D-Link DCS-6112 Manual de usuario

This document will guide you through the basic installation

process for your new D-Link Network Camera.

DCS-6112/DCS-6113/DCS-6113V

Documentation also available on CD

and via the D-Link Website

Quick Installation Guide

Fixed Dome Network Camera

Quick Installation Guide

Краткое руководство по установке

Guía de Instalación Rápida

Guia de Instalação Rápida

快速安裝指南

Petunjuk Pemasangan Cepat

D-Link DCS-6112/DCS-6113/DCS-6113V Quick Install Guide

ENGLISH

Quick Install Guide

This installation guide provides basic instructions for installing the DCS-6112/DCS-6113/

DCS-6113V Network Camera on your network. For additional information about how to

use the camera, please see the User’s Manual which is available on the CD included in

the package or from the D-Link support website.

Installation Steps

1. Verify the package contents against the list below.

2. Hardware Overview

3. Hardware Installation

4. Conguration with Wizard

5. Adjust the Viewing Angle

6. Attaching the Enclosure

1. Package Contents

• Network Camera

• Manual and Software on CD-ROM

• CAT5 Ethernet Cable

• AV / Power cable

• Power Adapter

• Screwdriver

• Screw

• Alignment Sticker

• Quick Install Guide

• Cable Tie

If any of the above items are missing, please contact your reseller.

D-Link DCS-6112/DCS-6113/DCS-6113V Quick Install Guide

ENGLISH

2. Hardware Overview

Dome Cover

Plastic housing

(DCS-6112/6113)

Metal Housing

(DCS-6113V)

D-Link DCS-6112/DCS-6113/DCS-6113V Quick Install Guide

ENGLISH

Light sensor

Judges lighting conditions and

switches from day mode to night

mode accordingly (Control IR-LED

and ICR on/off) (DCS-6113 only)

NTSC/PAL Switch

Switch for NTSC/PAL

video format

Infrared LEDs

Used to illuminate the camera's eld of

view at night (DCS-6113 only)

LED

Power and network

indicator

Ethernet (PoE)

RJ-45 connector for Ethernet

which can also be used to

power the camera using PoE

MicroSD Card Slot

Local MicroSD card for

storing recorded images

and video

DC Input

Connects to the 12V DC

power adapter to power

the camera

Video Output

Video output connector

for TV/Monitor

Lens

Fixed focus lens

3-Axis Mechanism

Adjust the camera’s

image to achieve the

desired orientation

Audio I/O and DI/DO

1: Audio GND

2: Audio out

3: Audio GND

4: Audio input

5: GND

6: Digital input

7: Digital output

8: 12V DC

DC input / Video Output

1: Ground of Video out

2: Video output

3: Ground of DC input

4: DC 12V

Audio Input / Output

Audio input/output connector for

an external speaker

Digital Input (DI) /Output (DO)

DI/DO connectors provide

a physical interface to send

and receive digital signals to

and from a variety of external

devices

Reset

Press and hold

this button for 10

seconds to reset

the camera

8 1

D-Link DCS-6112/DCS-6113/DCS-6113V Quick Install Guide

ENGLISH

3. Hardware Installation

Mounting to a Ceiling or a Wall

1. Locate an area on the ceiling or wall which is capable of supporting the weight of the

camera.

2. Attach the alignment sticker to the ceiling or wall.

3. Drill two pilot holes where the holes of the alignment sticker are located.

4. Insert the supplied plastic anchors into the drilled holes, and align the holes at the

base of the camera with the plastic anchors.

5. The camera can be mounted with the cable routed through the ceiling, wall, or from

the side.

6. Insert the provided screws through the holes. Use a screwdriver to tighten and

secure.

D-Link DCS-6112/DCS-6113/DCS-6113V Quick Install Guide

ENGLISH

General Connection (without PoE)

Connect the network camera to a switch or router via an Ethernet cable.

Connect the supplied power cable from the camera to a power outlet.

Connection with a PoE Switch

If using a PoE switch, connect the network camera to the switch via an Ethernet cable,

which will provide both power and data transmission over a single cable.

D-Link DCS-6112/DCS-6113/DCS-6113V Quick Install Guide

ENGLISH

4. Conguration with Wizard

Click Setup Wizard to begin the installation.

Insert the DCS-6112/DCS-6113/DCS-6113V CD into your computer's CD-ROM drive

to begin the installation. If the Autorun function on your computer is disabled, or if the

D-Link Launcher fails to start automatically, click Start > Run. Type D:\autorun.exe,

where D: represents the drive letter of your CD-ROM drive.

After clicking Setup Wizard, the following window will

open.

Click Next to continue.

Click Yes to accept the License Agreement.

Click Finish to complete the installation.

To start the installation process, click Next.

Note: The installation may take several minutes to

nish.

D-Link DCS-6112/DCS-6113/DCS-6113V Quick Install Guide

ENGLISH

Click on the D-Link Setup Wizard SE icon that was

created in your Windows Start menu.

Start > D-Link > Setup Wizard SE

Take a moment to conrm your settings and click Restart.

Select DHCP if your camera obtains an IP address

automatically when it boots up. Select static IP if the

camera will use the same IP address each time it is

started.

Click Next, to proceed to the next page.

Enter the Admin ID and password. When logging in for

the rst time, the default Admin ID is admin with the

password left blank.

Click Next, to proceed to the next page.

The Setup Wizard will appear and display the MAC

address and IP address of your camera(s). If you have

a DHCP server on your network, a valid IP Address

will be displayed. If your network does not use a

DHCP server, the network camera's default static IP

192.168.0.20 will be displayed.

Click the Wizard button to continue.

D-Link DCS-6112/DCS-6113/DCS-6113V Quick Install Guide

ENGLISH

Click on the D-Link Setup Wizard SE icon that was

created in your Windows Start menu.

Start > D-Link > Setup Wizard SE

Viewing Camera via Web Browser

This section shows your camera’s live video. You

can select your video prole and view or operate

the camera. For additional information about web

conguration, please refer to the user manual included

on the CD-ROM or the D-Link website.

Enter admin as the default username and leave the

password blank. Click OK to continue.

Select the camera and click the button labeled "Link"

to access the web conguration.

The Setup Wizard will automatically open your web

browser to the IP address of the camera.

D-Link DCS-6112/DCS-6113/DCS-6113V Quick Install Guide

ENGLISH

5. Adjust the viewing angle

Loosen the pan screw and turn the lens module left and right until the desired position

is achieved; tighten the pan screw once completed. Loosen the tilt screws on both

sides of the camera, and turn the lens module up and down until the desired position is

achieved; tighten the tilt screws once completed.

Loosen the image adjustment screw and turn the lens to adjust the network camera’s

image until the desired orientation is achieved, tighten the image adjustment screw once

completed.

6. Attaching the Enclosure

1. Align the inner side of the black cover with the notch on both sides of the lens, x the

black Cover.

2. If you choose to the feed the cable through the ceiling or wall, arrange the cable

neatly through the cable hole. If you choose to feed the cable from the side, remove

plate A.

3. Attach the dome cover to the camera as the direction shown below. With idiot-proof

mechanism design, the dome cover cannot be attached if the angle does not t.

4. Finally, make sure all parts of the camera are securely installed.

Loosen Tighten

Tilt 85°

Pan 350°

Rotate 350°

DCS-6113V DCS-6112/6113
