Deda Elementi ZERO2DB Manual de usuario

ZERO2DB

USeR’S MAnUAL

Ver. 2 - September 2019 ©Deda Elementi

ZERO2DB

CLINCHER DISC BRAKE WHEELSET

Congratulations on your new Deda Elementi wheels. Please read these instructions

carefully and follow them for correct use. An improper installation or wrong

application of the instructions could damage the product, that will be no more

covered under warranty, damage the bicycle or cause an accident resulting in injury

or death. Since specific tools and experience are necessary for proper installation,

it is recommended that the product be installed by an official Deda Elementi dealer

or a qualified bicycle technician.

GENERAL SAFETY INFORMATION ____________________________________________ pag. 4

WARRANTY _______________________________________________________________ pag. 5

PACKAGING ______________________________________________________________ pag. 6

TECHNICAL SPECIFICATIONS ________________________________________________ pag. 6

TIRES

_____________________________________________________________________ pag. 7

SPROCKETS INSTALLATION _________________________________________________ pag. 8

DISC BRAKE ROTOR _______________________________________________________ pag. 9

FITTING THE WHEELS ON THE FRAME ________________________________________ pag. 10

CLEANING, MAINTENANCE AND REPLACEMENT PARTS ________________________ pag. 13

eng

CONTENTS

eng

GENERAL SAFETY INFORMATION

It is under user’s responsibility to check regularly the product to determine the

need of maintenance or replacement. Wheels and their components are products

wearing during the standard use of the bike, for that reason we recommend users

to regularly inspect their bicycle and parts in order to ﬁnd any damage. If any

doubts or problems occur, stop riding the wheels and have them inspected by an

oﬃcial Deda Elementi dealer or a qualiﬁed bicycle technician.

These wheels have been designed and intended to be used on normal paved

surfaces. In case of use on not paved surfaces or oﬀ-road, wheels can be

subjected to damages, loose their functioning and cause serious accidents

and injury for the user.

Regularly check the wheels to make certain that they are installed correctly to

the bicycle and fastened securely to the frame and fork.

If any bicycle fall or accident occur, stop riding the wheels and have them

inspected carefully by an oﬃcial Deda Elementi dealer or a qualiﬁed bicycle

technician.

Frequently check the status of the wheels parts subjected to wear and if

necessary make the maintenance and/or parts replacement through the

oﬃcial Deda Elementi dealers.

It is recommended to make an inspection after each riding season or every

time in case of problems related to bearing, wheel out of center or damages

to single parts

Install only bicycle tires compatible with rims technical speciﬁcations included

in this user’s manual. The installation of tires not compatible can damage

the rim wheels, invalidate the Deda Elementi Warranty and cause serious

accidents and injury for the user.

Follow the minimum inﬂation pressure recommended by the tire manufacturer.

Never exceed the maximum inﬂation pressure permitted for this Deda

Elementi rim of 7 bar / 100 psi. The use of inﬂation pressures out of this

range can damage the rim, invalidate the Deda Elementi Warranty and cause

serious accidents and injury for the user.

Read the whole User’s Manual carefully and keep it in a safe place for later

reference.

WARRANTY

Deda Elementi warrants that all Deda Elementi products are free from defects in

materials or workmanship for a period of two years after original purchase unless

otherwise stated on the Warranty policy.

The Warranty is valid for the purchase of an original Deda Elementi product only.

2.1 LIMITS OF WARRANTY

In case of sale or product cession, the Warranty will be considered valid for a two

years period only from the original purchase.

The Warranty doesn’t cover damages caused by modifications, even small; any

kind of adaptations or alteration; maintenance performed by an unauthorized

people; use of the product outside the normal riding conditions on paved

road surfaces. The Warranty doesn’t cover even damages caused by impacts,

collisions, falls that may occur for accidental reasons.

The Warranty doesn’t cover aesthetic defects like: matting, chap, fading or other

phenomenons that may occur to the wheels during the use and after the bicycle

cleaning using water in pressure, solvents or similar products, petrol.

In case of imperfections, defects or damages found on the product, the user is

asked to contact the dealer within 10 (ten) days; after the ending of this period,

the Warranty will be no more considered due.

Deda Elementi reserves the right to modify partially or completely the products,

instructions and warranty without any notice to the customer.

eng

TECHNICAL SPECIFICATIONS:

* Sram XDR freehub body version

** Campagnolo freehub body version

*** Tubeless conversion kit not included into the wheels package

****Disc brake rotor not included into the wheel package

The Wheels package you have just purchased contains the following items:

The wheels

User’s Manual

Rim Tapes

PACKAGING

Wheels Model ZERO2DB

Compatibility cassettes

10s Shimano / Sram (with 1.80 mm spacer)

11s Shimano / Sram

*12s Sram

**10-11-12s Campagnolo

Rim

Size 622x19C

Width 24.0mm

Height 30.0mm

Rim tape 622x18mm

Tire Compatibility Clincher o Tubeless (***)

Recommended tire sizes min 700x25 - max 700x32

Hubs Front 100mm

Rear 142mm

Spokes

Front 293 mm; ﬂat; straight pull

Rear Non Drive side 293 mm; ﬂat; straight pull

Rear Drive side 292 mm; ﬂat; straight pull

Nipples 15 mm ABS, aluminum

Disc brake rotor compatibility Shimano® Center Lock (****)

Frames

compatibility

Thru-Axle Front 12x100 mm, Rear 12x142 mm (standard)

Traditional system

Front 100 mm,

Rear 135 mm

(kit available as spare part)

15 mm

Front Thru-Axle

Front TA 15 mm

(kit available as spare part)

Deda ZERO2DB wheels are designed to use clincher tires with inner tubes or Tubeless

tire. The Tubeless conversion kit is not included into the wheels box. Check tires and

inner tubes dimensions according to the rim technical specifications included in this

user’s manual.

WARNING: Do not use tubular or tubeless tires with this wheel. The use of no-

compatible tires with this wheel can cause sudden and unexpected loss of pressure,

loss of control and tire failure causing serious accident and injury for the user.

Before the tire installation check that rim tape is already installed in the right

position inside the rim; if not please install first the rim tape.

Make sure the rim tape cover all the rim bed holes along the entire circumference

of the wheel.

The valve hole on the rim tape has to be placed at the same position of the valve

hole of the rim wheel (Fig. 1).

Install the tire on the wheel and proceed with tire inflation as tire manufacturer

recommendations. Never exceed the maximum inflation pressure permitted for

this Deda Elementi rim of 7 bar / 100 psi.

TIRES

Fig 1

Valve hole

Rim tape

eng

WARNING: for Tubeless tire installation carefully read the instructions of the tire and

tubeless conversion kit manufacturer.

WARNING: Never exceed the maximum inflation pressure recommended by the

wheels manufacturer as indicated in this user’s manual. Excessive tire pressures

could damage the rim structure causing serious accident and injury for the user.

WARNING: Tire installation requires a specific experience of the product, in case

of doubts please contact an official Deda Elementi dealer or a qualified bicycle

technician. During tire installation don’t use tools or tire lever that can fold, damage or

make the rim edge fragile. An incorrect tire installation can cause serious accidents

and injury for the user.

Deda Elementi wheels are available with Shimano® 10-11 speed, Sram® 10-11-12

speed and Campagnolo® 10-11-12 speed cassette. Read and carefully follow the

installation instructions of the sprockets. The rear wheel with Shimano® freehub

body is supplied with a 1.80mm aluminum spacer that is intended to be used with

Shimano® /Sram® 10 speed cassette only . Please don’t use 1.80mm spacer with

11 speed cassette.

Sram 12 speed groupset requires the use of the XD-R freehub body compatible,

available as spare part (part. No. WD17XDRSL).

*with XD-R compatible freehub body

SPROCKETS INSTALLATION

Wheel Type Freehub Cassette Compatibility

Shimano/Sram Sram 12s* Shimano/Sram 11s Shimano/Sram 10s +

dist. 1.80mm

Campagnolo Campagnolo 12s Campagnolo 11s Campagnolo 10s

WARNING: Since specific tools and experience are necessary for proper

sprockets installation, in case of doubts it is recommended that the product will

be installed by an official Deda Elementi dealer or a qualified bicycle technician.

An incorrect sprockets installation can cause serious accidents and injury for the

user.

WARNING: Please make sure that wheel freehub body will be compatible with

your sprockets cassette before proceed with the assembly. The ensure missing of

the compatibility between wheel and sprockets cassette can cause malfunction

of the bicycle drive train causing serious accident and injury for the user.

Deda ZERO2DB Disc Brake wheels are compatible with Shimano® Center Lock

locking systems.

The disc brake rotors are not included into the wheels box.

For Rotors installation with Shimano® Center Lock locking systems read and

carefully follow the instructions of the disc brake manufacturer.

WARNING: Disc brake rotor installation requires a specific experience of the

product.

In case of doubts please contact an official Deda Elementi dealer or a qualified

bicycle technician.

An incorrect rotor installation can cause serious accidents and injury for the user.

DISC BRAKE ROTOR

eng

FITTING THE WHEELS ON THE FRAME

WARNING: Since specific experience is necessary for proper wheels installation, in

case of doubts it is recommended that the product be installed by an official Deda

Elementi dealer or a qualified bicycle technician. An incorrect wheels installation

can cause serious accidents and injury for the user.

Deda ZERO2DB wheels are pre-assembled from the factory with Thru- axle locking

system (Front 12x100, Rear 12x142). The Thru-axles are not included into the

wheels package.

For thru-axle installation and wheels locking to the frame and fork, read and carefully

follow the installation instructions provided by the bicycle and fork manufacturer.

WARNING: An incorrect installation of the through axle can cause the wheel

separation from the fork and cause serious accidents and injury for the user.

Conversion kit for Quick Release (100 mm Front/ 135 mm Rear) and Thru-axle (TA

15 mm Front) are available as spare parts.

Otros manuales para ZERO2DB

Tabla de contenidos

Otros manuales de Accesorios para bicicletas de Deda Elementi

Deda Elementi

Deda Elementi SL30DB Manual de usuario

Deda Elementi

Deda Elementi ZERO2DB Manual de usuario

Deda Elementi

Deda Elementi ALANERA 2020 Manual de usuario

Deda Elementi

Deda Elementi Superbox DCR Manual de usuario

Deda Elementi

Deda Elementi Jet Clip-On Manual de usuario

Deda Elementi

Deda Elementi RS4DB Manual de usuario

Deda Elementi

Deda Elementi SL4DB Manual de usuario

Deda Elementi

Deda Elementi SL38C Manual de usuario

Deda Elementi

Deda Elementi Gera Alloy Manual de usuario

Deda Elementi

Deda Elementi Alanera ALADCRPOB090X40 Manual de usuario

Deda Elementi

Deda Elementi WD30ALCL Manual de usuario

Deda Elementi

Deda Elementi SUPERBOX Manual de usuario

Deda Elementi

Deda Elementi Gera Carbon Manual de usuario

Deda Elementi

Deda Elementi Vinci Manual de usuario

Manuales populares de Accesorios para bicicletas de otras marcas

Sigma

Sigma BC 16.16 Manual de usuario

Playcore

Playcore Dero Setbacks Manual de usuario

VDO Cyclecomputing

VDO Cyclecomputing x3dw Manual de usuario

Cateye

Cateye RAPID X2 Manual de usuario

buratti meccanica

buratti meccanica Clorofilla Trail Manual de usuario

Shimano

Shimano SG-8R20 Instrucciones de funcionamiento

BOB

BOB YAK Manual de usuario

APLIC

APLIC 303303/20190717TW012 Manual de usuario

SRAM

SRAM AXS BlipBox Manual de usuario

Garmin

Garmin EDGE 500 Manual de usuario

Shimano

Shimano FD-RX810 Manual de usuario

Cateye

Cateye V2C - Manual de instrucciones

KMART

KMART 43115907 Manual de usuario

SIGMA SPORT

SIGMA SPORT Buster 2000 Manual de usuario

NVO Components

NVO Components STEM Manual de usuario

DAXYS

DAXYS BP188 Manual de usuario

XLC

XLC BV-W17 Manual de usuario

Akku Vision

Akku Vision e-bike vision 10046 Guía de inicio rápido
