Data Video SE-3000 Manual de usuario

SE-3000

VISUAL QUICK START GUIDE

UPDATED DECEMBER 2012

THIS GUIDE COVERS SE-3000 FIRMWARE VERSION 9.9.9b and ABOVE

PLEASE UPDATE YOUR UNIT BEFORE USING THIS GUIDE.

ALL PREVIOUS VERSIONS OF THIS GUIDE ARE NOW CONSIDERED OUT OF DATE.

NOTE: IF YOU ARE VIEWING THIS COMPUTER ON YOUR COMPUTER AS A PDF, YOU CAN NOW USE THE TABLE OF

CONTENTS TO JUMP TO A SECTION THAT YOU WANT TO SEE. OTHERWISE, PLEASE REFER TO THE PAGE NUMBERS.

For more information about the SE-3000, please visit

www.datavideo.us and visit the SE-3000 product page.

(This page is intentionally blank)

How To Update Firmware On The SE-3000

Keeping your SE-3000’s firmware updated is essential.

New updates will always be available to download from

the SE-3000 product page on the Datavideo US website.

It is quite easy to update the firmware yourself.

Note: You must update both the processor and the control

panel for the firmware to take effect. If you update only

one, the menu functions on the SE-3000 will not work

correctly.

What you will need:

USB extension cord (included with the SE-3000)

USB thumb drive (not included)

DOWNLOAD THE FIRMWARE

1. Download the

latest firmware

revision from the

SE-3000 product

page on our

website:

www.datavideo.us

. It will be shown

as a zip file.

Click on the “Product

Downloads” Tab to see the

available software

downloads for the SE-

3000.

2. Open the

downloaded zip

file from your

download folder or

from your saved

directory and copy

the “se3000”

folder onto an

empty USB stick or

thumb drive.

Note: Your USB

stick or thumb drive should

only have the “se3000”

folder on the main

directory. No other files

should be saved on the

drive while updating.

Note: The SE-3000 folder should have the following files:

Release Notes.txt

Se3000 Panel

Se3000 Processor

Se3000_CP_usb_startup.bat

Se3000_PU_usb_startup.bat

THE SE-3000 PROCESSOR UPDATE ( Always do this first)

1. Power off the SE-3000 processor and the control panel.

2. Remove the front panel from the processor by unscrewing

the four perimeter thumb screws.

Insert the USB extension cord that came with the SE-3000

into the USB slot on the circuit board.

Connect your thumb drive to the USB extension cord.

3. Power on the SE-3000 processor and the control panel.

4. Press the “SET UP” button in the Menu Button Group on the

control panel to check the firmware version number.

You have now successfully updated the firmware on the SE-

3000 processor, now you can update the SE-3000 Control

Panel.

The latest firmware version number will appear under

the control panel’s firmware information on the LCD

Screen.

5. Remove the USB extension cord and thumb drive, and re-

attach the processor panel.

THE SE-3000 CONTROL PANEL UPDATE

1. Power off the SE-3000 processor and the control panel.

2. Insert the thumb drive into the USB port on the side of the

touch screen monitor on the rear of the SE-3000 control

panel.

3. Power on the SE-3000 processor and the control panel.

The Control Panel will automatically detect the thumb drive.

4. Press the “SET UP” button in the Menu Button Group on the

control panel to check the firmware version number.

You have now successfully updated the firmware on the SE-

3000 Control Panel.

The latest firmware version number will appear under

the control panel’s firmware information on the LCD

Screen.

5. Now remove the USB stick from the SE-3000 control panel, and reboot the SE-3000. This is to verify everything has

been updated. After the panel initializes, press the “SET UP” button on the control panel to check the firmware

version number. The latest firmware version number should appear under the control panel’s firmware information in

the LCD Screen. This is how you will know that you now have the latest firmware, and the update was successful.

6. If you still see the old firmware version in the “SET UP” menu, the update was not successful. Repeat the steps from

the very beginning.

NOTE: If you have any problems with completing an SE-3000 firmware update, please call the

Datavideo USA office at 562-696-2324 (North, South and Central America customers only.)

TABLE OF CONTENTS

(GO TO PAGE 7 TO SKIP THE TABLE OF CONTENTS.)

1. INTRODUCTION

…………………………………………………7

1.1 KEY FEATURES

…………………………………………………7

2. CONTROL PANEL BUTTONS AND MENUS

…………………………………………………8

2.1 PROGRAM/PRESET BUTTON CROUP

…………………………………………………9

2.2 AUX/BUS DELEGATES

…………………………………………………9

2.3 KEYER CONTROL BUTTON GROUP (KEYER CONTROLS)

…………………………………………………10

2.4 MENU SELECT BUTTON GROUP (MENUS)

…………………………………………………10

2.5 TRANSITION CONTROL BUTTON GROUP

…………………………………………………10

2.6 TRANSITIONS BUTTON GROUP

…………………………………………………11

2.7 DSK TRANSITIONS

…………………………………………………11

2.8 FADE TO BLACK BUTTON GROUP

…………………………………………………11

2.9 USER SHOT BOX

…………………………………………………12

2.10 NUMERIC PAD BUTTON GROUP

…………………………………………………12

2.11 JOYSTICK BUTTON GROUP

…………………………………………………13

2.11.1 NORM KEY

…………………………………………………13

2.11.2 FINE KEY

…………………………………………………13

2.11.3 P ARAMETER CONTROL BUTTONS

…………………………………………………14

2.11.4 QUICK MENU BUTTONS

…………………………………………………14

2.11.5X Y Z BUTTONS

…………………………………………………14

2.11.6 JOYSTICK

…………………………………………………14

3. LCD TOUCH SCREEN MENUS

…………………………………………………15

3.1 HOME MENU

…………………………………………………15

3.2 KEYER MENU

…………………………………………………15

3.2.1 KEYER CONTROL MENU

…………………………………………………16

3.2.1.1 LIFT CONTROL

…………………………………………………16

3.2.1.2 GAIN CONTROL

…………………………………………………17

3.2.1.3 OPACITY CONTROL

…………………………………………………17

3.2.1.4 KEY INVERT CONTROL

…………………………………………………18

3.2.2 KEYER MATTE MENU

…………………………………………………18

3.2.2.1 HUE SAT LUMA FOR KEYER MATTE

…………………………………………………19

3.3 CHROMA MENU

…………………………………………………19

3.3.1 CHROMA MATTE MENU

…………………………………………………20

3.3.1.1 HUE, SAT,LUM A FOR CHROMA MATTE

…………………………………………………20

3.3.1.2 CHROMA MATTE OPACITY

…………………………………………………20

3.3.2 CHROMA KEY CONTROL MENU

…………………………………………………21

3.3.2.1 KEY ACCEPTANCE CONTROL

…………………………………………………21

3.3.2.3 CHROMA KEY LIFT CONTROL

…………………………………………………22

3.3.2.3 CHROMA GAIN CONTROL

…………………………………………………22

3.3.2.4 CHROMA OPACITY

…………………………………………………22

3.3.3 CHROMA COLOR SPILL MENU

…………………………………………………23

3.3.3.1 CHROMA ACCEPTANCE

…………………………………………………23

3.3.3.2 CHROMA SUPPRESS CONTROL

…………………………………………………24

3.3.3.3 BACKGROUND SUPRESSION CONTROL

…………………………………………………25

3.3.3.4 QUICK SET UP MENU

…………………………………………………25

3.4 MASK MENU

…………………………………………………26

3.4.1 MASK CONTROLS ( L,R,T,B)

…………………………………………………26

3.5 MATTE MENU

…………………………………………………27

3.5.1 HUE, SAT, LUMA CONTROLS FOR MATTE

…………………………………………………28

3.6 FREEZE

…………………………………………………28

3.6.1 FREEZE INPUT SELECTION

…………………………………………………28

3.6.2 FREEZE CONTROL AND MODES

…………………………………………………29

3.7 INPUTS MENU

…………………………………………………30

3.7.1 INPUT 1-16

…………………………………………………30

3.7.2 INPUT FORMAT AND UPCOVERTER CONTROL

…………………………………………………30

3.7.3 INPUT NAME

…………………………………………………31

3.7.4 PROC AMP

…………………………………………………31

3.7.5 DVI INPUT

…………………………………………………32

3.7.6 INPUT REMAPPING

…………………………………………………32

3.7.6.1 CROSSPOINT SELECT DIAGRAM

…………………………………………………32

3.8 OUTPUTS MENU

…………………………………………………33

3.8.1 OUTPUT SOURCE SELECTION

…………………………………………………33

3.8.2 MULTIVIEW MODE

…………………………………………………36

3.8.2.1 MULTI VIEW OUTS

…………………………………………………36

3.8.3 MULTIVIEW MAIN

…………………………………………………37

3.8.2.4 MULTI VIEW DIAGRAM

…………………………………………………37

3.8.2.5 MULTIVIEW INFO

…………………………………………………38

3.9 WIPE MENU

…………………………………………………38

3.9.1.1 WIPE SELECT CONTROL

…………………………………………………38

3.9.1.2 SOFT CONTROL

…………………………………………………39

3.9.1.3 WIDTH CONTROL

…………………………………………………40

3.9.1.4 LEVEL CONTROL

…………………………………………………40

3.9.1.5 SOFT BALANCE CONTROL

…………………………………………………41

3.9.2 WIPE BORDER

…………………………………………………41

3.9.2.1 HUE SAT LUMA FOR WIPE BORDER

…………………………………………………42

3.9.2.2 SOURCE CONTROL

…………………………………………………42

3.9.3 WIPE SHADE MENU

…………………………………………………43

3.9.3.1 HUE SAT LUMA FOR WIPE SHADE

…………………………………………………43

3.9.3.2 SHADE SOFT

…………………………………………………44

3.9.4 WIPE POSITION MENU

…………………………………………………44

3.9.4.1 X,Y, POSITION FOR WIPES

…………………………………………………45

3.9.4.2 ROTATION

…………………………………………………45

3.10 TRANSITION CONTROL

…………………………………………………46

3.10.1 MAIN TRANSITION MENU

…………………………………………………46

3.10.1.1 TRANSITION SELECT CONTROL

…………………………………………………47

3.11 FLEX SOURCE

…………………………………………………47
