Datalogic DS2x00N-DS4800 Series Guía
DS2X00N-DS4800 SCANNER FAMILY
SETUP PROCEDURE USING PROGRAMMING BARCODES
1 ID-NET™ NETWORK SETUP USING PROGRAMMING
BARCODES
For any DS2x00N-DS4800 Family scanner, programming barcodes can be used to setup the
ID-NET™ built-in high-speed interface dedicated for high-speed reader interconnection.
ID-NET™ is in addition to the Main and Auxiliary serial interfaces.
Following topologies are available:
ID-NET™ M/S Synchronized: Single station – multiple scanners
The ID-NET™ interface allows local connection of multiple scanners that are reading on
different sides of the same target. All scanners share a single presence sensor and
activate/deactivate simultaneously.
At the end of each reading phase a single data message is transmitted to the host.
Thanks to ID-NET™, data communication among scanners is highly efficient so that an
immediate result will be available.
Main Serial Interface (RS232 or RS485)
External Trigger (for On-Line Mode)
ID-NET™ (up to 16 devices - practical limit)
Host
13
2
Master
Slave#1 Slave#n
Power
Setup Procedure Using Programming Barcodes
2
ID-NET™ M/S Multidata: Multiple stations – single scanner
The ID-NET™ interface allows connection of scanners that are reading objects placed on
independent conveyors. All scanners are typically located far away from each other and they
use a dedicated presence sensor.
At the end of each reading phase, every scanner transmits its own data message to the host.
Thanks to ID-NET™, data collection among readers is accomplished at a high speed without
the need of an external multiplexing device. This leads to an overall cost reduction and to
simplified system wiring.
Terminal
Main Serial Interface (RS232 or RS485)
Auxiliary Serial Interface (Local Echo) (RS232)
External Trigger (for On-Line Mode)
ID-NET™ (up to 32 devices, max network extension of 1000 m)
Host
14
3
2
Master Slave#1 Slave#n
Power
Setup Procedure Using Programming Barcodes
3
1. Press and hold the X-PRESS™ button to enter the “AutoLearn Mode”. Once button is
pressed, the LED cycle appears as follows:
SETUP
LEARN
TEST
READ
Y
GOOD
TRIGGER
COM
STATUS
SETUP
LEARN
TEST
READ
Y
GOOD
TRIGGER
COM
STATUS
SETUP
LEARN
TEST
READ
Y
GOOD
TRIGGER
COM
STATUS
SETUP
LEARN
TEST
READ
Y
GOOD
TRIGGER
COM
STATUS
Just pressed.
After 2 seconds.
After 4 seconds.
Release the button to
enter the AutoLearn
Mode.
The laser beam turns ON
and the yellow LEARN
LED blinks: the
AutoLearn Mode is
working.
2. Now, put the barcode related to the planned role and address in front of the scanner.
The picture below shows, as example, the scanner configuration as “Slave 1” 1:
3. Once the scanner has successfully read the code, the LEDs stay on steady for 2
seconds:
SETUP
LEARN
TEST
READ
Y
GOOD
TRIGGER
COM
STATUS
Successful reading.
1the barcodes shown are examples, only. Use the barcodes in the Network Layout Barcodes paragraph for the
actual programming.
Slave 1
Setup Procedure Using Programming Barcodes
4
4. The scanner is programmed and the AutoLearn Mode ends. The green “ready” LED
is on.
SETUP
LEARN
TEST
READ
Y
GOOD
TRIGGER
COM
STATUS
Programming done.
5. Repeat steps 1..3 above to configure all the slaves and master. The maximum
number of scanners is 32, including the master.
6. Connect the master scanner to a PC by means of the Genius™ configuration software.
Master
Master
Slave 1
Slave n
Setup Procedure Using Programming Barcodes
5
7. Start the Genius™ Express Network Setup procedure. Refer to the Help On Line
document for details.
NOTE
Any network role can also be programmed using Genius™. Refer to the
Help On Line documentation for further details.
Setup Procedure Using Programming Barcodes
6
NETWORK LAYOUT BARCODES
ID-NET™ M/S Synchronized
Ì$+SYN00$-dÎ
Master
Ì$+SYN01$-kÎ
Slave 1
Ì$+SYN02$-rÎ
Slave 2
Ì$+SYN03$-yÎ
Slave 3
Ì$+SYN04$-ÄÎ
Slave 4
Ì$+SYN05$-ÂÎ
Slave 5
Ì$+SYN06$-'Î
Slave 6
Ì$+SYN07$-.Î
Slave 7
Setup Procedure Using Programming Barcodes
7
ID-NET™ M/S Synchronized
Ì$+SYN08$-5Î
Slave 8
Ì$+SYN09$-<Î
Slave 9
Ì$+SYN10$-jÎ
Slave 10
Ì$+SYN11$-qÎ
Slave 11
Ì$+SYN12$-xÎ
Slave 12
Ì$+SYN13$-ÃÎ
Slave 13
Ì$+SYN14$-ÊÎ
Slave 14
Ì$+SYN15$-&Î
Slave 15
Setup Procedure Using Programming Barcodes
8
ID-NET™ M/S Multidata
Ì$+MUL00$-8Î
Master
Ì$+MUL01$-?Î
Slave 1
Ì$+MUL02$-FÎ
Slave 2
Ì$+MUL03$-MÎ
Slave 3
Ì$+MUL04$-TÎ
Slave 4
Ì$+MUL05$-[Î
Slave 5
Ì$+MUL06$-bÎ
Slave 6
Ì$+MUL07$-iÎ
Slave 7
Setup Procedure Using Programming Barcodes
9
ID-NET™ M/S Multidata
Ì$+MUL08$-pÎ
Slave 8
Ì$+MUL09$-wÎ
Slave 9
Ì$+MUL10$->Î
Slave 10
Ì$+MUL11$-EÎ
Slave 11
Ì$+MUL12$-LÎ
Slave 12
Ì$+MUL13$-SÎ
Slave 13
Ì$+MUL14$-ZÎ
Slave 14
Ì$+MUL15$-aÎ
Slave 15
Setup Procedure Using Programming Barcodes
10
ID-NET™ M/S Multidata
Ì$+MUL16$-hÎ
Slave 16
Ì$+MUL17$-oÎ
Slave 17
Ì$+MUL18$-vÎ
Slave 18
Ì$+MUL19$-}Î
Slave 19
Ì$+MUL20$-DÎ
Slave 20
Ì$+MUL21$-KÎ
Slave 21
Ì$+MUL22$-RÎ
Slave 22
Ì$+MUL23$-YÎ
Slave 23
