D-Link DWL-AG700AP - AirPlus AG - Wireless Access... Manual de usuario

DWL-AG700AP User’s Manual

D-Link Systems, Inc.

Table of Contents

Table of Contents ............................................................................2

Package Contents ............................................................................3

Introduction ....................................................................................4

Connections ....................................................................................5

LEDs................................................................................................6

Features and Benefits ......................................................................7

Wireless Basics ................................................................................8

Installation Considerations ..............................................................9

Getting Started ............................................................................. 10

Using the Configuration Menu .................................................... 11

Networking Basics........................................................................ 30

Troubleshooting........................................................................... 46

Technical Specifications ............................................................... 52

Contacting Technical Support...................................................... 55

Warranty ..................................................................................... 56

Registration .................................................................................. 59

DWL-AG700AP User’s Manual

D-Link Systems, Inc.

Package Contents

Note: Using a power supply with a different voltage than the one included with the

DWL-AG700AP will cause damage and void the warranty for this product.

If any of the above items are missing, please contact your reseller.

Package Contents

D-Link

Air

Plus AG DWL-AG700AP

Wireless AG Access Point

Power Supply - 5V DC 2.0A

Manual on CD

Quick Installation Guide

Ethernet Cable

Minimum System Requirements

Computers with Windows XP/2000, Macintosh, or Linux-based operating

systems with an installed Ethernet Adapter

Internet Explorer version 6.0 or Netscape Navigator version 7.0 and above

DWL-AG700AP User’s Manual

D-Link Systems, Inc.

Introduction

With a maximum wireless signal rate of up to 54Mbps*, the DWL-AG700AP is a wireless

access point that enables dualband networks, conveniently delivering connectivity in

both the 802.11a and 802.11g bands.

With the DWL-AG700AP, bandwidth-intensive applications like graphics or multimedia

will benefit significantly because large files are able to move across the network quickly.

The D-Link

Air

Plus AG DWL-AG700AP provides maximum security with the option of

WPA or WEP. Additional security is provided with the optional use of filters for managing

network access.

With dualband capabilities, maximum wireless signal rates up to 54Mpbs, enhanced

security features including WPA and optional filter management, the DWL-AG700AP is

a versatile choice for your diverse network needs.

*Maximum wireless signal rate based on IEEE Standard 802.11a/g specifications. Actual data throughput will vary. Network

conditions and environmental factors lower actual data throughput rate.

DWL-AG700AP User’s Manual

D-Link Systems, Inc.

Connections

The Auto/MDIX LAN port automatically

senses the cable type when connecting

to Ethernet-enabled computers.

Pressing the Reset Button

restores the router to its original

factory default settings.

Receptor for the Power Adapter.

DWL-AG700AP User’s Manual

D-Link Systems, Inc.

LEDs

Power LED

A solid light indicates a proper

connection to the power supply.

WLAN LED

A solid light indicates that the wireless segment

(802.11a and/or 802.11b/g) is ready. This LED blinks

during data transmission.

LOCAL NETWORK

LED

A solid light indicates

a connection (10M

and/or 100M) to an

Ethernet port.The

LEDs blink during

data transmission.

DWL-AG700AP User’s Manual

D-Link Systems, Inc.

Features and Benefits

*Maximum wireless signal rate based on IEEE Standard 802.11a/g specifications. Actual data throughput will vary.

Better security with WPA-PSK - The DWL-AG700AP can securely connect to

wireless clients on the network using WPA-PSK providing a much higher level of

security for your data and communications than has previously been available.



Compatible with IEEE802.11a and IEEE802.11g standards to provide a wireless

data rate of up to 54Mbps.*



Backward compatible with the 802.11b standard to provide a wireless data rate

of up to 11Mbps with 802.11b devices - that means you can migrate your system to

the 802.11g standard on your own schedule without sacrificing connectivity.



Supports WEP encryption.



Optional filter management feature - Access to your network can be controlled by

the MAC addresses of the devices, using the optional filter tool included in your

convenient Web-based management utility.



DWL-AG700AP User’s Manual

D-Link Systems, Inc.

Wireless Basics

D-Link

wireless products are based on industry standards to provide easy-to-use and

compatible high-speed wireless connectivity within your home, business or public access

wireless networks. D-Link wireless products will allow you access to the data you want,

when and where you want it. You will be able to enjoy the freedom that wireless

networking brings.

A Wireless Local Area Network (WLAN) is a computer network that transmits and

receives data with radio signals instead of wires. WLANs are used increasingly in both

home and office environments, and public areas such as airports, coffee shops and

universities. Innovative ways to utilize WLAN technology are helping people to work

and communicate more efficiently. Increased mobility and the absence of cabling and

other fixed infrastructure have proven to be beneficial for many users.

People use WLAN technology for many different purposes:

Mobility - Productivity increases when people have access to data in any location

within the operating range of the WLAN. Management decisions based on real-time

information can significantly improve worker efficiency.

Low Implementation Costs - WLANs are easy to set up, manage, change and relocate.

Networks that frequently change can benefit from WLANs ease of implementation.

WLANs can operate in locations where installation of wiring may be impractical.

Installation and Network Expansion - Installing a WLAN system can be fast and easy

and can eliminate the need to pull cable through walls and ceilings.Wireless technology

allows the network to go where wires cannot go - even outside the home or office.

Inexpensive Solution - Wireless network devices are as competitively priced as

conventional Ethernet network devices.The DWL-AG700AP saves money by providing

multi-functionality, configurable in one of four different modes.

Scalability - WLANs can be configured in a variety of ways to meet the needs of specific

applications and installations. Configurations are easily changed and range from Peer-

to-Peer networks suitable for a small number of users to larger Infrastructure networks

to accommodate hundreds or thousands of users, depending on the number of wireless

devices deployed.

Wireless users can use the same applications they use on a wired network. Wireless

adapter cards used on laptop and desktop systems support the same protocols as

Ethernet adapter cards.

DWL-AG700AP User’s Manual

D-Link Systems, Inc.

The D-Link DWL-AG700AP lets you access your network, using a wireless connection,

from virtually anywhere within its operating range. Keep in mind, however, that the

number, thickness and location of walls, ceilings, or other objects that the wireless

signals must pass through, may limit the range. Typical ranges vary depending on the

types of materials and background RF (radio frequency) noise in your home or business.

The key to maximizing wireless range is to follow these basic guidelines:

Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or

appliances that generate RF noise.

Keep the number of walls and ceilings between the DWL-AG700AP and other

network devices to a minimum - each wall or ceiling can reduce your DWL-AG700AP’s

range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or

ceilings is minimized.

Be aware of the direct line between network devices. A wall that is 1.5 feet thick

(.5 meters), at a 45-degree angle appears to be almost 3 feet (1 meter) thick. At a

2-degree angle it looks over 42 feet (14 meters) thick! Position devices so that the

signal will travel straight through a wall or ceiling (instead of at an angle) for better

reception.

Building materials can impede the wireless signal - a solid metal door or aluminum

studs may have a negative effect on range. Try to position wireless devices and

computers with wireless adapters so that the signal passes through drywall or open

doorways and not other materials.

Installation Considerations

DWL-AG700AP User’s Manual

D-Link Systems, Inc.

Getting Started

Consult with your Cable or DSL provider for proper installation of the modem.

Connect the Cable or DSL modem to a Router.

(

See the printed Quick Installation Guide included with your router.

)

Install a wireless AG adapter into computer 1.

(

See the printed Quick Installation Guide included with the wireless AG

adapter.

)

You will need broadband Internet access.

Connect the Router to the DWL-AG700AP.

(

See the printed Quick Installation Guide included with the DWL-AG700AP.

)

Install a wireless AG adapter into computer 2.

(

See the printed Quick Installation Guide included with the wireless AG

adapter.

)
