INSTALLATION & CONFIGURATION MANUAL

DT-HDIPCOM

HD IP Streaming Server

NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | DT-HDIPCOM Manual v1.0 Page 2

Content

Safety Precautions ..................................................................................................................................................... 3

Package Contents....................................................................................................................................................... 3

Product Description ................................................................................................................................................... 4

Specifications............................................................................................................................................................. 5

Installation................................................................................................................................................................. 6

Unpacking and Inspection........................................................................................................................................ 6

Hardware Installation and Connections................................................................................................................... 6

Front-Panel ................................................................................................................................................................ 7

Procedure to connect to the Streaming Server via the Network port ........................................................................ 8

Overview Page ......................................................................................................................................................... 13

Encoder Setup.......................................................................................................................................................... 14

Video Control......................................................................................................................................................... 15

Audio Control......................................................................................................................................................... 17

Color Control.......................................................................................................................................................... 18

Enable Closed Captioning....................................................................................................................................... 18

Streaming Setup....................................................................................................................................................... 19

Stream Server ........................................................................................................................................................ 19

Broadcasting .......................................................................................................................................................... 20

Network Configuration ............................................................................................................................................ 22

Device Network...................................................................................................................................................... 22

DLNA Settings ........................................................................................................................................................ 23

Administration ......................................................................................................................................................... 24

Streaming Methods Case ......................................................................................................................................... 26

COM2000 LCI (Local Channel Insertion) ................................................................................................................... 26

HDIP Streaming Server Notes................................................................................................................................... 29

NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | DT-HDIPCOM Manual v1.0 Page 3

Safety Precautions

The presence of this symbol is to alert the installer and user to the presence of uninsulated

dangerous voltages within the product’s enclosure that may be of sufficient magnitude to produce

a risk of electric shock.

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS DEVICE TO RAIN OR

MOISTURE. DO NOT OPEN THE UNIT. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

DO NOT apply power to the unit until all connections have been made, all components have been installed and

all wiring has been properly terminated.

DO NOT terminate, change or uninstall any wiring without first disconnecting the unit’s power adapter from the

device.

This device is supplied with the appropriately rated 12VDC power supply with the center pin positive. The use of

any other power supply could cause damage and invalidate the manufacturer’s warranty.

DO NOT power on the unit until all cables and connections to the device have been properly connected.

The device should be installed in an environment consistent with its operating temperature specifications.

Placement next to heating devices and ducts is to be avoided as doing so may cause damage. The device should

not be placed in areas of high humidity.

DO NOT cover any of the device’s ventilation openings.

If the device has been in a cold environment allow it to warm to room temperature for at least 2 hours before

connecting power.

Package Contents

This package contains:

One DT-HDIPCOM IP Streaming Server

One Adaptor

One installation / configuration manual (An eManual will be supplied)

Inspect the package before starting installation to ensure there is no damage and all supplied contents are present.

Contact your distributor or dealer should the device be damaged or package contents are incomplete.

NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | DT-HDIPCOM Manual v1.0 Page 4

Product Description

Data-Tronix's DT-HDIPCOM HD IP Streamer allows the user to stream any one audio/video source over an IP Network

to up to anyTV's or connected computers within the IP Network. The IP Streamer accepts a HDMI, component, or

composite video input and the unit is designed to deliver a rich HD/SD streaming experience for its users deploying

MPEG-2 or MPEG-4 standards.

Combine any sources and stream them over the network for multiple sources. The DT-HDIPCOM HD streaming server

enables high-definition streaming with resolutions up to 1080p, providing a high quality viewing experience for your

customer. The unit is MPEG2 or MPEG4 switchable and supports UDP/RTP Streaming. The compact design saves

space and is easily controlled via a GUI for rapid deployment.

The DT-HDIPCOM features:

Dual Mode H.264 / MPEG-2 selectable output

Video resolution: Up to 1080p (H.264 only)

HDMI, component, composite inputs with auto detection

UDP/RTP/ Unicast/Multicast, DLNA Compatible, TCP

Variable Bit Rate control

Closed Captioning support

Audio format: MPEG-1-Layer2(MP2), AAC, Dolby Stereo Creator (AC3)

*Dolby is a trademark of Dolby Laboratories.

GigE output port

GUI for setup and control

Front panel LED Status Display

Easy installation and use

NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | DT-HDIPCOM Manual v1.0 Page 5

Specifications

Interfaces

Ethernet (output)

Combined IP Output Port (1Gbps)/Management Port 10Mbps)

USB (optional)

USB 2.0

Video Input

HDMI, YPbPr, CVBS

Audio Input

Analog, Coaxial, Optical

Encoding

Video Format

MPEG-2, AVC

Audio Format

MPEG-1 Layer 2(MP2), AAC, AC-3

Resolution

480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Video Bitrate

MPEG-2HD: 10-20 Mbps, MPEG-2 SD: 2-8 Mbps,

AVC HD: 2-10 Mbps, AVC SD: 1-4 Mbps

Audio Bitrate

128, 256, 384 Kbps

Streaming Protocols

HTTP Server (DLNA), UDP/RTP multicast, UDP/RTP unicast,

TCP unicast

MISC

Digital Living Network

Alliance (DLNA)

MediaServer 1.5

Closed Caption

Yes

Power Supply 12VDC 1.5AMP

Consumption

500mA

Operating Temperature

+32°F to +113°F ( 0°C to +45°C)

Storage Temperature

+14°F to +140°F ( -10°C to +60°C)

Dimension

9.29” x 6.10” x 1.37” (236mm x 155mm x 35mm)

Weight

2 lbs. and 1.1575 oz. (940g)

Manufactured under license of Dolby Laboratories

*Specifications subject to change without prior notice

NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | DT-HDIPCOM Manual v1.0 Page 6

Installation

System Installer must adhere to Article 820-40 of the NEC that provides guidelines for proper

grounding and specifies that the cable ground shall be connected to the grounding system of the

building, as close to the point of cable entry as possible.

Unpacking and Inspection

Each unit is shipped factory tested. Ensure all items are removed from the container prior to discarding any packing

material.

Thoroughly inspect the unit for shipping damage with particular attention to connectors and controls. If there is any

sign of damage to the unit or damaged or loose connectors contact your distributor immediately. Do not put the

equipment into service if there is any indication of defect or damage.

Hardware Installation and Connections

It is highly recommended that quality cables and connectors be used for all video and audio source

connections

1. Connect the media source (Satellite STB, Media player, or other media device) to the HDIP streaming server

by HDMI, YPbPr, or CVBS cables.

2. Connect the HDIP streaming server to local area network (LAN).

3. Plug the power adapter to the device and power up

4. In the same network segment, find the HDIP streaming server from Windows XP/7 “My Network Places” **

Note: For Windows XP enable UpnP.

5. Open the device's GUI by double-clicking the device icon(XP)

There are three (3) use cases supported by HDIP streamer: DLNA media server, UDP/RTP multicasting, and

TCP/UDP/RTP unicasting.

Limitations:

1. All UPnP/DLNA devices, including the HDIP streaming server (media-server), media-players, the SmartTV, the

set-top-box, and the controlling PC, should be located within same network segment/LAN.

2. If a DHCP server is present in the private network, the DT-HDIPCOM will use the IP address assigned by the

DHCP server.

3. If no DHCP server is present, the DT-HDIPCOM will use an assigned IP address (169.254.xxx.x).

NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | DT-HDIPCOM Manual v1.0 Page 7

Front-Panel

Buttons/LEDs

Description

Reboot button

Reboots the device (unsaved settings will be lost)

RST / UPG button

To reset all the settings of the device to factory default:

1.Press and hold the RST/UPG button and then connect power to

the device while pressing in the RST/UPG button.

2.Hold the button until CFG led to flashes 10 times (about 10

seconds)

3.After the CFG led stops flashing -release the button

To upgrade firmware using the USB port:

1.Plug-in the USB drive with the upgraded firmware image

(“hdip_upg.img”)

2.Press and hold the RST/UPG button and boot-up the device

3.USB led will flash while copying the image from USB drive (about

3~5 seconds)

4.Wait until the CFG led stop flashing

5.Release the RST/CFG button and wait for the device to reboot

and upgrade the firmware (about 1 minutes)

PWR

Power is ON

CFG

Indicates device is in configuration mode

USB

Indicates USB drive is mounted

MPEG-2

Indicates device is encoding video using MPEG-2

H.264

Indicates device is encoding video using H.264

MP2

Indicates device is encoding audio using MPEG-1 Layer 2

AAC

Indicates device is encoding audio using AAC

Dolby Digital

Indicates device is encoding audio using Dolby Digital

For

recording

NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | DT-HDIPCOM Manual v1.0 Page 8

Procedure to connect to the Streaming Server via the Network port

The following procedure will allow the installer to setup the Streaming Server via the GUI

1. Connect a standard CAT5e cable from HDIP Network port to a switch or directly

to a PC or laptop.

2. Using a PC go to the Control Panel to “Network and Internet”

Start- Control Panel ==> View Network Status and Tasks

3. Select 'Change Adapter Settings' from the left plane

NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | DT-HDIPCOM Manual v1.0 Page 9

4. Select Local Area Connection Icon

Then Right Click – Select Properties

Internet Protocol Version 4(TCP/IPv4) Properties

NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | DT-HDIPCOM Manual v1.0 Page 10

5. Change “Obtain an IP address automatically” to “Use the following IP address”

6. Set your LAN IP address to 192.168.1.2, with a subnet mask of 255.255.255.0.

7. Once your LAN IP address has been set, access the DT-HDIPCOM unit using your web browser and entering

“192.168.1.9” into your address bar.
