Dali KATCH G2 Manual de usuario

DALI KATCH G2

MANUAL

CONTENTS

1. Introduction ..............................3

2. Geing to know your KATCH G2...........4

3. Switch On and O .........................5

4. Volume Control ...........................6

5. Baery Charging..........................7

6. Bluetooth .................................8

7. True Wireless Stereo ....................11

8. Sound Modes ............................12

9. Wired Connections ......................13

10. Strap Extension..........................14

11. Factory Reset & Firmware Upgrade ......15

12. Cleaning .................................16

13. Disposal .................................16

14. Technical Speciﬁcations..................17

Model: KATCH G2

DALI KATCH G2

QUICK START GUIDE

SCAN THE CODE

FOR MORE INFO

3 sec

EQ-1

EQ-2

1. INTRODUCTION

Welcome to the DALI KATCH G2, and thank you for trusting DALI with your portable

music. The KATCH G2 takes the features and performance of the original DALI KATCH

and brings evolution to bear, with new colours, more baery life, enhanced Bluetooth

5.0 aptX HD wireless performance, and a True Wireless Stereo mode that enables two

KATCH G2 speakers to link and play stereo.

Some things have no need of change however and the DALI KATCH G2 borrows its

predecessor’s slish Danish design, vivid multi-driver sound, and exceptional build

quali. The newly evolved DALI KATCH G2 is the latest word in compact portable music.

Your DALI KATCH G2 packaging contains:

Universal Mains Charger (1.75 m cable length)

Quick Start Guide

Mains Charger Plugs

Travel Bag

2. GETTING TO KNOW YOUR KATCH G2

Mains Charge Input

USB Charge Output Socket

Stereo Mini-Jack Input

Bluetooth Release

Power On/O

Indicator Lights

Volume Down

Volume Up Sound Mode Toggle

5 6

3. SWITCH ON AND OFF

3.1 Switch ON

To switch ON your DALI KATCH G2:

1. Press and hold the Power On/O buon (Buon 2)

until the switch-on sound plays.

2. The indicator lights (Lights 3) will illuminate to show

that the KATCH G2 is ready for use.

When your DALI KATCH G2 is switched on, the

indicator lights (Lights 3) show the baery charge

state.

3.2 Switch OFF

To switch OFF your DALI KATCH G2:

1. Press and hold the Power On/O buon (Buon 2) until the

switch-o sound plays.

2. The indicator lights (Lights 3) will switch o unless the

KATCH G2 is connected to mains power via its charger (see

5.0).

If your DALI KATCH G2 remains unused for 20 minutes while

running on baery power it will switch o automatically.

Power On/

O

25% 50% 75% 100%

If your KATCH G2 does not switch on, connect it to

mains power via its charger (See 4.0).

4. VOLUME CONTROL

4.1 Volume Down

To reduce the volume of your DALI KATCH G2 press

the Volume Down buon (Buon 4).

To reduce the volume quickly, press and hold the

Volume Down buon (Buon 4).

4.2 Volume Up

To increase the volume of your DALI KATCH G2 press

the Volume Up buon (Buon 5).

To increase the volume quickly, press and hold the

Volume Up buon (Buon 5).

4.3 Volume Indications

The indicator lights (Lights 3) indicate the volume seing.

Volume

Down

Volume

NOTE

When playing Bluetooth

audio, as well as

adjusting volume with

the KATCH G2 buons,

you can also use the

volume buons on your

Bluetooth device.

5. BATTERY CHARGING

To charge the DALI KATCH G2 internal baery, connect the

included mains charger to the KATCH G2 (Connector 9).

Charging will begin as soon the charger is connected to mains

power. The indicator lights (Lights 3) will pulse slowly while

charging is underway while simultaneously indicating charge

state. A full baery charge will take lile more than 2 hours.

Playing music or using the USB charge output (Connector 7)

will increase charge time.

NOTE

Powering the DALI

KATCH G2 through the

mains charger enables

it to play louder and

with more energy. This

is recommended for

optimal performance

when playing loud par

music.

The KATCH G2 has

class leading baery life

but it will vary depending

on use. Play your music

louder and the baery

will drain a lile faster.

With a fully charged baery your KATCH G2 can play

music for up to 30 hours.

6. BLUETOOTH

6.1 Pairing

To connect a Bluetooth audio device to your DALI KATCH G2:

1. Switch on the KATCH G2 (See 3.1). It will immediately

become visible for pairing.

2. Initiate Bluetooth pairing from your audio device seings

and select “DALI KATCH G2”.

3. When pairing is established, the KATCH G2 Bluetooth

pairing sound will play and the indicator lights (Lights 3) will

illuminate in blue.

Indicator

Lights

NOTE

The DALI KATCH G2

employs Bluetooth 5.0

for enhanced range and

connection stabili, and

implements the aptX HD

wireless audio codec for

optimum sound quali.

If a Bluetooth audio device has been previously paired

with your DALI KATCH G2 and is within range, the

KATCH G2 will automatically reconnect to that device.

It is possible for two devices to be paired with your

DALI KATCH G2 simultaneously, only one device at a

time however will be able to connect and play audio.

6. BLUETOOTH

6.2 NFC Pairing

DALI KATCH G2 Bluetooth pairing can also be

initiated using NFC:

1. Switch on the DALI KATCH G2 (See 3.1).

2. Ensure that NFC is enabled in your Bluetooth

audio device.

3. Locate the NFC sensing area of your Bluetooth

audio device.

4. Hold the NFC sensing area of the audio device

close to the side of your KATCH G2, adjacent

to the Power On/O buon (Buon 2), as

shown in the illustration.

NOTE

NFC is short for “Near-

ﬁeld Communication”.

It employs the same

short range mobile

technology used for

mobile phone payments.

NFC Bluetooth pairing

is currently available

only with Android mobile

devices.

NFC

Power On/O 2

DALI KATCH G2 1 DALI KATCH G2 2 DALI KATCH G2 3DALI KATCH G2

6. BLUETOOTH

6.3 Bluetooth Release

If you are unable to pair a Bluetooth device

with your DALI KATCH G2 it is likely that two

devices are already paired. In this case:

1. Press and hold the KATCH G2 Bluetooth

release buon (Buon 1) until the

Bluetooth release sound plays and the

indicator lights ﬂash blue.

2. All paired devices will now be released,

enabling two new devices to be paired.

6.4 Bluetooth Naming

If you have multiple DALI KATCH G2 speakers it is possible to change

their Bluetooth names so that you can keep track of which is which.

1. Switch o each DALI KATCH G2 (See 3.2).

2. Press and hold the Power On/O buon (Buon 2).

3. When the switch on sound plays, keep holding the Power On/O

buon (Buon 2), while simultaneously pressing either the Volume

Up (Buon 5) or Volume Down (Buon 4) to scroll through the

possible name options (DALI KATCH G2, DALI KATCH G2 1, DALI

KATCH G2 2 and DALI KATCH G2 3). The indicator light display for

each option is illustrated in the diagram.
