Thermal Binocular
S750
Operator’s Manual
Zhejiang Dali Technology Co., Ltd
2
Warning and Attention
Never put the lens directly towards to the strong radiation
source (the Sun, direct or reflection lasor beam, etc ) in any
situation (power on or power off) since thermal inductor used in
infrared telescope is very sensitive. Otherwise, infrared telescope
will be damaged permanently.
The original package box must be used in the transportation. Do
not shake or hit the apparatus strongly in use and transportation.
Please use the original package box to store the apparatus. The
environment should be cool,dry,ventilated and no strong
electromagnetic field.
Protect the surface of the lens from being stained or damaged by
oil sludge and any chemical matters. Please put on the lens cap
after using.
Copy the recorded data in your computer in case of the images
and videos lost.
Never open the case or refit the apparatus. Only authorized
people from our company are allowed to do maintenance.
3
Content
1 OVERVIEW.....................................................................................................................................4
2 ACCESS.........................................................................................................................................4
3 MODEL APPEARANCE.................................................................................................................... 5
4 BUTTON FUNCTION...................................................................................................................... 6
5 INTERFACE...................................................................................................................................9
6 OPERATION...................................................................................................................................9
6.1 BATTERY INSTALL/UNINSTALL...................................................................................................9
6.1.1 Battery Install.......................................................................................................9
6.1.2 Battery uninstall................................................................................................ 10
6.2 NOTES ON THE BATTERY.........................................................................................................10
6.3 CAPTURE THERMAL IMAGE................................................................................................12
6.4 USB OPERATION.................................................................................................................12
7 OPERATION GUIDE.................................................................................................................... 13
7.1 Operation mode...............................................................................................................13
7.1.1Infrared imagery mode.............................................................................................. 13
7.1.2 Visible imagery mode.............................................................................................. 13
7.2 OPERATION MENU...............................................................................................................14
7.2.1Main setup menu...........................................................................................................14
7.2.2 Image setup menu.......................................................................................................15
7.2.3 System setup menu.................................................................................................. 19
7.2.4Cross setup menu.........................................................................................................20
7.2.5TASK OPERATION..................................................................................................................... 22
7.3 Phote、Video and Playback...................................................................................... 22
8 TECHNICAL SPECIFICATIONS.................................................................................................. 28
9TROUBLESHOOTING..........................................................................................................29
10 MAINTAINING.........................................................................................................................30
10.1CONTENT................................................................................................................................... 30
11 TRANSPORTATION AND STORAGE.......................................................................................... 32
11.1 STORAGE.........................................................................................................................32
11.2 TRANSPORTATION...........................................................................................................32
4
1 Overview
Thank you for selecting our S750 uncooled thermal binocular.
S750 is developed as whole day surveillance type thermal binocular,
which applies with DALI uncooled detector and display the target thermal
image. The model offer the internal memory system to record all picture
and videos. It meets the demands for public security, smuggling
suppression and boarder control.
2 Access
S750 uncooled thermal binocular
Safety case
Battery(Two normal temperature and two low temperature)
Battery charger
USB & Video cable
Operation manual
5
3 Model appearance
S750 top View
6
4 Button Function
7
S750 Thermal imaging camera have 6 function buttons. All function buttons use pressing
trigger mode,realize corresponding function through shot press(less than 1 second)、long
press(more than 1 second)、continuous press. Function definition on below list:
Button1
Button 2
Button 3
Button 4
Button 5
Button 6
Focus+
Focus -
AUTO/Polarit
y
Photo/Men
u
Video/Playbac
k
Revise/Whit
e Red
Infrared
absent
menu
short
time
press
Infrared
focusing step
forward
Infrared
focusing step
backward
Auto
focus
Video/Stop
Revise
Infrared
absent
menu long
time
press
Infrared
continuous
positive focus
(On pressing)
Infrared
continuous
reverse
focusing (On
pressing)
Black
hot/White
hot
polarity
change
Pop-up
main
menu
Pop-up
playback
menu
Switch to
visible
images
Visible
absent
menu
short
time
press
Cross mark
shown/hidden
/
/
Video/Stop
Revise
Visible
absent
menu long
time
press
/
/
/
Pop-up
main
menu
Pop-up
playback
menu
Switch to
infrared
images
Main menu
operatin
g state
short
time
press
Forward
single-step
adjustment/OK
Reverse
single-step
adjustment/OK
/
Switch
to next
menuitem
/
/
Main menu
operatin
g state
long time
press
Forward
continuous
adjustment(kee
p
pressing)/OK
Reverse
continuous
adjustment(kee
p
pressing)/OK
/
Switch
to next
menuitem
/
/
8
Video/
playback
selectio
n menu
Short
Press
Switch to next
item
Switch to
previous item
/
/
Confirm
/
Video/
playback
selectio
n menu
Long
Press
Switch to next
item
Switch to
previous item
/
/
Exit menu
/
Playback
file
selectio
n menu
Short
press
Switch file
single-pass
downward
Switch file
single-pass
upward
/
/
Playback
/
Playback
file
selectio
n menu
Long
press
Successive
switching file
downward
(keeping
pressing )
Successive
switching file
upward (keeping
pressing )
/
/
Exit menu
/
Playback
in
progress
Short
press
Skip to next
file
Skip to
previous file
/
/
/
/
Playback
in
progress
Long
press
Skip to next
file
Skip to
previous file
/
/
Exit
playback
/
9
5 Interface
Composite interfaces
External video、USB interface，Definition below：
Pin Num
Description
1
CVBS
2
VGND
3
NC
4
NC
5
+12V
6
GND/USBGND
7
USB5V
8
USB D+
9
USB D-
6 Operation
6.1 Battery Install/uninstall
6.1.1 Battery Install
Insert the battery inside the battery compartment, and pay attention to the battery
be placed in the right position as following picture shown.
screw the battery cover tightly.
Note: make sure the battery cover the closed in case of water inside the battery compartment
resulting in the system damaged.
10
6.1.2 Battery uninstall
6.2 Notes on the battery
The standard battery is Polymer lithium battery. Even if there is still electricity left in battery, it has no effect while
charging. Besides, please use the specified charger. If charge, push the battery into charger along with the battery track,
and connect battery and charger.
When charger is connected to power source, charging is started. On top right corner of LCD will indicate charging status
and it will twinkle. When battery electricity displays 100%, it means the battery is full.
Note:
Device standard features include 2 normal temperature battery and 2 low temperature
battery,suggest using normal temperature battery above 0℃,using low temperature
battery below 0℃.
Loose the screw
