Monitoring unit

AK-LM 330

User Guide

ADAP-KOOL®Refrigeration control systems

2 Menu operation RC8CC202 © Danfoss 09/2012 AK-LM 330 Vers. 1.4x

Menu list This menu function can be used together with system software type AKM. The description is divided

up into function groups that can be displayed on the PC screen. Within each group it is now possible

to show the measured values, or settings. Regarding the use of AKM, reference is made to the AKM

Manual.

Validity This menu operation (from September 2012) applies to controller type AK-LM 330, code Nos

080Z0170 with programme version 1.4x.

The operation is divided up into several

function groups. When a selection has been

made, push“OK”, and you may continue to

the next display. By way of example, "Ther-

mostat 1-4" has been selected here.

From the measure line the dierent val-

ues can be read. The values are constantly

updated.

In the list of settings the set values can be

seen. If a setting has to be changed, select

the parameter and proceed via“OK”.

Function groups

Measurements The various measurements can be read directly. If a graphic display of the measurements is required,

up to eight of them can be shown. Select the required measurements and push “Trend”.

Settings Settings can only be made for the daily operation. Conguration settings cannot be seen, changed or

written out. They can only be made from the Service Tool programme.

There are four kinds of settings, ON/OFF settings, settings with a variable value, time settings and

“reset alarms”.

Enter the new value or move the sliding scale up or down.

The new value will apply, when“OK”is pushed.

Set the required value and push“OK”

AK-LM 330 Vers. 1.4x Menu operation RC8CC202 © Danfoss 09/2012 3

Note It has been necessary to make a selection from the numerous measurements and settings coming

from the controller.

There is not room for all these in the AKM programme controls.

It can display:

• 8 thermostats

• 2 pressostats

• 2 volt inputs

• 8 digital alarm inputs

• 2 consumption gauges

If it is necessary to obtain access to all measurements and settings, see Using Service Tool, type AK-ST

500.

Go through the individual functions one by one and make the required settings. When settings have

been made for one controller, the set values may be used as a basis in the other controllers of the

same type and with the same software version. Copy the settings by using the copy settings function

in the AKM programme, and adjust subsequently any settings where there are deviations.

NB! If a list is required for noting down the individual settings, a printout can be made of it with

a function in the AKM programme. Read the next section, “Documentation”.

Documentation Documentation of the settings of the individual controllers can be made with the print function in the

AKM programme. Select the controller for which documentation of the settings is required and select

the “Print Settings”function (cf. also the AKM Manual).

Functions Shown below are function groups with corresponding measurements and settings. A printout of the

given settings can be made using the AKM function “Print Settings”(see above).

4 Menu operation RC8CC202 © Danfoss 09/2012 AK-LM 330 Vers. 1.4x

Select application

Measurements AK error When “ON”, the controller is in alarm condition.

Settings Main switch Main switch: ON: Regulation

OFF: Controller stopped

Conguration lock Locking conguration

To implement changes of certain parameters, the conguration lock must be“open".

Note: “Main switch” must be turned" OFF" to open conguration

0: Open

1: Locked

Select quick setup Selection of predened congurations.

When this is selected, all the controller settings and the denitions of input and out-

put will be adjusted to t the selected application.

(see manual for more details on individual predened settings).

Thermostat 1 - 4

Measurements AK error When “ON”, the controller is in alarm condition.

No. of thermostats The number of thermostats that have been dened can be read here.

1 to 8 can be read and operated in the following menus.

9 or more can only be read and operated from the Service Tool AK-ST

Th1 temp. Temperature Measurements on the sensor dened in "Thermostat 1"

Th 1 actual state The thermostat's actual value is shown here. ON or OFF.

2, 3, 4 There are similar settings for the other thermostats.

Settings Main switch Main switch: ON: Regulation

OFF: Controller stopped

Th1 Cut out temp Cut out value for relay which is dened in "Thermostat 1"

Th1 Cut in temp Cut in value for relay which is dened in "Thermostat 1"

Th1 High alarm limit High alarm limit "Thermostat 1"

Th1 High alarm delay Delay time for high alarm "Thermostat 1" (normal regulation)

Th1 High alarm del 2 Delay time 2 for high alarm "Thermostat 1" (e.g. after a defrost / cooling down)

Th1 Low alarm limit Low alarm limit "Thermostat 1"

Th1 Low alarm delay Delay time for low alarm "Thermostat 1"

Th1 DI def interlock Denition of switch to "Delay time 2" with DI signal

0: not used

1-16: Here, it is dened which DI input is to activate the long delay time.

Th1 DI alarm disable Denition of disarming alarm with DI signal

0: Not used

1-16: Here, the DI input that is to deactivate the alarm function is dened

Th1 Sensor select Here, the sensor that is to be used for "Thermostat 1" is dened

2, 3, 4 There are similar settings for the other thermostats.

Thermostat 5 - 8

Measurements AK error When “ON”, the controller is in alarm condition.

5, 6, 7, 8 Same function as for "Thermostat 1".

Settings Main switch Main switch: ON: Regulation

OFF: Controller stopped

5, 6, 7, 8 Same function as for "Thermostat 1".

AK-LM 330 Vers. 1.4x Menu operation RC8CC202 © Danfoss 09/2012 5

Pressostats 1 - 2

Measurements AK error When “ON”, the controller is in alarm condition.

No. of pressostats The number of pressostats that have been dened can be read here.

1 to 2 can be read and operated in the following menus.

3 or more can only be read and operated from the Service Tool AK-ST 500.

P1 pressure. Pressure reading for the transmitter dened in "Pressostat 1"

P1 actual state The pressostat's actual value is shown here. ON or OFF.

2 There are similar readings for "Pressostat 2".

Settings Main switch Main switch: ON: Regulation

OFF: Controller stopped

P1 Cut out pressure Cut out value for relay "Pressostat 1"

P1 Cut in pressure Cut in value for relay "Pressostat 1"

P1 High alarm limit High alarm limit "Pressostat 1"

P1 High alarm delay Delay time for high alarm "Pressostat 1"

P1 Low alarm limit Low alarm limit "Pressostat 1"

P1 Low alarm delay Delay time for low alarm "Pressostat 1"

P1 Sensor select The transmitter that is to send the signal to "Pressostat 1" is dened here.

2 There are similar settings for "Pressostat 2".

Voltage inputs

Measurements AK error When “ON”, the controller is in alarm condition.

No. of voltage input The number of voltage functions that have been dened can be read here.

1 to 2 can be read and operated in the following menus.

3 or more can only be read and operated from the Service Tool AK-ST 500.

V1 value The voltage measurement for the function dened in "Volt 1"

V1 actual state The function's actual value is shown here. ON or OFF.

2 There are similar readings for "Volt 2".

Settings Main switch Main switch: ON: Regulation

OFF: Controller stopped

V1 Cut out Cut out value for relay which is dened in "Volt 1"

V1 Cut out delay Delay time for cut out of relay

V1 Cut in Cut in value for relay which is dened in "Volt 1"

V1 Cut in delay Delay time for cut in of relay

V1 High alarm limit High alarm limit "Volt 1"

V1 High alarm delay Delay time for high alarm "Volt 1"

V1 Low alarm limit Low alarm limit "Volt 1"

V1 Low alarm delay Delay time for low alarm "Volt 1"

V1 Volt signal type The voltage area that is to send the signal to "Volt 1" is dened here.

0-5 V: Dened with setting = 9

1-5 V: Dened with setting = 11

0-10 V: Dened with setting = 10

2-10 V: Dened with setting = 12

(The received voltage is converted to a value which is dened by the following:

Lower voltage value = Min. read out. Higher voltage value = Max. read out.

It is these limits that form the function's setting values)

V1 Min read out Denition of the reading at the voltage area's lowest value

V1 Max read out Denition of the reading at the voltage area's highest value.

2 There are similar settings for "Volt 2".

6 Menu operation RC8CC202 © Danfoss 09/2012 AK-LM 330 Vers. 1.4x

DI alarm inputs 1-8

Measurements AK error When “ON”, the controller is in alarm condition.

No of DI input The number of DI inputs that have been dened can be read here.

1 to 8 can be read and operated in the following menus.

9 or more can only be read and operated from the Service Tool AK-ST 500.

DI1 status The signal's actual value for DI1 is shown here. On or O (On = alarm)

DI1 No. of cycles/24h The number of signals that have been changed to "On" within the last 24 hours can

be read here.

DI1 On time/24h The amount of time during which the signal has been "On" within the last 24 hours

(shown in %) can be read here.

2, 3, 4, 5, 6, 7,8 There are similar readings for the other DI inputs.

Settings Main switch Main switch: ON: Regulation

OFF: Controller stopped

DI1 alarm fct. When "On", the DI1 alarm function is active.

DI1 alarm delay Delay time for alarm "DI 1"

DI1 Input polarity The input signal's normal situation and alarm situation is dened here

On: Alarm, when the signal to the input is connected (short circuit/volt supply)

O: Alarm, when the signal to the input is cut o

DI1 Total no. of cyc. Readings for the total number of changes to "On". The value can be reset

DI1 Total ON time Readings for total On time. The value can be reset

2, 3, 4, 5, 6, 7,8 There are similar settings for the other DI inputs.

Utility meter 1-2

Measurements AK error When “ON”, the controller is in alarm condition.

No. of util meters Here, it is possible to read how many power reading functions have been dened.

1 to 2 can be read and operated in the following menus.

3 or more can only be read and operated from the Service Tool AK-ST 500.

UM1 Total consump. Readings for the total consumption registered by "Utility Meter 1"

UM1 Today consump. Readings for today's consumption registered by "Utility Meter 1"

UM1 Last week cons. Readings for last week's consumption registered by "Utility Meter 1"

UM1 Actual load Readings for actual load registered by "Utility Meter 1"

UM1 Average load Readings for average load registered by "Utility Meter 1"

2 There are similar readings for "Utility Meter 2".

Settings Main switch Main switch: ON: Regulation

OFF: Controller stopped

Load period Set period time for synchronising pulses

UM1 Start The measurements can be started and stopped here.

UM1 Pulses/unit Dene how many pulses are to be received for each unit of measure

UM1 Scale factor Set scale factor, if required

UM1 Preset counter The counter can be reset here.

2 There are similar settings for "Utility Meter 2".

AK-LM 330 Vers. 1.4x Menu operation RC8CC202 © Danfoss 09/2012 7

Display control

Measurements AK error When “ON”, the controller is in alarm condition.

Settings Main switch Main switch: ON: Regulation

OFF: Controller stopped

Display control A Set what should be read in "Display A"

Display control B Set what should be read in "Display B"

Display control C Set what should be read in "Display C"

Display control D Set what should be read in "Display D"

No reading = 0

"Thermostat 1" to be dened with setting = 1

"Thermostat 2" to be dened with setting = 2

"Thermostat 3" to be dened with setting = 3

"Thermostat 4" to be dened with setting = 4

"Thermostat 5" to be dened with setting = 5

"Thermostat 6" to be dened with setting = 6

"Thermostat 7" to be dened with setting = 7

"Thermostat 8" to be dened with setting = 8

"Thermostat 9" to be dened with setting = 9

"Thermostat 10" to be dened with setting = 10

"Pressostat 1" to be dened with setting = 11

"Pressostat 2" to be dened with setting = 12

"Pressostat 3" to be dened with setting = 13

"Pressostat 4" to be dened with setting = 14

"Pressostat 5" to be dened with setting = 15

"DI1 Alarm" to be dened with setting = 16

"DI2 Alarm" to be dened with setting = 17

"DI3 Alarm" to be dened with setting = 18

"DI4 Alarm" to be dened with setting = 19

"DI5 Alarm" to be dened with setting = 20

"DI6 Alarm" to be dened with setting = 21

"DI7 Alarm" to be dened with setting = 22

"DI8 Alarm" to be dened with setting = 23

"DI9 Alarm" to be dened with setting = 24

"DI10 Alarm" to be dened with setting = 25

"DI11 Alarm" to be dened with setting = 26

"DI12 Alarm" to be dened with setting = 27

"DI13 Alarm" to be dened with setting = 28

"DI14 Alarm" to be dened with setting = 29

"DI15 Alarm" to be dened with setting = 30

"DI16 Alarm" to be dened with setting = 31

Sensor type and calibration

Measurements AK error When “ON”, the controller is in alarm condition.

Settings Main switch Main switch: ON: Regulation

OFF: Controller stopped

Saux 1 oset Correction of the signal from the sensor "Saux 1" if necessary

2,3,4,5,6,7,8 Do for Saux 2,3,4,5,6,7,8

Paux 1 oset Correction of the signal from the pressure transmitter "Paux 1" if necessary

Paux 2 oset Correction of the signal from the pressure transmitter "Paux 2" if necessary

Saux 1 sensor type Denition of the sensor type for the input "Saux 1"

Pt 1000 ohm dened with setting = 0

PTC 1000 ohm dened with setting = 2

2,3,4,5,6,7,8 Do for Saux 2,3,4,5,6,7,8

Paux 1 sensor type Denition of pressure transmitter type and pressure area for "Paux 1"

AKS 32 -6 dened with setting = 1

AKS 32 -9 dened with setting = 4

AKS 32 -12 dened with setting = 7

8 Menu operation RC8CC202 © Danfoss 09/2012 AK-LM 330 Vers. 1.4x

DE-DB

AKS 32 -20 dened with setting = 10

AKS 32 -34 dened with setting = 13

AKS 32 -50 dened with setting = 16

AKS 32R -6 dened with setting = 2

AKS 32R -9 dened with setting = 5

AKS 32R -12 dened with setting = 8

AKS 32R -20 dened with setting = 11

AKS 32R -34 dened with setting = 14

AKS 32R - 50 dened with setting = 17

AKS 2050 -59 dened with setting = 31

AKS 2050 -99 dened with setting = 32

AKS 2050 -159 dened with setting = 33

User-dened dened with setting = 0. + settings via Service Tool.

2 Do for Paux 2.

Alarm priorities

Measurements AK error When “ON”, the controller is in alarm condition.

Settings Main switch Main switch: ON: Regulation

OFF: Controller stopped

The alarm priority of the following alarms can be changed:

High priority is dened with setting = 1

Medium priority is dened with setting = 2

Low priority is dened with setting = 3

Overriding the alarms is dened with setting = 0

Stand by mode (Interrupted regulation) See the above introduction

Saux 1 error See the above introduction

2,3,4,5,6,7,8 As for Saux 1

Paux 1 error See the above introduction

2,3,4,5,6,7,8 As for Paux 1

DI1 See the above introduction

2,3,4,5,6,7,8 As for DI1

Th.1 High alarm See the above introduction

Th 1 Low alarm See the above introduction

2,3,4,5,6,7,8 As for Th. 1

P1 Low alarm See the above introduction

P1 High alarm See the above introduction

2 As for P1

V1 High alarm See the above introduction

V1 Low alarm See the above introduction

2 As for V1

Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products

already on order provided that such alternations can be made without subsequential changes being necessary in specications already agreed.

Otros manuales para AK-LM 330

Tabla de contenidos

Otros manuales de Unidad de control de Danfoss

Danfoss

Danfoss USV-I Manual de usuario

Danfoss

Danfoss 088U0200 Manual de usuario

Danfoss

Danfoss AB-QM Series Manual de usuario

Danfoss

Danfoss MBC 5000 Manual de usuario

Danfoss

Danfoss TUA Manual de usuario

Danfoss

Danfoss Icon Master Guía del usuario

Danfoss

Danfoss VLT HVAC Drive FC 102 Manual de usuario

Danfoss

Danfoss OPTYMA Manual de usuario

Danfoss

Danfoss AMZ 112 Manual de usuario

Danfoss

Danfoss VHX-DUO Manual de instrucciones de instalación

Danfoss

Danfoss DSV 2 Manual de usuario

Danfoss

Danfoss EV210B Instrucciones de funcionamiento

Danfoss

Danfoss ESMD Manual de usuario

Danfoss

Danfoss PVG 100 Manual

Danfoss

Danfoss KVP Series Manual de usuario

Danfoss

Danfoss HPV Manual de usuario

Danfoss

Danfoss TEA 20 Manual de usuario

Danfoss

Danfoss MNF Series Manual de usuario

Danfoss

Danfoss VFS 2 Manual de usuario

Danfoss

Danfoss VLT HVAC Drive FC 102 Manual de usuario

Danfoss

Danfoss BVTS Manual de usuario

Danfoss

Danfoss EV250B NC Manual de instrucciones de instalación

Danfoss

Danfoss TCBE Manual de usuario

Danfoss

Danfoss HPVB15 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
