unit Operation ..............................................................................................114

Appendix A ....................................................................................................136

Appendix B ...................................................................................................137

Appendix C ...................................................................................................139

Appendix D ..................................................................................................140

Appendix E ...................................................................................................141

Intelligent Security & Fire Ltd

DV-IP RT

Introduction

What is the…

DV-IP RT ?

A comprehensive digital recording solution, the DV-IP RT is a stand-alone high-performance

recording system offering reliable, networked, scalable CCTV with real time viewing and recording

capabilities at an affordable price.

Ideal for installations were high record rates and network capabilities are required; the DV-IP RT

range includes Real Time ‘RT’ and Near Real Time ‘NT’ variants. RT units can achieve global record

rates of up to 25pps on all channels. NT units can achieve global record rates of up to 12pps on

all channels*. Both variants offer JPEG and MPEG-4 recording at scalable quality settings.

Dedicated Micros renowned MultiMode record feature enables an operator to set different recording

rates, resolution and compression formats across scheduled, normal and alarm modes for each

individual camera.

Available with 8, 16 or 32 camera inputs, all offering telemetry control, the DV-IP RT has built in

Alarm functionality and onboard Activity detection software.

Lip synched audio is available for each camera channels (except on 32 way unit).

To give operators maximum viewing exibility, the DV-IP RT can be congured to contain a mixture

of spot or main monitor outputs. Camera channels can be viewed in single or multi-screen mode on

a local monitor or remotely over an IP connection.

The accompanying Infra-Red (IR) Remote Control has a colour coded ‘Softkey’ interface with

conguration menus common to both local monitor and web interface, making for easy set-up and

operation.

Dedicated Micros trademark plug and play intuitive set-up and user-friendly interface helps keep

installation and operator training to a minimum.

The DV-IP RT includes as standard internal storage with expansion available via external high-

speed SATA ports. A DVD-R Writer and USB ports are provided for external video archiving.

The unit also offers integrated text support, allowing users to connect with cash registers in retail

applications to monitor Point Of Sale (POS) locations. Capturing and associating video with the

relevant text information allows the operator to search video footage by time, event, and text data to

provide evidence of fraud or to aid identication of regular offenders.

Among the many other features included as standard on the DV-IP RT are; multiway display and

remote monitoring using NetVu ObserVer (utilising DM’s unique TransCoding capabilities to provide

uent live and replay images).

With telemetry control of up to 16 cameras (including coax telemetry), control of dome cameras,

activity detection plus many more exciting features, the DV-IP RT is the ideal product when high-

performance video recording and transmission is required at an affordable cost.

For further information, please visit the website:

www.dedicatedmicros.com

or contact customer services in your region

* This manual is relevant to both RT and NT variants; all examples and images have been taken from

the RT unit.

Intelligent Security & Fire Ltd

DV-IP RT

Features

The DV-IP RT from Dedicated Micros is equipped with an array of valuable features designed to

enhance the operator experience.

• 8, 16 or 32 camera input options

• Real time recording at QCIF to 4CIF resolution

• Telemetry support (Coax & Serial)

• Lip Synched Audio for up to 16 camera channel (dependant on model)

• I.P Camera support

• Alarm Inputs & Outputs

• Two way network intercom

• Internal storage

• All DVR functions fully supported by Keyboard/IR Remote Control/Mouse

• Scalable recording settings

• MultiMode Recording - Dynamically-switchable resolution, record-rate & compression

(MPEG4/JPEG) per camera

• Built in activity detection

• HDMI monitor support

• Single and Multiway displays

• Live and playback viewing locally and over Ethernet

• Point&go telemetry control

• JPEG or MPEG-4 recording and transmission

• Web pages provide easy remote conguration

• Embedded NetVu Console functionality

• Easy to use on-screen, colour coded softkey menu options

• Text support and text search features ideal for retail installations

• Built in DVD-R writer and USB ports for download of video archive to external ash

memory and uploading software updates

• Optional external keyboard available

• Conguration via USB mouse and USB QWERTY keyboard

• BS8418 compliant

The DV-IP RT has NetVu Connected technology built-in to ensure maximum compatibility with future

developments in networked security. NetVu Connected technology enables the DV-IP RT to fully

interact with other NetVu Connected compatible products from Dedicated Micros including the DV-IP

Decoder, NetVu ObserVer and PDA Viewers. Providing interoperability between the worlds leading

security companies, NetVu Connected uses industry standard networking protocols supported by a

wide range of third party integration products and SDKs to ensure future on-going compatibility.

COMMON CONFIGURATION INTERFACE

A Common Conguration interface is displayed when the unit’s conguration screens are accessed

locally at the unit or remotely via a web browser. This unied system ensures that the installer is

familiar with the conguration screens irrespective of their location to the unit, minimising training

and familiarisation time and increasing the speed of installation and alteration.

Intelligent Security & Fire Ltd

DV-IP RT

The DV-IP RT includes a unique colour-coded menu structure and onscreen Graphical User

Interface (GUI). Context sensitive, the menu structure always represents the area of the menu the

user is in, allowing them to quickly select the options and settings they need without having to trawl

through menu pages and options. The colour coded buttons displayed on the monitor match those

on the IR Remote Control, whilst control can also be conducted through an attached USB Mouse or

supported Keyboard (DM/KBC1 / DM/KBC2).

VIDEO TIMELINE

The Video Timeline feature is a new intuitive interface for the control and navigation of playback

video. With control via the IR Remote Control or supported Keyboard, the colour-coded on-screen

display matches the buttons on the Remote Control or Keyboard allowing the user to control the

video forward or backwards in incremental steps of seconds, minutes, hours, days and weeks.

MAPS

Users can now navigate around their CCTV installation using graphical maps. Selecting the relevant

camera from the map will instantly connect the user to that cameras image stream. With the ability

to load bespoke map images and oor plans to reect their installations, the Maps feature is ideal for

quickly identifying camera locations around a site or CCTV network.

Point&go provides the user with easy to use, fast, accurate telemetry control via an attached

monitor. With no need for a telemetry keyboard, users are able to use Pan & Tilt control of a

Dedicated Micros Oracle Dome simply by clicking an area of the monitor. The camera will instantly

respond, positioning the selected area in the middle of the screen, ideal for tracking movement

through a scene.

ePTZ

Dedicated Micros ePTZ uses an advanced image ‘interpolation’ algorithm that reveals detailed

information that simple pixel-stretching digital zoom commands cannot. Users can operate ePTZ

as they would Analogue Zoom - moving around the scene and zooming in/out using the IR Remote

Control or a supported Keyboard - even on static analogue cameras. Electronic Zoom can be

carried out on both live and playback video. Providing the ability to retrospectively control and view

an image, a great aid in post-event analysis.

Absolute Positioning

Using Camera Selection Maps and the unique Absolute Positioning capability of Dedicated Micros

Oracle Dome cameras, an operator can, with one mouse click, select a camera and send it to view

an area of the site (Pan and tilt). Absolute Positioning is ideal for following someone from camera to

camera around a site and greatly increases event response time, particularly for operators unfamiliar

with a site layout and camera location.

Design of the manual

For ease of use, this manual has three parts:

1. Installation Shows details of how to install the unit and connect external devices.

2. Conguration Shows details of the unit’s menus.

3. Operation Shows quick reference details on how to control the unit.

The order and layout of these pages has been designed to help the setup process. It is

recommended that the menus are edited in sequential order to enable accurate, easy and efcient

setup.

Intelligent Security & Fire Ltd

DV-IP RT

Important Safeguards

Read Instructions

All the safety and operating instructions should be read before the unit is operated.

Power Sources

This unit should be operated only from the type of power source indicated on the manufacturer’s

label.

Servicing

Do not attempt to service this unit yourself as opening or removing covers may expose you to

dangerous voltage or other hazards.

Refer all servicing to qualied service personnel.

Ventilation

Ensure unit is properly ventilated to protect from overheating.

All the safety and operating instructions should be read before the unit is operated.

To prevent re or shock hazard, do not expose this equipment to rain or moisture. The lightning ash

with arrowhead symbol within an equilateral triangle is intended to alert the user of this equipment

that there are dangerous voltages within the enclosure which may be of sufcient magnitude to

constitute a risk of electric shock.

This is a class A product. In a domestic environment this product may cause radio interference in

which case the user may be required to take adequate measures.

Lightning Strike

The unit has some in-built protection for lightning strike, however it is recommended that isolation

transformers be tted to the system in areas where lightning is a common occurrence.

Regulatory Notes and FCC and DOC Information

(USA and Canadian Models Only)

Warning: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at their own expense.

If necessary, the user should consult the dealer or an experienced radio/television technician for

corrective action. The user may nd the following booklet prepared by the Federal Communications

Commission helpful: “How to Identify and Resolve Radio-TV Interference Problems”.

This booklet is available from the US Government Printing Ofce, Washington, DC20402,

Stock No. 004-000-00345-4.

This reminder is provided to call the CCTV system installer’s attention to Art. 820-40 of the NEC that

provides guidelines for proper grounding and, in particular, species that the cable ground shall be

connected to the grounding system of the building, as close to the point of cable entry as practical.

Intelligent Security & Fire Ltd

DV-IP RT

CE Mark

If this product is marked with the CE symbol it indicates compliance with all applicable directives.

Directive 89/336/EEC.

A ‘Declaration of Conformity’ is held at Dedicated Micros Ltd.,

1200 Daresbury Park, Daresbury, Cheshire, WA4 4HS, UK.

Laser

The unit supports an integrated CD/DVD writer, the following are additional warnings associated with

installing and operating the CD/DVD writer, please pay particular attention to this information.

• Caution - Use of controls or adjustments or performance of procedures other than those

specied herein may result in hazardous radiation exposure.

• To prevent exposure to laser emanations (harmful to the eyes), do not attempt to

disassemble this unit.

Intelligent Security & Fire Ltd

DV-IP RT

Installing the Unit

Before you start

Check the contents of the box

Remove all items from the packaging and check the items listed below are present:

• DV-IP RT (either 8, 16 or 32 input)

• IR Remote Control

• IR Remote Control Extender

• USB Mouse

• Power Leads

• Rack mounting brackets

• DV-IP RT Software disc

• DV-IP RT Installation & Operation Guide

• Quickstart Guide

If any of these items are missing, please contact Dedicated Micros Technical Support team.

Note: Before installing the DV-IP RT DVR, carefully read all Safety Instructions and the following

information on where the unit should be located.

Available Accessories

The following accessories can also used in conjunction with the DV-IP RT:

• KBC1 Keyboard

• KBC2 Keyboard

• Managed Storage Unit - Extend storage capacity

• Managed Continuous Archiving - Mirrored RAID1 storage unit

• Congurable 8 disk RAID system (default is RAID5)

For further information about any of the above products, please contact Dedicated Micros customer

services in your region.

Choosing a location for installation

• The DV-IP RT is designed to be desk, shelf or rack mounted.

• Ensure the DV-IP RT is properly ventilated to protect from overheating.

• Ensure there is a 3cm gap on both sides of the unit.

• Ensure the receiving end of the IR remote control extender faces the operator position

and is not more than 3 metres (10 feet) from the operator.

• Ensure the unit is not located anywhere it could be subject to mechanical shocks.

• The unit should be located in an area with low humidity and a minimum of dust. Avoid

places like damp basements or loft spaces.

• If the unit is to be installed in a closed assembly, the maximum operating temperature

must not exceed 40°C (104°F).

• Ensure there is reliable earthing of the mains outlet when tted to supply connections

(other than direct connection to the branch circuit).

• Any branch circuit supplying the unit must be rated at 15Amps.

• It is recommended that an uninterrupted power source be connected to the unit in case

of power failure (to ensure continuous operation of the unit).

Intelligent Security & Fire Ltd

DV-IP RT

ELECTRICALCONNECTIONS

Please ensure the following are available and have been tested prior to the installation:

• Mains point

• Network point

• Network cable

• Active video signals i.e. at least one working camera feed

• PC with CD ROM drive and connection to the same network as the DV-IP RT unit

(Recommended)

Quick Overview of DV-IP RT Record Settings

The DV-IP RT provides as default:

High performance recording on ALL cameras with minimal conguration.

Consistent recording duration and smooth motion video per camera regardless of the number

of cameras.

Default record settings for ‘Real Time’ variant units are MPEG4 25pps, JPEG 4pps or

MultiMode recording.

Default record settings for ‘Near Real Time’ variant units are MPEG4 12pps, JPEG 2pps or

MultiMode recording.

Pre-congured 2, 7, 14 or 30 day storage settings (dependant on model).

Complete Flexibility

The advanced record menu can be used to congure individual cameras to suit specic

requirements e.g. Entry/Exit routes. Various storage sizes are available dependant on the number of

cameras, the storage options and recording rate selected.

The picture quality can easily be increased if less than 30 days standard recording is required.

Note: It is the Installer/Owner’s responsibility to ensure that the record duration is set to the

necessary requirements of the application.

MultiMode Recording

The unit supports MultiMode recording which is a storage technology developed by Dedicated

Micros. This offers the ability to set different recording rates, resolutions and compression formats

across scheduled, normal and alarm modes for each individual camera.

By varying the quality, bit rate and le size of the recorded images, the MultiMode function can

increase recording capabilities of the unit.

MultiMode offers:

Ability to set different recording resolutions.

Ability to set and switch MPEG4 or JPEG compression recording as required.

Ability to set PPS recording rate per camera.

Dynamically switchable resolution when switching from Normal to Event recording.

Dynamically switchable compression between MPEG4 and JPEG from Normal to Event

recording.

Intelligent Security & Fire Ltd

DV-IP RT

Installation

Front Panel connections

Data

DVD-R Internal DVD-R drive (located under hinged ap)

USB USB2.0 connector (located under hinged ap)

LED’s Power - The Power LED will be green to indicate power is connected to the unit

HDD (Hard Disk Drive) - This will ash when images are being stored to the hard disk

Network - The Network LED will be green to indicate a connection

Rear Panel connections

32 Input model

16 Input model

8 Input model

REARPANELDWGSERVER.EPS

Intelligent Security & Fire Ltd

Tabla de contenidos

Otros manuales de Receptor de Dedicated Micros

Dedicated Micros

Dedicated Micros DV-IP NV8 Manual de usuario

Manuales populares de Receptor de otras marcas

Garmin

Garmin GA 23 Manual de usuario

Aiphone

Aiphone PS-12F Manual de usuario

IMES

IMES TCS-01CA-PMI Manual de usuario

BWI Eagle

BWI Eagle AIR-EAGLE SR Manual

AMIMON

AMIMON AMN12310 WHDI Manual de usuario

Dual

Dual DMCPA79BT Instrucciones de funcionamiento

Sound Associates

Sound Associates SA652P Manual de usuario

Sherwood

Sherwood NewCastle R-772 Manual de usuario

Audio

Audio A10-RX Series Manual de usuario

AllSee

AllSee PushShare PSRV1.1 Manual de usuario

DEMAG

DEMAG DRC-DR D2 Manual de usuario

Teleco

Teleco TVRCL868A02 Manual de usuario

Bosch

Bosch RF3222E Manual de usuario

Kramer

Kramer 631R Manual de usuario

Xpress

Xpress xmc10 Manual de usuario

JVC

JVC KD-MR1BTS Manual de usuario

Omega Engineering

Omega Engineering UWTC-REC3 Manual de usuario

e-survey

e-survey E300 Pro Manual de usuario
