Datacom Systems MULTINETswitch D28100BTSL Instrucciones de instalación

MULTINETswitch™/D2845TRSL

12345678

WAN

LAN

LINKS

SEGMENTS

MULTINETswitch™/D28100BT

DATACOMsystems

NETWORKS

12345678

WAN

LAN

LINKS

SEGMENTS

MULTINETswitch™/D2845TR

DATACOMsystems

NETWORKS

MULTINET

switch

™

HARDWARE

guide

MULTINETswitch™/D28100BTSL

Empowering Network Professionals

™

DATACOM

SYSTEMS INC™

December 2001

D28100SLseries

D28100BTSL

D2845TRSL

Part Number: 541-0053-B.04

MULTINET

switch

™

HARDWARE

guide

tion may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, pho-

tocopying, recording, or otherwise, without the prior written permission of Datacom Systems, Inc. To obtain this permission,

write to the attention of the Datacom Systems legal department at 9 Adler Drive, East Syracuse, New York 13057-1290, or call

315-463-9541.

Trademark Attribution

DS3 ACTIVEtap™, DS3switch™, FDDIswitch™, FIBERsplitter™, FIBERswitch™, FIBERSWITCHsystem™, GIGABITswitch™,

INSERTswitch™, INSERTunit™, LANswitch™, MULTINETswitch™, NETspan™, PROline™, RESEARCHpro™, RMON

SWITCHINGanalyzer™, UNIVERSALswitch™, and WANswitch™are trademarks of Datacom Systems, Inc. 1ST in Switching

Solutions®, DATACOMsystems®, LANclipper®, MANAgents®, and MULTIview®are registered trademarks of Datacom Systems,

Inc. All other registered and unregistered trademarks are the sole property of their respective owners. All specifications may be

changed without notice.

License Agreement

Notice To All Users: For the specific terms of your license to use the software that this documentation describes, consult the

readme.1st, license.txt, or other license document that accompanies your software, either as a text file or as part of the software

packaging. If you do not agree to all of the terms set forth therein, do not install the software. If applicable, you may return the

product to the place of purchase for a full refund.

Proprietary Notice

This document contains proprietary information about the MULTINETswitch™and is not to be disclosed or used except as

authorized by written contract with Datacom Systems, Inc.

iii

Compliance Testing

CAUTION: Changes or modifications to this unit not express-

ly approved by the party responsible for compliance could void

the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply

with the limits for a Class A digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide rea-

sonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manu-

al, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be

required to correct the interference at his own expense.

Certifications

This equipment has been tested and found to meet the radiated

and conducted emission limits for a Class A product of

EN 55022 to the EMC Directive 89/336/EEC requirements.

This equipment has been tested and found to meet the immuni-

ty levels for Class 1 tested to level 4 for EN 6100-4-2, level

2for EN 6100-4-3, level 2 for EN 6100-4-4, and level 2 for

EN 6100-4-5 to the EN 50082-1 requirements.

Preface

USERguide, Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . .v

Customer Service, World Wide Web . . . . . . . . . . . . . . . . .vi

Introduction

Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Hardware Installation

Connection Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Specs

General, Electrical Environmental, Mechanical . . . . . . . .A1

Panel Description

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B1

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B3

Daisy-Chain

Daisy-Chain Addressing, Connection Instructions . . . . . .C1

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .C3

MULTIview™Installation . . . . . . . . . . . . . . . . . . . . . . . . .C5

Troubleshooting

General, No Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D1

Control Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D3

Access Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D5

Warranty

Warranty, Limitation On Liability . . . . . . . . . . . . . . . . . .E1

TABLE OF

CCOONNTTEENNTTSS

USERguide

This USERguide is written assuming that you are installing the

MULTINETswitch™with a network analyzer such as Sniffer

Technologies DSS/RMON Pro console as the nerve center of a

Distributed Sniffer System. Further, it is assumed that switch

configuration will take place at a central location using

Datacom Systems ATTACHit™switch control software for

Windows95/98/NT. Below is a description of how this

USERguide is organized.

Section/Appendix Contents

Preface USERguide Purpose and Scope

Introduction Product Overview

Hardware Installation of Switch

Specifications Switch Information

Panel Description Front & Rear Details

Daisy-Chain Multiple Switches

Troubleshooting Solving Common Problems

Warranty Our Guarantee to You

Audience

This USERguide is written for the person who must install and

connect a MULTINETswitch™. The installer is assumed to be

familiar with Windows95/98/NT, know how networks operate,

and have operating knowledge of a network analyzer such as

Sniffer Technologies DSS/RMON Pro.

PPRREEFFAACCEE

Customer Service

This USERguide was written to help you get to know your

new MULTINETswitch™quickly and easily. We would wel-

come any comments or suggestions you may have regarding

this USERguide. Please send your remarks and recommen-

dations via mail, telephone, facsimile, or Internet E-mail.

Datacom Customer Service personnel are available from 8 AM

to 5:30 PM Eastern time, weekdays. Customer Service is avail-

able via telephone, facsimile, and Internet E-mail. Outside of

support hours, please leave a voice message and our Customer

Service Staff will return your call as soon as possible.

Mail: Datacom Systems, Inc.

Customer Service

9 Adler Drive

East Syracuse, NY 13057-1290

Tel: (315) 463-9541

FAX: (315) 463-9557

E-mail: [email protected]

World Wide Web

You can obtain additional information about Datacom

Systems, Inc. and its products and services from the World

Wide Web at http://www.datacomsystems.com.

PPRREEFFAACCEE

Product Description

Until Datacom’s MULTINETswitch™, there has been no

efficient means to monitor both Local Area Network seg-

ments and Wide Area Network links passing through a hub.

The MULTINETswitch™from Datacom Systems, Inc. is

the key that unlocks both network visibility in Local Area

Network and Wide Area Network environments at the same

time. The MULTINETswitch™provides a connection that

allows access to meet whatever monitoring or analysis

requirements your networks may have.

Like many network managers, you have an urgent need to

monitor and analyze paths between work stations and hubs.

The Datacom MULTINETswitches™are capable of switch-

ing up to two “Network Devices” between MULTINET

segments and links.

The MULTINETswitch™is capable of moving Sniffer

Technologies Distributed Sniffer System®(DSS) Servers

transparently from one network segment or network link to

another under computer control. The 2x8

MULTINETswitches™are designed to permit sharing one

and two DSS Servers, respectively, between eight network

segments and eight network links or up to 16 network seg-

ments and 16 network links by daisy-chaining two

MULTINETswitches™.

IINNTTRROODDUUCCTTIIOONN

Connection Instructions

The typical installation described herein will be for a

MULTINETswitch™with the Sniffer Technologies

Distributed Sniffer Systems®(DSS).

A representative installation for a 2x8 MULTINETswitch™

with a dual DSS is shown in Figure 1. A 2x8

MULTINETswitch™installation with two DSSs is shown in

Figure 2. Make the MULTINETswitch™interconnection

between the DSS Server(s), and individual network segments

as follows:

Step 1: For a MULTINETswitch™to dual DSS Server, con-

nect the

LAN MONITOR

port of the DSS Server to the

LAN

Common Port

of the MULTINETswitch™using one of the

cables as shown in Table 1. Connect the

WAN MONITOR

port

of the DSS Server to the

WAN Common Port

of the

MULTINETswitch™using a DRL312-3 cable.

Step 2: For a MULTINETswitch™to dual DSS Server, con-

nect the COM 1 port of the DSS Server to the

Control

port of

the MULTINETswitch™using a DRL293A-3 Control Cable.

Step 3: Connect network cables going to each network seg-

ment port and link port.

Step 4: Connect the Power Supply 5-pin DIN Male connec-

tor into the

Power

port of the MULTINETswitch™and then

plug the Power Supply into the external power source wall

receptacle.

When an 2x8 MULTINETswitch™is to be installed with two

DSS Servers as shown in Figure 2, Step 1 must be per-

formed for both DSS’s

MONITOR

ports to the

LAN Common

Port and WAN Common Port

, respectively, of the

MULTINETswitch™and Step 2 must be modified to connect

the COM1 port of each DSS to the

CONTROL

port of the

MULTINETswitch™using a DRL341-3-3 Control Y-cable.

HARDWARE

IINNSSTTAALLLLAATTIIOONN
