Danfoss Link HC Manual de usuario
Danfoss Link™ HC Hydronic Controller
Installation Guide
Danfoss Heating Solutions
MAKING MODERN LIVING POSSIBLE
Danfoss A/S
DK • 7100 Vejle
Phone +45 7488 8500
Fax +45 7488 8501
VIFZL15X © Danfoss 08/2010
3
VIFZL15X © Danfoss 08/2010
GB
DE
FR
DK
FI
NL
PL
CZ
Installation Guide Danfoss Link™ HC
Installation Guide
Installationsanleitung
Guide d’installation
Installationsmanual
Asennusohje
Installatiehandleiding
Instrukcja instalacji
Instalační příručka
4VIFZL15X © Danfoss 08/2010
Installation Guide Danfoss Link™ HC
Introduction ............................................................................5
Mounting
1: Mounting on wall ........................................................5
2: Mounting on DIN-rail.................................................... 5
Connections
1: Connecting actuators ....................................................6
2: Connecting pump and boiler controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3: Connections for Away Function...........................................6
4: Connections for Heating & Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
5: Power supply ........................................................... 7
6: Wiring diagram ......................................................... 7
7: External antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Configuration
1: Adding Danfoss Link™ HC to the system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2: Configure Danfoss Link™ HC............................................. 8
2a: Configure outputs.................................................. 9
2b: Configure inputs ....................................................9
3: Add an output to a room .................................................9
4: Configure a room .......................................................10
5: Remove an output ......................................................11
6: Factory reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Trouble shooting.........................................................................13
Technical specifications ................................................................. 13
Disposal instructions .................................................................... 13
Index
5
VIFZL15X © Danfoss 08/2010
Installation Guide Danfoss Link™ HC
GB
Danfoss Link™ is a wireless control system for a variety of heating systems.
The Danfoss Link™ HC (Hydronic Controller) is a part of this system allowing wireless control of
manifolds for water based floor heating/cooling.
Inputs:
Not in use
Away Function (external ON/OFF switch)
Heating/Cooling (external ON/OFF switch)
Front
cover
release
External
Antenna
Output LEDs
Install / Link TestOutput connections
Pump relay
Boiler relay
Introduction
The Danfoss Link™ HC should always be mounted in an horizontal upright position.
1: Mounting on wall
1. Remove front and side covers and mount with screws and wall plugs.
2: Mounting on DIN-rail
1. Mount DIN-rail parts. 2. Click on DIN-rail. 3. Release from DIN-rail.
Mounting
6VIFZL15X © Danfoss 08/2010
Installation Guide Danfoss Link™ HC
Make sure that all connections to the Danfoss Link™ HC are completed, before connecting to a 230 V
power supply.
1: Connecting actuators (24 V)
If NC (normally closed) actuators are installed for ON/OFF regulation, no further actuator output con-
figuration is needed.
1. Connect actuator wires to an output. 2. Fix the cable.
2: Connecting pump and boiler controls
The relays for pump and boiler are potential free contacts and can thus NOT be used as direct power
supply. Max. load is 230 V, 8 (2) A.
1. Connect wires for pump and boiler controls to their
respective output.
2. Fix the cable.
3: Connections for Away Function
The Away Function ensures a set room temperature fixed at 15°C for all Room Thermostats,
but it can be changed with the Danfoss Link™ CC.
1. Connect an external ON/OFF switch to the termi-
nals for Away Function. When this switch is closed
(ON) the system will override all room thermostat
set points and change it to 15°C.
2. Fix the cable.
Connections
7
VIFZL15X © Danfoss 08/2010
Installation Guide Danfoss Link™ HC
GB
4: Connections for Heating & Cooling
When the system is in cooling mode the actuator output will be activated (ON for NC
actuators / OFF for NO actuators) when the temperature in a room exceeds the set point.
When the system is in cooling mode an independent dew-point alarm function should be installed.
1. Connect an external ON/OFF switch to the
terminals for Heating & Cooling. When this
switch is closed (ON) the system will switch
from heating to cooling.
2. Fix the cable.
5: Power supply
When all actuators, pump and boiler controls and other inputs are installed, connect
the supply plug to a 230 V power supply.
If the power supply plug is removed during installation, make sure that the connection is made ac-
cording to existing law/legislation.
6: Wiring diagram
LN
9 10876 54321
Actuator outputsRelays
Input
230 V~
50 Hz
External
antenna
LN
Away
Heating / Cooling
max. 3 m
7: External antenne
The external antenna is installed as diverter when there is no transmission possible through a large
building, heavy construction or metal barrier, e.g. if the Danfoss Link™ HC is located in a metal cabinet/
box
1. Remove the plastic cover from the antenna con-
nection.
2. Connect the external antenna and place it on the
other side of the transmission barrier.
Connections
8VIFZL15X © Danfoss 08/2010
Installation Guide Danfoss Link™ HC
1: Adding Danfoss Link™ HC to the system
Adding Danfoss Link™ HC to a system is made from the Danfoss Link™ CC Central Controller. For
further information, see the Danfoss Link™ CC instruction manual: Configuration 7: Adding service
devices.
1. Select “Rooms and Devices”. 2. Select “Add Service Device”. 3. Select “Begin Registration”.
4. Select Install / Link Test on HC. 5. If wanted, edit room name with
the letter keys.
6. End with pressing “OK/Return”.
2: Configure Danfoss Link™ HC
Configuration Danfoss Link™ HC to a system is made from the Danfoss Link™ CC Central Controller.
For further information, see the Danfoss Link™ CC instruction manual: Configuration 7: Adding service
devices.
1. Select “Rooms and Devices”. 2. Select “Manage Devices”. 3. Select device to configure.
Configuration
9
VIFZL15X © Danfoss 08/2010
Installation Guide Danfoss Link™ HC
GB
2a: Configure outputs
1. Select “Set up Relays”. 2. Select “Boiler Relay” or “Pump
Relay”.
3. Choose your settings and press
“OK/Return”.
2b: Configure inputs
1. Select “Setup Inputs”. 2. Select input to configure. 3. Choose your settings and press
“OK/Return”.
3: Add an output to a room
Configuration Danfoss Link™ HC to a system is made from the Danfoss Link™ CC Central Controller.
For further information, see the Danfoss Link™ CC instruction manual: Configuration 7: Adding service
devices.
1. Select “Room devices”. 2. Select “Add a device”. 3. If Danfoss Link™ HC is installed,
a selection screen appears.
Configuration
10 VIFZL15X © Danfoss 08/2010
Installation Guide Danfoss Link™ HC
4. If more devices are installed,
select a device.
5. Select output. Only available
outputs are selectable.
6. Select heating emitter and press
“Actuator Settings”.
7. Select actuator type and press
“OK/Return”.
4: Configure a room
• Forecasting method:
by activation of the forecast
method, the system will automati-
cally predict the heating start-up
time necessary to reach desired
room temperature at desired time.
• Regulation type:
only in connection with electrical
heating systems.
1. Select “Heating regulation”. 2. Select type of regulation.
Configuration
11
VIFZL15X © Danfoss 08/2010
Installation Guide Danfoss Link™ HC
GB
5: Remove an output
1. Select “Rooms and Devices”. 2. Select “Manage Devices”. 3. Select an existing room.
4. Select “Room devices”. 5. Select “Remove a device”. 6. Select “Remove an output”.
7. Select “Yes, remove an output
now”.
Configuration
