D-Link DAP-2610 Manual de usuario

This document will guide you through the basic installation

process for your new D-Link Wireless AC Access Point.

DAP-2610

Quick Installation Guide

Nuclias Connect AC1300 Wave 2 Dual Band PoE Access Point

Documentation also available on

the D-Link Website

D-Link DAP-2610 Quick Install Guide

ENGLISH

DAP-2610 Quick Start Guide

This installation guide provides basic instructions for installing the DAP-2610 Wireless Access

Point on your network. For additional information about how to use the Access Point, please

see the User’s Manual which is available on the CD included in this package or from the

D-Link support website.

System Requirements

Minimum System Requirements:

• an Ethernet port, or an installed Ethernet adapter

• Internal Explore 11, Safari 7, Firefox 28, Google Chrome 33 or later versions of these

browsers

1. Package Contents

DAP-2610 802.11ac Power over Ethernet (PoE) Access Point

Mounting Brackets

Quick Start Guide

If any of the above items are missing, please contact your reseller.

NOTE no PSU supplied. To power the units use an D-Link PoE switch or the D-Link

DPE-101GI PoE injector.

D-Link DAP-2610 Quick Install Guide 3

ENGLISH

2. Hardware Overview

LED

Power/Status LED - Dual color (Red/green)

. Flash Red during booting up or malfunction

. Static Green while it’s ready/working

. Solid Red while boot up fail

Interfaces

Power Receptor

(*Note no longer used,

replaced by PoE)

LAN Port (PoE)

* PoE kit (injector and adapter) is NOT include in the package and it can be purchased

with the model name "DPE-101GI".

D-Link DAP-2610 Quick Install Guide

ENGLISH

2. Connect the access point and your computer to the same switch. Manage the access

point from the computer.

Enter http://dap2610.local/ in the address field of your browser, which is the default IP

address of the access point.

Username: admin

Password: admin

Power on the access point

To power on the DAP-2610, you can use ONE of the following methods:

1. Plug one end of your Ethernet cable into the LAN port of the DAP-2610, and the other

end into a port on a PoE switch.

2. Purchase separately a DPE-101GI PoE injector if you need to connect the Access

Point without a PoE Switch.

Congure the access point

To set up and manage the DAP-2610, use one of the following methods:

1. Connect the access point and your computer via DPE-101GI. Manage the access

point from the computer.

Ensure your computer is congured with a static IP address in http://dap2610.local/

subnet.

Launch a web browser, type the default IP address of the access point http://dap2610.

local/ and then press Enter.

Username: admin

Password: admin

3. Installation

Computer

PoE Switch

DAP-2610

Computer

PoE Injector

Power

Adapter

D-Link DAP-2610 Quick Install Guide 5

ENGLISH

Installation

1. Place the mounting bracket on a wall or

ceiling.

5. Plug the Ethernet cable into the LAN

port on the access point.

6. To attach the access point to the

mounting bracket.

2. Mark the points where you will insert the

screws. Take out the mounting ring.

3. Drill holes in the marked points and

insert the plastic wall anchors.

4. Use the supplied screws to attach the

mounting ring to the wall.

TECHNICAL SUPPORT dlink.com/support

Ver. 1.01(WW)_130x183

2019/10/10
