Daewoo RC-220 Manual de usuario

2 3

NAMES OF PARTS AND OPERATION TECHNIQUE

HOSE CONNECTION SUCTION CONTROL

•

The suction power control at

the hand grib enables you to

control suction power.

EXTENSION PIPE

• Press the button in the

direction shown by the

arrows and pull (or push)

the pipe.

WIDE SUCTION NOZZLE

• TUse this nozzle for cleaning both

carpeted and uncarpeted floors.

ON/OFF SWITCH

• Press the on/off switch.

CORD REWIND BUTTON

• Rewind the power cord by

pressing the cord rewind

button.

DUST METER

• When the colour of the

dust meter is changed to

RED for long time,

change the dust bag.

STORAGE

•

If you want to store the

cleaner, hitch the brush clip

onto the vacuum cleaner.

PRACTICAL PARKING

• If you want to stop vacuum

cleaning for a while, you

can place the brush clip

into the rest.

COMBI CREVICE NOZZLE

• Connecting the hose :

insert the hose firmly into

the hose inlet. (“Click”)

•

Disconnecting the hose: press

the button and pull the hose out

of the vacuum cleaner.

restbrush clip

CLEANING THE FILTER PRECAUTIONS FOR SAFE USE

This vacuum cleaner should only be used for normal dry household dust and dirt.

The manufacturer cannot be responsible for any damage caused by use or operation of the

cleaner contrary to these instructions.

If the cleaner is wrongly operated for a purpose other than that for which it is intended. no

liability can be accepted for any possible damage.

CHANGING THE DUST BAG

•

Switch off.

• Pull the filter case outwards

from the cleaner.

•

Separate the filter from the

filter case and shake the

dust out of the filter.

•

Do not vacuum areas which contain moisture

or water and inflammable matter, needles,

pins, razor blades, matches, cigarette-ends,

etc., since they may damage the cleaner or

dust bag or cause a fire.

•

When rewinding the power cord, hold the

plug body before pressing the cord rewind

button to prevent whipping.

•

Do not pull the power cord beyond the

specified length.

•

Make sure a dust bag and a motor protection

filter are always inserted.

•

This product provided with a cable which, if

damaged must be replaced by a repair shop

authorized by the manufacturer since special

tools are required.

•

Switch off and open the

cover.

•

Hold the cover while taking the

filter out of the cleaner.

•

Shake the dust out of the

filter.

EXHAUST FILTER

MOTOR PROTECTION

FILTER

•

Switch off and open the

cover.

•

Hold the cover while separating

the dustbag from the dustbag

holder.

•

Insert the new dust bag into

the dust bag holder properly

as shown in picture.

Note: If no dustbag has been

placed into the dustbag holder,

the cover cannot be closed.
