DEBIX Model A Manual de usuario

Polyhex Technology Co., Ltd.

1/108

www.debix.io

DEBIX User Manual

Version: V2.5 (2023-03)

Editor: Polyhex Technology Company Limited (http://www.polyhex.net/)

In recent years, with the ever-increasing product demand in fields of application such as

smart home, smart security, video surveillance and industrial automation, AI chips capable of

resolving problems in these fields have also emerged. Polyhex Technology has responded to

this demand with the launch of DEBIX, a development board based on NXP NPU processor

i.MX 8M Plus. It focuses on machine learning, vision processing, and industrial IoTs, meeting

the application needs of commercial and industrial fields such as education, security

monitoring, industrial automation, smart homes and smart cities.

Figure 1

Polyhex Technology Co., Ltd.

2/108

www.debix.io

INDEX

Chapter 1 About DEBIX ..............................................................................................................4

DEBIX Structure Overview ..................................................................................................5

DEBIX Tech Specs .............................................................................................................. 7

DEBIX I/O Interfaces ........................................................................................................... 8

Display Interface ................................................................................................................12

HDMI Interface ........................................................................................................... 12

LVDS Interface ............................................................................................................13

DSI Interface ...............................................................................................................16

Chapter 2 DEBIX Installation Guide .........................................................................................18

Hardware Installation .........................................................................................................20

Insert Micro SD card ...................................................................................................20

Connect the display device ........................................................................................ 20

Connect the keyboard and mouse ............................................................................. 21

Connect the network cable .........................................................................................21

Connect the power adapter ........................................................................................21

Software Installation .......................................................................................................... 22

Boot from the Micro SD card ......................................................................................22

Boot from eMMC ........................................................................................................ 23

Chapter 3 Using DEBIX ............................................................................................................27

Desktop Introduction ......................................................................................................... 27

System Browser ................................................................................................................ 28

File Management ...............................................................................................................28

First Time Use ................................................................................................................... 29

Change User Password .................................................................................................... 30

Wi-Fi Connection ............................................................................................................... 30

Change Language .............................................................................................................31

Setting up Access Point .....................................................................................................33

Shut Down ......................................................................................................................... 34

The three screens supported by DEBIX ........................................................................... 35

Use lidar module on DEBIX .............................................................................................. 44

Chapter 4 Introduction of Hardware Programming .................................................................48

GPIO Introduction ..............................................................................................................48

Usage of GPIO .................................................................................................................. 50

Polyhex Technology Co., Ltd.

3/108

www.debix.io

Chapter 5 DEBIX I/O Board ..................................................................................................... 53

Brief Introduction of DEBIX I/O Board ...............................................................................53

Interface Definition .............................................................................................................53

Connection with DEBIX Model A .......................................................................................55

DIP Switch Introduction ..................................................................................................... 61

CAN/RS485/RS232 ...........................................................................................................64

Usage of Type-C Debug ....................................................................................................69

Usage of CSI Camera ....................................................................................................... 73

Camera Interface Verification ............................................................................................75

Usage of DSI Display ........................................................................................................ 75

Usage of RTC .................................................................................................................... 78

Usage of LAN2 .................................................................................................................. 80

Usage of Raspberry Pi POE HAT ..................................................................................... 81

Chapter 6 DEBIX LoRa Board ................................................................................................. 85

Brief Introduction of DEBIX LoRa Board ...........................................................................85

Interface Definition .............................................................................................................85

Connection with DEBIX Model A .......................................................................................86

Verify Functions of LoRa Board ....................................................................................... 89

Chapter 7 DEBIX 4G Expansion Board ................................................................................... 91

Brief Introduction of DEBIX 4G Expansion Board ............................................................ 91

Interface definition ............................................................................................................. 91

Connection with DEBIX Model A .......................................................................................92

First use of 4G network ..................................................................................................... 96

Common Troubleshooting ............................................................................................... 104

Chapter 8 DEBIX PoE Module ...............................................................................................105

Brief Introduction of DEBIX PoE Module ........................................................................ 105

Interface definition ........................................................................................................... 105

Connection with DEBIX Model A/B ................................................................................. 106

Usage of PoE Module ..................................................................................................... 108

Polyhex Technology Co., Ltd.

4/108

www.debix.io

Chapter 1 About DEBIX

DEBIX is essentially a versatile single board computer, which can be widely used in artificial

intelligence, machine learning, industry 4.0, edge computation, gateway, IoT, security

monitoring etc..

The following are some of the powerful features of DEBIX:

●Powerful Quad Core Arm ® Cortex ® -A53 CPU with a Neural Processing Unit (NPU)

operating at up to 2.3 TOPS.

●The multimedia capabilities include video encode (including h.265) and decode,

3D/2D graphic acceleration, and multiple audio and voice functionalities.

●Real-time control with Cortex-M7. Robust control networks supported by dual CAN

FD and dual Gigabit Ethernet with Time Sensitive Networking (TSN).

●High industrial reliability with DRAM inline ECC.

●Designed for severe environmental conditions and industrial grade temperature

requirements. The wide CPU temperature range of -40°C to 105°C makes it suitable

for extreme operation environments like public transportation and industrial control

etc.

●The size of the board is nearly the same with a credit card, it has multiple extended

ports. This allows DEBIX to give full processor performance while being free from

application restrictions in physical space.

●Support mainstream operating systems including Android, Ubuntu, Yocto and

Windows 10 IoT.

DEBIX has a clear edge in the area of facial and object recognition applications which

combine machine learning and visual processing. Take facial recognition as an example:

DEBIX can simultaneously detect and identify the body frames and facial features of multiple

people. It can also be used in traffic control to identify vehicle types and information of drivers.

Using NPU to perform recognition operations not only increases the recognition speed, but

also sees a noticeable reduction to the burden on the CPU.

Polyhex Technology Co., Ltd.

5/108

www.debix.io

DEBIX’s TSN technology makes it essential for Industrial 4.0 applications, as it meets the

needs of industrial enterprises with precision oriented production time control, thus

increasing the interconnection speed of the IoT.

DEBIX Structure Overview

DEBIX's interface features a compact arrangement, the interface components are visible at a

glance. Let’s learn more about DEBIX’s interface through the following Figure 2.

Figure 2

Figure 3

Polyhex Technology Co., Ltd.

6/108

www.debix.io

DEBIX uses NXP i.MX 8M Plus based SoC, it has 2GB/4GB/6GB/8GB memory, supports

Gigabit Ethernet, dual-band wireless network and Bluetooth 5.0. The data specifications are

as below:

System

CPU

NXP i.MX 8M Plus (default), 4 x Cortex-A53, comes with an integrated

neural processing unit (NPU) that delivers up to 2.3 TOPS. Industrial

grade CPU runs at 1.6GHz, and commercial grade CPU runs at up to

1.8GHz. (i.MX 8M Plus series CPU optional)

with C520L 3D GPU andGC7000UltraLite 3D GPU

Memory

2GB LPDDR4 (4GB/6GB/8GB optional)

Storage

Default: Micro SD card(The Micro SD card should be prepared by the

users themselves, the capacity can be 8GB/16GB/32GB/64GB/128GB)

(Onboard 8GB/16GB/32GB/64GB/128GB eMMC optional)

Operating System

Android 11, Ubuntu 20.04, Yocto-L5.10.72_2.2.0, Windows 10 IoT

Enterprise

I/O Interfaces

Gigabit Network

10/100/1000M 2 Ethernet interfaces

1 x RJ45 with POE power supply (need POE power supply

module)

1 x pin header (without network transformer)

WIFI & BT

2.4G & 5G dual-frequency WIFI, BT5.0

USB

4 x USB 3.0 Host Type-A, 1 x USB 2.0 OTG Type-C

Audio

1 x 3.5mm headphone and composite microphone port

HDMI

1 x HDMI OUT

Expansion

40-Pin Double-Row

Headers

(1) 3 x UART, 2 x SPI, 2 x I2C, 2 x CAN, 1 x PWM, 2 x GPIO, dedicated

interfaces can be reused as GPIO ports

(2) 1 x SPDIF digital audio input/output

(3) 5V power supply, system reset, ON/OFF

LVDS

1 x LVDS, single & dual channel 8bit, double-row pin headers

MIPI CSI

1 x MIPI CSI, support 4-lane, 24Pin 0.5mm Pitch FPC socket

MIPI DSI

1 x MIPI DSI, support 4-lane, 24Pin 0.5mm Pitch FPC socket

PCIe

1 x PCIe, support PCIe x1, 19Pin 0.3mm Pitch FPC socket

Polyhex Technology Co., Ltd.

7/108

www.debix.io

Power Supply

DC 5V/3A Type-C

Mechanical & Environmental

Size

85.0mm x 56.0mm

CPU Temperature

-40 ˚ C to 105 ˚ C

DEBIX Tech Specs

Figure 4

Like any standard computer, DEBIX consists of a range of different computer components.

The most important component is the "brain" of the computer, the system-on-chip/SoC in the

center at the front of the motherboard.

The SoC contains most of the components of the computer, often containing both the central

processing unit (CPU) and the graphics processing unit (GPU). Next to the SoC you will find

another larger chip, the random access memory (RAM).

Polyhex Technology Co., Ltd.

8/108

www.debix.io

Figure 5 CPU&GPU Figure 6 RAM

There is a component with a metal cover in the upper left corner of the motherboard, it

contains the wireless communication module which contains the wireless network card and

Bluetooth components.

Figure 7

The eMMC is in the right down direction of WIFI & BT, it integrates a controller in its

enclosure, provides standard interfaces and manage the flash. The PMIC(PCA9450c) is in

the right down corner of the motherboard, it manages the power devices of the host machine.

DEBIX I/O Interfaces

DEBIX has 4 USB3.0 Host A ports, they are all USB3.0 interfaces. The Ethernet port is on

the right side of the USB 3.0, it connects DEBIX to the network through a cable with an RJ45

connector. There are two status indicators below the Ethernet port to show the signal

upstream or downstream status, one is Link, the other is Active:

Polyhex Technology Co., Ltd.

9/108

www.debix.io

Figure 8

There is a 3.5mm headphone interface with audio input/output function on the edge of the

board. Next to the headphone interface, there is a Type A HDMI connector for connecting a

display device, TV or projector. On the left side, there is a multifunctional OTG port for

programming, system updating, or USB drive & hard disk connecting etc. Next to the OTG

interface is the USB Type-C power port for DEBIX power supply. We recommend using a

5V/3A power adapter to ensure sufficient power supply.

Figure 9

Next to the OTG port is the CSI connector for camera module connection. There is also a

DSI connector for MIPI touch screen connection.

Figure 10

The 40-pin GPIO connectors on one side of DEBIX are for external hardware connections

such as LEDs, buttons, sensors, and functional modules, among the 40 pins, the 4 pins on

the right side of the 40 pins are called POE (Power Over Ethernet) connectors.

Polyhex Technology Co., Ltd.

10 /108

www.debix.io

Figure 11

U77410n0der the GPIO pins, there are two connectors, the right side connector J6 is 2x6Pin

LAN pins for connecting to the local network, the left side connector J10 is 2x15Pin LVDS

pins, it is a LVDS display output interface, it support single channel and dual channel LVDS

display.

Figure 12

Este manual sirve para los siguientes modelos

Tabla de contenidos

Manuales populares de Computadora de placa única de otras marcas

WIN Enterprises

WIN Enterprises PL-80910 Manual de usuario

AXIOMTEK

AXIOMTEK SBC81206 Series Manual de usuario

Embest

Embest SOM-PH8800 Manual de usuario

SeaLevel

SeaLevel SBC-R9 Manual de usuario

SMART Embedded Computing

SMART Embedded Computing ATCA-8310 Manual de usuario

WinSystems

WinSystems PPM-LX800-G Manual de usuario

GIGAIPC

GIGAIPC QBiX-PPC Series Manual de usuario

OLIMEX

OLIMEX A10S-OLinuXino-MICRO Manual de usuario

Commell

Commell FS-978 Manual de usuario

GIGAIPC

GIGAIPC QBiP-8665A/ Manual de usuario

VersaLogic

VersaLogic Python EBX-11 Manual de usuario

Micro Computer Specialists

Micro Computer Specialists IRV-3702 Manual de usuario

CompuLab

CompuLab SB-A510 Manual de usuario

Boser

Boser HS-7321 Manual de usuario

Premier Farnell

Premier Farnell Embest SBC8530 Manual de usuario

MicroSys Electronics

MicroSys Electronics miriac SBC-LS1043A2 Manual de usuario

Aaeon

Aaeon UP Manual de usuario

Portwell

Portwell WUX Series Manual de usuario
