D-Link DSB-C320 Manual de usuario
Before You Begin
You must have at least the following:
zPentium III 500 MHz, Celeron, AMD Athlon processor, or higher
z64MB RAM (or minimum OS requirement whichever is higher)
zMicrosoft Windows VISTA/XP/2000
zMicrosoft DirectX 9.0c or higher
zUpdate Service Pack
z200MB free hard drive space
zCD-ROM drive
zUSB Port (USB specificaiton version 1.1)
z24Bit color display adapter
zWindows compatible sound card and speakers (full duplex sound card
recommended)
Check Your Package Contents
These are the items included with your purchase:
If any of the below items are missing, please contact your reseller.
©2008 D-Link System, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective
holders. Software and specifications subject to change without notice.
This product works with the
following operating system
software: Windows
VISTA/XP/2000
D
S
B-
C
320 U
S
B P
C
C
AMERA
DSB-C320
D-Link 330K Pixel USB
PC Camera
CD-ROM(containing Drivers, Application
Software, PDF Installation Guide, PDF
Manual, and Warranty)
USB 1.1 Cable
Run the Driver CD
before you install
the PC Camera.The Driver
CD contains an
installation program that
simplifies your
installation process.
2
DSB-C320 Driver Installation
Please bring out the attached CD-ROM and follow the steps listed
below carefully to insure the installation of DSB-C320 will be
complete.
If the Autorun screen does not automatically start, click on Start >
Run, enter „D:\Autorun.exe” and click OK. „D” represents the letter
of your CD-ROM drive. Replace it if your CD-ROM drive is a different
letter.
Click Install DSB-C320
Driver
Insert the software CD into
CD-ROM. As you can see
the below picture,D-Link
DSB-C320 startup window
will be displayed.
3
Windows Vista Users
Click Next
4
Click Finish
Plug the USB cable into camera
and USB port on the PC directly.
When all setup
procedures are finished,
you MUST restart the
operating system manually
after you plugged the USB
cable into camera and USB
port as well as ran image
device sucessfully.
5
Windows XP/2000 Users
Click Next
Click Next
6
Click Next
Plug the USB cable into camera
and USB port on the PC directly.
When all setup
procedures are finished,
you MUST restart the
operating system manually
after you plugged the USB
cable into camera and USB
port as well as ran image
device sucessfully.
7
Driver Installing is Completed!
To confirm the DSB-C320 is properly installed, click “START”
→”SETTINGS”→”CONTROL PANEL”. Double-click ”SYSTEM”. Select
the ”HARDWARE” tab and click the ”DEVICE MANAGER” button.
Confirm that „”D-Link DSB-C320” appears in the ”IMAGE DEVICES”
section.
Once properly installed, you are ready to start immediately capturing
images and a creating video with the DSB-C320.
Please refer to the DSB-C320 Manual on the CD included with this
product for information on how to install and use the CrazyTalk Cam
Suite software.
8
Attention:
1. Make sure to install the driver and software BEFORE plugging the
camera into USB port.
2. We recommend plugging the cable connector to USB pot on PC
directly to avoid low voltage.
3. If a dialog box pops up and request to have the language setting file
replaced after plugging the camera into USB port, please simply click
“Yes” to continue.
4. Please download the latest update of “Service Pack” (from Start Æ
Windows Update) to keep the camera running smoothly.
5. If you have more than one image device in your system, please select
the “D-Link DSB-C320” as the PC Camera device. In this way, you can
use this camera to capture images.
6. Please update the DirectX to 9.0c version if you use old version or
never installed before. It can help webcam to run more smoothly.
9
Technical Support
You can find software updates and user documentation on the D-Link website.
Tech Support for customers in
Australia:
Tel: 1300-766-868
Monday to Friday 8:00am to 8:00pm EST
Saturday 9:00am to 1:00pm EST
http://www.dlink.com.au
e-mail: [email protected]
India:
Tel: 1800-222-002
Monday to Friday 9:30AM to 7:00PM
http://www.dlink.co.in/support/productsupport.aspx
Indonesia, Malaysia, Singapore and Thailand:
Tel: +62-21-5731610 (Indonesia)
Tel: 1800-882-880 (Malaysia)
Tel: +65 66229355 (Singapore)
Tel: +66-2-719-8978/9 (Thailand)
Monday to Friday 9:00am to 6:00pm
http://www.dlink.com.sg/support/
e-mail: support@dlink.com.sg
Korea:
Tel: +82-2-890-5496
Monday to Friday 9:00am to 6:00pm
http://www.d-link.co.kr
e-mail: lee@d-link.co.kr
New Zealand:
Tel: 0800-900-900
Monday to Friday 8:30am to 8:30pm
Saturday 9:00am to 5:00pm
http://www.dlink.co.nz
e-mail: support@dlink.co.nz
10
Technical Support
You can find software updates and user documentation on the D-Link website.
Tech Support for customers in
Egypt:
Tel: +202-2919035 or +202-2919047
Sunday to Thursday 9:00am to 5:00pm
http://support.dlink-me.com
e-mail: amostafa@dlink-me.com
Iran:
Tel: +98-21-88822613
Sunday to Thursday 9:00am to 6:00pm
http://support.dlink-me.com
e-mail: support.ir@dlink-me.com
Israel:
Tel: +972-9-9715701
Sunday to Thursday 9:00am to 5:00pm
http://www.dlink.co.il/support/
e-mail: [email protected]
Pakistan:
Tel: +92-21-4548158 or +92-21-4548310
Sunday to Thursday 9:00am to 6:00pm
http://support.dlink-me.com
e-mail: support.pk@dlink-me.com
South Africa and Sub Sahara Region:
Tel: +27-12-665-2165
08600 DLINK (for South Africa only)
Monday to Friday 8:30am to 9:00pm South Africa Time
http://www.d-link.co.za
Turkey:
Tel: +90-212-2895659
Monday to Friday 9:00am to 6:00pm
http://www.dlink.com.tr
U.A.E and North Africa:
Tel: +971-4-391-6480 (U.A.E)
Sunday to Wednesday 9:00am to 6:00pm GMT+4
Thursday 9:00am to 1:00pm GMT+4
http://support.dlink-me.com
