DaytonAudio HTA50BT Manual de usuario

HYBRID STEREO

TUBE AMPLIFIER

Model: HTA50BT User Manual

Thank you for purchasing the Dayton Audio HTA5 0BT Hybr id Stereo Tube Ampliﬁer. The tube preamp

stage impar ts a warm, natural sound quality while the solid state power amp offers superb audio ﬁdelity

and efﬁciency. Multiple input options including streaming audio from USB devices are available, and

Bluetooth 5.0 provides reﬁned wireless streaming from your mobile devices.

Features:

• 25W per channel RMS x2 into a 4 ohm load

• Built-in USB DAC for streaming digital media

• Bluetooth 5.0 wireless connectivity

• Doublesasahighﬁdelityheadphoneampliﬁer

• RCA mono subwoofer output

• Brushed aluminum housing lends a clean, modern look

• Wide variety of audio input options

• Short circuit protection circuitry

Top Panel:

1. Source Indicator

2. Source Selector

3. Play/Pause

4. Previous Track

5. Next Track

Front Panel:

6. Volume Control

Rear Panel:

7. Bluetooth Antenna

TurnthisantennatoaverticalpositionpriortousingtheBluetoothfeatureoftheampliﬁer.

8. PC-USB

9. AUX 2 Input

10. AUX 1 Input

11. Coaxial

12. Optical

13. Headphone Output

The HTA50BT doublesas aheadphoneampliﬁerthatwilleasilydrivemost headphones to

deliver a colossal sound stage and effortless dynamic range. The 1/8" stereo jack allows the

connection of most headphones.

Note: When headphones are plugged into the headphone jack, the speaker output connections

are disengaged.

14. Subwoofer Output

15. Front Left Speaker Connection

The speaker output connections utilize high quality binding posts which are color coded for easy

polarityidentiﬁcation.Thebindingpostswillacceptbananaplugsorbarewireupto14AWG.

16. Front Right Speaker Connection

The speaker output connections utilize high quality binding posts which are color coded for easy

polarityidentiﬁcation.Thebindingpostswillacceptbananaplugsorbarewireupto14AWG.

17. AC Power Connection

18. Input Voltage Selector

Thevoltageselectorswitchallowstheusertochangetheinputvoltagefortheampliﬁerbased

on their region’s voltage.

Top Panel

Front Panel

Rear Panel

Important Safety Instructions

To reduce the risk of electric shock, do not remove cover. No user

serviceable parts inside. Refer servicing to qualied personnel. To

reduce the risk of re and shock do not expose unit to rain or moisture.

The unit should be connected to an earth grounded AC electrical

socket. The unit should be operated in a well ventilated area. Minimum

clearance is 2 inches from the ventilation openings.

Dayton Audio®Last Revised: 1/12/2021

daytonaudio.com

tel + 937.743.8248

info@daytonaudio.com

705 Pleasant Valley Dr.

Springboro, OH 45066

USA

5-Year Limited Warranty

See daytonaudio.com for details

Speciﬁcations:

Power Output: 25 watts RMS x 2 into 4 ohms

Minimum Speaker Impedance: 4 ohm

Frequency Response: 20-20,000 Hz, ±2 dB

Channel Separation: 80 dB

Dynamic Range: >83 dB

Signal-to-Noise Ratio: >85 dB

Preampliﬁer Tubes: 6K4 x 2, 6UI x 2

Headphone Amp Output: 30 mW @ 600 ohms; 20 mW @ 300 ohms;

15 mW @ 32 ohms; 10 mW @ 16 ohms

(maximum @ 1 kHz, <1% THD+N)

Bluetooth Version: 5.0

Input Impedance: 47k ohms (minimum)

Input Sensitivity: 500 mV

Dimensions: 6.3" H x 7.5" W x 9.2" D

Weight: 6.6 lbs
