D-Link DIR-615S Manual de usuario
Quick Installation Guide
DIR-615S
Wireless N300 Router
DIR-615S Quick Installation Guide
BEFORE YOU BEGIN
Delivery Package
•Router DIR-615S
•Power adapter DC 12V/0.5A
•Ethernet cab e (CAT 5)
•“Quick Installation Guide” (brochure).
If any of the items are missing, p ease contact your rese er.
The “User Manual” and “Quick Installation Guide” documents are avai ab e
on D-Link website (see www.d ink.ru).
!Using a power supply with a different voltage rating than the one
included will cause damage and void the warranty for this product.
Default Settings
IP add ess of wi eless oute 192.168.0.1
Use name (login) admin
Passwo d admin
Name of wi eless netwo k (SSID) DIR-615
Netwo k key (PSK)
see WPS PIN on the
barcode abe on the
bottom pane of the
device
2
DIR-615S Quick Installation Guide
System Requirements and Equipment
•A computer with any operating system that supports a web browser.
•A web browser to access the web-based interface of the router:
◦App e Safari 5 and ater
◦Goog e Chrome 5 and ater
◦Microsoft Internet Exp orer 8 and ater
◦Mozi a Firefox 5 and ater
◦Opera 10 and ater.
•A NIC (Ethernet or Wi-Fi adapter) to connect to the router.
•An 802.11b, g, or n Wi-Fi adapter to create a wire ess network.
3
DIR-615S Quick Installation Guide
CONNECTING TO PC
PC with Ethernet Adapter
1. Make sure that your PC is powered off.
2. Connect an Ethernet cab e between any of LAN ports ocated on the back
pane of the router and the Ethernet port of your PC.
3. Connect the power cord to the power connector port on the back pane of
the router, then p ug the power adapter into an e ectrica out et or power
strip.
4. Turn on the router by pressing the ON/OFF button on its back pane .
5. Turn on your PC and wait unti your operating system is comp ete y
oaded.
Now you shou d configure your PC to obtain an IP address automatica y (as
DHCP c ient).
4
DIR-615S Quick Installation Guide
Obtaining P Address Automatically
in OS Windows XP
1. C ick the Sta t button and proceed to the Cont ol Panel > Netwo k
and Inte net Connections > Netwo k Connections window.
2. In the Netwo k Connections window, right-c ick the re evant Local
A ea Connection icon and se ect the P ope ties ine in the menu
disp ayed.
3. In the Local A ea Connection P ope ties window, on the Gene al
tab, se ect the Inte net P otocol (TCP/IP) ine. C ick the P ope ties
button.
5
DIR-615S Quick Installation Guide
4. Se ect the Obtain an IP add ess automatically and Obtain DNS
se ve add ess automatically radio buttons. C ick the OK button.
5. C ick the ОК button in the connection properties window.
Now your computer is configured to obtain an IP address automatica y.
6
DIR-615S Quick Installation Guide
Obtaining P Address Automatically
in OS Windows 7
1. C ick the Sta t button and proceed to the Cont ol Panel window.
2. Se ect the Netwo k and Sha ing Cente section. (If the Contro Pane
has the category view (the Catego y va ue is se ected from the View by
drop-down ist in the top right corner of the window), choose the View
netwo k status and tasks ine under the Netwo k and Inte net
section.)
3. In the menu ocated on the eft part of the window, se ect the Change
adapte settings ine.
4. In the opened window, right-c ick the re evant Local A ea Connection
icon and se ect the P ope ties ine in the menu disp ayed.
5. In the Local A ea Connection P ope ties window, on the
Netwo king tab, se ect the Inte net P otocol Ve sion 4 (TCP/IPv4)
ine. C ick the P ope ties button.
7
DIR-615S Quick Installation Guide
6. Se ect the Obtain an IP add ess automatically and Obtain DNS
se ve add ess automatically radio buttons. C ick the OK button.
7. C ick the OK button in the connection properties window.
Now your computer is configured to obtain an IP address automatica y.
8
DIR-615S Quick Installation Guide
PC with Wi-Fi Adapter
1. Connect the power cord to the power connector port on the back pane of
the router, then p ug the power adapter into an e ectrica out et or power
strip.
2. Turn on the router by pressing the ON/OFF button on its back pane .
3. Turn on your PC and wait unti your operating system is comp ete y
oaded.
4. Turn on your Wi-Fi adapter. As a ru e, modern notebooks with bui t-in
wire ess NICs are equipped with a button or switch that turns on/off the
wire ess adapter (refer to your PC documents). If your PC is equipped
with a p uggab e wire ess NIC, insta the software provided with your
Wi-Fi adapter.
Now you shou d configure your Wi-Fi adapter.
9
DIR-615S Quick Installation Guide
Configuring Wi-Fi Adapter in OS Windows XP
1. C ick the Sta t button and proceed to the Cont ol Panel > Netwo k
and Inte net Connections > Netwo k Connections window.
2. Se ect the icon of the wire ess network connection and make sure that
your Wi-Fi adapter is on.
3. Search for avai ab e wire ess networks.
4. In the opened Wi eless Netwo k Connection window, se ect the
wire ess network DIR-615 and c ick the Connect button.
5. In the opened window, enter the network key (see WPS PIN on the
barcode abe on the bottom pane of the device) in the Netwo k key and
Confi m netwo k key fie ds and c ick the Connect button.
After that the Wi eless Netwo k Connection Status window appears.
!
If you perform initia configuration of the router via Wi-Fi connection,
note that immediate y after changing the wire ess defau t settings of the
router you wi need to reconfigure the wire ess connection using the
new y specified settings.
