Installation guide

Remote VLT® Control Panel LCP 601 and Mounting

Kit

VLT® Soft Starter MCD 600

1 Overview

1.1 Description

The remote VLT® Control Panel LCP 601 can be mounted up to 3 m (9.8 ft) away from the soft starter. The LCP is rated IP65 when

mounted correctly in accordance with these instructions.

The LCP connects to the soft starter via the DB9 connector on a hardware expansion card. A hardware expansion card must be installed

to use the remote LCP with the soft starter. Separate kits are available with a dedicated LCP connector expansion card, or with no

expansion card for applications already using another smart card.

1.2 Parts List

Item Quantity

Remote VLT® Control Panel LCP 601 1

LCP connector expansion card (selected kits) 1

Cable, DB9 1

Gasket, foam 1

Installation guide 1

M3 x 16 screw 4

M3 flat washer 4

M3 spring washer 4

M3 nut 4

Jack screw 4

Table 1: Ordering Numbers

Kit Ordering number

Remote VLT® Cotrol Panel LCP 601 and Mounting Kit 175G0134

AN265232431650en-000101 / 175R1177 | 1

2 Installation

2.1 Installing the Expansion Card

Context:

WARNING

SHOCK HAZARD

The soft starter contains dangerous voltages when connected to mains voltage. Attaching or removing accessories when the

soft starter is connected to mains may cause death or serious injury.

-Isolate the soft starter from mains voltage before attaching or removing accessories.

CAUTION

RISK OF INJURY AND EQUIPMENT DAMAGE

Inserting foreign objects or touching the inside the soft starter while the expansion port cover is open may endanger

personnel, and can damage the soft starter.

-Be careful when installing the expansion cards and make sure not to touch the inside the soft starter.

Procedure

1. Push a small flat-bladed screwdriver into the slot in the center of the expansion port cover and ease the cover away from the soft

starter.

2. Line up the card with the expansion port. Gently push the card along the guide rails until it clicks into the soft starter.

1 2

e77ha739.10

Installation

Installation guide | Remote VLT® Control Panel LCP 601 and

Mounting Kit

AN265232431650en-000101 / 175R1177

2.2 Installing the Remote VLT® Control Panel LCP 601

Context:

NOTICE

The remote VLT® Control Panel LCP 601 can be safely connected or removed while the soft starter is running. It is not necessary

to remove mains or control voltage.

Procedure

1. Measure and drill 4 holes for the mounting screws and 2 holes for the DB9 connector, see 2.4 Mounting Diagram.

2. Apply the foam gasket to the back of the LCP.

3. Align the LCP over the holes and screw in place. Tighten the screws so that the foam gasket is compressed to half its original

thickness (torque approximately 1 Nm (8.8 in-lb)).

NOTICE

If the screws are too long, the gasket does not provide IP65 protection. Overtightening the screws can damage the LCP,

gasket, or panel.

4. Plug the cable into the LCP and the soft starter.

e77ha740.10

5. Press the faceplate onto the front of the LCP.

2.3 Control via the Remote VLT® Control Panel LCP 601

The soft starter only accepts start and reset commands from the remote VLT® Control Panel LCP 601 if parameter 1A Command Source is

set to Remote Keypad.

Installation

Installation guide | Remote VLT® Control Panel LCP 601 and

Mounting Kit

AN265232431650en-000101 / 175R1177 | 3

READY RUN TRIP

LOCAL

RESET

LOGS Alt

GRAPH TOOLS

CMD

STORE

BACK

e77ha716.10

1Four-line display for status and programming details.

3Menu

navigation

keys:

Back: Exit the

menu or

parameter,

or cancel a

parameter

change.

Menu/Store:

Enter a menu

or parameter,

or save a

parameter

change.

Arrow keys:

Scroll to the

next or previous

menu or

parameter,

change the

setting of the

current

parameter, or

scroll through

the status

screens.

5Local control keys.

2Status LEDs.

4Shortcut to the command source menu in Set-up Tools.

6Shortcut keys

for quick

access to

common tasks:

Logs:

Open the

Logs

Menu.

Graph: Select

which graph to

view, or pause/

restart the graph

(hold longer than

0.5 s).

Tools:

Open the

Set-up

Tools.

Illustration 1: Remote LCP

NOTICE

If the commissioning menu is open on the built-in LCP, the soft starter ignores all commands from the remote LCP except stop

commands.

Installation

Installation guide | Remote VLT® Control Panel LCP 601 and

Mounting Kit

AN265232431650en-000101 / 175R1177

NOTICE

The remote LCP can be safely connected or removed while the soft starter is running. It is not necessary to remove mains or

control voltage.

NOTICE

If parameter 1A Command Source is set to Remote LCP, removing the remote LCP causes a trip.

2.4 Mounting Diagram

Drill 4 mounting holes for screws (1 in each corner) and 2 holes for the DB9 connector.

NOTICE

The image is not to scale. Dimensions are given with the faceplate removed.

Installation

Installation guide | Remote VLT® Control Panel LCP 601 and

Mounting Kit

AN265232431650en-000101 / 175R1177 | 5

e77ha613.11

68 mm (2.7 in)

62 mm (2.45 in)

13 mm (0.5 in)

136 mm (5.35 in)

142 mm (5.6 in)

Illustration 2: Drilling Template

Installation

Installation guide | Remote VLT® Control Panel LCP 601 and

Mounting Kit

AN265232431650en-000101 / 175R1177

e77ha614.11

1Faceplate

3Jack screw

5Spring washer

7VLT® Control Panel LCP 601

9Panel

2Screw

4Flat washer

6Nut

8Gasket

10 Cable

Illustration 3: Exploded View

Installation

Installation guide | Remote VLT® Control Panel LCP 601 and

Mounting Kit

Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products

already on order provided that such alterations can be made without subsequential changes being necessary in specifications already agreed. All trademarks in this material are property of the respective

Danfoss A/S

Ulsnaes 1

DK-6300 Graasten

vlt-drives.danfoss.com
