Datacom Systems WANswitch W2358DSL Instrucciones de instalación

WAN

switch

™

HARDWARE

guide

WANswitch™/W2358DSL

LINKS

12345678

analyzer A

analyzer B

daisy A

daisy B

WAN

switch

™

/W2358D

DATACOMsystems

Empowering Network Professionals

™

DATACOM

SYSTEMS INC™

March 2002

W2358DSL

Part Number: 541-0052-C.01

WAN

switch

™

HARDWARE

guide

iii

Printed in the United States of America. No part of this publication

may be reproduced, stored in a retrieval system, or transmitted, in

any form or by any means, electronic, mechanical, photocopying,

recording, or otherwise, without the prior written permission of

Datacom Systems, Inc. legal department at 9 Adler Drive, East

Syracuse, New York 13057-1290, or call 315-463-9541.

License Agreement

Notice To All Users: For the specific terms of your license to

use the software that this documentation describes, consult the

readme.1st, license.txt, or other license document that accom-

panies your software, either as a text file or as part of the soft-

ware packaging. If you do not agree to all of the terms set forth

therein, do not install the software. If applicable, you may

return the product to the place of purchase for a full refund.

Proprietary Notice

This document contains proprietary information about the

WANswitch™and is not to be disclosed or used except as autho-

rized by written contract with Datacom Systems, Inc.

Trademark Attribution

DS3 ACTIVEtap™, DS3switch™, FDDIswitch™, FIBER-

splitter™, FIBERswitch™, FIBERSWITCHsystem™, GIGABIT-

switch™, INSERTswitch™, INSERTunit™, LANswitch™,

MULTINETswitch™, NETlogic Pro™, NETspan™, PERMA-

LINK™

, PROline™, RMON SWITCHINGanalyzer™,

UNIVERSALswitch™, and WANswitch™are trademarks of

Datacom Systems, Inc. 1ST in Switching Solutions®,

DATACOMsystems®, LANclipper®, MANAgents®, and

MULTIview®are registered trademarks of Datacom Systems,

Inc. All other registered and unregistered trademarks are the

sole property of their respective owners. All specifications may

be changed without notice.

Preface

HARDWAREguide, Audience . . . . . . . . . . . . . . . . . . . . . .v

Customer Service, World Wide Web . . . . . . . . . . . . . . . . .vi

Introduction

Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Hardware Installation

Connection Instructions (LM 2000 NIC) . . . . . . . . . . . . . .2

Connection Instructions (WANic) . . . . . . . . . . . . . . . . . . . .4

Specs

General, Electrical Environmental, Mechanical . . . . . . . .A1

Panel Description

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B1

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B3

Daisy-Chain

Daisy-Chain Addressing, Connection Instructions . . . . . .C1

Hardware Installation (LM 2000 NIC) . . . . . . . . . . . . . . .C3

Hardware Installation (WANic) . . . . . . . . . . . . . . . . . . . .C5

Troubleshooting

General, No Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D1

Control Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D3

Access Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D5

Warranty

Warranty, Limitation On Liability . . . . . . . . . . . . . . . . . .E1

TABLE OF

CCOONNTTEENNTTSS

HARDWAREguide

This HARDWAREguide is written assuming that you are

installing the WANswitch™with a network analyzer such as

Sniffer Technologies DSS/RMON Pro console as the nerve cen-

ter of a Distributed Sniffer System. Further, it is assumed that

switch configuration will take place at a central location using

Datacom Systems ATTACHit™switch control software for

Windows9x/NT/2000. Below is a description of how this

HARDWAREguide is organized.

Section/Appendix Contents

Preface HARDWAREguide Purpose

and Scope

Introduction Product Overview

Hardware Installation of Switch

Specifications Switch Information

Panel Description Front & Rear Details

Daisy-Chain Multiple Switches

Troubleshooting Solving Common Problems

Warranty Our Guarantee to You

Audience

This HARDWAREguide is written for the person who must

install and connect a WANswitch™. The installer is assumed to

be familiar with Windows9x/NT/2000, know how networks

operate, and have operating knowledge of a network analyzer

such as Sniffer Technologies DSS/RMON Pro.

PPRREEFFAACCEE

Customer Service

This HARDWAREguide was written to help you get to know

your new WANswitch™quickly and easily. We would wel-

come any comments or suggestions you may have regarding

this HARDWAREguide. Please send your remarks and rec-

ommendations via mail, telephone, facsimile, or Internet E-

mail.

Datacom Customer Service personnel are available from 8 AM

to 5:30 PM Eastern time, weekdays. Customer Service is avail-

able via telephone, facsimile, and Internet E-mail. Outside of

support hours, please leave a voice message and our Customer

Service Staff will return your call as soon as possible.

Mail: Datacom Systems, Inc.

Customer Service

9 Adler Drive

East Syracuse, NY 13057-1290

Tel: (315) 463-9541

FAX: (315) 463-9557

E-mail: [email protected]

World Wide Web

You can obtain additional information about Datacom

Systems, Inc. and its products and services from the World

Wide Web at http://www.datacomsystems.com.

PPRREEFFAACCEE

Product Description

Until Datacom’s WANswitch™, there has been no means of

cost effective resource sharing to monitor all the network

links of a Wide Area Network. The WANswitch™from

Datacom Systems, Inc. is the key that unlocks network vis-

ibility between links of a Wide Area Network environment.

The WANswitch™provides a connection that allows access

to meet whatever monitoring or analysis requirements your

networks may have.

Like many network managers, you have an urgent need to

provide easy connectivity between an Analyzer and an

array of attached Wide Area Networks. The Datacom

WANswitch™is capable of providing connectivity for V.35,

RS232, RS422, RS423, RS530, X.21, V.10, and V.11 Wide

Area Networks.

The WANswitch™is capable of moving Wide Area

Network protocol analyzers transparently from one net-

work link to another under computer control. The

W2358DSL is designed to permit sharing two WAN proto-

col analyzers between 8 network links or up to 32 network

links by daisy-chaining four WANswitches™.

IINNTTRROODDUUCCTTIIOONN

Connection Instructions (LM 2000 NIC)

The typical installation described herein will be for a

WANswitch™with the Pentium II Sniffer Technologies single

port WAN RS/V (LM 2000 NIC) Analyzer running

Sniffer®

Distributed Analysis Software.

Installation for a single

W2358DSL

is shown in Figure 1

using DRL311-2-4 V.35 Y-Cables to connect to the Wide

Area Networks. Installation for a single

W2358DSL

shown in Figure 2 using a Model M3415A WANlink™Panel

to connect to the Wide Area Networks. Make the W2358DSL

interconnection between a DSS Analyzer and individual net-

work links as follows:

Step 1: Connect the

MONITOR

port of one of the DSS

Analyzers to the

Common A

port of the WANswitch™ using a

DRL312-3 Common Cable.

Step 2: Connect the

MONITOR

port of the other DSS

Analyzer to the

Common B

port of the WANswitch™ using a

DRL312-3 Common Cable.

Step 3: Connect the DRL341-3-3 Control Y-cable DB9

Male lead labeled “

” to the COM 1 port of one of the DSS

Analyzers.

NOTE:

For single DSS Analyzer installations the DB9 Male

lead labeled “

” has been factory tie-wrapped into a 2-inch

coil approximately 8-inches from the common connector so it

can be easily stored above, below, or hang innocuously

behind the DSI switch. To install two Analyzers the DB9

Male lead labeled “

” tie-wrap is removed to make the

entire lead length available for installation.

Step 4: Connect the DRL341-3-3 Control Y-cable DB9

Male lead labeled “

” to the COM 1 port of the other DSS

Analyzer.

Step 5: Connect the DB9 Female lead of the DRL341-3-3

Control Y-cable to the

Control

port of the WANswitch™.

Step 6: Connect network cables to each link port.

Step 7: Connect the Power Supply 5-pin Male DIN connector

into the

POWER

port of the WANswitch™and then plug the

Power Supply into the external power source wall receptacle.

A green light within the center of the Datacom front panel

logo indicates power is on.

HARDWARE

IINNSSTTAALLLLAATTIIOONN
