Dedicated Micros Eco9 Manual de usuario

Setup Guide

Guide d’installation

Setup-Anleitung

Guía de programación

Guida per l’impostazione

Setup Handleiding

www.dedicatedmicros.com

IntelligentSecurity&Fire

Warning: Do not move the unit whilst the power is connected.

IntelligentSecurity&Fire

IntroductionContents

• Introduction 1

• Features 2

• Important Safeguards 3

• Installing Eco9 4

• Quick Install 6

• Connecting External Devices 7

- Connecting Storage Devices 7

- Connecting to Alarms & Relays 8

- Connecting to an Ethernet network 9

- Connecting Dial-up Devices 10

• Configuring Eco9 10

- Using the Menu 10

- Time, Date & Language 12

- Camera Viewing 13

- Schedule 13

- Record Schedule 14

- System Options 16

- Record Options 19

- Camera Setup 20

- Activity Camera Setup 21

• Operating the Internal CDR 22

• Using Eco9 23

What is Eco9?

Eco9 is a cost effective and easy to use video multiplexer, digital video

recorder, and network video transmitter in a one box solution. This manual

introduces you to the Eco9 and Eco9 with internal CD writer.

A video multiplexer?

• Designed with security in mind.

• Easy to use.

• Operates like a traditional multiplexer, not a PC

• All the feature you would expect from a Dedicated Micros multiplexer:

- Main and Spot monitor.

- Multiscreen displays.

- Activity detection.

- Alarms.

- Scheduling.

- Variable record rates.

A digital video recorder?

• Playback and record simultaneously, without affecting recording

• 31 days or more of time-lapse recordings in one box*.

• Instant access to images recorded on the hard disk with no tapes

Network transmission?

• View live and playback images across the network.

• No extra software to buy, Network Viewing software for Windows™

provided.

• Copy images across the network

*Refers to the 300 GB model at default settings.

ENGLISH

IntelligentSecurity&Fire

Live viewing 

Playback viewing 

Up to 5 network users at once 

Copy images across networks 

E-mail on event activation 

Internal CD Writer (Eco9 with CD Only) 

External storage support via SCSI (check for compatible models) 

The manual has three parts:

1. Installing Eco9

2. Configuring Eco9

3. Using Eco9

Features:

Auto detect cameras on power up 

Auto detect external storage on power up 

Default recording 

Loop-through connections 

Play, record, copy and transmit simultaneously 

Hidden camera option 

Scheduling 

VCR style playback 

Full, Quad and PIP playback 

Activity detection 

Alarms 

Event log with preview window 

Operation

Playback

Events

Installation Network Viewing

External storage devices

ENGLISH

IntelligentSecurity&Fire

Important Safeguards

The Eco9 is available with an integrated CD, please pay particular attention to

the following warnings when installing and using this model.

• Caution - Use of controls or adjustments of performance of procedures

other than those specified herein may result in hazardous radiation

exposure.

• To prevent exposure to laser emanations (harmful to the eyes), do not

attempt to disassemble this unit.

LIGHTNING STRIKE

The Eco9 has some in-built protection for lightening strike, however it is

recommended that isolation transformers be fitted to the system in areas

where lightening is a common occurrence.

REGULATORY NOTES FCC AND DOC INFORMATION

(USA and Canadian Models Only)

WARNING: This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to part 15 of the FCC rules. These

limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and,

if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the user

will be required to correct the interference at their own expense. If necessary,

the user should consult the dealer or an experienced radio/television technician

for corrective action. The user may find the following booklet prepared by the

Federal Communications Commission helpful: “How to Identify and Resolve

Radio-TV Interference Problems”. This booklet is available from the US

Government Printing Office, Washington, DC20402, Stock No. 004-000-00345-

Read Instructions

All the safety and operating instructions should be read before the unit

is operated.

Power Sources

This unit should be operated only from the type of power source

indicated on the manufacturer’s label.

Servicing

Do not attempt to service this unit yourself as opening or removing

covers may expose you to dangerous voltage or other hazards.

Refer all servicing to qualified service personnel.

Ventilation

Ensure unit is properly ventilated to protect from overheating.

To prevent fire or shock hazard, do not expose this equipment to rain or

moisture. The lightning flash with arrowhead symbol within an equilateral

triangle is intended to alert the user of this equipment that there are dangerous

voltages within the enclosure which may be of sufficient magnitude to

constitute a risk of electric shock.

This is a class A product. In a domestic environment this product may cause

radio interference in which case the user may be required to take adequate

measures.

WARNING

ENGLISH

IntelligentSecurity&Fire

Installing

BEFORE YOU START:

Check the contents of the box

The following items are included in the box:

PSU

Mains cable with three pin plug fitted (North America)

Mains cable without plug fitted (other regions)

Mains cable with two pin plug fitted (EC)

Choosing a location for installation

Eco9 is designed to be desk mounted. The following precautions must be

taken when installing Eco9:

• Openings in the unit’s case are provided for ventilation. To prevent

overheating, these openings should not be blocked or covered.

• When stacking units, ensure there is at least a 1/2" (1.5 cm) gap between

each unit.

• Ensure there is a 1" (3cm) gap on either side of the unit.

• Ensure the unit is not located in an area where it is likely to be subjected to

mechanical shocks.

• The unit should be located in an area with low humidity and a minimum of

dust. Avoid places like damp basements or dusty hallways.

• If using external storage, refer to the manufacturer’s instructions for

placement details.

• If the unit is to be installed in a closed assembly, the maximum operating

temperature must not exceed 40oC.

• Ensure there is reliable earthing of the mains outlet when fitted to supply

connections other than direct connections to the branch circuit.

This reminder is provided to call the CCTV system installer’s attention to Art.

820-40 of the NEC that provides guidelines for proper grounding and, in

particular, specifies that the cable ground shall be connected to the grounding

system of the building, as close to the point of cable entry as practical.

CE Mark

This product is marked with the CE symbol and indicates

compliance with all applicable directives.

Directive 89/336/EEC.

A “Declaration of Conformity” is held at Dedicated Micros Ltd.,

11 Oak Street, Swinton, Manchester M27 4FL.

ENGLISH

IntelligentSecurity&Fire

• When connecting the Eco9 to a branch circuit this must be rated 15Amps.

• It is recommended that a UPS (Un-interruptible Power Supply) be

connected to the unit in case of power failure. This will ensure the

continuous operation of the Eco9.

A quick overview of digital recording

Digital multiplex recorders work in exactly the same way as analogue

multiplexers except that they use hard disks to store video, instead of VCR

tapes. Analogue recording uses time-lapse recording to extend the length of

time recorded onto 2 or 3-hour tape - recording fewer pictures every second.

Adjusting the number of pictures recorded every second also extends the

length of time recorded onto the hard disk of a Eco9. However, other factors

also determine the amount of time that can be stored on the disk of a digital

multiplex recorder:

• The image quality

• The record rate

• The hard disk capacity

Image quality

Digital multiplex recorders store images in a compressed format, allowing

images to be recorded more efficiently. The higher the compression, the

smaller the file size, but the image quality will suffer. Eco9 can compress

images between 6KB and 45KB.

ENGLISH

Kilobytes and Gigabytes are units of storage:

1GB = 1024 Megabytes (MB)

1MB = 1024 Kilobytes (KB)

With analogue recording, the image quality is dependent on the type of VCR

being used; VHS or S-VHS. Eco9 allows the image quality to be altered by

adjusting the image size, for example, Low quality is 14KB, Medium is 18KB,

and High is 25KB*.

Using a larger image size will fill the hard disk faster than a smaller image size,

as more space is required to store it. To achieve the same amount of recording

time when a larger image size is used requires the record rate (PPS) to be

reduced.

* Note that as for all digital recording, image quality can vary for different scene types, Medium quality

may be 18KB in one scene, but it may be 30KB or more to get the same quality in a scene with

more detail.

Record rate

The record rate is the amount of pictures recorded to disk in a second, or

pictures per second (PPS). This is a system wide figure, so whether 1 or 9

cameras are recorded, the record rate remains the same. The update rate per

camera can be worked out using the record rate:

Update rate = No. of cameras

Record rate

Calculating recording time

Eco9 calculates the recording time automatically when the record rate and

image quality are entered. Alternatively, an interactive record calculator is

available for download from our web site:

www.dedicatedmicros.com

IntelligentSecurity&Fire

ENGLISH

Eco9 can be installed in as little as 4 steps, and being plug-and-play, cameras

will be detected and recorded automatically.

Note: The Eco9 non-CD version has exactly the same connections as shown.

Connections at rear of the Eco9

Video

VID1 to VID9 - 75Ohm BNC composite camera connections (1V pk-pk)

MON A - Main monitor, 75Ohm BNC composite monitor connection

(1V pk-pk)

MON B - Spot monitor, 75Ohm BNC composite monitor connection (1V

pk-pk)

Data

SCSI - 50-pin HD SCSI-2 connection

NET - RJ-45 10-baseT Ethernet connection

SERIAL 1 - 9-way (Male) D-type RS-232 serial port (PPP modem)

Alarms and relays

ALARMS - 25-Way (Female) D-Type, programmable direct alarms;

NO/NC

RELAYS - 9-Way (Female) D-Type

Eco9 is available with an integral CD writer. The CD writer is accessible from

the front panel of the Eco9.

Front panel layout

Important Information

Selecting CD-R’s and CD-RW’s

The internal CD writer in the Eco9 is not compatible with the Ultra Speed

CDR’s. Ensure that only High Speed or Multi-Speed CDR media is used. This

is normally written on the CDR packaging and on the disk itself.

Quick Install

IntelligentSecurity&Fire

ENGLISH

Connecting External Devices

Devices that can be connected to Eco9 include:

Storage devices

Alarm and relays

Ethernet networks

Dial-up modems

If you do not require any of the above devices to be connected to Eco9, move

on to ‘Configuring Eco9’ - Page 8.

Connecting storage devices

Images are recorded to the internal hard disk for instant playback and

searching by the operator. The capacity of the internal disk affects the amount

of images and time that can be recorded. For example, an Eco9 with a 80GB

hard disk can record for 8 days, while a 300GB hard disk allows one month of

recording.

The internal hard disk is a temporary storage device as the images are

constantly being overwritten after a certain period of time. If images need to be

kept for longer then external storage is required. The internal CD writer can be

used to extend the storage capacity of the Eco9.

Images can be copied from the internal hard disk onto CDR disks for long term

storage. CD’s are ideal for recording relatively small amounts of images such

as events, video clips, or incidents. These images can be played back on any

PC with a CD drive and DM Playback software installed.

The table below shows the recording times at typical recording rates (at

Medium image quality, 18KB):

STEP 1. Connect cameras

Connect cameras to the video inputs marked VID1 to VID9. Use the bottom

row of connectors for looping through to other equipment.

STEP 2. Connect monitors

Connect the video output marked MON A to the Main monitor (digital playback

and multiscreens).

Connect the video output marked MON B to the optional Spot monitor

(analogue full-screen images).

STEP 3. Connect the external devices

If external devices need to be connected to Eco9, go to the next section -

‘Connecting external devices’, before proceeding to Step 4.

STEP 4. Connect power

Once the Eco9 is in its final position and all external devices have been fitted and

powered, connect the PSU to the rear of the unit and apply the power. The power-

up procedure may take up to one minute before Eco9 can be used.

will now record all cameras without any further

programming!

Times indicate all cameras being copied to the CD.

IntelligentSecurity&Fire

ENGLISH

The 50-way high density SCSI-2 port on the rear of the Eco9 can be used as

an alternative to connect to external storage.

Compatible CD writers include; Yamaha CRW2200SX, Yamaha CRW3200SX,

Yamaha CRW-F1SX, Plextor Plexwriter PX-W1210TSE, Plextor Plexwriter PX-

W4012TSE.

Connecting Alarms and Relays

Dry contact alarms can be wired directly to the alarm connection on the back

on the Eco9. There are 10 alarm inputs, one for each camera, and a global

alarm input.

The alarm connections are as follows (view from solder side):

The polarity of the alarms - normally open or normally closed, can be set in the

‘Camera Setup’ menu.

The global alarm input is used to protect images. An alarm trigger performs the

following actions:

Note: If the standard PPS is set to 000PPS this will make the alarm cameras

exclusive record.

Relay connections are as follows:

Important Note: The onboard relays are rated at 24V 500mA, do not attempt

to connect mains power through the relays

IntelligentSecurity&Fire

Otros manuales para Eco9

Tabla de contenidos

Idiomas:

Otros manuales de DVR de Dedicated Micros

Dedicated Micros

Dedicated Micros BX2 Manual del propietario

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manual de usuario

Dedicated Micros

Dedicated Micros SD Range Instrucciones de funcionamiento

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manual de usuario

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manual de usuario

Dedicated Micros

Dedicated Micros D4 Manual de usuario

Dedicated Micros

Dedicated Micros NetVu Connected DS2 Instrucciones de instalación y funcionamiento

Dedicated Micros

Dedicated Micros D3 Manual de usuario

Dedicated Micros

Dedicated Micros DV-IP NV4 Manual de usuario

Dedicated Micros

Dedicated Micros TransVu Express Manual de usuario

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manual de usuario

Dedicated Micros

Dedicated Micros SD Excel Manual de usuario

Dedicated Micros

Dedicated Micros SD Range Manual de usuario

Dedicated Micros

Dedicated Micros DV-IP Series Manual de usuario

Dedicated Micros

Dedicated Micros EcoSense Instrucciones de funcionamiento originales

Dedicated Micros

Dedicated Micros Digital Sprite 2 Instrucciones de instalación y funcionamiento

Dedicated Micros

Dedicated Micros Digital Sprite 2 Instrucciones de instalación y funcionamiento

Dedicated Micros

Dedicated Micros D4 Instrucciones de instalación y funcionamiento

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manual de usuario

Dedicated Micros

Dedicated Micros Eco4 Series Instrucciones de funcionamiento originales

Dedicated Micros

Dedicated Micros SDA-32-6T Manual de usuario

Dedicated Micros

Dedicated Micros SD Range Instrucciones de funcionamiento

Dedicated Micros

Dedicated Micros NetVu Uniplex UP/MAN/002/M Guía de configuración

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manual de usuario

Manuales populares de DVR de otras marcas

FLIR

FLIR M3100E Series Manual de usuario

VTRACKPRO

VTRACKPRO FPRO300 Manual de usuario

Swann

Swann NVR-7085 models Manual de usuario

XtendLan

XtendLan DVR-1670C Manual de usuario

urmet domus

urmet domus 1093/004AHD Manual de usuario

Holux

Holux M1 Manual de usuario

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manual de usuario

Whistler

Whistler D16VRS Manual de usuario

Defender Security

Defender Security 82-20235 Manual de usuario

MISUMI

MISUMI MP-WF100M Manual de usuario

Speco

Speco D8HU Manual de usuario

UST

UST DDR-E04AA Instrucciones de uso

Consolidated

Consolidated Digital Video Recorder Manual de usuario

Mace

Mace DVR0404RW Guía de inicio rápido

RCA

RCA RTD315W Manual de usuario

FSM

FSM Colibri Grande PRO Manual de usuario

Hauppauge

Hauppauge HD PVR 2 Manual de usuario

Identivision

Identivision ICR-PH161i PIONEER Manual de usuario
