Wiring adaptor for electrical
appendices
KRP1BA58
Installation Manual
4P563369-1
English 1
Be sure to read this manual before installation and follow the instruction.
Accessories
Check if the following accessories are included:
Name Adaptor PCB Support Clamp Installation
manual
Shape
Quantity 1x 4x 3x 1x
Names of parts
Output terminals
X1A
English 2
Electric wiring
• Refer to the wiring diagram attached to the indoor unit before at-
tempting to wire.
• Make sure wires to units do not pass over the PC board when wiring.
• Wire the adaptor to the indoor unit as described below.
Indoor unit PC board
X33A
X1A
Receiving the operation display signal
Attaching an hour meter
Output is generated at the contact while the compressor is running.
HM
HM: Hour meter (field supply)
AC 220~240V
X1
X2
Example: Carrying capacity 20mA and above or 1.2A and below
Fan ON display
Output is generated at the contact while the fan is running.
OL
OL: Operation lamp (field supply)
AC 220~240V
X3
X4
Example: Carrying capacity 20mA and above or 1.2A and below
English 3
Installation
• Do not bundle low and high voltage wires together.
• Bundle any excess wires with the attached tie wraps to keep loose
wirings o the indoor unit PC board.
Ceiling-mounted cassette type
Note: Installation box for adaptor PCB is required to install the adaptor.
Lid of installation box KRP1H98
PCB support
Adaptor KRP1BA58
Installation box for adaptor PCB
KRP1H98
4P563369-1 2019.01
