DAP-2610

Quick Installation Guide

Nuclias Connect AC1300 Wave 2 Dual Band PoE Access Point

Contents

English 1

DAP-2610 Quick Installation Guide 1

ENGLISH

System Requirements

• Computers with Windows®, Macintosh®,

or Linux-based operating systems with an

installed Ethernet Adapter

• Internet Explorer 11, Safari 7, Firefox 28,

or Google Chrome 33 and above (for

conﬁguration)

Hardware Overview

LED Indicators

Figure 1: Front Panel LED

# LED Description

1Power/

Status

Green (Solid) - Device operational

Red (Flashing) - Device booting

up/Device malfunctioned

Red (Solid) - Device boot up

has failed

Table 1: LED Description

Before You Begin

This installation guide provides instructions

for installing the DAP-2610 on your network.

Additional documentation is also available on

the D-Link support website.

• Nuclias Connect Manual: For additional

information and instructions on how

to configure the device using Nuclias

Connect.

• DAP-2610 User Manual: For additional

information and instructions on how to

conﬁgure the device using the web user

interface.

Package Contents

This DAP-2610 package includes the following

items:

• DAP-2610 Access Point

• Power Adapter (Optional)

• Mounting Plate and Hardware

• Quick Start Guide

If any of the above items are damaged or

missing, please contact your local D-Link reseller.

Note: Using a power supply with a diﬀerent

voltage than the one recommended for the

device will cause damage and void the warranty

for this product.

Note: No power adapter is supplied with this

product. To power the unit, use an 802.3af PoE

Switch or an 802.3af PoE Injector.

2DAP-2610 Quick Installation Guide

ENGLISH

Interface Connectors

Figure 2: Rear Connectors

# Connector Description

1Power

Input

Input for the power adapter,

however the device can be

powered over Ethernet.

Note: An 802.3af PoE injector is not

included in the package contents,

but can be purchased separately.

2LAN(PoE)

Port

Gigabit RJ-45 port for data and

Power over Ethernet (PoE) power.

Table 2: Interface Description

Installation

The DAP-2610 can be powered using one of the

following two methods:

Using Power over Ethernet (PoE)

1. Use a standard Ethernet cable to connect

the LAN port on the DAP-2610 to a PoE

power source device such as an 802.3af

PoE switch or 802.3af PoE injector.

1 2

Using a Power Adapter (Optional)

1. Connect the power connector of the

adapter to the power input on the

DAP-2610 and plug the adapter into a

nearby power outlet.

Conguration

Using Nuclias Connect

The DAP-2610 is designed to be managed

through Nuclias Connect. Refer to the Nuclias

Connect Manual for detailed configuration

instructions.

Manual Conguration

Note: D-Link recommends manually conﬁguring

the device before mounting it.The management

computer, DHCP server and DAP-2610 must be

in the same subnet.

Use one of the following methods to access the

web user interface:

Connecting through Ethernet

1. Use an Ethernet cable to connect the

DAP-2610 to the management computer,

or to the switch or router the management

computer is connected to.

2. Manage the access point from a computer.

Enter dap2610.local in the address ﬁeld

of your browser.

3. Log in to the administration user

interface. The default login information is

Username: admin

Password: admin

DAP-2610 Quick Installation Guide 3

ENGLISH

Connecting Wirelessly

1. Connect the management computer to

the default SSID of the DAP-2610, “dlink”.

2. Manage the access point from a computer.

Enter dap2610.local in the address ﬁeld

of your browser.

3. Log in to the administration user

interface. The default login information is

Username: admin

Password: admin

Mounting

Mounting on a Solid Wall or Ceiling

Figure 3: Attaching the Mounting Plate

1. Use the mounting plate to mark the

location where to drill the holes in the

wall or ceiling.

2. Drill holes on the markings and place the

included anchors into the drilled holes.

3. Align and place the mounting plate on

top of the anchors and use the included

screws to secure the mounting plate to

the surface.

4. Plug the Ethernet cable into the LAN

(PoE) port of the device. Note: If you are

powering the device with a power adapter,

plug the adapter into the Power Input port.

Figure 4: Mounting the Device

5. Slide the DAP-2610 down into the grooves

on the mounting plate to secure it to

the plate.

Mounting with Ceiling Brackets

Figure 5: Attaching the Ceiling Brackets

1. Clip the two ceiling brackets onto a ceiling

crossbar.

4DAP-2610 Quick Installation Guide

ENGLISH

Figure 6: Attaching the Mounting Plate

2. Use the included screws to secure the

mounting plate to the ceiling brackets.

3. Plug the Ethernet cable into the LAN

(PoE) port of the device. Note: If you are

powering the device with a power adapter,

plug the adapter into the Power Input port.

Figure 7: Mounting the Device

4. Slide the DAP-2610 down into the grooves

on the mounting plate to secure it to

the plate.

ErP Power Usage

This device is an Energy Related Product (ErP) that automatically switches to a power-saving Network

Standby mode within 1 minute of no packets being transmitted. It can also be turned o through a

power switch to save energy when it is not needed.

Network Standby: 2.62 watts

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment o and on, the user is encouraged to try to correct the

interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/TV technician for help.

Non-modications Statement:

Any changes or modications not expressly approved by the party responsible for compliance could

void the user’s authority to operate this equipment.

Caution:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

This device and its antenna(s) must not be co-located or operating in conjunction with any other

antenna or transmitter except in accordance with FCC multi-transmitter product procedures. For product

available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is

not possible.

Note

The country code selection is for non-USA models only and is not available to all USA models. Per FCC

regulations, all WiFi product marketed in the USA must be xed to USA operational channels only.

RF Frequency Requirements

Appendix - Statements

This device is for indoor use only when using all channels in the 5.15 to 5.25 GHz frequency range. High

power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These

radar stations can cause interference with and/or damage this device. This device will not operate on

channels which overlap the 5600-5650 MHz band.

It is restricted to indoor environments only.

IMPORTANT NOTICE:

Innovation, Science and Economic Development Canada (ISED) Statement:

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Innovation, Science and Economic Development Canada (ISED) Statement:

This device complies with ISED licence-exempt RSS standard(s). Operation is subject to the following two

conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause undesired

operation of the device.

Le présent appareil est conforme aux CNR d’ISED applicables aux appareils radio exempts de licence.

L’exploitation est autorisée aux deux conditions suivantes :

(1) l’appareil ne doit pas produire de brouillage, et

(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le

brouillage est susceptible d’en compromettre le fonctionnement.

(i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for

harmful interference to co-channel mobile satellite systems;

(i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une

utilisation à l’intérieur an de réduire les risques de brouillage préjudiciable aux systèmes de satellites

mobiles utilisant les mêmes canaux;

Operations in the 5.25-5.35 GHz band are restricted to indoor usage only.

Les opérations dans la bande de 5.25-5.35 GHz sont limités à un usage intérieur seulement.

Radiation Exposure Statement

This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operated with minimum distance 0.28 m between the radiator

and your body.

Déclaration d’exposition aux radiations

Cet équipement est conforme aux limites d’exposition aux rayonnements ISED établies pour un

environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 0.28 m de

distance entre la source de rayonnement et votre corps.

Japan Voluntary Control Council for Interference Statement

TECHNICAL SUPPORT dlink.com/support

この装置は、クラス B情報技術装置です。この装置は、家庭環境で使用することを目的としてい

ますが、この装置がラジオやテレビジョン受信機に近接して使用されると、受信障害を引き起こ

すことがあります。

取扱説明書に従って正しい取り扱いをして下さい。

Japan Voluntary Control Council for Interference Statement

This is a Class B product based on the standard of the VCCI Council. If this is used near a radio or

television receiver in a domestic environment, it may cause radio interference. Install and use the

equipment according to the instruction manual.

電波法により5GHz帯は屋内使用に限ります。

Product and Warranty Information

To nd out more about D-Link Nuclias product or marketing information, please visit the website

http://www.dlink.com or https://www.nuclias.com.

The D-Link Limited Lifetime Warranty information is available at

http://www.dlink.com/warranty

VCCI-B

Notes

Otros manuales para DAP-2610

Tabla de contenidos

Otros manuales de Punto de acceso inalámbrico de D-Link

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manual de usuario

D-Link

D-Link Rangebooster N 650 Access Point DAP-1353 Manual de usuario

D-Link

D-Link xtreme n duo dap-1522 Manual de usuario

D-Link

D-Link AirPremier DWL-00AP Manual de usuario

D-Link

D-Link AirPlus Xtreme G DWL-2000AP Manual de usuario

D-Link

D-Link AirPremier N DAP-2690 Manual de usuario

D-Link

D-Link DAP-3310 Manual de usuario

D-Link

D-Link DWL-3500AP Manual de usuario

D-Link

D-Link DAP-600P Manual de usuario

D-Link

D-Link DAP-3520 - AirPremier N Dual Band Exterior PoE Access... Manual de usuario

D-Link

D-Link DAP-2330 v 1.0 Manual de usuario

D-Link

D-Link D DWL-G700AP DWL-G700AP Manual de usuario

D-Link

D-Link DWL-2700AP - AirPremier Outdoor Wireless Access... Manual de usuario

D-Link

D-Link DWL-G700AP - AirPlus G Access Point Manual de usuario

D-Link

D-Link DAP-2553 - Wireless N Dual Band Gigabit Access... Manual de usuario

D-Link

D-Link DAP-2020 Manual de usuario

D-Link

D-Link DWL-6720AP Manual de usuario

D-Link

D-Link AirPremier DAP-2565 Manual de usuario

D-Link

D-Link DAP-3520 - AirPremier N Dual Band Exterior PoE Access... Manual de usuario

D-Link

D-Link AirPremier N DAP-2310 Manual de usuario

D-Link

D-Link DPN-101G Manual de usuario

D-Link

D-Link DWL-6600AP Manual de usuario

D-Link

D-Link DAP-3315 Manual de usuario

D-Link

D-Link AirPro DWL-5000AP Manual de usuario

Manuales populares de Punto de acceso inalámbrico de otras marcas

Ubiquiti

Ubiquiti NanoStation NSM2 Manual de usuario

Cisco

Cisco Aironet 1550 Series Manual de usuario

Aruba

Aruba IAP-335 Manual de usuario

Advantek Networks

Advantek Networks AWN-AP-54MR Manual de usuario

IP-COM

IP-COM AP355 Manual de usuario

Buffalo

Buffalo AirStation WLA-L11G Manual de usuario

EnGenius

EnGenius EnStationACv2 Manual de usuario

xG Technology

xG Technology xMax CN1300 Manual de usuario

Widelink

Widelink ezWave WAP-1100 Series Manual de usuario

Edimax

Edimax CAP1200 Manual de usuario

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manual de usuario

Aruba

Aruba AP-203R Manual de usuario

LuXout Shades

LuXout Shades LUXSHADE MOTION Manual de usuario

CreatComm

CreatComm TB5F Manual de usuario

SineDigital

SineDigital MW-1500AP(H) Manual de usuario

TP-Link

TP-Link AP9650 V1 Manual de usuario

Draytek

Draytek VIGORAP 902 Manual de usuario

EnGenius

EnGenius EAP350 Manual de usuario
